<< A >> WIRING HARNESS CONNECTOR DISCONNECTION

Disconnect the following wiring harness connectors

Scheme 29

Scheme 29: << A >> WIRING HARNESS CONNECTOR DISCONNECTION
Connector numberConnector name
D-26 (2 -yellow)Side impact sensor connector (LH)
D-31 (4 -black)Heated seat assembly connector (LH) < Vehicle with heated seat >
D-32 (2 -gray)Seat slide sensor connector (Driver's seat)
D-33 (4 -black)Seat belt switch connector (Driver's seat)
D-34 (2 -yellow)Side airbag module (squib) connector (LH) < Vehicles with side airbag >
D-36 (2 -yellow)Side airbag module (squib) connector (RH) < Vehicles with side airbag >
D-37 (2 -black)Seat belt switch connector (Passenger's seat)
D-38 (4 -black)Heated seat assembly connector (RH) < Vehicle with heated seat >
D-39 (6)Front seat assembly connector (RH)
D-41 (2 -yellow)Side impact sensor (RH) connector

CONNECTOR REFERENCE

Note. When disconnecting the side air bag module connectors of D-34 and D-36, unlock the connector by sliding the locking button to the direction of the arrow as shown in the figure, and then disconnect the connector.

Scheme 30

Scheme 30

Scheme 31

Scheme 31: >> A << FRONT SEAT ASSEMBLY INSTALLATION
  1. Temporarily tighten the bolts in all mounting locations shown in the illustration with no load applied to the front seat cushion and check the operation of the seat slide.
  2. Tighten the bolts in all mounting locations to the specified torque.

Scheme 32

Scheme 32: CONTINUITY TEST OF HEATED SEAT SWITCH
  1. Check for continuity between terminals. TERMINALS REFERENCE CHART Item Switch position Tester connection Specified condition Driver's seat side HI 1 --5, 3 --8 Continuity exists (2ohms or less) OFF 1 --5, 3 --5, 5 --8 Open circuit LO 3 --5 Continuity exists (2ohms or less) Front passenger's seat side HI 4 --5, 8 --9 Continuity exists (2ohms or less) OFF 4 --5, 5 --8, 5 --9 Open circuit LO 5 --9 Continuity exists (2ohms or less)
  2. Check that the indicator is lighted at HI or LO when battery voltage is supplied to terminal 5 and terminal 8 is grounded.
  3. Check that indicator is lighted when battery voltage is supplied to terminals 2 and terminal 6.
