GENERAL INFORMATION

The front suspension is a McPherson strut with coil spring. The shock absorber is gas-filled hydraulic double-acting type.

Scheme 1

INTRODUCTION TO FRONT SUSPENSION DIAGNOSIS

If the front suspension is faulty, the vehicle will not run straightforward or noise will occur. Incorrect wheel alignment, malfunction of strut assembly, stabilizer bar, coil spring, or worn or out-of-balance tires can cause these problems.

FRONT SUSPENSION DIAGNOSIS TROUBLESHOOTING STRATEGY

Use these steps to plan your diagnostic strategy. If you follow them carefully, you will be sure that you have exhausted most of the possible ways to find a front suspension fault.

1. Gather information from the customer.
2. Verify that the condition described by the customer exists.
3. Find and repair the malfunction by following the Symptom Chart.
4. Verify malfunction is eliminated.

SYMPTOM CHART

SYMPTOM CHART

DIAGNOSIS

1. STEP 1. Check the tires. Refer to «DIAGNOSIS»(/mitsubishi/lancer-evolution/ix-2005-2007/remont/wheel-tire-system/#wheel-and-tire-lancer) . Q: Are the tires in normal condition? YES : Replace the tires as necessary, then go to Step 2 . NO : If out of balance, balance the tires as necessary. If excessively worn, replace the tires as necessary and go to Step 5 .
2. STEP 2. Check the wheel alignment. Q: Is the wheel alignment correct? YES : Go to Step 3 . NO : Adjust it, then go to Step 5 .
3. STEP 3. Check the ball joint. Q: Is the ball joint in good condition? YES : Go to Step 4 . NO : Replace it, then go to Step 5 .
4. STEP 4. Check the coil spring. Q: Is the coil spring in good condition? YES : Go to Step 5 . NO : Replace it, then go to Step 5 .
5. STEP 5. Check symptoms. Q: Is the malfunction eliminated? YES : The procedure is complete. NO : Return to Step 1 .

1. STEP 1. Check for broken or deteriorated stabilizer bar. Q: Is the stabilizer bar in good condition? YES : Go to Step 2 . NO : Replace it, then go to Step 3 .
2. STEP 2. Check the strut assembly for damage. Q: Is the strut assembly in good condition? YES : Go to Step 3 . NO : Replace it, then go to Step 3 .
3. STEP 3. Check symptoms. Q: Is the malfunction eliminated? YES : The procedure is complete. NO : Return to Step 1 .

1. STEP 1. Check for improper tire inflation pressure. Refer to «TIRE INFLATION PRESSURE CHECK»(/mitsubishi/lancer-evolution/ix-2005-2007/remont/wheel-tire-system/#wheel-and-tire-lancer__tire-inflation-pressure-check) . Q: Is the tire inflation correct? YES : Go to Step 2 . NO : Adjust it, then go to Step 4 .
2. STEP 2. Check for broken or deteriorated coil spring(s). Q: Are the coil spring(s) broken or deteriorated? YES : Replace the spring(s), then go to Step 4 . NO : Go to Step 3 .
3. STEP 3. Check for strut assembly damage. Q: Is the strut assembly damaged? YES : Replace it, then go to Step 4 . NO : Go to Step 4 .
4. STEP 4. Check symptoms. Q: Is the malfunction eliminated? YES : The procedure is complete. NO : Return to Step 1 .

1. STEP 1. Check for broken or deteriorated coil spring(s). Q: Is the coil spring(s) broken or deteriorated? YES : Replace it, then go to Step 2 . NO : Go to Step 2 .
2. STEP 2. Check symptoms. Q: Is the malfunction eliminated? YES : The procedure is complete. NO : Return to Step 1 .

