Lubrication - Lancer Evolution: Removal & Installation Mitsubishi Lancer X

Lubrication System 8 illustrations ~354 words

<< A >> OIL PRESSURE SWITCH REMOVAL

CAUTIONThe sealant is applied to the bolt. Remove the bolt with care not to break it.

Use special tool oil pressure switch wrench (MB992118) to remove the oil pressure switch.

Scheme 1

Scheme 1
Scheme 1

Scheme 2

Scheme 2: >> A << OIL PRESSURE SWITCH INSTALLATION
Scheme 2: >> A << OIL PRESSURE SWITCH INSTALLATION
  1. Apply sealant to the oil pressure switch thread. Specified sealant: Three bond 1215 or equivalent CAUTION: Do not start the engine until 2 hours or more have elapsed after installing the oil pressure switch.
  2. In the same manner as removal, use special tool oil pressure switch wrench (MD992118) to tighten the oil pressure switch to the specified torque. Tightening torque: 10 ± 2 N.m (89 ± 17 in-lb) NOTE: Within 3 minutes after the application of sealant, install the oil pressure switch.

Scheme 3

Scheme 3: REMOVAL AND INSTALLATION
Scheme 3: REMOVAL AND INSTALLATION

Scheme 4

Scheme 4: REMOVAL AND INSTALLATION
Scheme 4: REMOVAL AND INSTALLATION

Required Special Tool

  1. MB991346: Top Cover Wrench

Scheme 5

Scheme 5: << A >> ENGINE OIL PUMP SPROCKET CENTER BOLT/ENGINE OIL PUMP DRIVE CHAIN AND ENGINE OIL PUMP SPROCKE
Scheme 5: << A >> ENGINE OIL PUMP SPROCKET CENTER BOLT/ENGINE OIL PUMP DRIVE CHAIN AND ENGINE OIL PUMP SPROCKE
  1. Hold the engine oil pump sprocket with special tool MB991346.
  2. Loosen the engine oil pump sprocket center bolt and remove the engine oil pump drive chain and engine oil pump sprocket.

Scheme 6

Scheme 6: >> A << CRANKSHAFT SPROCKET INSTALLATION
Scheme 6: >> A << CRANKSHAFT SPROCKET INSTALLATION
  1. Wipe the dirt off of the crankshaft sprocket and the crankshaft using a rag, and then remove the grease from the portion shown in the illustration. NOTE: Remove grease to prevent a drop in the coefficient of friction of the pressing portion caused by adhesion of oil.
  2. Set the No. 1 piston at top dead center of the compression stroke.
  3. Install the crankshaft sprocket to the crankshaft.

>> B << ENGINE OIL PUMP SPROCKET/ENGINE OIL PUMP DRIVE CHAIN INSTALLATION

  1. Set the No. 1 piston at top dead center of the compression stroke.
  2. Install the engine oil pump sprocket to the engine oil pump case.
  3. Install the engine oil pump drive chain to the crankshaft sprocket.
  4. Install the engine oil pump drive chain to the engine oil pump sprocket.

Scheme 7

Scheme 7: REMOVAL AND INSTALLATION
Scheme 7: REMOVAL AND INSTALLATION

Required Special Tool

  1. MB991346: Top Cover Wrench

Scheme 8

Scheme 8: << A >> ENGINE OIL PUMP SPROCKET CENTER BOLT REMOVAL
Scheme 8: << A >> ENGINE OIL PUMP SPROCKET CENTER BOLT REMOVAL
  1. Secure the engine oil pump sprocket and the engine oil pump drive chain with tie-wrap to prevent slippage between the engine oil pump sprocket and the engine oil pump drive chain.
  2. Hold the engine oil pump sprocket with special tool MB991346.
  3. Remove the engine oil pump sprocket with the engine oil pump drive chain attached.
