Anti-Lock Braking System (ABS) - Except Evolution: Component Locations Mitsubishi Lancer IX

Anti-Lock/traction Control 3 illustrations ~130 words

Using the ABS Warning Light and Special Tool MB991529

Required Special Tool

  1. MB991529: Diagnostic Trouble Code Check Harness

Scheme 337

Scheme 337
Scheme 337

Scheme 338

Scheme 338
Scheme 338

Scheme 339

Scheme 339
Scheme 339
  1. Use special tool MB991529 to ground number 1 terminal of the data link connector. CAUTION: Do not depress the brake pedal after the ignition switch is turned "ON". If the brake pedal is depressed while the ABS is inoperative and the ignition switch is "ON", the ABS warning light will remain on. Because of this, diagnostic trouble codes will not be read out.
  2. Turn the ignition switch to the "ON" position.
  3. Read out a diagnostic trouble code by observing how the warning light flashes.
  4. Turn the ignition switch to the "LOOK" (OFF) position.
  5. Disconnect special tool MB991529.
