Scheme 1

Scheme 1: GENERAL INFORMATION

As for headlight assembly, a type with halogen bulbs for the high-beam and low-beam and a type with a discharge bulb for both high-beam and low-beam are established.
The halogen bulb type headlight assembly employs the four-light type integrated with the headlight (low-beam), headlight (high-beam), front turn-signal light, and position light. The dimmed headlight (low-beam) is also used as a daytime running light.
For the discharge bulb type headlight assembly, the headlight assembly with two headlights has been adopted which incorporates the projector type headlight (low-beam/high-beam), daytime running light, front turn-signal light, and position light. Also, the headlight manual leveling system has been adopted. The switching of headlight (low-beam/high-beam) is performed by the driving of light-shield in the projector unit using the signal from lighting switch.

SERVICE SPECIFICATIONS

Item			Standard value	Limit
Headlight aiming [at 7.62 m (25.0 ft.)]	Low-beam < Vehicles without discharge headlight >	Vertical direction	Horizontal line (H) ± 50.5 mm (± 2.0 inches) (± 0.38 degrees angle)
	Low-beam < Vehicles without discharge headlight >	Horizontal direction	± 126.4 mm (± 5.0 inches) (± 0.95 degrees angle) from the axis, which is 266.1 mm (10.5 inches) (2 degrees angle) rightward from the vertical line (V)
	Low-beam < Vehicles with discharge headlight >	Vertical direction	53.2 mm (2.1 inches) (0.4 degrees) below horizontal line (H). ± 50.5 mm (± 2.0 inches) (± 0.38 degrees angle)
	Low-beam < Vehicles with discharge headlight >	Horizontal direction	Elbow point intersects the vertical line (V). ± 126.4 mm (± 5.0 inches) (± 0.95 degrees angle)
Headlight intensity cd (at high-beam)				40,000 or more {when a screen is set 18.3m (60 ft.) ahead of the vehicle}

SERVICE SPECIFICATIONS

PRECAUTIONS ON HOW TO USE THE HEADLIGHT ASSEMBLY

Be careful with the following items as resin lenses are used in the headlight assembly.

Don't illuminate the headlight for three minutes or more when the headlight is covered with scratch protector.
Don't tape the outer lens.
Don't scratch the outer lens surface with a sharp edged special tool.
Use the specified genuine bulb.

SPECIAL TOOLS

SPECIAL TOOLS Tool Tool number and name Supersession Application MB991958 MB991824 MB991827 MB991910 MB991911 MB991914 MB991825 MB991826 M.U.T.-III sub-assembly Vehicle communication interface (V.C.I.) M.U.T.-III USB cable M.U.T.-III main harness A (Vehicles with CAN communication system) M.U.T.-III main harness B (Vehicles without CAN communication system) M.U.T.-III main harness C (for Chrysler models only) M.U.T.-III measurement adapter M.U.T.-III trigger harness MB991824-KIT NOTE: G: MB991826 M.U.T.-III Trigger Harness is not necessary when pushing V.C.I. ENTER key. CAUTION: M.U.T.-III main harness A (MB991910) should be used. M.U.T.-III main harness B and C should not be used for this vehicle. DTC, data list and actuator test check. MB991223 MB991219 MB991220 MB991221 MB991222 Harness set Check harness LED harness LED harness adapter Probe General service tool (jumper) Continuity check and voltage measurement at harness wire or connector For checking connector pin contact pressure For checking power supply circuit For checking power supply circuit For connecting a locally sourced tester MB992006 Extra fine probe - Continuity check and voltage measurement at harness wire or connector

Scheme 2

Scheme 2: SPECIAL TOOLS

Scheme 3

SERVICE PRECAUTIONS < DISCHARGE HEADLIGHT >

Before checking the discharge headlight related parts, be sure to read the following warnings and precautions carefully, and then perform necessary operations.

WARNING

Do not touch the socket and the connector while the headlights are on. High voltage is applied to the bulb socket and connector during headlight operation. The operator may be burnt or dead due to an electric shock by high voltage. Do not attempt to use a tester to check them. If the bulb socket and connectors should be inspected using a tester, the operator may be burnt or dead due to an electric shock by high voltage. Do not turn ON the headlights while the controller or the bulb is removed. If the headlights are turned ON with the controller or bulb removed, the operator may get burned by the high temperature of the bulb. The operator may be burnt or dead due to an electric shock by high voltage. Before service work, turn the lighting switch OFF and disconnect the battery terminal and the controller connector in a dry place. Do not touch the components with wet hands. If you work on the components with wet hands or in wet conditions, the operator may be burnt or dead due to an electric shock by high voltage.

WARNING

Do not illuminate the bare headlight bulb. (Do not illuminate the headlight using other than the vehicle power supply.) If the headlight bulb illuminates without fitting it in the headlight unit, it may burst due to rise in its internal pressure.

CAUTION

When reusing the controller with the discharge headlight damaged, observe the inspection procedures for the related parts of the discharge headlight before determining the reusability of the controller. If you fail to observe "How to check discharge headlight components," the vehicle may be damaged.

1 - 1 VISUAL CHECK OF CONTROLLER (CASE)

If any of the check items below are found, replace the controller.

Items to be checked	Why the controller should be replaced
Obvious deformation (warping, twisting, dents, nicks, chipped edges) of controller case	The printed circuit board or the element(s) may be cracked
Damaged connector (chipped or cracked plastics, or deformed terminal)	The damaged part(s) may cause poor connection or short circuit.

CONTROLLER CHECK ITEM REFERENCE

1 - 2 CHECK OF WIRING HARNESS BETWEEN CONTROLLER AND BULB

If any of the check items below are found, replace the wiring harness between the controller and the bulb.

WARNING

If the wiring harness between the controller and the bulb is damaged, always replace it. Attempting to repair the wiring harness may cause a melted harness wire, or may result in a burn or death due to an electric shock by high voltage.

Items to be checked	Why the controller should be replaced
Wiring harness shield damaged	Abnormal noise may cause.
Damaged connector (chipped or cracked plastics, or deformed terminal)	The damaged part(s) may cause poor connection or short circuit.

WIRING HARNESS CHECK REFERENCE

1 - 3 CHECK OF CONTROLLER OPERATION

If any of the abnormalities below are found, replace the controller.

Note. Ensure that the headlight control system and its circuit (power supply control at engine start and during steady illumination, high-voltage generating circuit, etc.) are working normally. Then, check whether any internal breakage has occurred in the controller. However, some internal breakage may not be found.

Check item (Check of illumination operation)
With the headlight bulb in the cold state (with the light turned off for 10 minutes or more) and in warm state (after the light is illuminated for 15 minutes or more, it is turned off for 1 minute), turn ON and OFF the headlight several times, and then check that the headlight illuminates without fail.
Observe the headlights until they illuminate steadily (approximately 5 minutes after switching them on). Check that the headlights do not flash or flicker.
Turn on the headlights for 30 minutes. Check that the brightness is the same between right and left lights.
Turn on the headlights for 30 minutes. Check that the headlights do not flash or flicker for 30 minutes.

CONTROLLER OPERATION REFERENCE

2. Troubleshooting procedure for discharge headlight (diagnostic procedure for malfunctions)

Check that the connectors are connected securely and the fuse has not been blown.
Before troubleshooting, read through the "SYMPTOM CHART" to understand what and how you should do. Follow all the procedures carefully.
The components should be checked with their connectors disconnected.

SYMPTOM CHART

Item to be checked	Trouble symptom
Item to be checked	The headlights do not illuminate.	The headlights flicker.	The headlights are dim.
Fuse	1
Wiring harness and connector	2	1
Column switch	3
Bulb	4	2	1
Controller	5	3	2
ETACS-ECU	6	4

SYMPTOM CHART

Note. The numbers indicate the sequence in which the component is checked. For the troubleshooting of other than the above, refer to TROUBLE SYMPTOM CHART . If ETACS-ECU fails, only the low-beam headlights will illuminate as a fail-safe measure.

STANDARD FLOW OF DIAGNOSTIC TROUBLESHOOTING

Refer to TROUBLESHOOTING CONTENTS .

HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)

Required Special Tools

MB991958: Scan Tool (M.U.T.-III Sub Assembly)

MB991824: Vehicle Communication Interface (V.C.I.)
MB991827: M.U.T.-III USB Cable
MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)

CAUTION

To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958.

Scheme 4

Ensure that the ignition switch is at the "LOCK" (OFF) position.
Start up the personal computer.
Connect special tool MB991827 to special tool MB991824 and the personal computer.
Connect special tool MB991910 to special tool MB991824.
Connect special tool MB991910 to the data link connector.
Turn the power switch of special tool MB991824 to the "ON" position. NOTE: When special tool MB991824 is energized, special tool MB991824 indicator light will be illuminated in a green color.
Start the M.U.T.-III system on the personal computer. NOTE: Disconnecting scan tool MB991958 is the reverse of the connecting sequence, making sure that the ignition switch is at the "LOCK" (OFF) position.

HOW TO READ AND ERASE DIAGNOSTIC TROUBLE CODES

Required Special Tools

MB991958: Scan Tool (M.U.T.-III Sub Assembly)

MB991824: Vehicle Communication Interface (V.C.I.)
MB991827: M.U.T.-III USB Cable
MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)

CAUTION

To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958.

Note. If the battery voltage is low, diagnostic trouble codes will not be set. Check the battery if scan tool MB991958 does not display.

Connect scan tool MB991958 to the data link connector.
Turn the ignition switch to the "ON" position.
Select "System select" from the start-up screen.
Select "From 2006 MY" of "Model Year." When the "Vehicle Information" is displayed, check the contents.
Select "ETACS" from "System List", and press the "OK" button. NOTE: When the "Loading Option Setup" list is displayed, check the applicable item.
Select "Diagnostic Trouble Code." to read the DTC.
If a DTC is set, it is shown.
Choose "Erase DTCs" to erase the DTC.

DIAGNOSTIC TROUBLE CODE CHART

CAUTION

On troubleshooting, if the ignition switch is turned ON while disconnecting connector(s), diagnostic trouble code(s) associated with other system may be set. On completion, confirm all systems for diagnostic trouble code(s). If diagnostic trouble code(s) are set, erase them all.

DTC No.	Diagnostic item
B16A2	Blown turn-signal light (LH) bulb
B16A3	Turn-signal light (LH) short circuit
B16A4	Blown turn-signal light (RH) bulb
B16A5	Turn-signal light (RH) short circuit

DIAGNOSTIC TROUBLE CODE CHART - ETACS-ECU

DTC No.	Diagnostic item
L0432	RLS (1) RS adaptation error
L0434	RLS (1) light sensor error
L0436	RLS (1) rain sensor error
(1) Rain light sensor (Lighting control sensor)

(1)	Rain light sensor (Lighting control sensor)

DIAGNOSTIC TROUBLE CODE CHART - LIN

Scheme 5

Scheme 5: < LANCER >

Scheme 6

Scheme 6: < LANCER SPORTBACK >

TROUBLE JUDGMENT

When the left bulb of turn-signal light is blown, the ETACS-ECU sets DTC B16A2.

TECHNICAL DESCRIPTION (COMMENT)

The ETACS-ECU sets DTC B16A2 under the following conditions.

If there is a malfunction to the left turn-signal light bulb, the blown left bulb counter counts once when the illumination of hazard or turn-signal light (left side) is attempted.
After the bulb counter reaches "3," DTC B16A2 is set.

