MAINTENANCE, REPAIR AND SERVICING EXPLANATIONS

This service information provides explanations, etc. concerning procedures for the inspection, maintenance, repair and servicing of the subject model. Unless otherwise specified, each service procedure covers all models. Procedures covering specific models are identified by the model codes, or similar designation (engine type, transaxle type, etc.). A description of these designations is covered in this service information under "VEHICLE IDENTIFICATION."

ON-VEHICLE SERVICE

The "ON-VEHICLE SERVICE" section has procedures for performing inspections and adjustments of particularly important components. These procedures are done with regard to maintenance and servicing, but other inspections (looseness, play, cracking, damage, etc.) must also be performed.

SERVICE PROCEDURES

The service steps are arranged in numerical order. Attention to be paid in performing vehicle service are described in detail in SERVICE POINTS.

STANDARD VALUE

Indicates the value used as the standard for judging whether or not a part or adjustment is correct.

LIMIT

Shows the maximum or minimum value for judging whether or not a part or adjustment is acceptable.

REFERENCE VALUE

Indicates the adjustment value prior to starting the work (presented in order to facilitate assembly and adjustment procedures, and so they can be completed in a shorter time).

DANGER, WARNING, AND CAUTION

DANGER, WARNING, and CAUTION call special attention to a necessary action or to an action that must be avoided. The differences among DANGER, WARNING, and CAUTION are as follows

1. If a DANGER is not followed, the result is severe bodily harm or even death.
2. If a WARNING is not followed, the result could be bodily injury.
3. If a CAUTION is not followed, the result could be damage to the vehicle, vehicle components or service equipment.

TIGHTENING TORQUE INDICATION

The tightening torque indicates a median and its tolerance by a unit of N.m (in-lb) or N.m (ft-lb). For fasteners with no assigned torque value, refer to TIGHTENING TORQUE .

SPECIAL TOOL NOTE

Only MMC special tool part numbers are called out in the repair sections of this service information. Please refer to the special tool cross-reference chart located at the beginning of each group, for the special tool number that is available in your market.

ABBREVIATIONS

The following abbreviations are used in this service information for classification of model types

2.0L ENGINE: Indicates the 1,998 cm 3 (121.9 cu in) < 4B11 > engine, or a model equipped with such an engine.

2.0L ENGINE NON-TURBO. Indicates the 1,998 cm 3 (121.9 cu in) < 4B11 > engine without charge air cooler turbocharger.

2.0L ENGINE TURBO. Indicates the 1,998cm 3 (121.9 cu in) < 4B11 > engine with charge air cooler turbocharger.

2.4L ENGINE. Indicates the 2,359 cm 3 (144.0 cu in) < 4B12 > engine, or a model equipped with such an engine.

A/C: Indicates the air conditioning.

ACD. Indicates the active center differential system.

AWD. Indicates the all wheel drive vehicles.

CVT. Indicates the continuously variable transaxle.

DOHC. Indicates an engine with the double overhead camshaft, or models equipped with such an engine.

ECM: Indicates the engine control module

FWD. Indicates the front wheel drive vehicles.

Keyless Operation System (KOS). Free-hand Advanced Security Transmitter (F.A.S.T.-key)

LSD. Indicates the limited slip differential.

MFI. Multiport fuel injection, or engines equipped with multiport fuel injection.

MIVEC. Indicates the Mitsubishi innovative valve timing electronic control system.

M/T. Indicates manual transaxle, or models equipped with manual transaxle.

TCM. Indicates the transaxle control module

TC-SST. Indicates the twin clutch-sportronic shift transmission.

Scheme 1

Scheme 2

VERIFY THE COMPLAINT

1. Make sure the customer's complaint and the service writer's work order description are understood before starting work.
2. Make sure the correct operation of the system is understood. Read the service information description to verify normal system operation.
3. Operate the system to see the symptoms. Look for other symptoms that were not reported by the customer, or on the work order, that may be related to the problem.

DETERMINE POSSIBLE CAUSES

Compare the confirmed symptoms to the diagnostic symptom indexes to find the right diagnosis procedure.

If the confirmed symptoms cannot be found on any symptom index, determine other possible causes.

1. Analyze the system diagrams and list all possible causes for the problem symptoms.
2. Rank all these possible causes in order of probability, based on how much of the system they cover, how likely they are to be the cause, and how easy they will be to check. Be sure to take experience into account. Consider the causes of similar problems seen in the past. The list of causes should be ranked in order from general to specific, from most-likely to least-likely, and from easy-to-check to hard-to-check.

FIND THE PROBLEM

After the symptoms have been confirmed, and probable causes have been identified, the next step is to make step-by-step checks of the suspected system components, junctions, and links in logical order.

Use the diagnostic procedures in the service information whenever possible. Follow these procedures carefully to avoid missing an important step in the diagnosis sequence. It might be the skipped step that leads to the solution of the problem.

If the service information doesn't have step-by-step procedures to help diagnose the problem, make a series of checks based on the ranked list of probable causes. Troubleshooting checks should be made in the order that the list of causes was ranked

1. General to specific
2. Most-likely to least-likely
3. Easy-to-check to hard-to-check

REPAIR THE PROBLEM

When the step-by-step troubleshooting checks find a fault, perform the proper repairs. Make sure to fix the root cause of the problem, not just the symptom. Just fixing the symptom, without fixing the root cause, will cause the symptom to eventually return.

VERIFY THE REPAIR

After repairs are made, recheck the operation of the system to confirm that the problem is eliminated. Be sure to check the system thoroughly. Sometimes new problems are revealed after repairs have been made.

TROUBLESHOOTING CONTENTS

Troubleshooting of electronic control systems for which the scan tool can be used follows the basic outline described below. Even in systems for which the scan tool cannot be used, part of these systems still follow this outline.

1. STANDARD FLOW OF DIAGNOSTIC TROUBLESHOOTING

Troubleshooting strategy is shown in each group.

2. SYSTEM OPERATION AND SYMPTOM VERIFICATION TESTS

If verification of the symptom(s) is difficult, procedures for checking operation and verifying symptoms are shown in the service information.

3. DIAGNOSTIC FUNCTION

The following trouble code diagnosis are shown.

1. How to read diagnostic trouble codes
2. How to erase diagnostic trouble codes
3. Input inspection service points

4. DIAGNOSTIC TROUBLE CODE CHART

If the scan tool displays a diagnostic trouble code, find the applicable inspection procedure according to this chart.

5. SYMPTOM CHART

If there are symptoms, even though the scan tools show that no DTCs are set, inspection procedures for each symptom will be found by using this chart.

6. DIAGNOSTIC TROUBLE CODE PROCEDURES

Indicates the inspection procedures corresponding to each diagnostic trouble code. (Refer to HOW TO USE THE INSPECTION PROCEDURES ).

7. SYMPTOM PROCEDURES

Indicates the inspection procedures corresponding to each symptom listed in the Symptom Chart. (Refer to HOW TO USE THE INSPECTION PROCEDURES ).

8. SERVICE DATA REFERENCE TABLE

Inspection items and normal judgement values have been provided in this chart as reference information.

9. CHECK AT ECU TERMINALS

Terminal numbers for the ECU connectors, inspection items, and standard values have been provided in this chart as reference information.

TERMINAL VOLTAGE CHECKS

1. Connect a needle-nosed wire probe to a voltmeter probe. CAUTION: Short-circuiting the positive (+) probe between a connector terminal and ground could damage the vehicle wiring, the sensor, the ECU, or all three. Use care to prevent this!
2. Insert the needle-nosed wire probe into each of the ECU connector terminals from the wire side, and measure the voltage while referring to the check chart. NOTE: Measure voltage with the ECU connectors connected. You may find it convenient to pull out the ECU to make it easier to reach the connector terminals. Checks don't have to be carried out in the order given in the chart.
3. If voltage readings differ from normal condition values, check related sensors, actuators, and wiring. Replace or repair as needed.
4. After repair or replacement, recheck with the voltmeter to confirm that the repair has corrected the problem.

TERMINAL RESISTANCE AND CONTINUITY CHECKS

1. Turn the ignition switch to the "LOCK" (OFF) position.
2. Disconnect the ECU connector. CAUTION: If resistance and continuity checks are performed on the wrong terminals, damage to the vehicle wiring, sensors, ECU, and/or ohmmeter may occur. Use care to prevent this!
3. Measure the resistance and check for continuity between the terminals of the ECU harness-side connector while referring to the check chart. NOTE: Checks don't have to be carried out in the order given in the chart.
4. If the ohmmeter shows any deviation from the Normal Condition value, check the corresponding sensor, actuator and related electrical wiring, then repair or replace.
5. After repair or replacement, recheck with the ohmmeter to confirm that the repair has corrected the problem.

10. INSPECTION PROCEDURES USING AN OSCILLOSCOPE

When there are inspection procedures using an oscilloscope, these are listed.

HOW TO USE THE INSPECTION PROCEDURES

The causes of many of the problems occurring in electric circuitry are generally the connectors, components, the ECU, and the harnesses between connectors, in that order. These inspection procedures follow this order. They first try to discover a problem with a connector or a defective component.

Scheme 3

Scheme 4

HARNESS INSPECTION

Check for an open or short circuit in the harness between the terminals which were faulty according to the connector measurements. Carry out this inspection while referring to HARNESS CONNECTOR INSPECTION . Here, "Check harness between power supply and terminal xx" also includes checking for blown fuse. For inspection service points when there is a blown fuse, refer to " INSPECTION SERVICE POINTS FOR A BLOWN FUSE ."

MEASURES TO TAKE AFTER REPLACING THE ECU

If the trouble symptoms have not disappeared even after replacing the ECU, repeat the inspection procedure from the beginning.

CONNECTOR MEASUREMENT SERVICE POINTS

Turn the ignition switch to the "LOCK" (OFF) position when connecting and disconnecting the connectors. Turn the ignition switch to "ON" when measuring, unless there are instructions to the contrary.

IF INSPECTING WITH THE CONNECTOR CONNECTED < WATERPROOF CONNECTORS >

Be sure to use special tool. Never insert a test probe from the harness side, as this will reduce the waterproof performance and result in corrosion.

Scheme 5

IF INSPECTING WITH THE CONNECTOR CONNECTED < ORDINARY (NON-WATERPROOF) CONNECTORS >

Required Special Tool

Scheme 6

1. MB992006: Extra Fine Probe Inspect by inserting a test probe from the harness side. If the connector is too small to insert a test probe (e.g. control unit connector), do not insert it forcibly. Use special tool MB992006 (extra fine probe).

IF INSPECTING WITH THE CONNECTOR DISCONNECTED

< When Inspecting a Female Pin >

Scheme 7

Scheme 8

1. From front side of the connector Required Special Tool: MB991219: Inspection Harness (Included in MB991223, Harness Set) The inspection harness for connector pin contact pressure should be used. The test probe should never be forcibly inserted, as it may cause a defective contact.
2. From back side of the connector (SRS-ECU harness side connector) Since the SRS-ECU harness connector is plated to improve conductivity, observe the warning below when checking this connector.

< When Inspecting a Male Pin >

Touch the pin directly with the test probe.

Scheme 9

Scheme 10

1. Connector is disconnected or improperly connected
2. Connector pins are pulled out
3. Stretched an broken wires at terminal section
4. Low contact pressure between male and female terminals
5. Low connection pressure due to rusted terminals or foreign matter lodged in terminals

CONNECTOR PIN INSPECTION

If the connector pin stopper is damaged, the terminal connections (male and female pins) will not be perfect even when the connector body is connected, because the pins may pull out of the back side of the connector. Therefore, gently pull the wires one by one to make sure that no pins pull out of the connector.

Scheme 11

CONNECTOR ENGAGEMENT INSPECTION

Required Special Tool

MB991219: Inspection Harness (contained in MB991223 Test Harness)

Use special tool, MB991219 to inspect the engagement of the male pins and female pins. [Pin drawing force: 1 N (0.2 pound) or more]

Scheme 12

HOW TO COPE WITH INTERMITTENT MALFUNCTIONS

Most intermittent malfunctions occur under certain conditions. If those conditions can be identified, the cause will be easier to find.

