Engine Controls - Service & Adjustment Specifications: Other Mitsubishi Lancer IX

Specifications 2 illustrations ~122 words

ENGINE COMPRESSION

Check engine compression with engine at normal operating temperature, all spark plugs removed and throttle wide open.

ApplicationPressure - psi (kPa)
Normal Compression Pressure
Diamante171 (1179)
Eclipse
2.4L185 (1275)
3.0L
With Variable Induction Control212 (1462)
Without Variable Induction Control119 (824)
Galant
2.4L185 (1275)
3.0L119 (824)
Lancer234 (1613)
Montero & Montero Sport171 (1179)
Outlander185 (1275)
Minimum Compression Pressure
Diamante127 (876)
Eclipse
2.4L139 (959)
3.0L
With Variable Induction Control149 (1027)
Without Variable Induction Control83 (575)
Galant
2.4L139 (959)
3.0L83 (575)
Lancer170 (1172)
Montero & Montero Sport127 (876)
Outlander139 (959)
Maximum Variation Between Cylinders
All Models14 (97)

COMPRESSION PRESSURE

VALVE CLEARANCE

Note. All engines are equipped with hydraulic lifters. No adjustment is required.

IGNITION COIL

ApplicationPrimarySecondary
Diamante.50-.709000-13,000
Eclipse & Galant
2.4L(1)8500-11,500
3.0L.56-.689400-12,800
Lancer, Montero & Outlander(1)8500-11,500
Montero Sport.74-.9020,100-27,300
(1) Coil primary circuit includes power transistor. For testing, see DISTRIBUTORLESS IGNITION SYSTEM (DIS) - 4-CYLINDER under IGNITION CHECKS in BASIC DIAGNOSTIC PROCEDURES article.
(1)Coil primary circuit includes power transistor. For testing, see DISTRIBUTORLESS IGNITION SYSTEM (DIS) - 4-CYLINDER under IGNITION CHECKS in BASIC DIAGNOSTIC PROCEDURES article.

IGNITION COIL RESISTANCE - Ohms @ 68°F (20°C)

HIGH TENSION WIRE RESISTANCE

ApplicationOhms
Diamante22,000
Except Diamante19,000

HIGH TENSION WIRE RESISTANCE

SPARK PLUGS

ApplicationDenso No.NGK No.Champion
DiamantePK16PR-P11PFR5G-11RC10PYP4
Eclipse
2.4LK16PR-U11BKR5E-11RC10YC4
3.0L
With Variable Induction ControlSK20PR-B8IFR6B(1)
Without Variable Induction ControlPK16PR11PFR5G-11RC10PYP4
Galant
2.4LK16PR-U11BKR5E-11RC10YC4
3.0LPK16PR11PFR5G-11RC10PYP4
Lancer & OutlanderK16PR-U11BKR5E-11RC10YC4
MonteroSK20PR-A8IFR6S(1)
Montero SportSK16PR-A11N/AN/A
(1) Information not available from manufacturer.
(1)Information not available from manufacturer.

SPARK PLUG TYPE

Application(1) Gap In. (mm)Maximum Gap In. (mm)Torque Ft. Lbs. (N.m)
Except Eclipse Equipped With Variable Induction Control & Montero.039-.043 (1.0-1.1).051 (1.3)14-22 (21-29)
Eclipse Equipped With Variable Induction Control & Montero.028-.031 (.7-.8).039 (1.0)14-22 (21-29)
(1) DO NOT adjust gap on Platinum-tipped or Iridium-tipped spark plugs.
(1)DO NOT adjust gap on Platinum-tipped or Iridium-tipped spark plugs.

SPARK PLUG SPECIFICATIONS

Scheme 12

Scheme 12: Firing Order (4-Cylinder)
Scheme 12: Firing Order (4-Cylinder)

Scheme 13

Scheme 13: Firing Order (V6)
Scheme 13: Firing Order (V6)

