WIPER/WASHER SWITCH CONTINUITY CHECK
< VEHICLES WITHOUT LIGHTING CONTROL SENSOR>
Scheme 53
| Switch position | Tester connection | Specified condition | |
|---|---|---|---|
| OFF | Open circuit | ||
| Windshield intermittent wiper interval adjusting knob | 6 - 3 | Operating the adjusting knob changes the resistance. | |
| Windshield washer switch | 6 - 7 | Continuity exists (Less than 2 ohms) | |
| Windshield wiper switch | Hi | 6 - 8 | Continuity exists (Less than 2 ohms) |
| Lo | 6 - 9 | Continuity exists (Less than 2 ohms) | |
| Int | 6 - 10 | Continuity exists (Less than 2 ohms) | |
| Mist | 6 - 11 | Continuity exists (Less than 2 ohms) | |
CONTINUITY SPECIFICATION
< VEHICLES WITH LIGHTING CONTROL SENSOR>
Scheme 54
| Switch position | Tester connection | Specified condition | |
|---|---|---|---|
| OFF | Open circuit | ||
| Windshield rain sensitive wiper function adjusting knob | 6 - 3 | Operating the adjusting knob changes the resistance. | |
| Windshield washer switch | 6 - 7 | Continuity exists (Less than 2 ohms) | |
| Windshield wiper switch | Hi | 6 - 8 | Continuity exists (Less than 2 ohms) |
| Lo | 6 - 9 | Continuity exists (Less than 2 ohms) | |
| Auto | 6 - 10 | Continuity exists (Less than 2 ohms) | |
| Mist | 6 - 11 | Continuity exists (Less than 2 ohms) | |
CONTINUITY SPECIFICATION
Scheme 55
- Remove the lighting switch and wiper/washer switch.
- Check that the continuity is present for the same terminal numbers of the column switch body connectors that remain on the steering column. CONTINUITY SPECIFICATION Column switch body Terminal number Normal condition Lighting switch side connector Wiper/washer switch side connector 3 - 3 6 - 6 7 - 7 8 - 8 9 - 9 10 - 10 11 - 11 Continuity exists (Less than 2 ohms)