TROUBLESHOOTING HINTS

Malfunction of turn-signal light bulb (left)
Malfunction of the ETACS-ECU
The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector

DIAGNOSIS

Required Special Tools

MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)

Scheme 7

Scheme 8

Scheme 9

Scheme 10

STEP 1. Bulb check. Check whether the left turn-signal light illuminates normally. Q: Is the check result normal? YES: Go to Step 2. NO: Replace the bulb of turn-signal light which does not illuminate.
STEP 2. Check headlight assembly (LH) connector A-31 < front >, side turn-signal light (LH) connector A-08 < side >, rear combination light (LH) connector F-20 < LANCER (rear) >, rear turn-signal light (RH) connector F-39 < LANCER SPORTBACK (rear) > for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Are headlight assembly (LH) connector A-31 < front >, side turn-signal light (LH) connector A-08 < side >, rear combination light (LH) connector F-20 < LANCER (rear) >, rear turn-signal light (RH) connector F-39 < LANCER SPORTBACK (rear) > in good condition? YES: Go to Step 3. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) .
STEP 3. Resistance measurement at headlight assembly (LH) connector A-31 < front >, side turn-signal light (LH) connector A-08 < side >, and rear combination light (LH) connector F-20 < LANCER (rear) >, rear turn-signal light (RH) connector F-39 < LANCER SPORTBACK (rear) >. Disconnect the connector, and measure at the wiring harness side. Measure the resistance between the connector terminal of light which does not illuminate and ground. Measure the resistance between the headlight assembly (LH) connector A-31 (terminal 6) and body ground. < Front > Measure the resistance between side turn-signal light (LH) connector A-08 (terminal 1) and body ground. < Side > Measure the resistance between rear combination light (LH) connector F-20 (terminal 1) and body ground. < LANCER (Rear) > Measure the resistance between rear turn-signal light (LH) connector F-39 (terminal 1) and body ground. < LANCER SPORTBACK (Rear) > OK: The measured value should be continuity exists (2 ohms or less). Q: Does the measured resistance value correspond with this range? YES: Go to Step 5 . NO: Go to Step 4.
STEP 4. Check the wiring harness between headlight assembly (LH) connector A-31 (terminal 6) < front >, side turn-signal light (LH) connector A-08 (terminal 1) < side >, rear combination light (LH) connector F-20 (terminal 1) < LANCER (rear) >, rear turn-signal light (LH) connector F-39 (terminal 1) < LANCER SPORTBACK (rear) > and ground. Check the ground wires for open circuit. Q: Are the wiring harness between headlight assembly (LH) connector A-31 (terminal 6) < front >, side turn-signal light (LH) connector A-08 (terminal 1) < side >, rear combination light (LH) connector F-20 (terminal 1) < LANCER (rear) >, rear turn-signal light (LH) connector F-39 (terminal 1) < LANCER SPORTBACK (rear) > and ground in good condition? YES: Go to Step 7 . NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Verify that the headlights illuminate normally.
STEP 5. Check ETACS-ECU connectors C-304 and C-311 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Are ETACS-ECU connectors C-304 < front or side > and C-311 < rear > in good condition? YES: Go to Step 6. NO: Replace the bulb(s) of the light that does not illuminate.
STEP 6. Check the wiring harness between headlight assembly (LH) connector A-31 (terminal 3) < front >, side turn-signal light (LH) connector A-08 (terminal 2) < side >, rear combination light (LH) connector F-20 (terminal 2) < LANCER (rear) >, rear turn-signal light (LH) connector F-39 (terminal 2) < LANCER SPORTBACK (rear) > and ETACS-ECU connector C-304 (terminal 9) < front or side > or C-311 (terminal 18) < rear >. NOTE: Also check intermediate connector D-14 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector D-14 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Check the power supply line for open circuit. Q: Are the wiring harness between headlight assembly (LH) connector A-31 (terminal 3) < front >, side turn-signal light (LH) connector A-08 (terminal 2) < side >, rear combination light (LH) connector F-20 (terminal 2) < LANCER (rear) >, rear turn-signal light (LH) connector F-39 (terminal 2) < LANCER SPORTBACK (rear) > and ETACS-ECU connector C-304 (terminal 9) < front or side > or C-311 (terminal 18) < rear > in good condition? YES: Go to Step 7. NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Verify that the headlights illuminate normally.
STEP 7. Using scan tool MB991958, Check whether the diagnostic trouble code is reset. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check whether the ETACS-ECU DTC is set. Q: Is the DTC set? YES: Replace the ETACS-ECU. NO: The procedure is complete.

Scheme 11

Scheme 11: < LANCER SPORTBACK >

When the left wiring harness of turn-signal light is short circuited, the ETACS-ECU sets DTC B16A3.

When the short circuit is detected three times consecutively, the ETACS-ECU sets the DTC B16A3.

The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector
Malfunction of the ETACS-ECU

Required Special Tools

MB992006: Extra fine probe
MB991223: Harness set
MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)

STEP 1. Check headlight assembly (LH) connector A-31 < front >, side turn-signal light (LH) connector A-08 < side >, rear combination light (LH) connector F-20 < LANCER (rear) >, rear turn-signal light (RH) connector F-39 < LANCER SPORTBACK (rear) > for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Are headlight assembly (LH) connector A-31 < front >, side turn-signal light (LH) connector A-08 < side >, rear combination light (LH) connector F-20 < LANCER (rear) >, rear turn-signal light (RH) connector F-39 < LANCER SPORTBACK (rear) > in good condition? YES: Go to Step 2. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) .
STEP 2. Check ETACS-ECU connectors C-304 and C-311 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Are ETACS-ECU connectors C-304 < front or side > and C-311 < rear > in good condition? YES: Go to Step 3. NO: Replace the bulb(s) of the light that does not illuminate.
STEP 3. Check the wiring harness between headlight assembly (LH) connector A-31 (terminal 3) < front >, side turn-signal light (LH) connector A-08 (terminal 2) < side >, rear combination light (LH) connector F-20 (terminal 2) < LANCER (rear) >, rear turn-signal light (LH) connector F-39 (terminal 2) < LANCER SPORTBACK (rear) > and ETACS-ECU connector C-304 (terminal 9) < front or side > or C-311 (terminal 18) < rear >. NOTE: Also check intermediate connector D-14 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector D-14 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Check the power supply line for short circuit. Q: Are the wiring harness between headlight assembly (LH) connector A-31 (terminal 3) < front >, side turn-signal light (LH) connector A-08 (terminal 2) < side >, rear combination light (LH) connector F-20 (terminal 2) < LANCER (rear) >, rear turn-signal light (LH) connector F-39 (terminal 2) < LANCER SPORTBACK (rear) > and ETACS-ECU connector C-304 (terminal 9) < front or side > or C-311 (terminal 18) < rear > in good condition? YES: Go to Step 4. NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Verify that the headlights illuminate normally.
STEP 4. Using scan tool MB991958, Check whether the diagnostic trouble code is reset. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Q: Is the DTC set? YES: Replace the ETACS-ECU. NO: The procedure is complete.

Scheme 12

Scheme 12: < LANCER >

Scheme 13

Scheme 13: < LANCER SPORTBACK >

DIAGNOSTIC FUNCTION

When the right bulb of turn-signal light is blown, the ETACS-ECU sets DTC B16A4.

The ETACS-ECU sets DTC B16A4 under the following conditions.

If there is a malfunction to the right turn-signal light bulb, the blown right bulb counter counts once when the illumination of hazard or turn-signal light (right side) is attempted.
If the blown right bulb counter reaches "3," the DTC B16A4 is set.

Malfunction of turn-signal light bulb (right side)
Malfunction of the ETACS-ECU
The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector

Required Special Tools

MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)

Scheme 14

Scheme 15

Scheme 16

Scheme 17

STEP 1. Bulb check. Check whether the bulb of turn-signal light which does not illuminate is normal. Q: Is the check result normal? YES: Go to Step 2. NO: Replace the bulb of turn-signal light which does not illuminate.
STEP 2. Check headlight assembly (RH) connector A-47 < front >, side turn-signal light (RH) connector A-01 < side >, rear combination light (RH) connector F-06 < LANCER (rear) >, rear turn-signal light (RH) connector F-36 < LANCER SPORTBACK (rear) > for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Are headlight assembly (RH) connector A-47 < front >, side turn-signal light (RH) connector A-01 < side >, rear combination light (RH) connector F-06 < LANCER (rear) >, rear turn-signal light (RH) connector F-36 < LANCER SPORTBACK (rear) > in good condition? YES: Go to Step 3. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) .
STEP 3. Resistance measurement at headlight assembly (RH) connector A-47 < front >, side turn-signal light (RH) connector A-01 < side >, rear combination light (RH) connector F-06 < LANCER (rear) >, and rear turn-signal light (RH) connector F-36 < LANCER SPORTBACK (rear) >. Disconnect the connector, and measure at the wiring harness side. Measure the resistance between the connector terminal of light which does not illuminate and body ground. Measure the resistance between the headlight assembly (RH) connector A-47 (terminal 6) and body ground. < Front > Measure the resistance between the side turn-signal light (RH) connector A-01 (terminal 1) and body ground. < side > Measure the resistance between the rear combination light (RH) connector F-06 (terminal 1) and body ground. < LANCER (rear) > Measure the resistance between the rear turn-signal light (RH) connector F-36 (terminal 1) and body ground. < LANCER SPORTBACK (rear) > OK: The measured value should be continuity exists (2 ohm or less). Q: Does the measured resistance value correspond with this range? YES: Go to Step 5 . NO: Go to Step 4.
STEP 4. Check the wiring harness between headlight assembly (RH) connector A-47 (terminal 6) < front >, side turn-signal light (RH) connector A-01 (terminal 1) < side >, rear combination light (RH) connector F-06 (terminal 1) < LANCER (rear) >, rear turn-signal light (RH) connector F-36 (terminal 1) < LANCER SPORTBACK (rear) > and ground. Check the ground wires for open circuit. Q: Are the wiring harness between headlight assembly (RH) connector A-47 (terminal 6) < front >, side turn-signal light (RH) connector A-01 (terminal 1) < side >, rear combination light (RH) connector F-06 (terminal 1) < LANCER (rear) >, rear turn-signal light (RH) connector F-36 (terminal 1) < LANCER SPORTBACK (rear) > and ground in good condition? YES: Go to Step 7 . NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary.
STEP 5. Check ETACS-ECU connectors C-304 and C-311 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Are ETACS-ECU connectors C-304 and C-311 in good condition? YES: Go to Step 6. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) .
STEP 6. Check the wiring harness between headlight assembly (RH) connector A-47 (terminal 3) < front >, side turn-signal light (RH) connector A-01 (terminal 2) < side >, rear combination light (RH) connector F-06 (terminal 2) < LANCER (rear) >, rear turn-signal light (RH) connector F-36 (terminal 2) < LANCER SPORTBACK (rear) > and ETACS-ECU connector C-304 (terminal 16) < front or side > or C-311 (terminal 19) < rear >. NOTE: Also check intermediate connector D-11 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector D-11 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Check the power supply line for open circuit. Q: Are the wiring harness between headlight assembly (RH) connector A-47 (terminal 3) < front >, side turn-signal light (RH) connector A-01 (terminal 2) < side >, rear combination light (RH) connector F-06 (terminal 2) < LANCER (rear) >, rear turn-signal light (RH) connector F-36 (terminal 2) < LANCER SPORTBACK (rear) > and ETACS-ECU connector C-304 (terminal 16) < front or side > or C-311 (terminal 19) < rear > in good condition? YES: Go to Step 7. NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary.
STEP 7. Using scan tool MB991958, Check whether the diagnostic trouble code is reset. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Q: Is the DTC set? YES: Replace the ETACS-ECU. NO: The procedure is complete.

Scheme 18

Scheme 18: < LANCER SPORTBACK >

When the right wiring harness of turn-signal light is short circuited, the ETACS-ECU sets DTC B16A5.

When the short circuit is detected three times consecutively, the ETACS-ECU sets the DTC B16A5.

The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector
Malfunction of the ETACS-ECU

Required Special Tools

MB992006: Extra fine probe
MB991223: Harness set
MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)

STEP 1. Check headlight assembly (RH) connector A-47 < front >, side turn-signal light (RH) connector A-01 < side >, rear combination light (RH) connector F-06 < LANCER (rear) >, rear turn-signal light (RH) connector F-36 < LANCER SPORTBACK (rear) > for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Are headlight assembly (RH) connector A-47 < front >, side turn-signal light (RH) connector A-01 < side >, rear combination light (RH) connector F-06 < LANCER (rear) >, rear turn-signal light (RH) connector F-36 < LANCER SPORTBACK (rear) > in good condition? YES: Go to Step 2. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) .
STEP 2. Check ETACS-ECU connectors C-304 and C-311 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Are ETACS-ECU connectors C-304 and C-311 in good condition? YES: Go to Step 3. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) .
STEP 3. Check the wiring harness between headlight assembly (RH) connector A-47 (terminal 3) < front >, side turn-signal light (RH) connector A-01 (terminal 2) < side >, rear combination light (RH) connector F-06 (terminal 2) < LANCER (rear) >, rear turn-signal light (RH) connector F-36 (terminal 2) < LANCER SPORTBACK (rear) > and ETACS-ECU connector C-304 (terminal 16) < front or side > or C-311 (terminal 19) < rear >. NOTE: Also check intermediate connector D-11 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector D-11 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Check the power supply line for short circuit. Q: Are the wiring harness between headlight assembly (RH) connector A-47 (terminal 3) < front >, side turn-signal light (RH) connector A-01 (terminal 2) < side >, rear combination light (RH) connector F-06 (terminal 2) < LANCER (rear) >, rear turn-signal light (RH) connector F-36 (terminal 2) < LANCER SPORTBACK (rear) > and ETACS-ECU connector C-304 (terminal 16) < front or side > or C-311 (terminal 19) < rear > in good condition? YES: Go to Step 4. NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary.
STEP 4. Using scan tool MB991958, Check whether the diagnostic trouble code is reset. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Erase the DTC. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Q: Is the DTC set? YES: Replace the ETACS-ECU. NO: The procedure is complete.