1. ASK THE CUSTOMER ABOUT THE MALFUNCTION

Ask what it feels like, what it sounds like, etc. Then ask about driving conditions, weather, frequency of occurrence, and so on.

2. DETERMINE THE CONDITIONS FROM THE CUSTOMER'S RESPONSES

Typically, almost all intermittent malfunctions occur from conditions like vibration, temperature and/or moisture change, poor connections. From the customer's responses, it should be reasoned which condition is most likely.

3. USE SIMULATION TEST

Use the simulation tests below to attempt to duplicate the customer's complaint. Determine the most likely circuit(s) and perform the simulation tests on the connectors and parts of that circuit(s). Be sure to use the inspection procedures provided for diagnostic trouble codes and trouble symptoms.

For temperature and/or moisture condition related intermittent malfunctions, try to change the conditions of the suspected circuit components, then use the simulation tests below.

4. VERIFY THE INTERMITTENT MALFUNCTION IS ELIMINATED

Repair the malfunctioning part and try to duplicate the condition(s) again to verify the intermittent malfunction has been eliminated.

SIMULATION TESTS

Note. In case of difficulty in finding the cause of the intermittent malfunction, the data recorder function in the scan tool is effective.

For these simulation tests, shake, then gently bend, pull, and twist the wiring of each of these examples to duplicate the intermittent malfunction.

Scheme 13

1. Shake the connector up-and-down, and right-and-left.
2. Shake the wiring harness up-and-down, and right-and-left. Especially, check the splice points of wiring harnesses carefully. Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) .
3. Shake the part or sensor.

HOW TO TREAT PAST TROUBLE

Since the trouble may still be present even the status is "Stored", set the vehicle to the diagnostic trouble code detection condition and check that the status changes to "Active". If the status does not change from "Stored", carry out the following procedure.

1. Establish from the customer whether a fuse or connector has been replaced or disconnected.
2. If yes, erase the diagnostic trouble code, and then check that no diagnostic code is reset. If no diagnostic trouble code is reset, the diagnosis is complete.
3. If no, follow the applicable Diagnostic Trouble Code Chart. Then check the wiring harness and connector, and refer to " «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ."

INSPECTION SERVICE POINTS FOR A BLOWN FUSE

Remove the blown fuse and measure the resistance between the load side of the blown fuse and the ground. Close the switches of all circuits which are connected to this fuse. If the resistance is almost 0 ohms at this time, there is a short somewhere between these switches and the load. If the resistance is not 0 ohms, there is no short at the present time, but a momentary short has probably caused the fuse to blow.

The main causes of a short circuit are the following.

Scheme 14

1. Harness being clamped by the vehicle body
2. Damage to the outer casing of the harness due to wear or heat
3. Water getting into the connector or circuitry
4. Human error (mistakenly shorting a circuit, etc.)

VEHICLES IDENTIFICATION NUMBER LOCATION

The vehicle identification number (VIN) plate is located on a plate attached to the left top side of the instrument panel.

Scheme 15

Scheme 16

CODE CHART

(FOR FEDERAL EMISSION REGULATION)

VEHICLE IDENTIFICATION NUMBER LIST (FOR FEDERAL EMISSION REGULATION)

(FOR CALIFORNIA EMISSION REGULATION)

VEHICLE IDENTIFICATION NUMBER LIST (FOR CALIFORNIA EMISSION REGULATION)

VEHICLES FOR PUERTO RICO, GUAM AND SAIPAN

VEHICLE IDENTIFICATION NUMBER LIST (FOR PUERTO RICO, GUAM AND SAIPAN)

VEHICLES FOR CANADA

VEHICLE IDENTIFICATION NUMBER LIST (CANADA)

VEHICLES FOR MEXICO

VEHICLE IDENTIFICATION NUMBER LIST (MEXICO)

The vehicle identification number (VIN) plate is located on a plate attached to the left top side of the instrument panel.

Scheme 17

CODE CHART

VEHICLE IDENTIFICATION NUMBER LIST (FOR FEDERAL EMISSION REGULATION)

VEHICLE IDENTIFICATION NUMBER LIST (FOR CALIFORNIA EMISSION REGULATION)

VEHICLES FOR PUERTO RICO

VEHICLE IDENTIFICATION NUMBER LIST (FOR PUERTO RICO)

VEHICLES FOR GUAM AND SAIPAN

VEHICLE IDENTIFICATION NUMBER LIST (FOR GUAM AND SAIPAN)

VEHICLE IDENTIFICATION NUMBER LIST (CANADA)

CHASSIS NUMBER

The chassis number is stamped on the front floor pan.

CHASSIS NUMBER CODE CHART

CHASSIS NUMBER CODE

Scheme 18

VEHICLE IDENTIFICATION CODE PLATE

The vehicle information code plate is riveted to the face of the passenger's door sill.

CODE CHART

CODE CHART

For monotone color vehicles, the body color code shall be indicated.

Scheme 19

TIRE AND LOADING INFORMATION PLACARD

The tire and loading information placard is located on the inside sill of the driver's door.

Scheme 20

ENGINE MODEL STAMPING

The engine model is stamped on the cylinder block.

These engine model numbers are as shown as follows.

ENGINE MODEL STAMPING REFERENCE

The engine serial number is stamped near the engine model number.

Scheme 21

ENGINE SERIAL NUMBER REFERENCE

2.0L ENGINE < NON-TURBO >

Except vehicles for RALLIART

Scheme 22

GENERAL DATA AND SPECIFICATIONS

ITEM SPECIFICATION

2.0L ENGINE < TURBO >

Vehicles for RALLIART

Scheme 23

ITEM SPECIFICATION

2.4L ENGINE

Except vehicles for RALLIART

ITEM SPECIFICATION

Except vehicles for RALLIART

Scheme 24

ITEM SPECIFICATION

Vehicles for RALLIART

Scheme 25

ITEM SPECIFICATION

Except vehicles for RALLIART

ITEM SPECIFICATION

CAUTIONS FOR WORKING IN ENGINE COMPARTMENT < 2.0L ENGINE Turbo >

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

1. Items to review when servicing SRS: Be sure to read «GENERAL INFORMATION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/airbag/#supplemental-restraint-system-srs-except-lancer-evolution) in Supplemental Restraint System (SRS). For safe operation, please follow the directions and heed all warnings. Wait at least 60 seconds after disconnecting the battery cable before doing any further work. The SRS system is designed to retain enough voltage to deploy the air bag even after the battery has been disconnected. Serious injury may result from unintended air bag deployment if work is done on the SRS system immediately after the battery cable is disconnected. Warning labels must be heeded when servicing or handling SRS components. Warning labels can be found in the following locations (Refer to «WARNING/CAUTION LABELS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/airbag/#supplemental-restraint-system-srs-except-lancer-evolution) ). Always use the designated special tools and test equipment. Store components removed from the SRS in a clean and dry place. The air bag module should be stored on a flat surface and placed so that the pad surface is facing upward. Never attempt to disassemble or repair the SRS components (SRS-ECU, air bag module and clock spring). If there is a defect, replace the defective part. Whenever you finish servicing the SRS, check the SRS warning light operation to make sure that the system functions properly. Be sure to deploy the air bag before disposing of the air bag module or disposing of a vehicle equipped with an air bag (Refer to «AIR BAG MODULE AND SEAT BELT PRE-TENSIONER DISPOSAL PROCEDURES»(/mitsubishi/lancer-evolution/x-2007-2016/remont/airbag/#supplemental-restraint-system-srs-except-lancer-evolution) ).
2. Observe the following when carrying out operations on places where SRS components are installed, including operations not directly related to the SRS air bag. When removing or installing parts, do not allow any impact or shock to occur to the SRS components. If heat damage may occur during paint work, remove the SRS-ECU, the air bag module, clock spring, the front impact sensor, the side impact sensor, and the seat belt pre-tensioner. SRS-ECU, air bag module, clock spring, front impact sensor, the side impact sensor: 93°C (200°F) or more Seat belt pre-tensioner: 90°C (194°F) or more

SERVICING ELECTRICAL SYSTEM

Scheme 26

1. Note the following before proceeding with working on the electrical system. Never perform unauthorized modifications to any electrical device or wiring. Such modifications might lead to a vehicle malfunction, over-capacity or short-circuit that could result in a fire in the vehicle. CAUTION: Before connecting or disconnecting the negative battery cable, be sure to turn the ignition switch to the "LOCK" (OFF) position and turn off the lights (If this is not done, there is the possibility of semiconductor parts being damaged). After completion of the work (and the negative battery terminals is connected), warm up the engine and allow it to idle for approximately 10 minutes under the conditions described below in order to stabilize engine control conditions, and then check to be sure that the idle is satisfactory. Engine coolant temperature: 85 - 95°C (185 - 203°F) Lights and all accessories: OFF Transaxle: "P" position Steering wheel: straight-forward position
2. When servicing the electrical system, disconnect the negative cable terminal from the battery.

HOW TO SHIFT LOCK FORCED RELEASE

If the shift lever cannot be moved from the P position due to discharged battery or similar reasons, release the shift lock by observing the procedure below.

Scheme 27

Scheme 28

1. Remove the floor console box cup holder and the floor console panel assembly (Refer to «FLOOR CONSOLE ASSEMBLY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/gauges-instrument-panels/#interior-except-lancer-evolution) ).
2. Turn the ignition switch to the position other than the LOCK (OFF) position.
3. Insert a screwdriver or a similar tool from the section "A" shown in the figure. While pressing the shift lock forced release switch, move the shift lever.

Scheme 29

1. Turn the ignition switch to the position other than the LOCK (OFF) position.
2. Remove the shift lock forced release switch cover shown in the figure. While pressing the shift lock forced release switch with a screwdriver or a similar tool, move the selector lever.

SCAN TOOL (MULTI USE TESTER {M.U.T.-III} SUB ASSEMBLY)

Note. M.U.T.-III trigger harness is not necessary when pushing V.C.I. ENTER key.

Scheme 30

HOW TO PERFORM VEHICLE IDENTIFICATION NUMBER (VIN) WRITING

Follow the procedure below to register the VIN of the Wireless Control Module (WCM) and the Keyless Operation System (KOS).

The VIN is stored in the engine control module (ECM), WCM, and the KOS-ECU. If the VIN is improperly erased, the engine warning light or the keyless operation system warning indicator illuminate, and the diagnostic trouble code is displayed. When the ECM, WCM, and the KOS-ECU are replaced, follow the procedure below to write the VIN.

Scheme 31

WRITING PROCEDURE

Required Special Tools

1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: V.C.I. MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A

Connect scan tool MB991958 to the 16-pin data link connector as follows.

Note. For details on how to use scan tool MB991958, refer to the M.U.T.-III Owner's Manual.

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

1. Ensure that the ignition switch is at the "LOCK" (OFF) position.
2. Start up the personal computer.
3. Connect special tool MB991827 to special tool MB991824 and the personal computer.
4. Connect special tool MB991910 to the special tool MB991824.
5. Connect special tool MB991910 to the data link connector of the vehicle.
6. Turn the special tool MB991824 power switch to the "ON" position. NOTE: When the special tool MB991824 is energized, the special tool MB991824 indicator light will be illuminated in a green color.
7. Start the "M.U.T.-III system" on the personal computer and turn the ignition switch to the "ON" position.
8. Select "F.A.S.T./IMMO/Keyless/TPMS" button from the "System Select" screen. Then, select the applicable option code item and push the OK button.
9. Select "Special Function" on the next screen.
10. Select "ENG key code & VIN Reg." from the "Special Function" screen.
11. Push the OK button after "ENG key code & VIN Reg." is displayed.
12. Push the OK button after "Completed. Press the OK button and move to VIN writing function." is displayed.
13. Enter the VIN of registering vehicle and push the OK button.
14. Push the OK button after "VIN Writing will start. Are you sure?" is displayed.
15. Return to the previous screen and "In Progress" is displayed at the lower-left corner on the screen.
16. Push the OK button after "Completed." is displayed.
17. VIN writing result is displayed.
18. Complete the scan tool MB991958.
19. Disconnecting the scan tool MB991958 is the reverse of the connecting sequence, making sure that the ignition switch is at the "LOCK" (OFF).
20. Push the OK button after "Completed." is displayed.
21. Terminate the scan tool MB991958.
22. Turn the ignition switch to the "LOCK" (OFF) position and then disconnect scan tool MB991958.

