DRIVE BELT ADJUSTMENT (DIAMANTE)
| Application | (1) Deflection Belt - In. (mm) |
|---|
| A/C & Generator | .31-.38 (7.9-9.7) |
| P/S | .43-.56 (11.0-14.2) |
| (1) With 22 lbs. (10 kg) pressure applied on longest belt run midway between pulleys. (Scheme 1)and (Scheme 2). |
| (1) | With 22 lbs. (10 kg) pressure applied on longest belt run midway between pulleys. (Scheme 1)and (Scheme 2). |
BELT ADJUSTMENT (DIAMANTE)
Scheme 1
Scheme 2
DRIVE BELT ADJUSTMENT (ECLIPSE, GALANT, LANCER, MONTERO & OUTLANDER)
| Application | (1) Deflection New Belt - In. (mm) | (1) Deflection Used Belt - In. (mm) |
|---|
| Eclipse |
| 2.4L |
| A/C & P/S | .34-.43 (8.8-11.0) | .49-.56 (12.5-14.3) |
| Generator | .17-.21 (4.4-5.3) | .28-.33 (7.2-8.4) |
| 3.0L |
| A/C & Generator | .24-.30 (6.2-7.6) | .35-.40 (9.0-10.0) |
| P/S | .33-.37 (8.4-9.3) | .46-.53 (11.7-13.3) |
| Galant |
| 2.4L |
| P/S Or A/C & P/S | .34-.43 (8.8-11.0) | .49-.56 (12.5-14.3) |
| Generator | .17-.21 (4.4-5.3) | .28-.33 (7.2-8.4) |
| 3.0L |
| A/C & Generator | .24-.30 (6.2-7.6) | .35-.40 (9.0-10.0) |
| P/S | .33-.41 (8.4-10.4) | .46-.53 (11.7-13.3) |
| Lancer |
| A/C & P/S | .27-.35 (7.0-9.0) | .39-.43 (10.0-11.0) |
| Generator | .26-.33 (6.7-8.5) | .41-.47 (10.5-12.0) |
| Montero & Outlander | (2) | (2) |
| (1) With 22 lbs. (10 kg) pressure applied on longest belt run midway between pulleys. (Scheme 3)- (Scheme 8). (2) Automatic belt tensioner is used. Belt tension adjustment is not required. |
| (1) | With 22 lbs. (10 kg) pressure applied on longest belt run midway between pulleys. (Scheme 3)- (Scheme 8). |
| (2) | Automatic belt tensioner is used. Belt tension adjustment is not required. |
BELT ADJUSTMENT (ECLIPSE, GALANT, LANCER, MONTERO & OUTLANDER)
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
DRIVE BELT ADJUSTMENT (MONTERO SPORT)
| Application | (1) Deflection New Belt - In. (mm) | (1) Deflection Used Belt - In. (mm) |
|---|
| A/C | .16-.20 (4.3-5.1) | .22-.25 (5.6-6.4) |
| Generator (2) |
| A | .16-.20 (4.3-5.1) | .28-.33 (7.0-8.4) |
| B | .24-.29 (6.0-7.4) | .40-.46 (10.1-11.7) |
| P/S |
| 3.0L | .42-.53 (10.6-13.6) | .58-.65 (14.6-16.6) |
| 3.5L | .44-.56 (11.1-14.3) | .61-.68 (15.3-17.4) |
| (1) With 22 lbs. (10 kg) pressure applied on longest belt run midway between pulleys. (Scheme 9)- (Scheme 11). (2) Generator belt could be measured on 2 sides. |
| (1) | With 22 lbs. (10 kg) pressure applied on longest belt run midway between pulleys. (Scheme 9)- (Scheme 11). |
| (2) | Generator belt could be measured on 2 sides. |
BELT ADJUSTMENT (MONTERO SPORT)
Scheme 9
Scheme 10
Scheme 11