When the lighting control sensor is installed with the wrong procedure, DTC L0432 is stored by LIN.

The lighting control sensor may have been installed with the wrong procedure.

Incorrect installation procedure: Connect the connector before mounting the lighting control sensor onto the optical coupler of the windshield.
Correct installation procedure: Mount the lighting control sensor onto the optical coupler of the windshield. Wipe the windshield surface thoroughly, and check that the surface is dry. Then, connect the connector.

Lighting control sensor improperly installed
Lighting control sensor (rain sensor) abnormal operation

Required Special Tools

MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)

STEP 1. Using scan tool MB991958, Check whether the diagnostic trouble code is reset. Disconnect the connector from the lighting control sensor, and connect the connector to the lighting control sensor again. Then, check again if the DTC is set to LIN. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__how-to-connect-the-scan-tool) ." Disconnect the connector of lighting control sensor, and connect it again. NOTE: When connecting the connector, follow the correct installation procedure. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Q: Is the DTC set? YES: Go to Step 2. NO: The lighting control sensor is installed with the wrong procedure.
STEP 2. Lighting control sensor installation surface check Visually check the presence of scratches or air bubbles < diameter of 5 mm (0.2 inch) or more > on the windshield to which the lighting control sensor is installed. In addition, visually check that the optical coupler is not broken and that the lighting control sensor can be installed. Q: Is the check result normal? YES: Go to Step 3. NO: Replace the windshield (Refer to «WINDSHIELD»(/mitsubishi/lancer-evolution/x-2007-2016/remont/windows/#window-glass-except-lancer-evolution) )
STEP 3. Using scan tool MB991958, Check whether the diagnostic trouble code is reset. Check again if the DTC is set to LIN. Wipe the windshield surface of the lighting control sensor section thoroughly, and check that the surface is dry. Then, perform the lighting control sensor (rain sensor) adaptation. < Refer to «LIGHTING CONTROL SENSOR (RAIN SENSOR) ADAPTATION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/wiperwasher-systems/#windshield-wiper-system-and-washer-system-except-lancer-evolution__lighting-control-sensor-rain-sensor-adaptation) >. Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Check if DTC is set. Q: Is the DTC set? YES: Replace the lighting control sensor. NO: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ).

If a trouble occurs in the lighting control sensor, DTC L0434 and L0436 are stored to LIN.

Malfunction of the lighting control sensor

Required Special Tools

MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)

Using scan tool MB991958, Check whether the diagnostic trouble code is reset.

Check again if the DTC is set to LIN.

CAUTION

To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958.

Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__how-to-connect-the-scan-tool) ."
Erase the DTC.
Turn the ignition switch from "LOCK" (OFF) position to "ON" position.
Check if DTC is set. Q: Is the DTC set? YES: Replace the lighting control sensor. NO: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ).

TROUBLE SYMPTOM CHART

Trouble symptom			Inspection Procedure No.	Reference
Headlight and taillight	None of headlights (low-beam) illuminates.		1	INSPECTION PROCEDURE 1: NONE OF HEADLIGHTS (LOW-BEAM) ILLUMINATES.
	None of headlights (high-beam) illuminates.		2	INSPECTION PROCEDURE 2: NONE OF HEADLIGHTS (HIGH-BEAM) ILLUMINATES.
	The headlights illuminate at low-beam (high-beam does not illuminate) regardless of the lighting switch positions.		3	INSPECTION PROCEDURE 3: THE HEADLIGHTS ILLUMINATE AT LOW-BEAM (HIGH-BEAM DOES NOT ILLUMINATE) REGARDLESS OF THE LIGHTING SWITCH POSITIONS.
	Headlights do not illuminate when the passing switch is operated.		4	INSPECTION PROCEDURE 4: HEADLIGHTS DO NOT ILLUMINATE WHEN THE PASSING SWITCH IS OPERATED.
	One of the headlights does not illuminate.		5	INSPECTION PROCEDURE 5: ONE OF THE HEADLIGHT(S) DOES NOT ILLUMINATE.
	High-beam indicator light does not illuminate normally.		6	INSPECTION PROCEDURE 6: HIGH-BEAM INDICATOR LIGHT DOES NOT ILLUMINATE NORMALLY.
	The headlight automatic shutdown function does not work normally.		7	INSPECTION PROCEDURE 7: THE HEADLIGHT AUTOMATIC SHUTDOWN FUNCTION DOES NOT WORK NORMALLY.
	Daytime running light function does not work normally.	Halogen type headlight	8	INSPECTION PROCEDURE 8: DAYTIME RUNNING LIGHT FUNCTION DOES NOT WORK NORMALLY. < HALOGEN TYPE HEADLIGHT >
	Daytime running light function does not work normally.	Discharge type headlight	8	INSPECTION PROCEDURE 8: DAYTIME RUNNING LIGHT FUNCTION DOES NOT WORK NORMALLY. < DISCHARGE TYPE HEADLIGHT >
	One of the tail lights, side marker lights or the license plate lights does not Illuminate.		9	INSPECTION PROCEDURE 9: ONE OF THE POSITION LIGHT, THE TAILLIGHT, THE REAR SIDE MARKER LIGHTS OR THE LICENSE PLATE LIGHT DOES NOT ILLUMINATE.
	The auto light function does not work normally.		10	INSPECTION PROCEDURE 10: THE AUTO LIGHT FUNCTION DOES NOT WORK NORMALLY.
Turn-signal light	None of turn-signal lights illuminates.		11	INSPECTION PROCEDURE 11: NONE OF TURN-SIGNAL LIGHTS ILLUMINATES.
	The comfort flashing function does not work normally.		12	INSPECTION PROCEDURE 12: THE COMFORT FLASHING FUNCTION DOES NOT WORK NORMALLY.
	The turn-signal indicator lights do not illuminate.		13	INSPECTION PROCEDURE 13: THE TURN-SIGNAL INDICATOR LIGHTS DO NOT ILLUMINATE.
The welcome light function does not work normally.			14	INSPECTION PROCEDURE 14: THE WELCOME LIGHT FUNCTION DOES NOT WORK NORMALLY.
The coming home light function does not work normally.			15	INSPECTION PROCEDURE 15: THE COMING HOME LIGHT FUNCTION DOES NOT WORK NORMALLY.

TROUBLE SYMPTOM CHART

Inspection Procedure 1: None of headlights (low-beam) illuminates

CAUTION

Whenever the ECU is replaced, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.

Scheme 19

Scheme 20

If none of headlights (low-beam) illuminates, the headlight switch input circuit, headlight relay (LOW), or ETACS-ECU may have a problem.

Malfunction of column switch
Malfunction of headlight relay (LOW)
Malfunction of the ETACS-ECU
Damaged harness wires and connectors

Required Special Tools

MB992006: Extra fine probe
MB991223: Harness set
MB991958 Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827 M.U.T.-III USB Cable MB991910 M.U.T.-III Main Harness A (Vehicles with CAN communication system)

STEP 1. Using scan tool MB991958, read the diagnostic trouble code. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Check whether the ETACS-ECU related DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Diagnose the ETACS-ECU. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__diagnostic-trouble-code-chart) . NO: Go to Step 2.
STEP 2. Using scan tool MB991958, check data list Use the ETACS-ECU service data to check the signals related to the operation of headlight function. Turn the headlight switch to the ON position. CHECK DATA LIST ITEM 341 Item No. Item name Normal condition Item 341 Headlight switch ON Q: Do scan tool MB991958 display the items "Headlight switch" as normal condition? YES: Go to Step 3. NO: Troubleshoot the ETACS-ECU. Refer to «TROUBLE SYMPTOM CHART FOR INPUT SIGNAL»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__trouble-symptom-chart-for-input-signal) .
STEP 3. Check headlight relay (LOW) connector A-25X for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is headlight relay (LOW) connector A-25X in good condition? YES < Halogen type >: Go to Step 5 . YES < Discharge type >: Go to Step 4. NO: Repair the damaged parts.
STEP 4. Check of headlight relay (LOW) Refer to «HEADLIGHT RELAY (LOW) CHECK < VEHICLES WITH DISCHARGE HEADLIGHT >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__headlight-relay-low-check-vehicles) . Q: Is the headlight relay (LOW) in good condition? YES: Go to Step 5. NO: Replace the headlight relay (LOW). Verify that the high-beam headlights illuminate normally.
STEP 5. Check the battery power supply circuit to the headlight relay (LOW). Measure the voltage at headlight relay (LOW) connector A-25X. CAUTION: The top and bottom of the headlight relay (LOW) are difficult to identify. Prior to inspection, confirm the triangle mark on the relay box. Disconnect headlight relay (LOW) connector A-25X and measure the voltage available at the relay box side of the connector. Measure the voltage between terminal 4 and ground. OK: The voltage should measure approximately 12 volts (battery positive voltage). Q: Is the measured voltage approximately 12 volts (battery positive voltage)? YES: Go to Step 6. NO: Go to Step 8 .
STEP 6. Check ETACS-ECU connector C-312 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is ETACS-ECU connector C-312 in good condition? YES: Go to Step 7. NO: Repair the damaged parts.
STEP 7. Check the wiring harness between headlight relay (LOW) connector A-25X (terminal 1) and ETACS-ECU connector C-312 (terminal 6). Check the output line for open circuit. Q: Is the wiring harness between headlight relay (LOW) connector A-25X (terminal 1) and ETACS-ECU connector C-312 (terminal 6) in good condition? YES: Go to Step 9 . NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Verify that the low-beam headlights illuminate normally.
STEP 8. Check the wiring harness between headlight relay (LOW) connector A-25X (terminal 4) and the fusible link (36). Check the power supply line for open circuit. Q: Is the wiring harness between headlight relay (LOW) connector A-25X (terminal 4) and fusible link (36) in good condition? YES: Go to Step 9. NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Verify that the low-beam headlights illuminate normally.
STEP 9. Temporarily replace the headlight relay (LOW), and retest the system. Temporarily replace the headlight relay (LOW), check that the headlights (low-beam) illuminate normally. Q: Does the headlights (low-beam) do not illuminate in good condition? YES: Replace the headlight relay (LOW). NO: Replace the ETACS-ECU.

Inspection Procedure 2: None of headlights (high-beam) illuminates

CAUTION

Whenever the ECU is replaced, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.

Scheme 21

If none of headlights (high-beam) illuminates, the headlight switch input circuit, headlight relay (HIGH), or ETACS-ECU may have a problem.

Malfunction of column switch
Malfunction of headlight relay (HIGH)
Malfunction of the ETACS-ECU
Damaged harness wires and connectors

Required Special Tools

MB992006: Extra fine probe
MB991223: Harness set
MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)

STEP 1. Using scan tool MB991958, read the diagnostic trouble code. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Check whether the ETACS-ECU related DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Diagnose the ETACS-ECU. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__diagnostic-trouble-code-chart) . NO: Go to Step 2.
STEP 2. Using scan tool MB991958, check data list Use the ETACS-ECU service data to check the signals related to the operation of headlight function. Turn the headlight switch to the ON position. CHECK DATA LIST ITEM 341 Item No. Item name Normal condition Item 341 Headlight switch ON Turn the passing switch to the ON position. CHECK DATA LIST ITEM 350 Item No. Item name Normal condition Item 350 Headlight switch (flasher) ON Q: Do scan tool MB991958 display the items "Headlight switch" and "Headlight switch (flasher)" as normal condition? YES: (Normal conditions are displayed for all items.) Go to Step 3. NO: (Normal condition is not displayed.) Troubleshoot the ETACS-ECU. Refer to «TROUBLE SYMPTOM CHART FOR INPUT SIGNAL»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__trouble-symptom-chart-for-input-signal) .
STEP 3. Check headlight relay (HIGH) connector A-17X for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is headlight relay (HIGH) connector A-17X in good condition? YES: Go to Step 4. NO: Repair the damaged parts.
STEP 4. Check of headlight relay (HIGH) Refer to «HEADLIGHT RELAY (HIGH) CHECK»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__headlight-relay-high-check) . Q: Is the headlight relay (HIGH) in good condition? YES: Go to Step 5. NO: Replace the headlight relay (HIGH). Verify that the high-beam headlights illuminate normally.
STEP 5. Check the battery power supply circuit to the headlight relay (HIGH). Measure the voltage at headlight relay (HIGH) connector A-17X CAUTION: The top and bottom of the headlight relay (HIGH) are difficult to identify. Prior to inspection, confirm the triangle mark on the relay box. Disconnect headlight relay (HIGH) connector A-17X and measure the voltage available at the relay box side of the connector. Measure the voltage between terminal 2/4 and ground. OK: The voltage should measure approximately 12 volts (battery positive voltage). Q: Is the measured voltage approximately 12 volts (battery positive voltage)? YES: Go to Step 6. NO: Go to Step 8 .
STEP 6. Check ETACS-ECU connector C-312 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is ETACS-ECU connector C-312 in good condition? YES: Go to Step 7. NO: Repair the damaged parts.
STEP 7. Check the wiring harness between headlight relay (HIGH) connector A-17X (terminal 1) and ETACS-ECU connector C-312 (terminal 13). Check the output line for open circuit. Q: Is the wiring harness between headlight relay (HIGH) connector A-17X (terminal 1) and ETACS-ECU connector C-312 (terminal 13) in good condition? YES: Go to Step 9 . NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Verify that the high-beam headlights illuminate normally.
STEP 8. Check the wiring harness between headlight relay (HIGH) connector A-17X (terminal 2/4) and the fusible link (36). Check the power supply line for open circuit. Q: Is the wiring harness between headlight relay (HIGH) connector A-17X (terminal 2/4) and fusible link (36) in good condition? YES: Go to Step 9. NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Verify that the high-beam headlights illuminate normally.
STEP 9. Retest the system Q: Does the headlights (high-beam) do not illuminate in good condition? YES: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ). NO: Replace the ETACS-ECU.

