<< A >> THROTTLE BODY MOUNTING BOLTS REMOVAL
Remove the throttle body mounting bolts and put the throttle body aside so as not to interfere the knock sensor connector disconnection.
Scheme 3
Set the connector of the knock sensor to the area shown in the illustration, and tighten the knock sensor to the specified torque.
Tightening torque: 20 ± 2 N.m (15 ± 1 ft-lb)
Scheme 4
Scheme 5
Set the connector of the knock sensor to the position shown in the illustration, and tighten it to the specified torque.
Tightening torque: 20 ± 2 N.m (15 ± 1 ft-lb)