1. STEP 1. Check for lack of lubrication. Q: Is lubrication inadequate? YES : Lubricate it, then go to Step 5 . NO : Go to Step 2 .
2. STEP 2. Check the tightened parts for looseness as well as the bushings for wear. Q: Are the tightened parts and bushings in good condition? YES : Go to Step 3 . NO : Replace it, then go to Step 5 .
3. STEP 3. Check for broken coil spring. Q: Is the coil spring broken? YES : Replace it, then go to Step 5 . NO : Go to Step 4 .
4. STEP 4. Check for strut assembly damage. Q: Is the strut assembly damaged? YES : Replace it, then go to Step 5 . NO : Go to Step 5 .
5. STEP 5. Check symptoms. Q: Is the malfunction eliminated? YES : The procedure is complete. NO : Return to Step 1 .

SPECIAL TOOLS

SPECIAL TOOLS CHART TOOL TOOL NUMBER AND NAME SUPERSESSION APPLICATION MB991004 Wheel alignment gauge attachment MB991004-01 or General service tool Wheel alignment measurement A: MB991237 Spring compressor body B: MB991238 Arm set MIT221369 or general service tool Front coil spring compression MB991680 Wrench set A: MB991681 Wrench B: MB991682 Socket - Strut assembly disassembly and reassembly MB991006 Preload socket MB990228-01 Lower arm ball joint breakaway torque check MB990800 Ball joint dust cover installer MB990800-01or General service tool Lower arm ball joint dust cover installation MB990883 Rear suspension bushing arbor MB990883-01 or general service tool Lower arm bushing removal and press-fitting MB990971 Rear wheel bearing & installer joint - MB990887 Ring - MB990890 Rear suspension bushing base MB990890-01 or general service tool MB991897 Ball joint remover MB991113-01 or general service tool Tie rod end Knuckle disconnection NOTE: Steering linkage puller (MB990635 or MB991113)is also used to disconnect knuckle and tie rod end ball joint

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

FRONT WHEEL ALIGNMENT CHECK AND ADJUSTMENT

Required Special Tool

1. MB991004: Wheel Alignment Gauge Attachment. Measure wheel alignment with alignment equipment on a level surface. The front suspension, steering system, and wheels should be serviced to normal condition before measuring wheel alignment.

TOE-IN

Standard value: 1 +/- 2 mm (0.04 +/- 0.08 inch)

Scheme 12

1. Adjust the toe-in by undoing the clip and jam nut, and turning the left and right tie rod turnbuckles by the same amount (in opposite directions). NOTE: The toe will move out as the left turnbuckle is turned toward the front of the vehicle and the right turnbuckle is turned toward the rear of the vehicle.
2. Install the clip and tighten the jam nut to the specified torque. Tightening torque: 40 +/- 5 N.m (30 +/- 3 ft-lb)
3. Confirm that the toe-in is at the standard value.
4. Use a turning radius gauge to check that the steering angle is at the standard value.

STEERING ANGLE

Standard value

STEERING ANGLE SPECIFICATIONS

CAMBER, CASTER AND KINGPIN INCLINATION

Standard value

CAMBER, CASTER AND KINGPIN INCLINATION SPECIFICATIONS

Note. Camber and caster are preset at the factory and cannot be adjusted. For vehicles with aluminum type wheels, attach the camber/caster/kingpin gauge to the drive shaft by using special tool MB991004. Tighten special tool MB991004 to the same torque 245 +/- 29 N.m (181 +/- 21 ft-lb) as the drive shaft nut.

Scheme 13

LOWER ARM BALL JOINT END PLAY CHECK

1. Raise the vehicle.
2. Remove the stabilizer bar from the lower arm assembly.
3. Move the lower arm up and down with your hands to check for an excessive play in the axial direction of the ball joint. If there is an excessive play, replace the lower arm assembly.

BALL JOINT DUST COVER CHECK

1. Press the dust cover with your finger to check that there are no cracks or damage in the dust cover.
2. If the dust cover is cracked or damaged, replace the lower arm assembly.