Inspection Procedure 3: The headlights illuminate at low-beam (high-beam does not illuminate) regardless of the lighting switch positions

CAUTION

Whenever the ECU is replaced, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.

If the headlights illuminate only at low-beam regardless of the lighting switch position, the headlight fail-safe function may be active.

Malfunction of column switch
Malfunction of the ETACS-ECU
Damaged harness wires and connectors

Required Special Tools

MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)

STEP 1. Using scan tool MB991958, read the diagnostic trouble code. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Check whether the ETACS-ECU related DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Diagnose the ETACS-ECU. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__diagnostic-trouble-code-chart) . NO: Go to Step 2.
STEP 2. Retest the system Q: Do the headlights illuminate normally? YES: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ). NO: Replace the ETACS-ECU.

Inspection Procedure 4: Headlights do not illuminate when the passing switch is operated

CAUTION

Whenever the ECU is replaced, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.

If none of headlights (low-beam and high-beam) illuminates, the passing switch input circuit or ETACS-ECU may have a problem.

Malfunction of column switch
Malfunction of the ETACS-ECU
Damaged harness wires and connectors

Required Special Tools

MB991223: Harness set
MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)

STEP 1. Check that the headlights operate. Check that the low-beam and high-beam headlights illuminate normally. Q: Is the check result normal? YES: Go to Step 2. NO: Refer to «INSPECTION PROCEDURE 1: NONE OF HEADLIGHTS (LOW-BEAM) ILLUMINATES»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__inspection-procedure-1-none-of-headlights) and «INSPECTION PROCEDURE 2: NONE OF HEADLIGHTS (HIGH-BEAM) ILLUMINATES»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__inspection-procedure-2-none-of-headlights) .
STEP 2. Using scan tool MB991958, read the ETACS-ECU diagnostic trouble code. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Check whether the ETACS-ECU related DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Diagnose the ETACS-ECU. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__diagnostic-trouble-code-chart) . NO: Go to Step 3.
STEP 3. Retest the system Q: Do the headlights (low-beam and high-beam) illuminate normally when turning ON the passing switch? YES: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ). NO: Replace the ETACS-ECU.

Scheme 22

Scheme 22: Inspection Procedure 5: One of the headlight(s) does not illuminate

Scheme 23

When one of the headlights does not illuminate, the wiring harness, connector(s), or the bulb may have a problem, or the fuse may be burned out.

Malfunction of the headlight bulbs
Malfunction of the headlight assembly
Damaged harness wires and connectors

Required Special Tools

MB992006: Extra fine probe
MB991223: Harness set

STEP 1. Check headlight assembly connector A-31 < LH > or A-47 < RH >, for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is headlight assembly connector A-31 < LH > or A-47 < RH > in good condition? YES: Go to Step 2. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) .
STEP 2. Check bulb. Check the bulb(s) of headlight that does not illuminate. NOTE: If discharge-type lower beam headlights do not illuminate, their bulbs cannot be inspected. In this case, assume the bulbs to be normal and proceed with steps. Q: Is the bulb in good condition? YES: Go to Step 3. NO: Replace the bulb(s) of the light that does not illuminate.
STEP 3. Check the wiring harness between headlight assembly connector and headlight relay connector. Check the power supply line for open circuit. Check the wiring harness between headlight assembly (LH) connector A-31 (terminal 2) and headlight relay (LOW) connector A-25X (terminal 3). < LH-LOW > Check the wiring harness between headlight assembly (LH) connector A-31 (terminal 1) and headlight relay (HIGH) connector A-17X (terminal 3). < LH-HIGH > Check the wiring harness between headlight assembly (LH) connector A-31 (terminal 6) and ground. < LH-LOW and HIGH > Check the wiring harness between headlight assembly (RH) connector A-47 (terminal 2) and headlight relay (LOW) connector A-25X (terminal 3). < RH-LOW > Check the wiring harness between headlight assembly (RH) connector A-47 (terminal 1) and headlight relay (HIGH) connector A-17X (terminal 3). < RH-HIGH > Check the wiring harness between headlight assembly (RH) connector A-47 (terminal 6) and ground. < RH-LOW and HIGH > Q: Is the wiring harness between headlight assembly connector and headlight relay connector in good condition? YES: Replace the headlight assembly that does not illuminate. NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Verify that the headlights illuminate normally.

Inspection Procedure 6: High-beam indicator light does not illuminate normally

CAUTION

Whenever the ECU is replaced, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.

Scheme 24

If the high-beam indicator does not illuminate normally, the harness in the CAN bus lines, connector(s), ETACS-ECU, or combination meter may have a problem.

Malfunction of the ETACS-ECU
Malfunction of combination meter
Damaged harness wires and connectors

Required Special Tools

MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)

STEP 1. Check of headlight (high-beam). Check that the headlights (high-beam) illuminate/extinguish normally when the lighting switch is operated. Q: Is the check result normal? YES: Go to Step 2. NO: Refer to «INSPECTION PROCEDURE 2: NONE OF HEADLIGHTS (HIGH-BEAM) ILLUMINATES»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__inspection-procedure-2-none-of-headlights) ."
STEP 2. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch from "LOCK" (OFF) position to "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 3. NO: Repair the CAN bus line. (Refer to «DIAGNOSIS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__diagnosis) ).
STEP 3. Using scan tool MB991958, read the ETACS-ECU diagnostic trouble code. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Check whether the ETACS-ECU related DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Diagnose the ETACS-ECU. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__diagnostic-trouble-code-chart) . NO: Go to Step 4.
STEP 4. Using scan tool MB991958, check actuator test. Turn the ignition switch to the "ON" position. Perform the actuator test for the combination meter, and check that the high-beam indicator light illuminates (Refer to «ACTUATOR TEST TABLE < VEHICLES WITHOUT COLOR LIQUID CRYSTAL DISPLAY >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/gauges-instrument-panels/#combination-meter-except-lancer-evolution) ). Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the check result normal? YES: Replace the ETACS-ECU. NO: Replace the combination meter.

Inspection Procedure 7: The headlight automatic shutdown function does not work normally

CAUTION

Whenever the ECU is replaced, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.

OPERATION

The ETACS-ECU operates this function in accordance with the input signals from column switch (lighting switch), ignition switch (IG1), and front door switch (LH).

If the headlight automatic shutdown function does not work normally, the above described input circuits or ETACS-ECU may have a problem. Also, it may be possible that the headlight automatic shutdown function is set to "Disable" through configuration function.

Malfunction of front door switch (LH)
Malfunction of the ETACS-ECU
The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector

Required Special Tools

MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)

STEP 1. Using scan tool MB991958, Check the configuration function. Use the ETACS-ECU configuration function to check that the "Head light auto cut customize" is set to "Enable (C-spec.)" CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Use the ETACS-ECU configuration function to check that the "Headlight auto cut customize" is set to "C-spec." Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the check result normal? YES: Go to Step 2. NO: Use the ETACS-ECU configuration function to set the "Headlight auto cut customize" to "Enable (C-spec.)" (Refer to «CUSTOMIZATION FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__customization-function) ).
STEP 2. Using scan tool MB991958, read the diagnostic trouble code. Turn the ignition switch to the "ON" position. Check whether the ETACS-ECU related DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Diagnose the ETACS-ECU (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__diagnostic-trouble-code-chart) ). NO: Go to Step 3.
STEP 3. Using scan tool MB991958, check data list. Use the ETACS-ECU service data to check the signals related to the operation of headlight automatic shutdown function. Turn the ignition switch to the LOCK (OFF) position. Illuminate the headlights. CHECK DATA LIST ITEMS 206 & 254 Item No. Item name Normal condition Item 206 Head light LO ON duty 100% Item 254 IG voltage 1 V or less Open the driver's door. CHECK DATA LIST ITEM 256 Item No. Item name Normal condition Item 256 Dr door ajar switch Open Q: Does scan tool MB991958 display the items "Head light LO ON duty", "IG voltage" and "Dr door ajar switch" as normal condition? YES: Go to Step 4. NO: Troubleshoot the ETACS-ECU. Refer to «TROUBLE SYMPTOM CHART FOR INPUT SIGNAL»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__trouble-symptom-chart-for-input-signal) .
STEP 4. Retest the system Check that the headlight automatic shutdown function works normally. Q: Is the check result normal? YES: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ). NO: Replace the ETACS-ECU.

Inspection Procedure 8: Daytime running light function does not work normally. < Halogen type headlight >

CAUTION

Whenever the ECU is replaced, ensure that the input and output signal circuits are normal.

Scheme 25

If the daytime running light function does not work, connector(s), wiring harness in the CAN bus lines, the engine control module, the combination meter, the ETACS-ECU or the input signal circuit may be defective.

Trouble in input signal system
Malfunction of headlight relay (LOW)
Malfunction of the ETACS-ECU
Damaged harness wires and connectors

Required Special Tools

MB991223: Harness Set
MB992006: Extra Fine Probe
MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: V.C.I. MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A

STEP 1. Verify the headlight (low-beam) operation. Check to see that the headlight (low-beam) lights up properly when operating the dimmer switch while the headlight switch is ON. Q: Do the headlights (low-beam) illuminate normally? YES: Go to Step 2. NO: Refer to «INSPECTION PROCEDURE 1: NONE OF HEADLIGHTS (LOW-BEAM) ILLUMINATES»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__inspection-procedure-1-none-of-headlights) .
STEP 2. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 3. NO: Repair the CAN bus line (Refer to «DIAGNOSIS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__diagnosis) ).
STEP 3. Using scan tool MB991958, read the ETACS-ECU diagnostic trouble code. Check whether ETACS-ECU DTCs are set. Turn the ignition switch to the "ON" position. Check for ETACS-ECU DTCs. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Diagnose the ETACS-ECU. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__diagnostic-trouble-code-chart) . NO: Go to Step 4.
STEP 4. Using scan tool MB991958, read the MFI system diagnostic trouble code. Check whether engine control module DTCs are set or not. Turn the ignition switch to the "ON" position. Check for engine control module DTCs. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Diagnose the MFI system. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) < 2.0L Engine non-turbo >, «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) < 2.0L Engine turbo >, «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) < 2.4L Engine >. NO: Go to Step 5.
STEP 5. Check the parking brake switch. Check the input signals from the parking brake switch. Turn the ignition switch to the "ON" position. Check that the brake warning light on the combination meter goes off when the parking brake lever is released. Turn the ignition switch to the "LOCK" (OFF) position. Q: Does the brake warning light go off? YES: Go to Step 6. NO: Refer to «INSPECTION PROCEDURE 2: WHEN THE PARKING BRAKE LEVER IS PULLED, THE BRAKE WARNING LIGHT DOES NOT ILLUMINATE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/parking-brake-system/#parking-brakes-except-lancer-evolution) . Verify that the daytime running light function does not work normally.
STEP 6. Temporarily replace the headlight relay (LOW), and retest the system. After temporarily replacing the headlight relay (LOW), with the ignition switch being in the ON position (engine is running), release the parking brake (parking brake switch: OFF) and turn the lighting switch to the OFF or TAIL position, and then check if the headlights (low-beam) illuminate with a reduced beam state. Q: Does the headlights (low-beam) do not illuminate in good condition? YES: Replace the headlight relay (LOW). NO: Replace the ETACS-ECU.

Inspection Procedure 8: Daytime running light function does not work normally. < Discharge type headlight >

CAUTION

Whenever the ECU is replaced, ensure that the input and output signal circuits are normal.

Scheme 26

COMMENTS ON TROUBLE SYMPTOM

If the daytime running lights do not illuminate, the wiring harness connector(s), the bulb or the ETACS-ECU may have a problem.