IGNITION TIMING

ApplicationBaseActual
Diamante2-8 @ About 700(1) (4) 10 @ About 700
Eclipse
2.42-8 @ About 700(1) (3) 10 @ About 700
3.0L2-8 @ About 700(2) (3) 15 @ About 700
Galant
2.4L2-8 @ About 700(1) (3) 10 @ About 700
3.0L2-8 @ About 700(1) (3) 15 @ About 700
Lancer2-8 @ About 700(1) (3) 8 @ About 700
Montero2-8 @ About 750(1) (3) 10 @ About 750
Montero Sport2-8 @ About 700(2) (3) 10 @ About 700
Outlander3-7 @ About 700(1) (3) 10 @ About 700
(1) Timing will be advanced at higher altitudes, 5-10 degrees, depending on altitude. (2) Timing will be advanced at higher altitudes, 5-15 degrees, depending on altitude. (3) Actual ignition timing is approximate and may fluctuate plus or minus 7 degrees. (4) Actual ignition timing is approximate and may fluctuate plus or minus 8 degrees.
(1)Timing will be advanced at higher altitudes, 5-10 degrees, depending on altitude.
(2)Timing will be advanced at higher altitudes, 5-15 degrees, depending on altitude.
(3)Actual ignition timing is approximate and may fluctuate plus or minus 7 degrees.
(4)Actual ignition timing is approximate and may fluctuate plus or minus 8 degrees.

IGNITION TIMING SPECIFICATIONS (Degrees BTDC @ RPM)

ACCELERATOR PEDAL POSITION SENSOR

APP Sensor Terminals No.(1) Millivolts
1 & 3905-1165
(1) With ignition on and accelerator pedal position sensor in idle position.
(1)With ignition on and accelerator pedal position sensor in idle position.

APP SENSOR ADJUSTMENT SPECIFICATIONS (MONTERO)

Accelerator Pedal Position Sensor Terminals No.(1) k/Ohms
1 & 2; 7 & 83.5-6.5
2 & 3; 6 & 8(2)
4 & 5(3)
(1) Measured with accelerator pedal position sensor in idle position and at 68°F (20°C). (2) Resistance should smoothly change as throttle is opened. (3) With accelerator pedal depressed not continuity should be present.
(1)Measured with accelerator pedal position sensor in idle position and at 68°F (20°C).
(2)Resistance should smoothly change as throttle is opened.
(3)With accelerator pedal depressed not continuity should be present.

APP SENSOR RESISTANCE SPECIFICATIONS (MONTERO)

FUEL PUMP

ApplicationAt Idle W/Vacuum psi (kPa)At Idle W/O Vacuum psi (kPa)
All Models39 (270)47-50 (330-350)

REGULATED FUEL PRESSURE

IDLE SPEED

ApplicationRPM
All Models600-800

CURB IDLE SPEED SPECIFICATIONS

INJECTOR RESISTANCE

Application(1) Ohms
All Models13-16
(1) Resistance at 68°F (20°C)
(1)Resistance at 68°F (20°C)

INJECTOR RESISTANCE

THROTTLE POSITION SENSOR

ApplicationTerminals No.(1) Millivolts
Diamante With Traction Control1 & 3580-690
Diamante Without Traction Control1 & 3(2) 400-1000
Eclipse & Galant1 & 3535-735
Lancer1 & 2335-935
Montero & Montero Sport1 & 3535-735
Outlander2 & 4535-735
(1) With ignition on and TP sensor in idle position. (2) Test with .055" (1.4 mm) thick feeler gauge inserted to a maximum depth of .118" (3 mm) between throttle lever and free lever.Test with .177" (.45 mm) thick feeler gauge inserted between fixed SAS and throttle lever.
(1)With ignition on and TP sensor in idle position.
(2)Test with .055" (1.4 mm) thick feeler gauge inserted to a maximum depth of .118" (3 mm) between throttle lever and free lever.Test with .177" (.45 mm) thick feeler gauge inserted between fixed SAS and throttle lever.

TP SENSOR ADJUSTMENT SPECIFICATIONS

Application/Terminal No.(1) k/Ohms
Eclipse & Galant
1 & 43.5-6.5
1 & 3(2)
Diamante
1 & 43.5-6.5
3 & 4(2)
Lancer
2 & 32.0-4.0
1 & 2(2)
Montero
2 & 42.0-4.0
Montero Sport
1 & 43.5-6.5
2 & 4(2)
Outlander
1 & 43.5-6.5
1 & 2(2)
(1) Measured with TP sensor in idle position and at 68°F (20°C). (2) Resistance should smoothly change as throttle is opened.
(1)Measured with TP sensor in idle position and at 68°F (20°C).
(2)Resistance should smoothly change as throttle is opened.

TP SENSOR RESISTANCE SPECIFICATIONS
