Inspection Procedure 17: Keyless Entry Hazard Light Answerback Function, The Dome Light Answerback Function Or The Horn Answerback Function Does Not Work Normally Mitsubishi Lancer X рестайлинг

Keyless Operation System (Kos) - Lancer: Diagnosis 4 illustrations ~1297 words

Inspection Procedure 17: Keyless Entry Hazard Light Answerback Function, The Dome Light Answerback Function Or The Horn Answerback Function Does Not Work Normally

CAUTIONBefore replacing the ECU, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.
  1. Function setting error or no setting with a customization
  2. Malfunction of the turn signal lights
  3. Malfunction of the dome light
  4. Malfunction of the horn
  5. Malfunction of ETACS-ECU

Scheme 83

Scheme 83: DIAGNOSIS
Scheme 83: DIAGNOSIS
  1. STEP 1. Verify the operation hazard warning light Check that the hazard warning light illuminate normally. Q: Is the check result normal? YES: Go to Step 2. NO: Refer to «INSPECTION PROCEDURE 1: "HAZARD WARNING LIGHT DOES NOT ILLUMINATE»(ref-592569-S10035702222014011000000) ."
  2. STEP 2. Verify the operation of the dome light. Check that the dome lights illuminate normally. Q: Is the check result normal? YES: Go to Step 3. NO: Refer to «INSPECTION PROCEDURE 1 "THE FRONT DOME LIGHT DOES NOT ILLUMINATE NORMALLY»(ref-592570-S31813693852014011000000) ." or «INSPECTION PROCEDURE 2 "THE REAR DOME LIGHT DOES NOT ILLUMINATE NORMALLY»(ref-592570-S29700339852014011000000) ."
  3. STEP 3. Verify the horn. Check that the horn normally. Q: Is the check result normal? YES: Go to Step 4. NO: Replace the horn (Refer to «REMOVAL AND INSTALLATION»(ref-592571-S02847896412014011000000) ).
  4. STEP 4. Check the operation of the keyless entry system. Operate the keyless operation key and check that all doors lock and unlock. Q: Is the check result normal? YES: Go to Step 5. NO: Refer to «INSPECTION PROCEDURE 15: "KEYLESS ENTRY SYSTEM DOES NOT WORK»(ref-592552-S14812083352014011000000) ."
  5. STEP 5. Check the customize function. Check that any one of the followings other than "Lock: 0, Unlock: 0" is set for "Hazard answerback" with a customization function. Lock: 1, Unlock: 2 Lock: 1, Unlock: 0 Lock: 0, Unlock: 2 Lock: 2, Unlock: 1 Lock: 2, Unlock: 0 Lock: 0, Unlock: 1 Q: Is the check result normal? YES: Go to Step 6. NO: Set "Hazard answerback" to any one other than "Lock: 0, Unlock: 0" with a customization function (Refer to «ID CODES REGISTRATION PROCEDURES»(ref-592552-S39380452992014011000000) ).
  6. STEP 6. Check the customize function. Check that any one of the followings other than "Not sound horn" is set for "Horn chirp by keyless" with a customization function. Lock any time W lock any time Q: Is the check result normal? YES: Go to Step 7. NO: Set "Horn chirp by keyless" to any one other than "Not sound horn" with a customization function (Refer to «ID CODES REGISTRATION PROCEDURES»(ref-592552-S39380452992014011000000) ).
  7. STEP 7. Using scan tool MB991958, read the diagnostic trouble code. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(ref-592552-S08493997622014011000000) ." Turn the ignition switch to the "ON" position. Check whether the KOS-ECU related DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Diagnose the KOS-ECU. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-592552-S28404952642014011000000) . NO: Go to Step 8.
  8. STEP 8. Check of the troubles Check if the keyless entry answerback function works normally. Q: Is the check result normal? YES: The diagnosis is complete. NO: Replace ETACS-ECU.
  1. The keyless operation key may be defective
  2. The receiver antenna module may be defective
  3. The KOS-ECU may be defective
  4. The ETACS-ECU may be defective
  5. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector

