WINDSHIELD WASHER FLUID EJECTION CHECK
Note. Use special tool Adjustment tool, washer nozzle (MB992326) to adjust the splashing points of the nozzle.
Adjustment of the mist type washer nozzle injection position
| CAUTION | Do not use tools other than the special tool (MB992326) to adjust the injection angle because the washer nozzle may get damaged. Adjust the splashing position within the specified adjustment range, otherwise the windshield cannot be washed properly. |
Scheme 63
Scheme 64
Scheme 65
Scheme 66
Scheme 67
- Use the special tool, washer nozzle adjustment tool (MB992326) to adjust the splashing points of the nozzle.
- Insert the mist type washer nozzle adjusting side of the special tool (MB992326) into the injection part of the mist type washer nozzle as shown in the illustration (A).
- Move the special tool (MB992326) up and down to adjust the angle of the washer nozzle as shown in the illustration (B). NOTE: If the washer nozzle cannot be moved smoothly, adjust the angle while pressing the special tool (MB992326) against the washer nozzle.
