FASTENER TIGHTENING SPECIFICATIONS
| ITEM | SPECIFICATION | |
|---|---|---|
| Air cleaner | ||
| Air cleaner bolt | 8.8 ± 1.0 N.m (78 ± 9 in-lb) | |
| Air cleaner bracket bolt | 11 ± 1 N.m (97 ± 9 in-lb) | |
| Airflow sensor nut | 8.8 ± 1.0 N.m (78 ± 9 in-lb) | |
| Air intake hose clamp bolt | 3.9 ± 1.0 N.m (38 ± 8 in-lb) | |
| Exhaust manifold | ||
| Exhaust manifold bracket bolt | M8 | 19 ± 3 N.m (14 ± 2 ft-lb) |
| M10 | 35 ± 6 N.m (26 ± 4 ft-lb) | |
| Exhaust manifold nut | M8 | 17 ± 2 N.m (12 ± 2 ft-lb) |
| M10 | 30 ± 3 N.m (22 ± 2 ft-lb) | |
| Front exhaust pipe nut | 50 ± 10 N.m (37 ± 7 ft-lb) | |
| Heat protector bolt | 13 ± 1 N.m (115 ± 9 in-lb) | |
| Heated oxygen sensor | 44 ± 5 N.m (33 ± 3 ft-lb) | |
| Power steering pump bracket stay bolt | 49 ± 9 N.m (36 ± 7 ft-lb) | |
| Power steering oil pump attaching bolt | M8 | 22 ± 4 N.m (16 ± 3 ft-lb) |
| M10 | 44 ± 10 N.m (33 ± 7 ft-lb) | |
| Pressure hose clamp bolt | 12 ± 25 N.m (102 ± 22 in-lb) | |
| Exhaust pipe and main muffler | ||
| Center exhaust pipe nut | 59 ± 10 N.m (44 ± 7 ft-lb) | |
| Front exhaust pipe bolt | 50 ± 10 N.m (37 ± 7 ft-lb) | |
| Front exhaust pipe nut | 50 ± 10 N.m (37 ± 7 ft-lb) | |
| Hanger bolt | 13 ± 2 N.m (111 ± 22 in-lb) | |
| Main muffler bolt | 45 ± 5 N.m (34 ± 3 ft-lb) | |
| Intake manifold | ||
| EGR valve bolt | 22 ± 4 N.m (16 ± 3 ft-lb) | |
| Intake manifold bolt and nut | 19 ± 3 N.m (14 ± 2 ft-lb) | |
| Intake manifold stay bolt | 31 ± 3 N.m (23 ± 2 ft-lb) | |
| Manifold differential pressure sensor bolt | 5.0 ± 1.0 N.m (45 ± 8 in-lb) | |
| Throttle body stay bolt | 24 ± 3 N.m (18 ± 2 ft-lb) | |
| Vacuum hose and pipe assembly bolt | 11 ± 1 N.m (98 ± 8 in-lb) | |
| Vacuum pipe bolt | 5.0 ± 1.0 N.m (45 ± 8 in-lb) | |