VIN WRITING STEPS FOR WCM AND KOS-ECU

Connect scan tool MB991958 to the 16-pin data link connector as follows.

Note. For details on how to use scan tool MB991958, refer to the M.U.T.-III Owner's Manual.

Scheme 39

Scheme 40

Scheme 41

Scheme 42

1. Ensure that the ignition switch is at the "LOCK" (OFF) position.
2. Start up the personal computer.
3. Connect special tool MB991827 to special tool MB991824 and the personal computer.
4. Connect special tool MB991910 to the special tool MB991824.
5. Connect special tool MB991910 to the data link connector of the vehicle.
6. Turn the special tool MB991824 power switch to the "ON" position. NOTE: When the special tool MB991824 is energized, the special tool MB991824 indicator light will be illuminated in a green color.
7. Start the "M.U.T.-III system" on the personal computer and turn the ignition switch to the "ON" position.
8. Select "F.A.S.T./IMMO/Keyless/TPMS" button from the "System Select" screen. Then, select the applicable option code item and push the OK button.
9. Select "Coding" on the next screen.
10. Select "VIN Writing" on "Coding" screen.
11. Push the OK button after the VIN written in the engine control module is displayed.
12. Push the OK button after "VIN Writing will start. Are you sure?" is displayed.
13. Push the OK button after "Completed." is displayed.
14. Result of VIN writing is displayed.
15. Resister the other ID code. (Refer to «ID CODE REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/door-locks-anti-theft-systems/#keyless-operation-system-kos-except-lancer-evolution__id-codes-registration-judgment-table) < Vehicles with KOS > or «ID CODE REGISTRATION JUDGMENT TABLE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__id-codes-registration-judgment-table) < Vehicles with WCM >.)

CODING LIST

Before troubleshooting, check that the coding data written into the engine control module, TC-SST-ECU and ETACS-ECU are normal. If they are not the same as the initial settings, various functions and systems will not work correctly.

VARIANT CODING

Required Special Tools

1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)

The coding data can be checked by operating scan tool MB991958.

Note. For details on how to use the scan tool MB991958, refer to the M.U.T.-III Owner's manual.

1. Ensure that the ignition switch is at the "LOCK" (OFF) position.
2. Start up the personal computer.
3. Connect special tool MB991827 to special tool MB991824 and the personal computer.
4. Connect special tool MB991910 to special tool MB991824.
5. Connect special tool MB991910 to the data link connector.
6. Turn the power switch of special tool MB991824 to the "ON" position. NOTE: When special tool MB991824 is energized, special tool MB991824 indicator light will be illuminated in a green color.
7. Start the "M.U.T.-III system" on the personal computer.
8. Turn the ignition switch to the "ON" position.
9. Select "System select" from the start-up screen.
10. Select "From 2006 MY" under "Model Year". Check that "Vehicle Information" contents are correct.
11. On the system list screen, select "MPI/GDI/DIESEL" to check the engine control module data, "AT/CVT/A-MT/TC-SST" to check the TC-SST data, and "ETACS" to check the ETACS-ECU data. NOTE: If "Loading Option Setup" list is shown, click appropriate box.
12. Select "Coding."
13. Select "Coding information & copy."
14. If the displayed coding information is different from the corresponding initial setting in the list, replace the ECU with a correctly coded one. For replacement of the engine control module, refer to «REMOVAL AND INSTALLATION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) < 2.0L Non-turbo Engine > or «REMOVAL AND INSTALLATION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) < 2.0L Turbo Engine > or «REMOVAL AND INSTALLATION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) < 2.4L Engine >. For replacement of the TC-SST-ECU*, refer to «TRANSAXLE ASSEMBLY»(/mitsubishi/lancer-evolution/x-2007-2016/remont/automatic-trans/#twin-clutch-sportronic-shift-transmission-tc-sst-on-vehicle-service-except-lancer-evolution) . For replacement of the ETACS-ECU, refer to «REMOVAL AND INSTALLATION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__removal-and-installation) . NOTE: *: TC-SST-ECU cannot be disassembled. Thus, replace the transaxle assembly.

ENGINE CONTROL MODULE CODING DATA LIST

ENGINE CONTROL MODULE CODING DATA LIST

TC-SST-ECU CODING DATA LIST

TC-SST-ECU CODING DATA LIST

ETACS-ECU CODING DATA LIST

Note. The items to be displayed may differ depending on the version of the ETACS-ECU.

ETACS-ECU CODING DATA LIST

OPTION CODING

Required Special Tools

1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)

The engine control module and ETACS-ECU option coding data can be checked or changed by operating scan tool MB991958.

1. How to check option coding data Connect the scan tool MB991958. Turn the ignition switch to the "ON" position. Select "System select" from the start-up screen. Select "From 2006 MY" under "Model Year". Check that "Vehicle Information" contents are correct. Select "MP/GDI/DIESEL" or "ETACS" from "System List", and then press "OK" button. NOTE: If "Loading Option Setup" list is shown, click appropriate box. Select "Coding." Select "Option Coding Information." Check the displayed option coding information.
2. How to change option coding data Connect the scan tool MB991958. Turn the ignition switch to the "ON" position. Select "System select" from the start-up screen. Select "From 2006 MY" under "Model Year". Check that "Vehicle Information" contents are correct. Select "MP/GDI/DIESEL" or "ETACS" from "System List", and then press "OK" button. NOTE: If "Loading Option Setup" list is shown, click appropriate box. Select "Coding." Select "Option Coding." Change to correct option coding data.

LIST < ENGINE CONTROL MODULE >

ENGINE CONTROL MODULE REFERENCE

LIST < ETACS-ECU >

ETACS-ECU SPECIFICATION

INITIALIZATION PROCEDURE FOR LEARNING VALUE IN MFI ENGINE

When the following service is performed, initialize the learning value.

1. At replacing engine assembly*
2. At replacing throttle body and at cleaning
3. At replacing knock sensor NOTE: * Initialize CVT-related learning value.

INITIALIZATION PROCEDURE

Required Special Tools

1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: V.C.I. MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A

1. After the ignition switch is in "LOCK" (OFF) position, connect scan tool MB991958 to the diagnosis connector.
2. Turn the ignition switch to the "ON" position.
3. Select "MFI" form System select Screen of scan tool MB991958.
4. Select "Special Function" form MFI Screen.
5. Select "Learned value reset" from Special Function Screen.
6. Select "All learned value" form Learned value reset Screen.
7. Initialize the learning value by pressing the "ON" button.
8. After initializing the learning value, the learning value of MFI engine idling is necessary. (Refer to «ENGINE IDLING LEARNING PROCEDURE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution) ).

PURPOSE

When the ECM is replaced, or when the learned value is initialized, the idle may not be stabilized. Carry out the learning method by following the procedures below.

LEARNING PROCEDURE

1. Start the engine and warm to reach 80°C (176°F) or more. NOTE: When the engine coolant temperature is 80°C (176°F) or more, the warm-up is not needed if the ignition switch is in "ON" position once.
2. Turn the ignition switch to "LOCK" (OFF) position.
3. After 10 seconds or more, start the engine again.
4. For 10 minutes, carry out the idling under the condition shown below and then confirm the engine idles normally. Transaxle: Neutral (P range on vehicles with CVT or TC-SST) Operation in ignition-related, fan and attachments: Not to be operated Engine coolant temperature: 80°C (176°F) or more NOTE: If the engine stalls while idling, check for a dirty (on the throttle valve) of the throttle body and clean if needed. Then perform the service from Procedure 1 again.

INITIALIZATION PROCEDURE FOR THROTTLE ACTUATOR CONTROL MOTOR

When the battery cable is disconnected and reconnected, throttle actuator control motor valve (Fully closed position) is eliminated, so that the throttle valve opening angle control would not be performed correctly. When the battery cable is disconnected and reconnected, initialize the throttle actuator control motor using the following procedure.

1. Turn the ignition switch to the "ON" position then, turn the ignition switch to "LOCK" (OFF) position.
2. For 10 seconds or more, keep the ignition switch in "LOCK" (OFF) position.

TIMING CHAIN LEARNED VALUE RESET < 2.0L ENGINE Non-turbo, 2.4L ENGINE >

Required Special Tools

1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: V.C.I. MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A

1. After the ignition switch is in "LOCK" (OFF) position, connect scan tool MB991958 to the diagnosis connector.
2. Turn the ignition switch to the "ON" position.
3. Select "MFI" form System select Screen of scan tool MB991958.
4. Select "Special Function" form MFI Screen.
5. Select "Timing chain maintenance" from Special Function Screen.
6. Select "Learned value reset" form Timing chain maintenance Screen.
7. Press "ON" to reset the learning value.

The ECM carries out the electrical generation control according to the charge level of the battery, based on the battery current sensor signal. To improve the effect of reducing the fuel consumption by the electrical generation control, it is necessary to accurately detect the charge level of the battery. For this, if the following services are performed, carry out the battery current sensor calibration.

1. Replacing the battery current sensor
2. Replacing the ECM

Scheme 43

1. After the ignition switch is in "LOCK" (OFF) position, disconnect the battery cable from the negative battery terminal.
2. Remove the battery current sensor from the battery cable (Do not disconnect the battery current sensor connector).
3. Connect the battery cable without the battery current sensor to the negative battery terminal.
4. Connect the M.U.T.-III to the diagnosis connector (But do not start the engine).
5. Turn the ignition switch to the ON position.
6. Select "MFI" from System select Screen of the M.U.T.-III.
7. Select "Special Function" from MFI Screen.
8. Select "Learning" from Special Function Screen.
9. Select "Battery current SNSR.calibration" from Learning Screen.
10. Start the calibration by pressing the "OK" button.
11. Confirm that the M.U.T.-III data list item No. 119 Battery current sensor calibration is "Completed".
12. After the ignition switch is in "LOCK" (OFF) position, disconnect the M.U.T.-III.
13. Install the battery current sensor.

TIMING CHAIN MAINTENANCE < 2.0 L ENGINE Turbo >

If the vehicle equipped with 2.0 L ENGINE Turbo continues the rough driving like competitive running *1 , the amount of carbon mixed into the engine oil tends to increase. This can possibly cause the timing chain to gradually elongate. To prevent this, the function or logic monitoring the amount of elongation of the timing chain is integrated into the ECM. When the ECM detects the elongation of the timing chain, the warning is shown on the multi-information display of combination meter as shown in the illustration. This gives the driver the information that the visual check of the elongation of the timing chain is necessary. If this warning is continuously neglected, the timing chain can possibly interfere with the other engine components, resulting in the engine damaged.

Scheme 44

Note. *1: The competitive running means the running that constantly repeats the cycle of the full opened position of the accelerator pedal and the full closed position of the accelerator pedal.

The ECM stores the timing chain conditions as the learning value when the timing chain is installed. The ECM stores the amount of elongation of the timing chain in the EEPROM as the current learning value, compared with the learning value. The ECM judges that the visual check of the elongation of the timing chain is necessary when the current learning value exceeds the specified value. Thus, use the scan tool MB991958 to always carry out the maintenance of the learning value related to the timing chain that is stored by the ECM after the following service.