PROBABLE CAUSES

Burned-out daytime running light bulb
Malfunction of the daytime running light relay
Malfunction of the ETACS-ECU
Damaged harness wires and connectors

Required Special Tools

MB991223: Harness Set
MB992006: Extra Fine Probe
MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: V.C.I. MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A

Scheme 27

Scheme 28

STEP 1. Check that the tail/stop lights and headlights operate. Check that the tail/stop lights and headlights illuminate normally. Q: Do the tail/stop lights and headlights operate normally? YES: Go to Step 2. NO: Check the tail/stop lights and the headlights (Refer to «TROUBLE SYMPTOM CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__trouble-symptom-chart) ).
STEP 2. Check the daytime running light bulb. Remove the daytime running light bulb. Verify that the daytime running light bulb is not damaged or burned out. Q: Is the daytime running light bulb in good condition? YES: Go to Step 3. NO: Replace the fog light bulb. Verify that the daytime running lights illuminate normally.
STEP 3. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 4. NO: Repair the CAN bus line (Refer to «DIAGNOSIS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__diagnosis) ).
STEP 4. Using scan tool MB991958, read the ETACS-ECU diagnostic trouble code. Check whether ETACS-ECU DTCs are set. Turn the ignition switch to the "ON" position. Check for ETACS-ECU DTCs. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Diagnose the ETACS-ECU. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__diagnostic-trouble-code-chart) . NO: Go to Step 5.
STEP 5. Using scan tool MB991958, read the MFI system diagnostic trouble code. Check whether engine control module DTCs are set or not. Turn the ignition switch to the "ON" position. Check for engine control module DTCs. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Diagnose the MFI system. «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-non-turbo-except-lancer-evolution) . < 2.0L Engine non-turbo >, «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-20l-turbo-except-lancer-evolution) . < 2.0L Engine turbo >, «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/testing-diagnostics/#multiport-fuel-injection-mfi-24l-except-lancer-evolution) . < 2.4L Engine >. NO: Go to Step 6.
STEP 6. Check the parking brake switch. Check the input signals from the parking brake switch. Turn the ignition switch to the "ON" position. Check that the brake warning light on the combination meter goes off when the parking brake lever is released. Turn the ignition switch to the "LOCK" (OFF) position. Q: Does the brake warning light go off? YES: Go to Step 7. NO: Refer to «INSPECTION PROCEDURE 2: WHEN THE PARKING BRAKE LEVER IS PULLED, THE BRAKE WARNING LIGHT DOES NOT ILLUMINATE»(/mitsubishi/lancer-evolution/x-2007-2016/remont/parking-brake-system/#parking-brakes-except-lancer-evolution) . Verify that the daytime running light function does not work normally.
STEP 7. Check daytime running light (LH) connector A-32, daytime running light (RH) A-46 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is daytime running light (LH) connector A-32, daytime running light (RH) A-46 in good condition? YES: Go to Step 8. NO: Repair the damaged parts.
STEP 8. Check the ground circuit to the daytime running light (LH) or daytime running light (RH). Measure the resistance at daytime running light (LH) connector A-32 or daytime running light (RH) connector A-46. Disconnect the connector, and measure at the wiring harness side. Check the resistance between the fog light connector and ground. Resistance between A-32 daytime running light (LH) connector terminal No. 4 and ground Resistance between A-46 daytime running light (RH) connector terminal No. 4 and ground OK: The measured value should be continuity exists (2 ohms or less). Q: Is the measured resistance 2 ohms or less? YES: Go to Step 10 . NO: Go to Step 9.
STEP 9. Check the wiring harness between daytime running light (LH) connector A-32 (terminal 4) or daytime running light (RH) connector A-46 (terminal 4) and ground. Check the ground wires for open circuit. Q: Is the wiring harness between daytime running light (LH) connector A-32 (terminal 4) or daytime running light (RH) connector A-46 (terminal 4) and ground in good condition? YES: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ). NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Verify that the daytime running lights illuminate normally.
STEP 10. Check daytime running light relay connector A-20X for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is daytime running light relay connector A-20X in good condition? YES: Go to Step 11. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) .
STEP 11. Check the daytime running light relay. Refer to «DAYTIME RUNNING LIGHT RELAY CHECK < VEHICLES WITH DISCHARGE HEADLIGHT >»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__daytime-running-light-relay-check) . Q: Is the daytime running light relay in good condition? YES: Go to Step 12. NO: Replace the daytime running light relay. Verify that the daytime running lights illuminate normally.
STEP 12. Check the battery power supply circuit to the daytime running light relay. Measure the voltage at daytime running light relay connector A-20X. CAUTION: The top and bottom of the daytime running light relay are difficult to identify. Prior to inspection, confirm the triangle mark on the relay box. Disconnect daytime running light relay connector A-20X and measure the voltage available at the relay box side of the connector. Measure the voltage between terminal 2 and ground, and also between terminal 4 and ground. OK: The voltage should measure approximately 12 volts (battery positive voltage). Q: Is the measured voltage approximately 12 volts (battery positive voltage)? YES: Go to Step 14 . NO: Go to Step 13.
STEP 13. Check the wiring harness between daytime running light relay connector A-20X (terminal 2 and 4) and fusible link (36). Check the power supply line for open circuit. Q: Is the wiring harness between daytime running light relay connector A-20X (terminal 2 and 4) and fusible link (36) in good condition? YES: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ). NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Verify that the daytime running lights illuminate normally.
STEP 14. Check ETACS-ECU connector C-312 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is ETACS-ECU connector C-312 in good condition? YES: Go to Step 15. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) .
STEP 15. Check the wiring harness between daytime running light relay connector A-20X (terminal 1) and ETACS-ECU connector C-312 (terminal 10). Check the communication wires for open circuit. Q: Is the wiring harness between daytime running light relay connector A-20X (terminal 1) and ETACS-ECU connector C-312 (terminal 10) in good condition? YES: Go to Step 16. NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Verify that the daytime running lights illuminate normally.
STEP 16. Retest the system. Q: Does the daytime running lights illuminate in good condition? YES: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ). NO: Replace the ETACS-ECU.

Scheme 29

Scheme 29: < LANCER >

Scheme 30

Scheme 30: < LANCER SPORTBACK >

If one of the position light, the taillight, the rear side marker light or the license plate light does not illuminate normally, the harness, connector(s), or bulb(s) may have a problem, or the fuse may be burned out.

Malfunction of bulbs
Malfunction of rear combination light
Malfunction of rear combination light harness
Malfunction of taillight
Malfunction of license plate light
Malfunction of headlight
The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector

Required Special Tools

MB992006: Extra fine probe
MB991223: Harness set

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

STEP 1. Bulb check. Check the bulb(s) of the light that does not illuminate. Q: Is the check result normal? YES < LANCER >: Go to Step 2. YES < LANCER SPORTBACK >: Go to Step 8 . NO: Replace the bulb(s) of the light that does not illuminate.
STEP 2. Check headlight assembly connector A-31 (position light: LH) or A-47 (position light: RH), rear combination light connector F-20 (taillight/rear side marker light: LH) or F-06 (taillight/rear side marker light: RH), taillight connector F-18 (LH) or F-07 (RH), license plate light connector F-13 (LH) or F-11 (RH) for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is headlight assembly connector A-31 (position light: LH) or A-47 (position light: RH), rear combination light connector F-20 (taillight/rear side marker light: LH) or F-06 (taillight/rear side marker light: RH), taillight connector F-18 (LH) or F-07 (RH), license plate light connector F-13 (LH) or F-11 (RH) in good condition? YES: Go to Step 3. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) .
STEP 3. Resistance measurement at headlight assembly connector A-31 (position light: LH) or A-47 (position light: RH), rear combination light connector F-20 (taillight/rear side marker light: LH) or F-06 (taillight/rear side marker light: RH), taillight connector F-18 (LH) or F-07 (RH), license plate light connector F-13 (LH) or F-11 (RH). Disconnect the connector, and measure at the wiring harness side. Measure the resistance between the connector of light which does not illuminate and the body ground. Measure the resistance between headlight assembly connector A-31 (position light: LH) or A-47 (position light: RH) (terminal 6) and body ground. Measure the resistance between rear combination light connector F-20 (taillight/rear side marker light: LH) or F-06 (taillight/rear side marker light: RH) (terminal 1) and body ground. Measure the resistance between taillight connector F-18 (LH) or F-07 (RH) (terminal 1) and body ground. Measure the resistance between license plate light connector F-13 (LH) or F-11 (RH) (terminal 1) and body ground. OK: The measured value should be continuity exists (2 ohms or less). Q: Does the measured resistance value correspond with this range? YES: Go to Step 5 . NO: Go to Step 4.
STEP 4. Check the wiring harness between headlight assembly connector, rear combination light connector, taillight connector or license plate light connector and the body ground. Check the ground line for open circuit. Check the wiring harness between headlight assembly (position light: LH) connector A-31 (terminal 6) and the body ground. Check the wiring harness between headlight assembly (position light: RH) connector A-47 (terminal 6) and the body ground. Check the wiring harness between rear combination light (taillight/rear side marker light: LH) connector F-20 (terminal 1) and the body ground. Check the wiring harness between rear combination light (taillight/rear side marker light: RH) connector F-06 (terminal 1) and the body ground. Check the wiring harness between taillight (LH) connector F-18 (terminal 1) and the body ground. NOTE: Also check intermediate connector F-23 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector F-23 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Check the wiring harness between taillight (RH) connector F-07 (terminal 1) and the body ground. NOTE: Also check intermediate connector F-23 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector F-23 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Check the wiring harness between license plate light (LH) connector F-13 (terminal 1) and the body ground. NOTE: Also check intermediate connector F-15 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector F-15 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Check the wiring harness between license plate light (RH) connector F-11 (terminal 1) and the body ground. NOTE: Also check intermediate connector F-15 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector F-15 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Q: Is the wiring harness between headlight assembly connector, rear combination light connector, taillight connector or license plate light connector and the body ground in good condition? YES: Go to Step 7 . NO: Repair the wiring harness.
STEP 5. Check ETACS-ECU connector C-304 or C-311 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is ETACS-ECU connector C-304 or C-311 in good condition? YES: Go to Step 6. NO: Repair the damaged parts.
STEP 6. Check wiring harness between headlight assembly connector, rear combination light connector, taillight connector or license plate light connector and ETACS-ECU connector. Check the power supply line for open circuit or short circuit. Check the wiring harness between headlight assembly (position light: LH) connector A-31 (terminal 4) and ETACS-ECU connector C-304 (terminal 3). Check the wiring harness between headlight assembly (position light: RH) connector A-47 (terminal 4) and ETACS-ECU connector C-304 (terminal 7). Check the wiring harness between rear combination light (taillight/rear side marker light: LH) connector F-20 (terminal 3) and ETACS-ECU connector C-311 (terminal 10). NOTE: Also check intermediate connectors D-14 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector D-14 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Check the wiring harness between rear combination light (taillight/rear side marker light: RH) connector F-06 (terminal 3) and ETACS-ECU connector C-311 (terminal 13). NOTE: Also check intermediate connector D-11 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector D-11 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Check the wiring harness between taillight (LH) connector F-18 (terminal 2) and ETACS-ECU connector C-311 (terminal 10). NOTE: Also check intermediate connectors D-14 and F-23 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector D-14 or F-23 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Check the wiring harness between taillight (RH) connector F-07 (terminal 2) and ETACS-ECU connector C-311 (terminal 13). NOTE: Also check intermediate connectors D-14 and F-23 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector D-14 or F-23 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Check the wiring harness between license plate light (LH) connector F-13 (terminal 2) and ETACS-ECU connector C-311 (terminal 10). NOTE: Also check intermediate connectors D-14 and F-15 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector D-14 or F-15 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Check the wiring harness between license plate light (RH) connector F-11 (terminal 2) and ETACS-ECU connector C-311 (terminal 10). NOTE: Also check intermediate connectors D-14 and F-15 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector D-14 or F-15 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Q: Is the wiring harness between headlight assembly connector, rear combination light connector, taillight connector or license plate light connector and ETACS-ECU connector in good condition? YES: Go to Step 7. NO: Repair the wiring harness.
STEP 7. Retest the system. Check that the position light, taillight, rear side marker light, or license plate light illuminate normally. Q: Do the position light, taillight, rear side marker light, or license plate light work normally? YES (The light illuminate normally.): The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ). NO < When the position light does not illuminate >: Replace the position light socket. NO < When the rear combination light (taillight/rear side marker light) do not illuminate >: Replace the rear combination light socket. NO < When the taillight do not illuminate >: Replace the taillight socket. NO < When the license plate light does not illuminate >: Replace the license plate light socket.
STEP 8. Check headlight assembly connector A-31 (position light: LH) or A-47 (position light: RH), rear combination light connector F-20 (taillight: LH) or F-06 (taillight: RH), rear side marker light connector F-40 (LH) or F-35 (RH), license plate light connector F-13 (LH) or F-11 (RH) for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is headlight assembly connector A-31 (position light: LH) or A-47 (position light: RH), rear combination light connector F-20 (taillight: LH) or F-06 (taillight: RH), rear side marker light connector F-40 (LH) or F-35 (RH), license plate light connector F-13 (LH) or F-11 (RH) in good condition? YES: Go to Step 9. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) .
STEP 9. Resistance measurement at headlight assembly connector A-31 (position light: LH) or A-47 (position light: RH), rear combination light connector F-20 (taillight: LH) or F-06 (taillight: RH), rear side marker light connector F-40 (LH) or F-35 (RH), license plate light connector F-13 (LH) or F-11 (RH). Disconnect the connector, and measure at the wiring harness side. Measure the resistance between the connector of light which does not illuminate and the body ground. Measure the resistance between headlight assembly connector A-31 (position light: LH) or A-47 (position light: RH) (terminal 6) and body ground. Measure the resistance between rear combination light connector F-20 (taillight: LH) or F-06 (taillight: RH) (terminal 3) and body ground. Measure the resistance between rear side marker light connector F-40 (LH) or F-35 (RH) (terminal 1) and body ground. Measure the resistance between license plate light connector F-13 (LH) or F-11 (RH) (terminal 1) and body ground. OK: The measured value should be continuity exists (2 ohms or less). Q: Does the measured resistance value correspond with this range? YES: Go to Step 11 . NO: Go to Step 10.
STEP 10. Check the wiring harness between headlight assembly connector, rear combination light connector, rear side marker light connector or license plate light connector and the body ground. Check the ground line for open circuit. Check the wiring harness between headlight assembly (position light: LH) connector A-31 (terminal 6) and the body ground. Check the wiring harness between headlight assembly (position light: RH) connector A-47 (terminal 6) and the body ground. Check the wiring harness between rear combination light connector F-20 (taillight: LH) (terminal 3) and the body ground. Check the wiring harness between rear combination light connector F-06 (taillight: RH) (terminal 3) and the body ground. Check the wiring harness between rear side marker light connector F-40 (LH) (terminal 1) and the body ground. Check the wiring harness between rear side marker light connector F-35 (RH) (terminal 1) and the body ground. Check the wiring harness between license plate light (LH) connector F-13 (terminal 1) and the body ground. NOTE: Also check intermediate connector F-31 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector F-31 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Check the wiring harness between license plate light (RH) connector F-11 (terminal 1) and the body ground. NOTE: Also check intermediate connector F-31 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector F-31 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Q: Is the wiring harness between headlight assembly connector, rear combination light connector, rear side marker light connector or license plate light connector and the body ground in good condition? YES: Go to Step 13 . NO: Repair the wiring harness.
STEP 11. Check ETACS-ECU connector C-304 or C-311 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is ETACS-ECU connector C-304 or C-311 in good condition? YES: Go to Step 12. NO: Repair the damaged parts.
STEP 12. Check wiring harness between headlight assembly connector, rear combination light connector, rear side marker light connector or license plate light connector and ETACS-ECU connector. Check the power supply line for open circuit or short circuit. Check the wiring harness between headlight assembly (position light: LH) connector A-31 (terminal 4) and ETACS-ECU connector C-304 (terminal 3). Check the wiring harness between headlight assembly (position light: RH) connector A-47 (terminal 4) and ETACS-ECU connector C-304 (terminal 7). Check the wiring harness between rear combination light (taillight: LH) connector F-20 (terminal 2) and ETACS-ECU connector C-311 (terminal 10). NOTE: Also check intermediate connectors D-14 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector D-14 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Check the wiring harness between rear combination light (taillight: RH) connector F-06 (terminal 2) and ETACS-ECU connector C-311 (terminal 13). NOTE: Also check intermediate connector D-11 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector D-11 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Check the wiring harness between rear side marker light (LH) connector F-40 (terminal 2) and ETACS-ECU connector C-311 (terminal 10). NOTE: Also check intermediate connector D-14 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector D-14 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Check the wiring harness between rear side marker light (RH) connector F-35 (terminal 2) and ETACS-ECU connector C-311 (terminal 13). NOTE: Also check intermediate connector D-11 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector D-11 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Check the wiring harness between license plate light (LH) connector F-13 (terminal 2) and ETACS-ECU connector C-311 (terminal 10). NOTE: Also check intermediate connectors D-14 and F-30 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector D-14 or F-30 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Check the wiring harness between license plate light (RH) connector F-11 (terminal 2) and ETACS-ECU connector C-311 (terminal 10). NOTE: Also check intermediate connectors D-14 and F-30 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector D-14 or F-30 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/body-electrical/#general-electrical-except-lancer-evolution) . Q: Is the wiring harness between headlight assembly connector, rear combination light connector, rear side marker light connector or license plate light connector and ETACS-ECU connector in good condition? YES: Go to Step 13. NO: Repair the wiring harness.
STEP 13. Retest the system. Check that the position light, taillight, rear side marker light, or license plate light illuminate normally. Q: Do the position light, taillight, rear side marker light, or license plate light work normally? YES (The light illuminate normally.): The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ). NO < When the position light does not illuminate >: Replace the position light socket. NO < When the rear combination light (taillight) do not illuminate >: Replace the rear combination light socket. NO < When the rear side marker light do not illuminate >: Replace the rear side marker light socket. NO < When the license plate light does not illuminate >: Replace the license plate light socket.

