SPECIAL TOOLS
SPECIAL TOOLS Tool Tool number and name Supersession Application MB992080 Belt tension meter set MB9912081 Belt tension meter MB992082 Microphone assembly Tool not available Drive belt tension (frequency) measurement MB991958 Scan tool (M.U.T.-III sub assembly) MB991824 Vehicle communication interface (V.C.I.) MB991827 M.U.T.-III USB cable MB991910 M.U.T.-III main harness A (Vehicles with CAN communication system) MB991911 M.U.T.-III main harness B (Vehicles without CAN communication system) MB991914 M.U.T.-III main harness C (for Chrysler models only) MB991825 M.U.T.-III adapter harness MB991826 M.U.T.-III trigger harness MB991824-KIT NOTE: MB991826 M.U.T.-III Trigger Harness is not necessary when pushing V.C.I. ENTER key. CAUTION: For vehicles with CAN communication, use M.U.T.-III main harness A to send simulated vehicle speed. If you connect M.U.T.-III main harness B instead, the CAN communication does not function correctly. Ignition timing check Curb idle speed check Idle mixture check Erasing the diagnostic trouble code MB992278 Belt tension release wrench - Auto-tensioner tension release MB990767 Front hub and flange yoke holder MB990767-01 Holding the crankshaft pulley MD998719 Pin MIT308239 MB992103 Chain tension release bar - Camshaft and camshaft sprocket assembly (exhaust side) removal MD998772 Valve spring compressor General service tool Valve spring compression MB992090 Retainer holder attachment - MB992089 Retainer holder C - MB992085 Valve stem seal pliers - Valve stem seal removal MD998737 Valve stem seal installer MD998737-01 Valve stem seal press-fitting MD998727 Oil pan FIPG cutter MD998727-01 Engine oil pan removal MB991883 Flywheel stopper General service tool Supporting the flywheel < M/T > or drive plate < CVT > MD998718 Crankshaft rear oil seal installer MD998718-01 Press-fitting the crankshaft rear oil seal MB991448 Bush remover and installer base MB991448-01 Press-fitting the crankshaft front oil seal MB991614 Angle gauge - Balancer shaft and oil pump module installation MB991928 Engine hanger MB991929 Joint (50) x 2 MB991930 Joint (90) x 2 MB991931 Joint (140) x 2 MB991932 Foot (standard) x 4 MB991933 Foot (short) x 2 MB991934 Chain and hook assembly Tool not available Supporting the engine assembly NOTE: Special tool MB991454 is a part of engine hanger attachment set MB991453. MB991895 Engine hanger Tool not available MB991527 Hanger Tool not available MB992201 Engine hanger plate - MB991454 Engine hanger balancer MZ203827-01
Scheme 359
Scheme 360
Scheme 361
Scheme 362
Scheme 363
Scheme 364
Scheme 365
Scheme 366
Scheme 367
Scheme 368
Scheme 369
- Remove the radiator condenser tank mounting bolt, and move the radiator condenser tank to a place where it does not interfere with the drive belt tension check (Refer to «RADIATOR»(ref-592635-S40209669162014011000000) ). CAUTION: Check the drive belt tension after turning the crankshaft clockwise one turn or more.
- Make sure that the indicator mark on the auto-tensioner is within the area marked with A in the illustration.
- If the mark is out of the area A, replace the drive belt (Refer to «<< B >> DRIVE BELT REMOVAL»(ref-592642-S15094576832014011000000) ). NOTE: The drive belt tension adjustment is not necessary as the auto-tensioner is adopted.
- Install the radiator condenser tank to the original position (Refer to «RADIATOR»(ref-592635-S40209669162014011000000) ).