MAINTENANCE ITEMS

LEARNED VALUE READ&SAVE AND WRITE LEARNED VALUE (CHANGED ECU)

Required Special Tools

1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: V.C.I. MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A

1. After the ignition switch is in "LOCK" (OFF) position, connect scan tool MB991958 to the diagnosis connector.
2. Turn the ignition switch to the "ON" position.
3. Select "MFI" from System select Screen of scan tool MB991958.
4. Select "Special Function" from MFI Screen.
5. Select "Timing chain maintenance" from Special Function Screen.
6. Select "Learned value Read&Save" from Timing chain maintenance Screen.
7. Press "OK" to store the learning value file. NOTE: When the learning value file is appropriately stored, "Learned value Save Complete" is shown on the screen of the scan tool MB991958. NOTE: Calculating the amount of elongation of the timing chain by the ECM takes the time. Thus, the file cannot be stored for a while after the ECM initialization or replacement.
8. Replace the ECM.
9. Select "Learned value reset" from Timing chain maintenance Screen.
10. Select the learning value file stored during Step 3 to write the learning value. NOTE: Use only the learning value file stored during Step 3 without using any other files. NOTE: When the learning value is appropriately written, "Learned value writing Completed." is shown on the screen of the scan tool MB991958.

LEARNED VALUE RESET

Required Special Tools

1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: V.C.I. MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A

1. After the ignition switch is in "LOCK" (OFF) position, connect scan tool MB991958 to the diagnosis connector.
2. Turn the ignition switch to the "ON" position.
3. Select "MFI" from System select Screen of scan tool MB991958.
4. Select "Special Function" from MFI Screen.
5. Select "Timing chain maintenance" from Special Function Screen.
6. Select "Learned value reset" from Timing chain maintenance Screen.
7. Press "OK" to reset the learning value.

TEST/LIMIT VALUE READOUT

Required Special Tools

1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: V.C.I. MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A

1. After the ignition switch is in "LOCK" (OFF) position, connect scan tool MB991958 to the diagnosis connector.
2. Turn the ignition switch to the "ON" position.
3. Select "MFI" from System select Screen of scan tool MB991958.
4. Select "Special Function" from MFI Screen.
5. Select "Timing chain maintenance" from Special Function Screen.
6. Select "Test/Limit value readout" from Timing chain maintenance Screen.
7. Read the value of percentage (%) shown on the screen. NOTE: The value of percentage (%) shown on the screen is the amount of elongation of the timing chain calculated by the ECM based on the learning value, and thus is not the actual amount. Use this for the reference only.

FORM-IN-PLACE GASKET (FIPG)

The engine has several parts to which the form-in-place gasket (FIPG) is used. To sufficiently achieve the aims of this gasket, it is necessary to pay attention to the application amount, procedure, and surface status.

If the application amount is too small, a leakage will occur. If the application amount is excessive, the FIPG will overflow and cause a clogging or narrowing of water and oil paths. Therefore, to eliminate the leak from the joint, it is indispensable that the FIPG be applied with a correct amount and without any gap.

Because the FIPG used for the engine parts becomes hardened by the reaction with the atmospheric moisture, it is normally used for the metal flange section.

DISASSEMBLY

The parts installed with the FIPG can be disassembled easily without using any special method. However, in some cases, it is necessary to tear the sealant in between the mating surfaces by tapping the parts with a wooden hammer or similar tools. It is acceptable to lightly hit in a smooth, thin gasket scraper into the mating surface, but, in this case, a sufficient caution is required not to damage the mating surface. The oil pan FIPG cutter (Special tool: MD998727) is provided. Thus, use this special tool.

GASKET SURFACE CLEANING

Use a gasket scraper or wire brush to completely remove all the foreign materials adhering to the gasket surface. Check that the FIPG application surface is smooth. There must be no grease or foreign material adhesion to the gasket surface. Do not forget to remove the old FIPG remaining in the mounting hole and tapped hole.

APPLICATION PROCEDURE

Apply the FIPG with a specified diameter and without any gap. Completely enclose around the mounting hole. When the FIPG is not hardened, it can be wiped off. When the FIPG is still moistened (within three minutes), perform the installation to the specified position. At the time of installation, prevent the FIPG from adhering to locations other than it is necessary. After the installation, until a sufficient period of time (approximately for two hours) elapses, do not contact the oil or water to the application area. Also, do not start the engine. Because the FIPG application procedure may differ depending on the application area, apply the FIPG according to the procedure described in the text.

BOLTS AND NUTS WITH STABILIZER FOR COEFFICIENT OF FRICTION

The bolts and nuts with stabilizer for coefficient of friction have been used for the connections such as the suspension arm and crossmember in order to stabilize the axial force and to ensure the high axial force at bolt/nut connections, resulting in improved reliability.

Note. The bolts and nuts with stabilizer for coefficient of friction mean that the bolts and nuts with surface treatment to stabilize and reduce the coefficient of friction, allowing to achieve the stable axial force and to secure the high axial force with low tightening torque.

APPLICATION OF ANTI-CORROSION AGENTS AND UNDERCOATS

Be careful not to apply oil or grease to the heated oxygen sensor. If applied, the sensor may malfunction. Protect the heated oxygen sensor with a cover before applying anti-corrosion agent, etc.

Scheme 45

1. If high-pressure car-washing equipment or steam car-washing equipment is used to wash the vehicle, be sure to maintain the spray nozzle at a distance of at least approximately 40 cm (16 in.) from any plastic parts and all opening parts (doors, luggage compartment, etc.).
2. If high-pressure car-washing equipment or steam car-washing equipment is used to wash the vehicle, be sure to observe the following instructions to prevent damages to the plastic parts. Spray nozzle distance: Approximately 40 cm (16 in.) or more Spray pressure: 3,900 kPa or less Spray temperature: 82°C (180°F) or less Time of intensive spraying to one point: Within 30 seconds

FRONT TOWING PICKUP < FWD >

Scheme 46

1. The vehicle may be towed on its rear wheels for extended distances provided the parking brake is released. It is recommended that vehicles be towed using the front pickup whenever possible.

FRONT TOWING PICKUP < AWD >

Scheme 47

1. If this vehicle is towed, use flat bed equipment only.

REAR TOWING PICKUP

Scheme 48

1. If this vehicle is towed, use flat bed equipment only.

TOWING WHEN KEYS ARE NOT AVAILABLE

When a locked vehicle must be towed and keys are not available, the vehicle may be lifted and towed from the front, provided the parking brake is released. If not released, the rear wheels should be placed on a tow dolly.

SAFETY PRECAUTIONS

The following precautions should be taken when towing the vehicle

1. Do not lift or tow the vehicle by attaching to or wrapping around the bumper.
2. Any loose, protruding, or damaged parts such as hoods, doors, fenders, trim, etc. should be secured or removed prior to moving the vehicle.
3. Refrain from going under a vehicle when it is lifted by the towing equipment, unless the vehicle is adequately supported by safety stands.
4. Never allow passengers to ride in a towed vehicle.
5. State and local rules and regulations must be followed when towing a vehicle.

FLOOR JACK

Scheme 49

POST TYPE

Special care should be taken when raising the vehicle on a frame contact type hoist. The hoist must be equipped with the proper adapters in order to support the vehicle at the proper locations.

Scheme 50

TIGHTENING TORQUE

Each torque value in the table is a standard value for tightening under the following conditions.

1. Bolts, nuts and washers are all made of steel and plated with zinc.
2. The threads and bearing surface of bolts and nuts are all in dry condition.

The values in the table are not applicable

1. If toothed washers are inserted.
2. If plastic parts are fastened.
3. If bolts are tightened to plastic or die-cast inserted nuts.
4. If self-tapping screws or self-locking nuts are used.

STANDARD BOLT AND NUT TIGHTENING TORQUE

TIGHTENING TORQUE SPECIFICATION

FLANGE BOLT AND NUT TIGHTENING TORQUE

TIGHTENING TORQUE SPECIFICATION

LUBRICATION AND MAINTENANCE

Maintenance and lubrication service recommendations have been compiled to provide maximum protection for the vehicle owner's investment against all reasonable types of driving conditions. Since these conditions vary with the individual vehicle owner's driving habits, the area in which the vehicle is operated and the type of driving to which the vehicle is subjected, it is necessary to prescribe lubrication and maintenance service on a time frequency as well as mileage interval basis.

Oils, lubricants and greases are classified and graded according to standards recommended by the Society of Automotive Engineers (SAE), the American Petroleum Institute (API) and the National Lubricating Grease Institute (NLGI).

MAINTENANCE SCHEDULES

Information for service maintenance is provided in the "SCHEDULED MAINTENANCE TABLE." Three schedules are provided; one for "Required Maintenance." one for "General Maintenance" and one for "Severe Usage Service."

The item numbers in "SCHEDULED MAINTENANCE TABLE" correspond to the section numbers in "MAINTENANCE SERVICE."

SEVERE SERVICE

Vehicles operating under severe service conditions will require more frequent service.

Component service information is included for vehicles operating under one or more of the following conditions

1. Trailer towing or police, taxi or commercial type operation.
2. Operation of Vehicle Short-trip operation at freezing temperature (engine not thoroughly warmed up) More than 50% operation in heavy city traffic during hot weather above 32°C (90°F) Extensive idling Driving in sandy areas Driving in salty areas Driving in dusty conditions Driving off-road

ENGINE OIL

Either of the following engine oils should be used: Engine oils displaying ILSAC certification symbol or conforming to the API classification SM.

For further details, refer to " LUBRICANTS SELECTION " section .

LUBRICANTS AND GREASES

Semi-solid lubricants bear the NLGI designation and are further classified as grades 0, 1, 2, 3, etc.

Whenever "Chassis Lubricant" is specified, Multipurpose Grease, NLGI grade Number 2, should be used.

FUEL USAGE STATEMENT

This vehicle must use unleaded gasoline only.

This vehicle has a fuel filler tube which is especially designed to accept only the smaller-diameter unleaded gasoline dispensing nozzle.

GASOLINE CONTAINING ALCOHOL

Some gasoline sold at service stations contain alcohol although they may not be so identified.

Using fuels containing alcohol is not recommended unless the nature of the blend can be determined as being satisfactory.

Gasohol: A mixture of 10% ethanol (grain alcohol) and 90% unleaded gasoline may be used in your vehicle. If driveability problems are experienced as a result of using gasohol, it is recommended that the vehicle be operated on gasoline.

Methanol: Do not use gasoline containing methanol (wood alcohol). Using this type of alcohol can result in vehicle performance deterioration and damage critical parts in the fuel system components. Fuel system damage and performance problems resulting from the use of gasoline containing methanol may not be covered by the new vehicle warranty.

GASOLINE CONTAINING METHYL TERTIARY BUTYL ETHER (MTBE)

Unleaded gasoline containing 15% or less MTBE may be used in your vehicle. (Fuel containing MTBE over 15% in volume may cause reduced engine performance and produce vapor lock or hard starting.

MATERIALS ADDED TO FUEL

Indiscriminate use of fuel system cleaning agents should be avoided. Many of these materials intended for gum and varnish removal may contain highly active solvents or similar ingredients that can be harmful to gasket and diaphragm materials used in fuel system component parts.

RECOMMENDED LUBRICANTS

RECOMMENDED LUBRICANTS AND LUBRICANT CAPACITIES SPECIFICATIONS

LUBRICANT CAPACITY TABLE

LUBRICANT CAPACITY SPECIFICATIONS

Use only engine oils displaying the ILSAC certification symbol ("Starburst" symbol) on the container.

Scheme 51

If these oils are not available, an API classification SM or higher can be used.

Scheme 52

OIL VISCOSITY < 2.0L ENGINE Non-turbo, 2.4L ENGINE >

The SAE grade number indicates the viscosity of the oil. A proper SAE grade number should be selected according to ambient temperature.

Note. SAE 5W-20 engine oil is strongly recommended for optimum fuel economy and cold starting.

Scheme 53

OIL VISCOSITY < 2.0L ENGINE Turbo >

Note. SAE 0W-30 and 0W-40 engine oil are recommended to use to improve engine startability on a very cold weather condition.

Scheme 54

SCHEDULED MAINTENANCE SERVICE FOR EMISSION CONTROL AND PROPER VEHICLE PERFORMANCE

Inspection and service should be performed any time if a malfunction is observed or suspected.