Inspection Procedure 10: The auto light function does not work normally

CAUTION

Whenever the ECU is replaced, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.

The ETACS-ECU operates this function in accordance with the input signals from driving distance, lighting control sensor, and column switch (auto light switch). Also, when the column switch (lighting switch) is in the "AUTO" position, and when an abnormality is present to the auto light circuit, the fail-safe function is activated and the low beam is turned ON at all times regardless of the brightness around the vehicle.

If the auto light function does not work normally, the above input signal circuit(s) or the ETACS-ECU may have a problem.

Malfunction of the lighting control sensor
Malfunction of the column switch
Malfunction of the ETACS-ECU
The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector

Required Special Tools

MB991958 Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827 M.U.T.-III USB Cable MB991910 M.U.T.-III Main Harness A (Vehicles with CAN communication system)

STEP 1. Using scan tool MB991958, diagnose the CAN bus line CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 2. NO: Repair the CAN bus line (Refer to «DIAGNOSIS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__diagnosis) ).
STEP 2. Using scan tool MB991958, read the diagnostic trouble code. Check if DTC is set to the LIN. Q: Is the DTC set? YES: Refer to «DTC CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__diagnostic-trouble-code-chart) . NO: Go to Step 3.
STEP 3. Using scan tool MB991958, read the ETACS diagnostic trouble code. Check if DTC is set to the ETACS-ECU. Q: Is the DTC set? YES: Troubleshoot the ETACS (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__diagnostic-trouble-code-chart) ). NO: Go to Step 4.
STEP 4. Check that the headlights operate. Check that the headlights (low-beam) illuminate normally. Q: Is the check result normal? YES: Go to Step 5. NO: Refer to «INSPECTION PROCEDURE 1: NONE OF HEADLIGHTS (LOW-BEAM) ILLUMINATES»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__inspection-procedure-1-none-of-headlights) .
STEP 5. Using scan tool MB991958, check data list Use the ETACS-ECU service data to check the signals related to the operation of auto light function. Turn the lighting switch to the "AUTO" position. CHECK DATA LIST ITEM 348 Item No. Item name Normal condition Item 348 Headlight switch (auto) ON Q: Do scan tool MB991958 display the items "Headlight switch (auto)" as normal condition? YES: Go to Step 6. NO: Troubleshoot the ETACS-ECU. Refer to «TROUBLE SYMPTOM CHART FOR INPUT SIGNAL»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__trouble-symptom-chart-for-input-signal) .
STEP 6. Lighting control sensor check Check the lighting control sensor. Refer to «LIGHTING CONTROL SENSOR (LIGHT SENSOR) CHECK»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__lighting-control-sensor-light-sensor-check) . Q: Is the check result normal? YES: Go to Step 7. NO: Replace the lighting control sensor.
STEP 7. Retest the system Check that the auto light function works normally. Q: Is the check result normal? YES: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ). NO: Replace the ETACS-ECU.

If none of turn-signal lights illuminates, the ignition switch (IG1), the turn-signal light switch input circuit or the ETACS-ECU may have a problem.

Malfunction of column switch
Malfunction of the ETACS-ECU
The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector

Required Special Tools

MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)

STEP 1. Using scan tool MB991958, read the ETACS-ECU diagnostic trouble code. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Check whether the ETACS-ECU DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Diagnose the ETACS-ECU (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__diagnostic-trouble-code-chart) ). NO: Go to Step 2.
STEP 2. Using scan tool MB991958, check data list. Using the ETACS-ECU service data, check the signals related to the illumination of turn-signal light. Turn the ignition switch to the "ON" position. CHECK DATA LIST ITEM 254 Item No. Item name Normal conditions Item 254 IG voltage Battery positive voltage Q: Does scan tool MB991958 display the item "IG voltage" as normal condition? YES: Go to Step 3. NO: Troubleshoot the ETACS-ECU. Refer to «INSPECTION PROCEDURE 2 "ETACS-ECU DOES NOT RECEIVE ANY SIGNAL FROM THE IGNITION SWITCH (IG1)"»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution) .
STEP 3. Retest the system. Check that turn-signal lights illuminate. Q: Do turn-signal lights work normal? YES: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ). NO: Replace the ETACS-ECU.

If the comfort flashing function does not work normally, the turn-signal light switch input circuit(s) and ETACS-ECU may have a problem.

Malfunction of column switch
Malfunction of the ETACS-ECU
The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector

Required Special Tools

MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)

STEP 1. Using scan tool MB991958, Check the configuration function. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Use the ETACS-ECU configuration function to check that the "Comfort flasher" is set to "Enable". Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the "Comfort flasher" set to "Enable"? YES: Go to Step 2. NO: Use the ETACS-ECU customize function to set the "Comfort flasher" to "Enable" (Refer to «CUSTOMIZATION FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__customization-function) ).
STEP 2. Using scan tool MB991958, read the ETACS-ECU diagnostic trouble code. Turn the ignition switch to the "ON" position. Check whether the ETACS-ECU DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Diagnose the ETACS-ECU (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__diagnostic-trouble-code-chart) ). NO: Go to Step 3.
STEP 3. Check that the turn-signal light operate. Check that the turn-signal light work normally when the ignition switch is in the "ON" position. Q: Do turn-signal lights work normally? YES: Go to Step 4. NO: Refer to «INSPECTION PROCEDURE 11: NONE OF TURN-SIGNAL LIGHTS ILLUMINATES»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution) .
STEP 4. Retest the system Check that the comfort flashing function works normally. Q: Does comfort flashing function works normally? YES: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ). NO: Replace the ETACS-ECU.

Inspection Procedure 13: The turn-signal indicator lights do not illuminate

CAUTION

Whenever the ECU is replaced, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.

If the turn-signal light indicator does not illuminate normally, the harness in the CAN bus lines, connector(s), ETACS-ECU, or combination meter may have a problem.

Malfunction of the ETACS-ECU
Malfunction of combination meter
The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector

Required Special Tools

MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)

STEP 1. Check turn-signal light. Check that the turn-signal light flashes normally when the turn-signal switch is operated. Q: Do Turn-signal light work normally? YES: Go to Step 2. NO: Refer to «INSPECTION PROCEDURE 11: NONE OF TURN-SIGNAL LIGHTS ILLUMINATES»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution) .
STEP 2. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 3. NO: Repair the CAN bus line (Refer to «DIAGNOSIS»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#controller-area-network-can-except-lancer-evolution__diagnosis) ).
STEP 3. Using scan tool MB991958, read the diagnostic trouble code. Check if diagnostic trouble code is set to the ETACS-ECU. Turn the ignition switch to the "ON" position. Check whether the ETACS-ECU related DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Diagnose the ETACS-ECU. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__diagnostic-trouble-code-chart) . NO: Go to Step 4.
STEP 4. Using scan tool MB991958, check actuator test. Connect scan tool MB991958 to the data link connector. Turn the ignition switch to the "ON" position. Set scan tool MB991958 to the actuator test mode. Item 7: Indicator1 Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the check result normal? YES: Replace the ETACS-ECU. NO: Replace the combination meter.

Inspection Procedure 14: The welcome light function does not work normally

CAUTION

Whenever the ECU is replaced, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.

When the welcome light function does not operate normally, the keyless entry system or the ETACS-ECU may have a problem. Or, the welcome light function may have been set to disabled using the customization function.

