Ignition Switch - Except Evolution: Other Mitsubishi Lancer IX

Ignition key reminder tone alarm

The ignition key reminder tone alarm will sound under the following condition, and warn the driver to remove the ignition key.

IGNITION SWITCH CONTINUITY CHECK

Disconnect ignition switch connector C-87 without removing the ignition switch and steering lock cylinder. Then check the continuity.

Scheme 4

Scheme 5

Scheme 6

Scheme 7

1. Ignition key reminder switch continuity check. Disconnect key reminder switch connector C-88 without removing the ignition switch and steering lock cylinder. Then check the continuity.
2. Ignition key ring antenna check. Check for continuity between terminal 3 and terminal 7. Standard value: 2ohm or less