SCHEDULED MAINTENANCE

GENERAL MAINTENANCE SERVICE FOR PROPER VEHICLE PERFORMANCE

GENERAL MAINTENANCE SERVICE

SCHEDULED MAINTENANCE UNDER SEVERE USAGE CONDITIONS

Maintenance should be carried out according to the following table

SCHEDULED MAINTENANCE UNDER SEVERE USAGE CONDITIONS

Severe usage conditions

1. Driving on dusty, rough, muddy or salt-spread roads
2. Towing or police, taxi or commercial operation
3. Extensive idling and/or low speed operation
4. Repeated short-trip operation at freezing temperatures (engine not thoroughly warmed up)
5. Extended use of brakes while driving
6. Driving in sandy areas
7. More than 50% operation in heavy city traffic during hot weather above 32°C (90°F)

Inspection and service should be performed any time a malfunction is observed or suspected.

SCHEDULED MAINTENANCE SERVICE

GENERAL MAINTENANCE SERVICE

Maintenance should be carried out according to the following table

SCHEDULED MAINTENANCE UNDER SEVERE USAGE CONDITIONS

Severe usage conditions

1. Driving on dusty, rough, muddy or salt-spread roads
2. Towing or police, taxi or commercial operation
3. Extensive idling and/or low speed operation
4. Repeated short-trip operation at freezing temperatures (engine not thoroughly warmed up)
5. Extended use of brakes while driving
6. Driving in sandy areas
7. More than 50% operation in heavy city traffic during hot weather above 32°C (90°F)

CHECK FOR LEAKS

Check for damage or leakage in the fuel lines and connections.

CHECK CONDITION

1. Inspect the surface of fuel hoses for heat and mechanical damage. Hard and brittle rubber, cracking, tears, cuts, abrasions and excessive swelling indicate deterioration of the rubber.
2. If the fabric casing of the rubber hose is exposed by cracks and abrasions in the fuel system, the hoses should be replaced.

REPLACE

The air cleaner element will become dirty during use, reducing its effectiveness. Replace it with a new one.

Replacement of air cleaner element

Scheme 55

1. Unclamp the air cleaner housing.
2. Remove the air cleaner element and install a new one.
3. When clamping the air cleaner housing in place, be sure that the cover is completed closed.

CHECK FOR LEAKS AND CLOGGING

If the fuel-vapor vent line is clogged or damaged, fuel vapor will escape into the atmosphere causing excessive emissions. Disconnect the line at both ends, and blow it clean with compressed air. Remove the fuel tank filler tube cap from the filler tube and check to see if there is evidence that the seal makes improper contact to the filler tube.

Scheme 56

1. Spark plugs must spark properly to assure proper engine performance and reduce exhaust emission level. Therefore, they should be replaced periodically with new ones. Spark plug type SPARK PLUGS SPECIFICATION Maker 2.0L engine 2.4L engine NGK DIFR6C11 DIFR5C11
2. The new plugs should be checked for the proper gap. Spark plug gap: 1.0 - 1.1 mm (0.039 - 0.043 inch)
3. Install the spark plugs and tighten to 25 ± 4 N.m (18 ± 3 ft-lb).

INSPECT AND ADJUST

Note. Perform the valve clearance check and adjustment at the engine cold state.

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

1. Remove all of the ignition coils.
2. Remove the cylinder head cover. CAUTION: Turn the crankshaft always clockwise.
3. Turn the crankshaft clockwise, and align the timing mark on the exhaust camshaft sprocket against the upper face of the cylinder head as shown in Figure. Therefore, No. 1 cylinder goes to the compression top dead center.
4. Using a thickness gauge, measure the valve clearance with the arrow shown in Figure. If deviated from the standard value, make note for the valve clearance. Standard value: Intake valve 0.20 ± 0.03 mm (0.008 ± 0.0012 inch) Exhaust valve 0.30 ± 0.03 mm (0.012 ± 0.0012 inch)
5. Turn the crankshaft clockwise 360 degrees, and put the timing mark on the exhaust camshaft sprocket in position shown in Figure. Therefore, No. 4 cylinder goes to the compression top dead center.
6. Check the valve clearance with the arrow shown in Figure. In the same procedure as 4.
7. If the valve clearance is deviated from the standard value, remove the camshaft and the valve tappet. For the camshaft removal, refer to «REMOVAL AND INSTALLATION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/mechanical/#engine-mechanical-20l-non-turbo-except-lancer-evolution) < 2.0L Engine Non-turbo > or «REMOVAL AND INSTALLATION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/mechanical/#engine-mechanical-24l-except-lancer-evolution) < 2.4L Engine >.
8. Using a micrometer, measure the thickness of the removed valve tappet.
9. Calculate the thickness of the newly installed valve tappet through the following equation. thickness of newly installed valve tappet thickness of removed valve tappet measured valve clearance Equation Intake valve: A = B + [C - 0.20 mm (0.008 inch)] Exhaust valve: A = B + [C - 0.30 mm (0.012 inch)] NOTE: The valve tappet ranges 3,000 - 3,690 mm (0.1181 - 0.1453 inch) and has 47 types per 0.015 mm (0.0006 inch). The thickness below a decimal point is stamped on the reverse side of the valve tappet.
10. Install the valve tappet selected through the procedure 9, and put the camshaft in position. For the camshaft installation, refer to «REMOVAL AND INSTALLATION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/mechanical/#engine-mechanical-20l-non-turbo-except-lancer-evolution) < 2.0L Engine Non-turbo > or «REMOVAL AND INSTALLATION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/mechanical/#engine-mechanical-24l-except-lancer-evolution) < 2.4L Engine >.
11. After installing the timing chain, measure the valve clearance using the procedure 3 to 6. Confirm the clearance is within the standard value. CAUTION: Completely remove all the old FIPG, which might be remaining among the components.
12. After completely removing the liquid gasket adhering on the timing chain case, cylinder block and cylinder head, degrease them with white gasoline. CAUTION: The cylinder head cover should be installed within 3 minutes of applying liquid gasket.
13. Apply a 4 mm bead of liquid gasket as illustrated. Specified sealant: THREE BOND 1217G or equivalent
14. Install the cylinder head cover and tighten the tightening bolts using the following procedures. Temporarily tighten to the following torque in order shown in the illustration. Tightening torque: 3.0 ± 1.0 N.m (27 ± 9 in-lb) Tighten to the specified torque in order shown in the illustration. Specified torque: 5.5 ± 0.5 N.m (49 ± 9 in-lb)
15. Install the ignition coils.

Scheme 65

1. Remove the radiator condenser tank mounting bolts.
2. Move the radiator condenser tank to a place where it will not be a hindrance when checking the drive belt tension. CAUTION: Check the drive belt tension after turning the crankshaft clockwise one turn or more.
3. Make sure that the indicator mark on the auto-tensioner is within the area marked with A in the illustration.
4. If the mark is out of the area, replace the drive belt. (Refer to «REMOVAL AND INSTALLATION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/mechanical/#engine-mechanical-20l-non-turbo-except-lancer-evolution__removal-and-installation) < 2.0L ENGINE NON-TURBO > or «REMOVAL AND INSTALLATION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/mechanical/#engine-mechanical-24l-except-lancer-evolution__removal-and-installation) < 2.4L ENGINE >). NOTE: The drive belt tension check is not necessary as the auto-tensioner is adopted.
5. Tighten the radiator condenser tank mounting bolts to the specified torque. Tightening torque: 12 ± 2 N.m (102 ± 22 in-lb)

CHECK AND SERVICE

1. Check for holes and exhaust gas leaks due to damage, corrosion, etc.
2. Check the joints and connections for looseness and exhaust gas leaks.
3. Check the rubber hangers and brackets for damage.

Scheme 66

1. Start the engine and allow it to warm up until the temperature of the engine coolant reaches 80 - 90°C (176 - 194°F.) WARNING: Use care as engine oil could be hot.
2. Remove the engine oil filler cap.
3. Remove the engine room under cover extension (Refer to «UNDER COVER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exterior-body-panels/#under-cover-except-lancer-evolution) .)
4. Remove the engine oil pan drain plug to drain engine oil.
5. Install a new engine oil pan drain plug gasket so that it faces in the direction shown in the illustration, and then tighten the engine oil pan drain plug to the specified torque. Tightening torque: 39 ± 5 N.m (29 ± 3 ft-lb)
6. Refill the specified quantity of engine oil. Specified Engine Oil: Engine oils displaying the ILSAC certification symbol ("Starburst" symbol) or conforming to the API classification SM or higher Total quantity (Includes volume inside engine oil filter): < 2.0 L ENGINE Non-turbo >: 4.3 dm 3 (4.52 quarts) < 2.4 L ENGINE >: 4.6 dm 3 (4.82 quarts) NOTE: SAE 5W-20 engine oil is strongly recommended for optimum fuel economy and cold starting.
7. Install the engine oil filler cap.
8. Let the engine run for a few minutes.
9. Stop the engine, and then check the engine oil level using the engine oil level gauge after a few minutes.
10. Install the engine room under cover extension (Refer to «UNDER COVER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exterior-body-panels/#under-cover-except-lancer-evolution) .)

10. ENGINE OIL FILTER

The quality of replacement filters varies considerably. Only high quality filters should be used to assure most efficient service.

Genuine oil filters require that the filter is capable of withstanding a pressure of 1,765 kPa (256 psi) are high quality filters and are recommended as follows

Mitsubishi Oil Filter Part Number: MD360935 or equivalent

ENGINE OIL FILTER SELECTION

This vehicle is equipped with a full-flow, throw-away oil filter.

The same type of filter is recommended as a replacement filter for this vehicle. It is possible, particularly in cold weather, that this vehicle may develop high oil pressure for a short duration. Make sure that any replacement filter used on this vehicle is a high-quality filter. The filter must withstand a pressure of 1,800 kPa (261 psi) [manufacturer's specifications] to avoid filter and ultimately engine damage. The following is a high-quality filter and is strongly recommended for use on this vehicle: Mitsubishi Engine Oil Filter Part number MD360935.

Any replacement oil filter should be installed in accordance with the oil filter manufacturer's installation instructions.

Scheme 67

Scheme 68

1. Start the engine and allow it to warm up until the temperature of the coolant reaches 80 - 90°C (176 - 194°F) WARNING: Use care as oil could be hot.
2. Remove the engine oil filler cap.
3. Remove the drain plug to drain oil.
4. Use the respective tool in the following table to remove the engine oil filter. SPECIAL TOOL SPECIFICATION Number Special tool MD360935 Oil filter wrench (MB991396) or equivalent
5. Clean the filter bracket side mounting surface and ensure the old O-ring has been removed.
6. Apply a small amount of engine oil to the O-ring of the new oil filter.
7. Screw on the oil filter by hand until it touches the surface of the flange and then tighten it with an oil filter wrench. SPECIAL TOOL DESCRIPTION Number Special tool Tightening torque MD360935 MB991396 or equivalent Approximately 3/4 turn [14 ± 2 N.m (124 ± 18 in-lb)]
8. Install the drain plug and refill engine oil (Refer to «SPECIAL TOOLS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/lubrication-system/#engine-lubrication-except-lancer-evolution__special-tools) ).
9. Rev the engine a few times, and check to be sure that no engine oil leaks at the oil filter.