Required Special Tools

  1. MB992006: Extra fine probe
  2. MB991223: Harness set
  3. MB991958 Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827 M.U.T.-III USB Cable MB991910 M.U.T.-III Main Harness A

Scheme 84

Scheme 84
Scheme 84

Scheme 85

Scheme 85
Scheme 85

Scheme 86

Scheme 86
Scheme 86
  1. STEP 1. Check the operation of the keyless operation system (keyless entry system). Operate the keyless operation key and check that all doors lock and unlock. Q: Is the check result normal? YES: Go to Step 2. NO: Refer to «INSPECTION PROCEDURE 15: "KEYLESS ENTRY SYSTEM DOES NOT WORK»(ref-592552-S14812083352014011000000) ."
  2. STEP 2. Using scan tool MB991958, read the diagnostic trouble code. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(ref-592552-S08493997622014011000000) ." Turn the ignition switch to the "ON" position. Check whether the KOS-ECU related DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Diagnose the KOS-ECU. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-592552-S28404952642014011000000) . NO: Go to Step 3.
  3. STEP 3. Check trunk lid lock actuator connector F-12 and ETACS-ECU connector C-311 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is trunk lid lock actuator connector F-12 and ETACS-ECU connector C-311 in good condition? YES: Go to Step 4. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-592557-S11382637462014011000000) .
  4. STEP 4. Check the trunk lid latch assembly. Remove the trunk lid latch assembly. Refer to «REMOVAL AND INSTALLATION»(ref-592572-S05830018242014011000000) . TRUNK LID LATCH OPERATION Lever position Battery connection Lever operation At the "OFF" position Connect terminal No. 2 and the negative battery terminal. Connect terminal No. 3 and the positive battery terminal. The lever moves from the "OFF" position to the "OPEN" position. Q: Is the trunk lid actuator normal? YES: Go to Step 5. NO: Replace the trunk lid latch assembly.
  5. STEP 5. Check the ground circuit to the trunk lid lock actuator. Measure the resistance at trunk lid lock actuator connector F-12. Disconnect trunk lid lock actuator connector F-12 and measure the resistance available at the wiring harness side of the connector. Measure the resistance value between terminal 2 and ground. The resistance should be 2 ohms or less. Q: Is the measured resistance 2 ohms or less? YES: Go to Step 7 . NO: Go to Step 6.
  6. STEP 6. Check the wiring harness between trunk lid lock actuator connector F-12 (terminal 2) and ground. Check the ground wires for open circuit. NOTE: Also check intermediate connector F-23 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector F-23 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(ref-592557-S11382637462014011000000) . Q: Is the wiring harness between trunk lid lock actuator connector F-12 (terminal 2) and ground in good condition? YES: No action is necessary and testing is complete. NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Check that the trunk lid opener function works normally.
  7. STEP 7. Check the wiring harness between trunk lid lock actuator connector F-12 (terminal 3) and ETACS-ECU connector C-311 (terminal 1). Check the input/output line for open or short circuit. NOTE: Also check intermediate connectors D-14, F-23 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connectors D-14, F-23 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(ref-592557-S11382637462014011000000) . Q: Is the wiring harness between trunk lid lock actuator connector F-12 (terminal 3) and ETACS-ECU connector C-311 (terminal 1) in good condition? YES: Go to Step 8. NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Check that the trunk lid opener function works normally.
  8. STEP 8. Retest the system. Check if the keyless entry system (trunk lid open) works normally. Q: Is the check result normal? YES: Intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(ref-592551-S36408212772014011000000) ). NO: Replace the ETACS-ECU. When the ETACS-ECU is replaced, register the keyless ID. Refer to «ID CODES REGISTRATION PROCEDURES»(ref-592552-S39380452992014011000000) .