Malfunction of the keyless entry system
Malfunction of the ETACS-ECU

Required Special Tools

MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)

Scheme 38

STEP 1. Using scan tool MB991958, Check the configuration function. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Check that any one of the followings other than "Disabled" is set for "Welcome light" with a customization function. Small light Head light Turn the ignition switch to the "LOCK" (OFF) position. Q: Is it set to other than "Disabled"? YES: Go to Step 2. NO: Set "Welcome light" to any one other than "Disabled" with a customization function (Refer to «CUSTOMIZATION FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__customization-function) ).
STEP 2. Using scan tool MB991958, read the ETACS-ECU diagnostic trouble code Turn the ignition switch to the "ON" position. Check whether the ETACS-ECU DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Diagnose the ETACS-ECU. (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__diagnostic-trouble-code-chart) ) NO: Go to Step 3.
STEP 3. Check the keyless entry system operation Check that the keyless entry system operation normally. Q: Is the check result normal? YES: Go to Step 4. NO: Troubleshoot the keyless entry system. Refer to «TROUBLE SYMPTOM CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/door-locks-anti-theft-systems/#keyless-operation-system-kos-except-lancer-evolution__trouble-symptom-chart) < KOS > or «TROUBLE SYMPTOM CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#wireless-control-module-wcm-except-lancer-evolution__trouble-symptom-chart) < WCM >.
STEP 4. Check the tail lights and headlights. When the lighting switch is operated, check that the tail lights and headlights illuminate/go off normally. Q: Is the check result normal? YES: Go to Step 5. NO: Troubleshoot the tail lights and headlights. Refer to «TROUBLE SYMPTOM CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__trouble-symptom-chart) .
STEP 5. Retest the system. Check that the welcome light function works normally. Q: Is the check result normal? YES: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ). NO: Replace the ETACS-ECU.

Inspection Procedure 15: The coming home light function does not work normally

CAUTION

Whenever the ECU is replaced, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.

When the coming home light function does not operate normally, the keyless entry system or the ETACS-ECU may have a problem. Or, the coming home light function may have been set to disabled using the customization function.

Malfunction of the keyless entry system
Malfunction of the ETACS-ECU

Required Special Tools

MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)

STEP 1. Using scan tool MB991958, Check the configuration function. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__how-to-connect-the-scan-tool) ." Turn the ignition switch to the "ON" position. Check that any one of the followings other than "Disabled" is set for "Coming home light" with a customization function. 15 sec 30 sec 60 sec 180 sec Turn the ignition switch to the "LOCK" (OFF) position. Q: Is it set to other than "Disabled"? YES: Go to Step 2. NO: Set "Coming home light" to any one other than "Disabled" with a customization function (Refer to «CUSTOMIZATION FUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__customization-function) ).
STEP 2. Using scan tool MB991958, read the ETACS-ECU diagnostic trouble code Turn the ignition switch to the "ON" position. Check whether the ETACS-ECU DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Diagnose the ETACS-ECU. (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution__diagnostic-trouble-code-chart) ) NO: Go to Step 3.
STEP 3. Using scan tool MB991958, check data list Use the ETACS-ECU data list to check the signals related to the front dome light. Turn the ignition switch to the LOCK (OFF) position. CHECK DATA LIST ITEM 254 Item No. Item name Normal condition Item 254 IG voltage 1 V or less OK: Normal condition is displayed. Q: Is the check result normal? YES: Go to Step 4. NO: Troubleshoot the ETACS-ECU. Refer to «INSPECTION PROCEDURE 2: MALFUNCTION OF THE IGNITION SWITCH (IG1) INPUT/OUTPUT SIGNAL»(/mitsubishi/lancer-evolution/x-2007-2016/remont/communication-devices/#electronic-time-and-alarm-control-system-etacs-except-lancer-evolution) .
STEP 4. Check the headlights. When the lighting switch is operated, check that the headlights illuminate/go off normally. Q: Is the check result normal? YES: Go to Step 5. NO: Troubleshoot the headlights. Refer to «TROUBLE SYMPTOM CHART»(/mitsubishi/lancer-evolution/x-2007-2016/remont/headlights/#headlight-system-except-lancer-evolution__trouble-symptom-chart) .
STEP 5. Retest the system. Check that the coming home light function works normally. Q: Is the check result normal? YES: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/hoistjack/#general-information-except-lancer-evolution__how-to-cope-with-intermittent-malfunctions) ). NO: Replace the ETACS-ECU.

LIN < LIGHTING CONTROL SENSOR (LIGHT SENSOR) >

Item No.	Scan tool display	Check conditions	Normal conditions
7001	RLS IG1	When the ignition switch is in the "LOCK" or "ACC" position	OFF
7001	RLS IG1	When the ignition switch is in the "ON" or "START" position	ON
7002	RLS Light sensor sensitivity	When the customize value of lighting control sensor sensitivity is set to Level 1 (fast)	Level 1 bright
		When the customize value of lighting control sensor sensitivity is set to Level 2 (slightly fast)	Level 2 bright
		When the customize value of lighting control sensor sensitivity is set to Level 3 (normal)	Level 3
		When the customize value of lighting control sensor sensitivity is set to Level 4 (slightly slow)	Level 4 dark
		When the customize value of lighting control sensor sensitivity is set to Level 5 (slow)	Level 5 dark
7004	RLS Radio ACC	When the ignition switch is in the "LOCK" or "START" position	OFF
7004	RLS Radio ACC	When the ignition switch is in the "ACC" or "ON" position	ON
7007	RLS Vehicle speed	Perform a test run of the vehicle.	The values displayed on the speedometer and the scan tool MB991958 are almost the same.
7009	RLS Low beam "ON" request	When the lighting control sensor area is bright	OFF
7009	RLS Low beam "ON" request	When the lighting control sensor area is dark	ON
7010	RLS judgment illuminance output	When the lighting control sensor area changes from dark to bright	The value displayed on the scan tool MB991958 increases.
7010	RLS judgment illuminance output	When the lighting control sensor area changes from bright to dark	The value displayed on the scan tool MB991958 decreases.
7011	RLS Taillight "ON" request	When the lighting control sensor area is bright	OFF
7011	RLS Taillight "ON" request	When the lighting control sensor area is dark	ON
7012	RLS Tunnel detect output	When the lighting control sensor area is bright	OFF
7012	RLS Tunnel detect output	When the lighting control sensor area is dark	ON
7014	RLS specification		EU
7015	RLS ECU Diagnostic Version
7016	RLS ECU Hardware Version
7017	RLS ECU Software Version
7018	RLS ECU Part number		8634A001
7019	RLS ECU Serial number

DATA LIST REFERENCE TABLE (LIGHTING CONTROL SENSOR)

Scheme 39

Scheme 39: PRE-AIMING INSTRUCTIONS (LOW-BEAM)

Inspect for rusted or faulty headlight assemblies.
These conditions must be corrected before a satisfactory adjustment can be made.
Inspect tire inflation, and adjust if necessary.
If the fuel tank is not full, place a weight in the trunk of the vehicle to simulate weight of a full tank [3 kg (6.6 pounds) per gallon].
There should be no other load in the vehicle other than driver or substituted weight of approximately 68 kg (150 pounds) placed in driver's position.
Turn the headlight leveling switch to the switch position "0." < Vehicles with headlight manual leveling system >
Thoroughly clean headlight lenses.
Place the vehicle on a level floor, perpendicular to a flat screen 7.62 m (25.0 ft) away from the bulb center-marks on the headlight lens.
Rock vehicle sideways to allow vehicle to assume its normal position.
Bounce the front suspension through three (3) oscillations by applying the body weight to hood or bumper.
Set the distance between the screen and the bulb center marks of the headlight as shown in the illustration.
Four lines of adhesive tape (or equivalent markings) are required on screen or wall: Position a vertical tape or mark so that it is aligned with the vehicle center line. Measure the distance from the center-marks on the headlight lens to the floor [reference value: 679.5 mm (26.75 inches)]. Transfer the measurement to the screen. Horizontal tape or mark on the screen is for reference of vertical adjustment. Measure the distance from the center line of the vehicle to the center of each headlight. Transfer the measurement to the screen. Vertical tape or mark on the screen with reference to the center line of each headlight bulb.

Scheme 40

Scheme 40: HEADLIGHT ADJUSTMENT (LOW-BEAM)

Scheme 41

Scheme 42

The low-beam headlight will project on the screen upper edge of the beam (cut-off).
Turn the adjusting screw to achieve the specified low-beam cut-off location on the aiming screen. Standard value < Vehicles without discharge headlight >: (Vertical direction) Horizontal line (H) ± 50.5 mm (± 2.0 inches) (± 0.38 degrees angle) (Horizontal direction): ± 126.4 mm (± 5.0 inches) (± 0.95 degrees angle) from the axis, which is 266.1 mm (10.5 inches) (2 degrees angle) rightward from the vertical line (V) Standard value < Vehicles with discharge headlight >: (Vertical direction) 53.2 mm (2.1 inches) (0.4 degrees) below horizontal line (H). ± 50.5 mm (± 2.0 inches) (± 0.38 degrees angle) (Horizontal direction): Elbow point intersects the vertical line (V). ± 126.4 mm (± 5.0 inches) (± 0.95 degrees angle) CAUTION: Do not cover a headlight for more than three minutes to prevent the plastic headlight lens deformation. NOTE: High-beam pattern should be correct when the low-beams are adjusted properly.

LUMINOUS INTENSITY MEASUREMENT

Set the headlights to high-beam.
Using a photometer, and following its manufacturer's instruction manual, measure the headlight center intensity and check to be sure that the limit value is satisfied. Limit: 40,000 cd or more {When a screen is set 18.3m (60 feet) ahead of the vehicle} NOTE: When measuring the intensity, maintain an engine speed of 2,000 r/min, with the battery fully charged. There may be special local regulations pertaining to headlight intensity. Be sure to make any adjustments necessary to satisfy such regulations. If an illuminometer is used to make the measurements, convert its values to photometer values by using the following formula. I =E x r 2 I = intensity (cd) E = illumination (lux) r = distance (m) from headlights to illuminometer

HEADLIGHT BULB (LOW-BEAM) REPLACEMENT < VEHICLES WITHOUT DISCHARGE HEADLIGHT >

CAUTION

Do not touch the bulb surface with bare hands or dirty gloves. If the bulb surface (glass part) gets dirty, immediately clean it with alcohol or thinner. After drying completely, install the bulb.

Disconnect the connector, and twist the headlight bulb (low-beam) to remove.

Scheme 43

HEADLIGHT BULB (HIGH-BEAM) REPLACEMENT < VEHICLES WITHOUT DISCHARGE HEADLIGHT >

CAUTION

Do not touch the bulb surface with bare hands or dirty gloves. If the bulb surface (glass part) gets dirty, immediately clean it with alcohol or thinner. After drying completely, install the bulb.

Scheme 44

Twist the socket cover to remove.
Disconnect the connector, and twist the headlight bulb (high-beam) to remove.

Scheme 45

Scheme 45: DAYTIME RUNNING LIGHT BULB REPLACEMENT < VEHICLES WITH DISCHARGE HEADLIGHT >

Twist the socket cover to remove.
Twist the daytime running light socket to remove it.

POSITION LIGHT BULB REPLACEMENT

Disconnect the connector, and twist the position light socket to remove it.

Scheme 46

Scheme 46: POSITION LIGHT BULB REPLACEMENT

FRONT TURN-SIGNAL LIGHT BULB REPLACEMENT

Disconnect the connector, and twist the front turn-signal light socket to remove it.

Scheme 47

Scheme 47: FRONT TURN-SIGNAL LIGHT BULB REPLACEMENT

HEADLIGHT AUTOMATIC-SHUTDOWN FUNCTION CHECK

Confirm that the headlights turn OFF in one second if the driver's door is opened when the ignition switch is OFF and the lighting switch is ON (HEAD position). If there is a malfunction, perform the troubleshooting (Refer to TROUBLE SYMPTOM CHART ).

HEADLIGHT AUTO LIGHT FUNCTION CHECK

Under the direct sunlight with the ignition switch ON and the lighting switch in the AUTO position, check that the headlight automatically illuminates when the lighting control sensor receiver is covered by hand. If there is any trouble, carry out the troubleshooting. (Refer to TROUBLE SYMPTOM CHART ).

Note. When covering the lighting control sensor receiver, be careful not to touch the windshield surface (where the lighting control sensor receiver is mounted). (The lighting control sensor receiver has limited resistance to oil.)

WELCOME LIGHT FUNCTION CHECK

When the lighting switch is in the OFF or AUTO position, unlock the door by the keyless entry system and check that the taillights or headlights turn on. If there is a malfunction, perform the troubleshooting (Refer to TROUBLE SYMPTOM CHART ).

Note. As for the vehicles with lighting control sensor, carry out the inspection in the dark place.