Scheme 69

Scheme 70

1. Remove the filler plug and gasket.
2. Check that the oil level is up to the lower edge of the filler plug hole.
3. Check that the oil is not noticeably dirty.
4. Tighten the filler plug and new gasket, to the specified torque. Tightening torque: 49 ± 19 N.m (37 ± 14 ft-lb)

TRANSAXLE OIL REPLACEMENT

1. Remove the filler plug and gasket.
2. Remove the drain plug and gasket, and drain the oil.
3. Tighten the drain plug and new gasket, to the specified torque. Tightening torque: 49 ± 19 N.m (37 ± 14 ft-lb)
4. Fill with DiaQueen NEW MULTI GEAR OIL API classification GL-3, SAE 75W-80 until the level comes to the lower portion of filler plug hole. Quantity: 2.5 dm 3 (2.6 quarts)
5. Tighten the filler plug and new gasket to the specified torque. Tightening torque: 49 ± 19 N.m (37 ± 14 ft-lb)

CHECK OIL LEVEL AND CONDITION

Scheme 71

Scheme 72

1. Drive the vehicle until the transmission fluid is warmed up to the normal operating temperature 70 - 80°C (158 - 176°F). NOTE: Use M.U.T.-III. to measure the transmission fluid temperature. NOTE: When a certain amount of time is required to warm up the transmission fluid to the normal operating temperature 70 - 80°C (158 - 176°F), check the oil level referring to the characteristics chart.
2. Park the vehicle on a level surface.
3. Move the selector lever to every position to fill the torque converter and the hydraulic circuit with the transmission fluid, and then move the selector lever to "P" or "N" range.
4. Wipe clean the area around the dipstick, and then remove the dipstick to check the condition of the transmission fluid. NOTE: If the transmission fluid smells burnt or is excessively deteriorated or dirty, the transmission fluid is contaminated with particles of the metal bushings and friction material. In these cases, the transaxle must be overhauled.
5. Check that the transmission fluid level is within the "H" area on the dipstick. If the fluid level is low, add the transmission fluid to the "H" level. Transmission fluid: DIA QUEEN CVTF-J1 NOTE: When the transmission fluid level is low, the oil pump sucks air together with the transmission fluid, and produces air bubbles in the hydraulic circuit. The air bubbles in the hydraulic circuit decreases the hydraulic pressure, causing the delayed shift or slippage of the belt, clutch, and brake. When the transmission fluid level is too high, the fluid is stirred by the gear and foams up, and the problems similar to those when the transmission fluid level is low will occur. In either case, air bubbles cause the overheat and oxidation of the transmission fluid, which prevents normal operation of the valve, clutch, and brake. Beside, when the transmission fluid is foamy, it flows out of the transaxle vent hole. This may be taken as the fluid leakage by mistake.
6. Insert the dipstick securely.

Scheme 73

1. Remove the drain plug on the bottom of the transaxle case to drain the transmission fluid. Draining amount: Approximately 5.1 dm 3 (5.39 qt)
2. Install the drain plug with a new gasket to the transaxle case, and tighten it to the specified torque. Tightening torque: 34 ± 2 N.m (25 ± 2 ft-lb) CAUTION: If the transaxle case becomes full before filling 5.1 dm 3 (5.39 qt) of transmission fluid, stop filling the transmission fluid.
3. Fill in the new transmission fluid through the filler tube. Filling amount: Approximately 5.1 dm 3 (5.39 qt) Transmission fluid: DIA QUEEN CVTF-J1
4. Start up the engine and let it idle for 1 to 2 minutes.
5. Move the selector lever to every position, and then move it to the "P" or "N" range.
6. Stop the engine and perform the above steps 1 to 5 again.
7. Stop the engine, and discharge a small amount of transmission fluid to check for fouling. If fouling is found, repeat steps 1 to 5 until clean transmission fluid comes out.
8. Drive the vehicle until the transmission fluid is warmed up to the normal operating temperature 70 - 80°C (158 - 176°F), and check the transmission fluid level. It must be within the "H" area on the dipstick. NOTE: The "COLD" level is for reference only. Use the "H" level as the criteria. NOTE: Use M.U.T.-III. to measure the transmission fluid temperature. NOTE: When a certain amount of time is required to warm up the transmission fluid to the normal operating temperature 70 - 80°C (158 - 176°F), check the fluid level referring to the characteristics chart.
9. Adjust the transmission fluid level to the specified level. Refill the transmission fluid when the fluid level is low, and drain the transmission fluid through the drain plug when the fluid level is high.
10. Securely insert the dipstick into the filler tube.
11. TCM records the deterioration level of the transmission fluid. After replacing the transmission fluid with new one, use M.U.T.-III to reset the deterioration level recorded in TCM.

Scheme 74

Scheme 75

Scheme 76

Scheme 77

1. Remove the engine room under cover front A (Refer to «UNDER COVER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exterior-body-panels/#under-cover-except-lancer-evolution) .) WARNING: When removing the radiator cap, use care to avoid contact with hot engine coolant or steam. Place a shop towel over the radiator cap and turn the radiator cap counterclockwise a little to let the pressure escape through the vinyl tube. After relieving the steam pressure, remove the radiator cap by slowly turning it counterclockwise.
2. Drain the engine coolant from the radiator, heater core and engine after unplugging the radiator drain plug and removing the radiator cap.
3. Remove the engine room under cover front B (Refer to «UNDER COVER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exterior-body-panels/#under-cover-except-lancer-evolution) .)
4. Disconnect the cooling water line hose and drain the engine coolant in the water jacket.
5. Drain the water in the water jacket by unplugging the drain plug of the cylinder block.
6. Remove the radiator condenser tank and drain the engine coolant.
7. Connect the cooling water line hose.
8. Replace the cylinder block drain plug gasket, and tighten the drain plug to the specified torque. Tightening torque: 39 ± 3 N.m
9. Securely tighten the radiator drain plug.
10. Reinstall the radiator condenser tank. CAUTION: Do not use alcohol or methanol anti-freeze or any engine coolants mixed with alcohol or methanol anti-freeze. The use of an improper anti-freeze can cause corrosion of the aluminum components.
11. Use special tool LLC changer (MB991871) to refill the engine coolant up to the top of the radiator port. Recommended antifreeze: DIA QUEEN SUPER LONG LIFE COOLANT PREMIUM or equivalent* NOTE: *similar high quality ethylene glycol based non-silicate, non-amine, non-nitrate and non-borate coolant with long life hybrid organic acid technology. Quantity: 7.0 dm 3 (7.4 quarts) [includes 0.65 dm 3 (0.63 quarts) in the radiator condenser tank] NOTE: For how to use special tool MB991871, refer to its manufacturer's instructions.
12. Tighten the radiator cap securely.
13. Remove the radiator condenser tank cap, and add the engine coolant up to the "FULL" line.
14. Turn the A/C switch to OFF position to start the engine and warm up until the cooling fan operates. NOTE: This step opens the thermostat fully.
15. Rev the engine several times and then stop it. Check that there are no engine coolant leaks.
16. Remove the radiator cap with the engine cool, and then refill the engine coolant up to the top of the radiator port.
17. Tighten the radiator cap securely. CAUTION: Do not overfill the radiator condenser tank.
18. Remove the radiator condenser tank cap, and add the engine coolant up to the "FULL" line.
19. Reinstall the engine room under cover front A, B (Refer to «UNDER COVER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exterior-body-panels/#under-cover-except-lancer-evolution) .)

INSPECT

Inspect the surface of radiator hoses and heater hoses for heat and mechanical damage. Hard and brittle rubber, cracking, tears, cuts, abrasions and excessive swelling indicate deterioration of the rubber.

BRAKE PAD CHECK

Scheme 78

Scheme 79

1. Visually check the thickness of brake pad from the inspection hole of the caliper body. Standard value: 10.0 mm (0.39 inch) Limit: 2.0 mm (0.08 inch)
2. If the brake pad thickness is less than the limit value, replace the brake pad (Refer to «BRAKE PAD CHECK»(/mitsubishi/lancer-evolution/x-2007-2016/remont/mechanical-hydraulic/#basic-brake-system-except-lancer-evolution__brake-pad-check) ).

Scheme 80

1. Remove contaminants or corrosion from the brake disc surface.
2. Use a micrometer to measure the brake disc thickness at minimum eight points which are 10 mm (0.39 inch) inward from its circumference. Standard value: 26.0 mm (1.02 inches) < Front > 10.0 mm (0.39 inch) < Rear > Limit: 24.4 mm (0.96 inch) < Front > 8.4 mm (0.33 inch) < Rear >
3. If the brake disc thickness is worn beyond the limit value at more than one point, replace the brake disc and check its run-out.

BRAKE DISC RUN-OUT CHECK AND CORRECTION

Place a dial gauge ca. 5 mm (0.2 inch) inward from the circumference of the brake disc to measure its run-out.

Limit

0.06 mm (0.0024 inch) < Front >

0.08 mm (0.0032 inch) < Rear >

Scheme 81

BRAKE LINING THICKNESS CHECK

Scheme 82

1. Remove the brake drum.
2. Measure the thickness of the brake lining at the area with the most wear. Standard value: 4.0 (0.16 inch) Limit: 1.0 mm (0.04 inch)
3. Replace the shoe and lining assembly if the brake lining thickness is less than the limit or if it is not worn evenly. For installation procedures for the shoe and lining assembly, refer to «REAR DRUM BRAKE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/mechanical-hydraulic/#basic-brake-system-except-lancer-evolution) .

Scheme 83

1. Remove the brake drum.
2. Measure the inside diameter of the brake drum at two or more locations. Standard value: 203 mm (8.0 inches) Limit: 205 mm (8.1 inches)
3. Replace the brake drums, shoe and lining assembly when wear exceeds the limit value or is badly imbalanced.

Scheme 84

1. Remove the brake drum.
2. Check if the liquid leaks from around the boot of the wheel cylinder visually or by touching with fingers.

CHECK FOR DETERIORATION OR LEAKS

Inspection of brake hoses should be included in all brake service operations.

The hoses should be checked for

1. Incorrect length, severe surface cracking, pulling, scuffing or worn spots. (If the fabric casing of the hoses is exposed by cracks or abrasion in the rubber hose cover, the hoses should be replaced. Eventual deterioration of the hose and possible bursting failure may occur).
2. Incorrect installation, twisting or interference with wheel, tire or chassis.

Scheme 85

1. These components, which are permanently lubricated at the factory, do not require periodic lubrication. Damaged seals and boots should be replaced to prevent leakage or grease contamination.
2. Inspect the dust cover and boots for proper sealing, leakage and damage, and replace them if defective.

Scheme 86

1. These components, which are permanently lubricated at the factory, do not require periodic lubrication. Damaged seals and boots should be replaced to prevent leakage or grease contamination.
2. Inspect the dust cover and boots for proper sealing, leakage and damage. Replace them if defective.

INSPECT FOR LOOSENESS AND DAMAGE

Visually inspect the front/rear suspension components for deterioration and damage. Re-tighten the front/rear suspension components retaining bolts to specified torque.

ROTATE

Rotate tires regularly to equalize tire wear and help extend tire life. Recommended tire rotation is every 12,000 km (7,500 miles).

Timing for the rotation may vary according to vehicle condition, road surface conditions, and individual driver's habits.

When rotating tires, check for uneven wear, damage, and wheel alignment. Abnormal wear is usually caused by incorrect tire pressure, improper wheel alignment, out-of balance wheels, or severe braking.

The first rotation is the most important, to achieve more uniform wear for all tires on the vehicle.

Scheme 87

Scheme 88

1. Remove the glove box (Refer to «GLOVE BOX»(/mitsubishi/lancer-evolution/x-2007-2016/remont/gauges-instrument-panels/#interior-except-lancer-evolution) ).
2. Loosen the two lugs as shown in figure to replace the clean air filter.
3. Install the glove box.

Check for damage or leakage in the fuel lines and connections.

1. Inspect the surface of fuel hoses for heat and mechanical damage. Hard and brittle rubber, cracking, tears, cuts, abrasions and excessive swelling indicate deterioration of the rubber.
2. If the fabric casing of the rubber hose is exposed by cracks and abrasions in the fuel system, the hoses should be replaced.

The air cleaner element will become dirty during use, reducing its effectiveness. Replace it with a new one.

Replacement of air cleaner element

Scheme 89

1. Unclamp the air cleaner housing.
2. Remove the air cleaner element and install a new one.
3. When clamping the air cleaner housing in place, be sure that the cover is completed closed.

If the fuel-vapor vent line is clogged or damaged, fuel vapor will escape into the atmosphere causing excessive emissions. Disconnect the line at both ends, and blow it clean with compressed air. Remove the fuel tank filler tube cap from the filler tube and check to see if there is evidence that the seal makes improper contact to the filler tube.

