Rear Axle - Except Evolution: Removal & Installation Mitsubishi Lancer IX

Wheel Hubs 7 illustrations ~189 words

HUB BOLT REPLACEMENT

Required Special Tools

  1. MB990767: End Yoke Holder
  2. MB991618: Hub Bolt Remover
  1. Remove the brake drum.
  2. Use special tools MB990767 and MB991618 to remove the hub bolts. NOTE: To retain a space for removing the hub bolts, remove near the retainer spring mounting position.
  3. Install the plain washer to the new hub bolt, and install the bolt with a nut.

Scheme 6

Scheme 6

Scheme 7

Scheme 7

REMOVAL AND INSTALLATION

CAUTIONFor the vehicles with ABS, care must be taken not to scratch or damage the teeth of the ABS rotor. The ABS rotor must never be dropped. If the teeth of the ABS rotor are chipped, resulting in a deformation of the ABS rotor, it will not be able to accurately detect the wheel rotation speed, and the system will not function normally. The rear hub assembly should not be dismantled. When removing the rear hub assembly, the wheel bearing inner race may be left at the spindle side. In this case, always replace the rear hub assembly, otherwise the hub will damage the oil seal, causing oil leaks or excessive play.

Scheme 8

Scheme 8

Required Special Tool

  1. MB990767: End Yoke Holder
  2. MD998801: Remover
  3. MD998812: Installer Cap
  4. MD998813: Installer 100
  5. MD998815: Installer Adapter

<< A >> SELF-LOCKING NUT REMOVAL

CAUTIONDo not apply the vehicle weight to the wheel bearing while loosening the self-locking nut, or the wheel bearing will be damaged.

Use special tool MB990767 to remove the self-locking nut.

Scheme 9

Scheme 9

<< B >> ABS ROTOR REMOVAL

Use special tools MD998812, MD998813, MD998815 and MD998801 to press out ABS rotor from the rear hub assembly.

Scheme 10

Scheme 10: << B >> ABS ROTOR REMOVAL

>> A << ABS ROTOR INSTALLATION

CAUTIONWhen installing, take care not to deform the ABS rotor.

Press-fit the ABS rotor to the rear hub assembly.

>> B << SELF-LOCKING NUT INSTALLATION

CAUTIONBefore securely tightening the self-locking nuts, make sure there is no load on the wheel bearings. Otherwise the wheel bearing will be damaged.

Scheme 11

Scheme 11
  1. Using special tool MB990767, tighten the self-locking nut.
  2. After tightening the self-locking nut, crimp the nut to meet the concave portion of the spindle.

Scheme 12

Scheme 12