COMING-HOME LIGHT FUNCTION CHECK

After turning the ignition switch to the LOCK (OFF) position, check that passing operation lights up the headlights. If there is a malfunction, perform the troubleshooting (Refer to TROUBLE SYMPTOM CHART ).

CUSTOMIZATION FUNCTION

By operating the ETACS system or MMCS of scan tool MB991958, the following functions can be programmed. The programmed information is held even when the battery is disconnected.

Adjustment item (scan tool display)	Adjustment item	Adjusting contents (scan tool display)	Adjusting contents
ACC power auto cut	Time to ACC power cut-off when the ignition switch is in the ACC position	Disable	No function
		30 min	30 minutes (initial condition)
		60 min	60 minutes
Turn power source	Adjustment of turn-signal light operation condition	ACC or IG1	Operable with ACC or ON position
Turn power source	Adjustment of turn-signal light operation condition	IG1	Operable with ON position (initial condition)
Comfort flasher	With/without comfort flasher function	Disable	No function
Comfort flasher	With/without comfort flasher function	Enable	With function (initial condition)
Comfort flasher switch time	Switch operation time to activate the comfort flasher function	Normal	0.4 seconds (initial condition)
Comfort flasher switch time		Long	0.8 seconds
Sensitivity for auto light	Lighting control sensor sensitivity (illumination intensity) < vehicles with auto light >	Level 1 bright	High-high ambient brightness
		Level 2 bright	High ambient brightness
		Level 3	Standard ambient brightness (initial condition)
		Level 4 dark	Low ambient brightness
		Level 5 dark	Low-low ambient brightness
Hazard answer back	Adjustment of the number of keyless hazard warning light answer back flashes	Lock:1, Unlock:2	LOCK: Flashes once, UNLOCK: Flashes twice (initial condition)
		Lock:1, Unlock:0	LOCK: Flashes once, UNLOCK: No flash
		Lock:0, Unlock:2	LOCK: No flash, UNLOCK: Flash twice
		Lock:2, Unlock:1	LOCK: Flash twice, UNLOCK: Flash once
		Lock:2, Unlock:0	LOCK: Flash twice, UNLOCK: No flash
		Lock:0, Unlock:1	LOCK: No flash, UNLOCK: Flash once
		Lock:0, Unlock:0	No function
Headlight auto cut customize	Adjustment of headlight automatic shutdown function	Disable	No function
Headlight auto cut customize	Adjustment of headlight automatic shutdown function	Enable (C-spec.)	With function (initial condition)
Welcome light	Disabling or enabling welcome light function < Vehicles with welcome light >	Disabled	No function
		Small light	Tail light illuminates. (initial condition)
		Head light	Headlight illuminates.
Coming home light	Disabling or enabling coming home light function	Disabled	No function
		15 sec	Headlight illuminates for 15 seconds.
		30sec	Headlight illuminates for 30 seconds. (initial condition)
		60 sec	Headlight illuminates for 60 seconds.
		180 sec	Headlight illuminates for 180 seconds.

CUSTOMIZATION FUNCTION TABLE

Scheme 48

Scheme 48: HEADLIGHT REMOVAL AND INSTALLATION

Scheme 49

Scheme 49: << A >> HEADLIGHT CONTROL UNIT (HARNESS) REMOVAL < VEHICLES WITH DISCHARGE HEADLIGHT >

Scheme 50

As shown in the figure, use the commercial tool to remove it.
To insert the tool available in the market into the headlight assembly from the opening at the ignitor side, firstly remove the headlight control unit, the socket cover, the ignitor and the earth connector.
Using the commercial tool, make the resin washer sag to push up the harness above the resin washer.
Pull out the harness from the headlight assembly.

<< B >> HEADLIGHT BULB REMOVAL < VEHICLES WITH DISCHARGE HEADLIGHT >

CAUTION

Do not touch the bulb surface with bare hands or dirty gloves. If the bulb surface (glass part) gets dirty, immediately clean it with alcohol or thinner. After drying completely, install the bulb.

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Twist the socket cover to remove.
Disconnect the igniter.
Release the bulb securing spring, and remove the bulb.

Scheme 55

Scheme 55: >> A << HEADLIGHT CONTROL UNIT INSTALLATION < VEHICLES WITH DISCHARGE HEADLIGHT >

Scheme 56

As shown in the figure, doubly wrap the portion in the vinyl tape, from the headlight control unit connector root to the point where the harness separation is hidden.
Install the harness to the headlight assembly. At that time, fitting the harness into the resin washer is unnecessary.

Scheme 57

Scheme 57: HEADLIGHT LEVELING SWITCH REMOVAL AND INSTALLATION

Scheme 58

Scheme 58: LIGHTING CONTROL SENSOR REMOVAL AND INSTALLATION

<< A >> LIGHTING CONTROL SENSOR REMOVAL

While pushing the clamp to the windshield side, pry up the clamp to disengage the right and left claws using the screwdriver (-), and then remove the lighting control sensor.

Scheme 59

Scheme 59: << A >> LIGHTING CONTROL SENSOR REMOVAL

>> A << LIGHTING CONTROL SENSOR INSTALLATION

CAUTION

After executing the lighting control sensor (rain sensor) adaptation, do not touch the lighting control sensor (or do not move it from the fixed position).

Mount the lighting control sensor onto the optical coupler, and then connect the connector.
When reusing the lighting control sensor or when the lighting control sensor is pushed to check the installation condition, install the connector and the lighting control sensor cover and wipe the windshield thoroughly. When the windshield is dry, execute the lighting control sensor (rain sensor) adaptation. < Refer to «LIGHTING CONTROL SENSOR (RAIN SENSOR) ADAPTATION»(/mitsubishi/lancer-evolution/x-2007-2016/remont/wiperwasher-systems/#windshield-wiper-system-and-washer-system-except-lancer-evolution__lighting-control-sensor-rain-sensor-adaptation) >. NOTE: Be careful not to touch the lighting control sensor receiver. (The lighting control sensor receiver has limited resistance to oil.)

HEADLIGHT RELAY (LOW) CHECK < VEHICLES WITH DISCHARGE HEADLIGHT >

Battery voltage	Terminal number	Normal conditions
Not energized	3 - 4	No continuity
With current supply [terminal 2 (+), terminal 1 (-)]	3 - 4	Continuity exists (2 ohms or less)

HEADLIGHT RELAY (LOW) CONTINUITY CHECK

Scheme 60

HEADLIGHT RELAY (HIGH) CHECK

Battery voltage	Terminal number	Normal conditions
Not energized	3 - 4	No continuity
With current supply [terminal 2 (+), terminal 1 (-)]	3 - 4	Continuity exists (2 ohms or less)

HEADLIGHT RELAY (HIGH) CONTINUITY CHECK

Scheme 61

DAYTIME RUNNING LIGHT RELAY CHECK < VEHICLES WITH DISCHARGE HEADLIGHT >

Battery voltage	Terminal number	Normal conditions
Not energized	3 - 4	No continuity
With current supply [terminal 2 (+), terminal 1 (-)]	3 - 4	Continuity exists (2 ohms or less)

DAYTIME RUNNING LIGHT RELAY CONTINUITY CHECK

Scheme 62

HEADLIGHT LEVELING SWITCH CHECK

Measured terminals	Switch position	Resistance value ohms
4 - 6	0	750
	1	1,110
	2	1,470
	3	1,830
	4	2,190
5 - 6	0, 1, 2, 3, 4	2,810

HEADLIGHT LEVELING SWITCH CHECK

Scheme 63

LIGHTING CONTROL SENSOR (LIGHT SENSOR) CHECK

Using the scan tool MB991958, check the LIN data list as follows.

Under the direct sunlight, turn the ignition switch to the ON position and the lighting switch to the AUTO position.
When the lighting control sensor receiver is covered by hand, and if the item No. 7009 (RLS Low beam "ON" request) and the item No. 7011 (RLS Taillight "ON" request) turn from OFF to ON, it is judged normal. NOTE: Before inspection using the scan tool MB991958, wipe off the windshield clearly. Then check that there is no abnormality on the windshield surface where the lighting control sensor is mounted. When covering the lighting control sensor receiver, be careful not to touch the windshield surface (where the lighting control sensor receiver is mounted). (The lighting control sensor receiver has limited resistance to oil.)

BRACKET REPAIR OF HEADLIGHT ASSEMBLY

CAUTION

If damage is present to locations other than the repairable bracket, replace the assembly. Apply a tape to the area around the damaged bracket to prevent damage. During repair work, be careful not to damage the repair bracket installation bosses.

When brackets A, B and C shown in the figure are damaged, a low-cost repair can be performed by mounting a repair bracket.

Scheme 64

OPERATIONS BEFORE REPAIRING BRACKET

Remove the headlight assembly.

Scheme 65

Scheme 65: REPAIR PROCEDURE OF BRACKET A

Scheme 66

Scheme 67

Cut the damaged bracket A so that it has the larger dimension than the dimension shown in the figure from the mounting boss seating face.
Smoothen the bracket cut surface using the sandpaper.
Fix the repair bracket A to the headlight assembly using the tapping screw.

Scheme 68

Scheme 68: REPAIR PROCEDURE OF BRACKET B

Scheme 69

Scheme 70

Cut off the damaged bracket B.
Remove the remaining bracket cut surface using the sandpaper.
Fix the repair bracket B to the headlight assembly using the tapping screw.

Scheme 71

Scheme 71: REPAIR PROCEDURE OF BRACKET C

Scheme 72

Scheme 73

Cut the damaged bracket C so that it has the dimension shown in the figure.
Smoothen the bracket cut surface using the sandpaper.
Fix the repair bracket C to the headlight assembly using the tapping screw.

OPERATIONS AFTER REPAIRING BRACKET

Mount the headlight assembly to the vehicle.
Check that the headlight assembly does not vibrate during driving.
Check whether each light built in the headlight assembly and the headlight leveling system are properly operated.
Perform the headlight aiming adjustment and light intensity measurement.

REPAIR BRACKET PART NUMBER

Part name	Part number
Headlight (LH) bracket kit	8301B173
Headlight (RH) bracket kit	8301B174

REPAIR BRACKET PART NUMBER

Headlight System - Except Lancer Evolution Mitsubishi Lancer Evolution X

Scheme 1

SERVICE SPECIFICATIONS

PRECAUTIONS ON HOW TO USE THE HEADLIGHT ASSEMBLY

SPECIAL TOOLS

Scheme 2

Scheme 3

SERVICE PRECAUTIONS < DISCHARGE HEADLIGHT >

1 - 1 VISUAL CHECK OF CONTROLLER (CASE)

1 - 2 CHECK OF WIRING HARNESS BETWEEN CONTROLLER AND BULB

1 - 3 CHECK OF CONTROLLER OPERATION

2. Troubleshooting procedure for discharge headlight (diagnostic procedure for malfunctions)

SYMPTOM CHART

STANDARD FLOW OF DIAGNOSTIC TROUBLESHOOTING

HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)

Scheme 4

HOW TO READ AND ERASE DIAGNOSTIC TROUBLE CODES

DIAGNOSTIC TROUBLE CODE CHART

Scheme 5

Scheme 6

TROUBLE JUDGMENT

TECHNICAL DESCRIPTION (COMMENT)

TROUBLESHOOTING HINTS

DIAGNOSIS

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

DIAGNOSTIC FUNCTION

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

TROUBLE SYMPTOM CHART

Inspection Procedure 1: None of headlights (low-beam) illuminates

Scheme 19

Scheme 20

Inspection Procedure 2: None of headlights (high-beam) illuminates

Scheme 21

Inspection Procedure 3: The headlights illuminate at low-beam (high-beam does not illuminate) regardless of the lighting switch positions

Inspection Procedure 4: Headlights do not illuminate when the passing switch is operated

Scheme 22

Scheme 23

Inspection Procedure 6: High-beam indicator light does not illuminate normally

Scheme 24

Inspection Procedure 7: The headlight automatic shutdown function does not work normally

OPERATION

Inspection Procedure 8: Daytime running light function does not work normally. < Halogen type headlight >

Scheme 25

Inspection Procedure 8: Daytime running light function does not work normally. < Discharge type headlight >

Scheme 26

COMMENTS ON TROUBLE SYMPTOM

PROBABLE CAUSES

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Inspection Procedure 10: The auto light function does not work normally

Inspection Procedure 13: The turn-signal indicator lights do not illuminate

Inspection Procedure 14: The welcome light function does not work normally

Scheme 38

Inspection Procedure 15: The coming home light function does not work normally

LIN < LIGHTING CONTROL SENSOR (LIGHT SENSOR) >

Scheme 39

Scheme 40

Scheme 41

Scheme 42

LUMINOUS INTENSITY MEASUREMENT

HEADLIGHT BULB (LOW-BEAM) REPLACEMENT < VEHICLES WITHOUT DISCHARGE HEADLIGHT >