1. Spark plugs must spark properly to assure proper engine performance and reduce exhaust emission level. Therefore, they should be replaced periodically with new ones. Spark plug type SPARK PLUG SPECIFICATION Maker Identification No. NGK DILKR7B6
2. The new plugs should be checked for the proper gap. Spark plug gap: 0.5 - 0.6 mm (0.020 - 0.023 inch)
3. Install the spark plugs and tighten to 18 ± 2 N.m (13 ± 1 ft-lb).

Note. Perform the valve clearance check and adjustment at the engine cold state.

Scheme 90

Scheme 91

1. Remove all of the ignition coils.
2. Remove the cylinder head cover. CAUTION: Turn the crankshaft always clockwise.
3. Turn the crankshaft clockwise, and align the timing mark on the exhaust camshaft sprocket against the upper face of the cylinder head as shown in Figure. Therefore, No.1 cylinder goes to the compression top dead center.
4. Using a thickness gauge, measure the valve clearance with the arrow shown in Figure. If deviated from the standard value, make note for the valve clearance. Standard value: Intake valve 0.20 ± 0.03 mm (0.008 ± 0.0012 inch) Exhaust valve 0.30 ± 0.03 mm (0.012 ± 0.0012 inch)
5. Turn the crankshaft clockwise 360 degrees, and put the timing mark on the exhaust camshaft sprocket in position shown in Figure. Therefore, No. 4 cylinder goes to the compression top dead center.
6. Check the valve clearance with the arrow shown in Figure. In the same procedure as 4.
7. If the valve clearance is deviated from the standard value, remove the camshaft and the valve tappet. For the camshaft removal, refer to «REMOVAL AND INSTALLATION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/mechanical/#engine-overhaul-20l-turbo-except-lancer-evolution) < 2.0L Engine Turbo >.
8. Using a micrometer, measure the thickness of the removed valve tappet.
9. Calculate the thickness of the newly installed valve tappet through the following equation. thickness of newly installed valve tappet thickness of removed valve tappet measured valve clearance Equation Intake valve: A = B + [C - 0.20 mm (0.008 inch)] Exhaust valve: A = B + [C - 0.30 mm (0.012 inch)] NOTE: The valve tappet ranges 3,000 - 3,690 mm (0.1181 - 0.1453 inch) and has 47 types per 0.015 mm (0.0006 inch). The thickness below a decimal point is stamped on the reverse side of the valve tappet.
10. Install the valve tappet selected through the procedure 9, and put the camshaft in position. For the camshaft installation, refer to «REMOVAL AND INSTALLATION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/mechanical/#engine-mechanical-20l-turbo-except-lancer-evolution) < 2.0L Engine Turbo >.
11. After installing the timing chain, measure the valve clearance using the procedure 3 to 6. Confirm the clearance is within the standard value. CAUTION: Completely remove all the old FIPG, which might be remaining among the components.
12. After completely removing the liquid gasket adhering on the timing chain case, cylinder block and cylinder head, degrease them with white gasoline. CAUTION: The cylinder head cover should be installed within 3 minutes of applying liquid gasket.
13. Apply a 4 mm bead of liquid gasket as illustrated. Specified sealant: THREE BOND 1217G or equivalent
14. Install the cylinder head cover and tighten the tightening bolts using the following procedures. Temporarily tighten to the following torque in order shown in the illustration. Tightening torque: 3.0 ± 1.0 N.m (27 ± 9 in-lb) Tighten to the specified torque in order shown in the illustration. Specified torque: 5.5 ± 0.5 N.m (49 ± 9 in-lb)
15. Install the ignition coils.

1. Remove the radiator condenser tank mounting bolts.
2. Move the radiator condenser tank to a place where it will not be a hindrance when checking the drive belt tension. CAUTION: Check the drive belt tension after turning the crankshaft clockwise one turn or more.
3. Make sure that the indicator mark on the auto-tensioner is within the area marked with A in the illustration.
4. If the mark is out of the area A, replace the drive belt. (Refer to «REMOVAL SERVICE POINTS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/mechanical/#engine-mechanical-20l-turbo-except-lancer-evolution) ). NOTE: The drive belt tension check is not necessary as the auto-tensioner is adopted.
5. Tighten the radiator condenser tank mounting bolts to the specified torque. Tightening torque: 12 ± 2 N.m (102 ± 22 in-lb)

1. Check for holes and exhaust gas leaks due to damage, corrosion, etc.
2. Check the joints and connections for looseness and exhaust gas leaks.
3. Check the rubber hangers and brackets for damage.

CHANGE

1. Start the engine and allow it to warm up until the temperature of the engine coolant reaches 80 - 90°C (176 - 194°F.) WARNING: Use care as engine oil could be hot.
2. Remove the engine oil filler cap.
3. Remove the engine room under cover extension (Refer to «UNDER COVER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exterior-body-panels/#under-cover-except-lancer-evolution) .)
4. Remove the engine oil pan drain plug to drain engine oil.
5. Install a new engine oil pan drain plug gasket so that it faces in the direction shown in the illustration, and then tighten the engine oil pan drain plug to the specified torque. Tightening torque: 39 ± 5 N.m (29 ± 3 ft-lb) CAUTION: For vehicles with turbocharger, engine oil must be properly maintained to avoid engine and/or turbocharger damage. To better protect your engine and turbocharger, use fully synthetic engine oil.
6. Refill with specified quantity of engine oil. Specified Engine Oil: Engine oils displaying the ILSAC certification symbol ("Starburst" symbol) or conforming to the API classification SM or higher Total quantity (Includes volume inside engine oil filter): 5.1 dm 3 (5.42 quarts) NOTE: Select engine oil of the proper SAE viscosity number according to the atmospheric temperature. NOTE: SAE 0W-30 and 0W-40 engine oil are recommended to use to improve engine startability on a very cold weather condition.
7. Install the engine oil filler cap.
8. Let the engine run for a few minutes.
9. Stop the engine, and then check the engine oil level using the engine oil level gauge after a few minutes.
10. Install the engine room under cover extension (Refer to «UNDER COVER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exterior-body-panels/#under-cover-except-lancer-evolution) .)

The quality of replacement filters varies considerably. Only high quality filters should be used to assure most efficient service. Genuine oil filters require that the filter is capable of withstanding a pressure of 1,765 kPa (256 psi) are high quality filters and are recommended as follows

Mitsubishi Oil Filter Part Number: MD356000 or equivalent

This vehicle is equipped with a full-flow, throw-away oil filter.

The same type of filter is recommended as a replacement filter for this vehicle. It is possible, particularly in cold weather, that this vehicle may develop high oil pressure for a short duration. Make sure that any replacement filter used on this vehicle is a high-quality filter. The filter must withstand a pressure of 1,800 kPa (261 psi) [manufacturer's specifications] to avoid filter and ultimately engine damage. The following is a high-quality filter and is strongly recommended for use on this vehicle: Mitsubishi Engine Oil Filter Part number MD356000.

Any replacement oil filter should be installed in accordance with the oil filter manufacturer's installation instructions.

Scheme 92

1. Start the engine and allow it to warm up until the temperature of the coolant reaches 80 - 90°C (176 - 194°F) WARNING: Use care as oil could be hot.
2. Remove the engine oil filler cap.
3. Remove the engine room under cover extension (Refer to «UNDER COVER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exterior-body-panels/#under-cover-except-lancer-evolution) ).
4. Remove the drain plug to drain oil.
5. Use the respective tool in the following table to remove the engine oil filter. SPECIAL TOOL DESCRIPTION Number Special tool MD356000 MB991610 or equivalent
6. Clean the filter bracket side mounting surface and ensure the old O-ring has been removed.
7. Apply a small amount of engine oil to the O-ring of the new oil filter.
8. Screw on the oil filter by hand until it touches the surface of the flange and then tighten it with an oil filter wrench. SPECIAL TOOL DESCRIPTION Number Special tool Tightening torque MD356000 MB991610 or equivalent Approximately 3/4 turn [14 ± 2 N.m (124 ± 17 in-lb)]
9. Install the drain plug and refill engine oil (Refer to «ON-VEHICLE SERVICE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/lubrication-system/#engine-lubrication-except-lancer-evolution) ).
10. Rev the engine a few times, and check to be sure that no engine oil leaks at the oil filter.
11. Install the engine room under cover extension (Refer to «UNDER COVER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exterior-body-panels/#under-cover-except-lancer-evolution) ).

TRANSMISSION FLUID LEAKAGE CHECK

1. Clean the transaxle exterior, and visually check the transaxle for fluid leaks.
2. If the fluid is leaking from the oil pan or the oil seal, replace the part. If the fluid is leaking from the part other than the oil pan and the oil seal, replace the transaxle assembly.

Scheme 93

Scheme 94

1. Remove the engine room under cover front B assembly. (Refer to «UNDER COVER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exterior-body-panels/#under-cover-except-lancer-evolution) .)
2. Start the engine, and let it run at idle to warm it up for 15 minutes.
3. Move the shift lever to every position (P, R, N, D, manual mode) (Hold for 20 seconds in each position), and then move it to the P range.
4. Stop the engine.
5. Remove the air cleaner element and air cleaner intake duct. (Refer to «AIR CLEANER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exhaust/#engine-intake-system-and-exhaust-system-except-lancer-evolution) .)
6. Remove the filler plug. CAUTION: The drained fluid can be reused if it is between the replacement intervals. < Replacement interval > Normal condition: 96,000 km (60,000 miles) Severe condition: 48,000 km (30,000 miles) When reusing the drained fluid, make sure that no foreign object gets into the fluid.
7. Remove the drain plugs, and leave it for 3 minutes to drain the fluid. NOTE: Because the fluid in the oil cooler, oil filter, and transaxle assembly cannot be drained, the amount of drained fluid will be approximately 5.5 dm 3 (approximately 5.8 quarts).
8. Tighten the drain plugs to the specified torque. Tightening torque: 35 ± 5 N.m (26 ± 4 ft-lb) CAUTION: Measure the drained fluid. If the drained fluid is less than approximately 5.5 dm 3 (approximately 5.8 quarts), add new fluid to make it approximately 5.5 dm 3 (approximately 5.8 quarts).
9. Fill the fluid into the filler plug. Brand name: Dia Queen SSTF-I Filling amount: Approximately 5.5 dm 3 (approximately 5.8 quarts)
10. Tighten the filler plug to the specified torque. Tightening torque: 35 ± 5 N.m (26 ± 4 ft-lb)
11. Install the air cleaner element and air cleaner intake duct. (Refer to «AIR CLEANER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exhaust/#engine-intake-system-and-exhaust-system-except-lancer-evolution) .)
12. Install the engine room under cover front B assembly. (Refer to «UNDER COVER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exterior-body-panels/#under-cover-except-lancer-evolution) .)

TRANSMISSION FLUID CHANGE

1. Remove the engine room under cover front B assembly. (Refer to «UNDER COVER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exterior-body-panels/#under-cover-except-lancer-evolution) .)
2. Start the engine, and let it run at idle to warm it up for 15 minutes.
3. Move the shift lever to every position (P, R, N, D, manual mode) (Hold for 20 seconds in each position), and then move it to the P range.
4. Stop the engine.
5. Remove the air cleaner element and air cleaner intake duct. (Refer to «AIR CLEANER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exhaust/#engine-intake-system-and-exhaust-system-except-lancer-evolution) .)
6. Remove the filler plug.
7. Remove the drain plug, and leave it for 3 minutes to drain the fluid. NOTE: Because the fluid in the oil cooler, oil filter, and transaxle assembly cannot be drained, the amount of drained fluid will be approximately 5.5 dm 3 (approximately 5.8 quarts).
8. Tighten the drain plug to the specified torque. Tightening torque: 35 ± 5 N.m (26 ± 4 ft-lb)
9. Fill the fluid into the filler plug. Brand name: Dia Queen SSTF-I Filling amount: Approximately 5.5 dm 3 (approximately 5.8 quarts)
10. Tighten the filler plug to the specified torque. Tightening torque: 35 ± 5 N.m (26 ± 4 ft-lb)
11. Install the air cleaner element and air cleaner intake duct. (Refer to «AIR CLEANER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exhaust/#engine-intake-system-and-exhaust-system-except-lancer-evolution) .)
12. Install the engine room under cover front B assembly. (Refer to «UNDER COVER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exterior-body-panels/#under-cover-except-lancer-evolution) .)

For information concerning the replacement procedures, refer to REMOVAL SERVICE POINTS .

Scheme 95

Scheme 96

Scheme 97

1. Remove the engine room under cover front B assembly. (Refer to «UNDER COVER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exterior-body-panels/#under-cover-except-lancer-evolution) .)
2. Remove the filler plug and gasket.
3. Check that the oil level is not 14 mm (0.6 inch) below the bottom of the oil filler plug hole.
4. Check that the oil is not excessively foul and has moderate viscosity.
5. If the oil level is not in between the upper limit and the lower limit, refill the specified oil to the bottom of the oil filler plug hole. Brand name: DiaQueen LSD gear oil
6. Install the filler plug and new gasket, then tighten them to the specified torque. Tightening torque: 32 ± 2 N.m (24 ± 1 ft-lb)
7. Install the engine room under cover front B assembly. (Refer to «UNDER COVER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exterior-body-panels/#under-cover-except-lancer-evolution) .)

Scheme 98

1. Remove the engine room under cover front B assembly. (Refer to «UNDER COVER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exterior-body-panels/#under-cover-except-lancer-evolution) .)
2. Remove the drain plug and gasket to drain the oil.
3. Install the drain plug and new gasket, then tighten them to the specified torque. Tightening torque: 32 ± 2 N.m (24 ± 1 ft-lb)
4. Remove the filler plug and gasket, then fill the oil up to the lower edge of the filler plug hole. Brand name: DiaQueen LSD gear oil Quantity: 0.8 dm 3 (0.85 quarts)
5. Install the filler plug and new gasket, then tighten them to the specified torque. Tightening torque: 32 ± 2 N.m (24 ± 1 ft-lb)
6. Install the engine room under cover front B assembly. (Refer to «UNDER COVER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exterior-body-panels/#under-cover-except-lancer-evolution) .)

Scheme 99

1. Remove the trunk room side trim lid on the right of the trunk room.
2. If the vehicle has been run, leave it for 90 min. or more in an ordinary temperature {10 - 30°C (50 - 86°F)} to allow the accumulator internal pressure to drop. NOTE: If the ambient temperature is 10°C (50°F) or less, allow more time to leave the vehicle to stand idle.
3. Check that the oil reservoir fluid level is in between MAX and MIN.
4. If the fluid level is not in between MAX and MIN, fill the specified fluid. Brand name: DIAMOND ATF SP III
5. Install the trunk room side trim lid.

< WHEN THE SCAN TOOL IS USED >

1. Remove the trunk room side trim lid on the right of the trunk room. CAUTION: Turn the ignition switch to the "LOCK (OFF)" position before connecting or disconnecting the scan tool.
2. Set the scan tool to the 16-pin diagnosis connector.
3. Turn the ignition switch to the ON position.
4. Using the scan tool, forcibly activate the hydraulic unit (item No. 03) to reduce the pressure inside the accumulator. NOTE: With the forced activation (oil level check mode), the hydraulic unit direction valve is operated 20 seconds to right and left, and then the operation is cancelled automatically. Also, using the clear key on the scan tool, the activation can be forcibly cancelled. When the functions are suspended by the fail-safe function, the hydraulic unit cannot be forcibly activated.
5. Check that the oil reservoir fluid level is in between MAX and MIN.
6. If the fluid level is not in between MAX and MIN, fill the specified fluid. Brand name: DIAMOND ATF SP III
7. Install the trunk room side trim lid.

Scheme 100

Scheme 101

1. Remove the engine room under cover front A (Refer to «UNDER COVER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exterior-body-panels/#under-cover-except-lancer-evolution) .) WARNING: When removing the radiator cap, use care to avoid contact with hot engine coolant or steam. Place a shop towel over the radiator cap and turn the radiator cap counterclockwise a little to let the pressure escape through the vinyl tube. After relieving the steam pressure, remove the radiator cap by slowly turning it counterclockwise.
2. Drain the engine coolant from the radiator, heater core and engine after unplugging the radiator drain plug and removing the radiator cap.
3. Remove the engine room under cover front B. (Refer to «UNDER COVER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exterior-body-panels/#under-cover-except-lancer-evolution) .)
4. Remove the air cleaner intake hose (Refer to «AIR CLEANER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exhaust/#engine-intake-system-and-exhaust-system-except-lancer-evolution) .)
5. Disconnect the turbocharger water return hose and drain the engine coolant in the water jacket.
6. Remove the radiator condenser tank and drain the engine coolant.
7. Connect the turbocharger water return hose.
8. Reinstall the air cleaner intake hose (Refer to «AIR CLEANER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exhaust/#engine-intake-system-and-exhaust-system-except-lancer-evolution) .)
9. Securely tighten the radiator drain plug.
10. Reinstall the radiator condenser tank. CAUTION: Do not use alcohol or methanol anti-freeze or any engine coolants mixed with alcohol or methanol anti-freeze. The use of an improper anti-freeze can cause corrosion of the aluminum components.
11. Use special tool LLC changer (MB991871) to refill the engine coolant up to the top of the radiator port. Recommended antifreeze: DIA QUEEN SUPER LONG LIFE COOLANT PREMIUM or equivalent* NOTE: *similar high quality ethylene glycol based non-silicate, non-amine, non-nitrate and non-borate coolant with long life hybrid organic acid technology. Quantity: 7.5 dm 3 (7.9 quarts) [includes 0.65 dm 3 (0.63 quarts) in the radiator condenser tank] NOTE: For how to use special tool MB991871, refer to its manufacturer's instructions.
12. Tighten the radiator cap securely.
13. Remove the radiator condenser tank cap, and add the engine coolant up to the "FULL" line.
14. Turn the A/C switch to OFF position to start the engine and warm up until the cooling fan operates. NOTE: This step opens the thermostat fully.
15. Rev the engine several times and then stop it. Check that there are no engine coolant leaks.
16. Remove the radiator cap with the engine cool, and then refill the engine coolant up to the top of the radiator port.
17. Tighten the radiator cap securely. CAUTION: Do not overfill the radiator condenser tank.
18. Remove the radiator condenser tank cap, and add the engine coolant up to the "FULL" line.
19. Reinstall the engine room under cover front A, B (Refer to «UNDER COVER»(/mitsubishi/lancer-evolution/x-2007-2016/remont/exterior-body-panels/#under-cover-except-lancer-evolution) .)

Inspect the surface of radiator hoses and heater hoses for heat and mechanical damage. Hard and brittle rubber, cracking, tears, cuts, abrasions and excessive swelling indicate deterioration of the rubber.

BRAKE PADS CHECK

Scheme 102

Scheme 103

1. Visually check the thickness of brake pad from the inspection hole of the caliper body. Standard value: 10.0 mm (0.39 inch) Limit: 2.0 mm (0.08 inch)
2. If the brake pad thickness is less than the limit value, replace the brake pad (Refer to «BRAKE PAD REPLACEMENT < RALLIART >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/mechanical-hydraulic/#basic-brake-system-except-lancer-evolution) ).

BRAKE DISC THICKNESS CHECK

1. Remove contaminants or corrosion from the brake disc surface.
2. Use a micrometer to measure the brake disc thickness at minimum eight points which are 10 mm (0.39 inch) inward from its circumference. Standard value: 24.0 mm (0.94 inch) < Front > 10.0 mm (0.39 inch) < Rear > 22.4 mm (0.88 inch) < Front > 8.4 mm (0.33 inch) < Rear >
3. If the brake disc thickness is worn beyond the limit value at more than one point, replace the brake disc and check its run-out.

Place a dial gauge ca. 5 mm (0.2 inch) inward from the circumference of the brake disc to measure its run-out.

Limit

0.06 mm (0.0024 inch) < Front >

0.08 mm (0.0032 inch) < Rear >

Inspection of brake hoses should be included in all brake service operations.

The hoses should be checked for

Scheme 104

1. Incorrect length, severe surface cracking, pulling, scuffing or worn spots. (If the fabric casing of the hoses is exposed by cracks or abrasion in the rubber hose cover, the hoses should be replaced. Eventual deterioration of the hose and possible bursting failure may occur).
2. Incorrect installation, twisting or interference with wheel, tire or chassis.

INSPECT FOR GREASE LEAKS AND DAMAGE

1. These components, which are permanently lubricated at the factory, do not require periodic lubrication. Damaged seals and boots should be replaced to prevent leakage or grease contamination.
2. Inspect the dust cover and boots for proper sealing, leakage and damage, and replace them if defective.

1. These components, which are permanently lubricated at the factory, do not require periodic lubrication. Damaged seals and boots should be replaced to prevent leakage or grease contamination.
2. Inspect the dust cover and boots for proper sealing, leakage and damage. Replace them if defective.

Visually inspect the front/rear suspension components for deterioration and damage. Re-tighten the front/rear suspension components retaining bolts to specified torque.

1. Remove the filler plug.
2. Remove the drain plug and drain oil.
3. Tighten the drain plug to the specified torque. Tightening torque: 64 ± 4 N.m (47 ± 2 ft-lb)
4. Add the oil until the level comes to the lower portion of the filler plug hole. Specified gear oil: MITSUBISHI Genuine DIA QUEEN LSD gear oil
5. Tighten the filler plug to the specified torque. Tightening torque: 49 ± 9 N.m (36 ± 6 ft-lb)

Rotate tires regularly to equalize tire wear and help extend tire life. Recommended tire rotation is every 12,000 km (7,500 miles).

Timing for the rotation may vary according to vehicle condition, road surface conditions, and individual driver's habits.

When rotating tires, check for uneven wear, damage, and wheel alignment. Abnormal wear is usually caused by incorrect tire pressure, improper wheel alignment, out-of balance wheels, or severe braking.

The first rotation is the most important, to achieve more uniform wear for all tires on the vehicle.

Scheme 105

1. Remove the glove box (Refer to «GLOVE BOX»(/mitsubishi/lancer-evolution/x-2007-2016/remont/gauges-instrument-panels/#interior-except-lancer-evolution) ).
2. Loosen the two lugs as shown in figure to replace the clean air filter.
3. Install the glove box.

MAIN SEALANT AND ADHESIVE TABLE

SEALANT AND ADHESIVE SPECIFICATION

See also:
• HARNESS CONNECTOR INSPECTION
• GENERAL INFORMATION
• FLOOR CONSOLE ASSEMBLY
• ID CODE REGISTRATION JUDGMENT TABLE
• ID CODE REGISTRATION JUDGMENT TABLE
• REMOVAL AND INSTALLATION
• REMOVAL AND INSTALLATION
• REMOVAL AND INSTALLATION
• TRANSAXLE ASSEMBLY
• REMOVAL AND INSTALLATION
• TIMING CHAIN ELONGATION VISUAL CHECK
• REMOVAL AND INSTALLATION
• REMOVAL AND INSTALLATION
• REMOVAL AND INSTALLATION
• REMOVAL AND INSTALLATION
• UNDER COVER
• SPECIAL TOOLS
• BRAKE DISC CHECK
• BRAKE PAD CHECK
• REMOVAL AND INSTALLATION
• REMOVAL AND INSTALLATION
• ON-VEHICLE SERVICE
• AIR CLEANER
• TIGHTENING TORQUE
• HOW TO USE THE INSPECTION PROCEDURES
• INSPECTION SERVICE POINTS FOR A BLOWN FUSE
• HOW TO COPE WITH INTERMITTENT MALFUNCTION
• OPTION CODING
• ENGINE IDLING LEARNING PROCEDURE