Note. If the dust cover is cracked or damaged, it is possible that there may also be damage to the ball joint.

REMOVAL AND INSTALLATION

Scheme 14

INSPECTION

1. Check for oil leaks from the strut assembly.
2. Check the strut assembly for damage or deformation.

Scheme 15

Required Special Tools

1. MB991237: Spring Compressor
2. MB991238: Arm Set
3. MB991680: Wrench Set

Scheme 16

1. Use special tools MB991237 and MB991238 to compress the coil spring. WARNING: To prevent the piston rod jam nut inside the strut from loosening, do not use an impact wrench when the jam nut is loosened.
2. Use special tools MB991681 and MB991682 to secure the strut, and then remove the jam nut.

Scheme 17

<< B >> STRUT ASSEMBLY DISPOSAL

The gas must be discharged from the strut assembly before discarding it. Place the assembly horizontally with its piston rod extended. Then drill a hole of approximately 3 mm (0.1 inch) in diameter at the location shown in the illustration and discharge the gas.

Scheme 18

>>A<< UPPER SPRING SEAT INSTALLATION

If the upper spring seat peeled off the pad, adhere the seat and the pad with a double-sided tape.

Scheme 19

Scheme 20

1. Ensure that the bearing is seated correctly. CAUTION: Do not use an impact wrench to tighten the bolt of special tool MB991237, otherwise the special tool will break.
2. Install special tools MB991237 and MB991238 to the strut assembly same as its removal.
3. While the coil spring is being compressed by the special tools, temporarily tighten the jam nut.
4. Align the hole in the strut assembly lower spring seat with the hole in the upper spring seat. NOTE: Using a rod as shown facilitates the alignment.
5. Align both ends of the coil spring with the grooves in the spring seat, and then loosen the special tools. CAUTION: Do not use an impact wrench to tighten the jam nut, otherwise the jam nut will not be tightened securely.
6. Using special tools MB991681 and MB991682, tighten the jam nut to 60 +/- 10 N.m (45 +/- 7 ft-lb).

Scheme 21

1. Check the bearing for wear or rust.
2. Check the rubber parts for damage or deterioration.
3. Check the spring for deformation, deterioration or damage.
4. Check the shock absorber for deformation.

Scheme 22

Required Special Tool

1. MB991006: Preload Socket

<< A >> LOWER ARM AND CROSSMEMBER DISCONNECTION

Lift the transaxle with a garage jack, and then withdraw the front mounting bolt on the left lower arm assembly.

Scheme 23

>>A<< JAM NUT INSTALLATION

Tighten the jam nut until the bolt protruding length meets the standard value.

Standard value (A): 22 +/- 1.5 mm (0.87 +/- 0.06 inch)

Scheme 24

1. Check the bushing for wear and deterioration.
2. Check the lower arm for bend or breakage.
3. Check all bolts for condition and straightness.

LOWER ARM BALL JOINT BREAKAWAY TORQUE CHECK

1. After shaking the ball joint stud several times, use special tool MB991006 to measure the breakaway torque of the ball joint. Standard value: 0 - 3.9 N.m (0 - 35 in-lb)
2. If the measured value is not within the standard value, or if the ball joint is difficult to turn or does not turn smoothly, replace the lower arm assembly.

LOWER ARM BALL JOINT DUST COVER CHECK

1. Check the dust cover for cracks or damage by pushing it with your finger.
2. If the dust cover is cracked or damaged, replace the lower arm.

Note. Cracks or damage to the dust cover may cause damage to the ball joint. When it is damaged during service work, replace the dust cover.

Scheme 25

BALL JOINT DUST COVER REPLACEMENT

Required Special Tool

1. MB990800: Ball Joint Remover and Installer

If the dust cover is damaged accidentally during service work, replace the dust cover as follows

1. Remove the dust cover.
2. Apply multipurpose grease to the lip and inside of the dust cover.
3. Using special tool MB990800, drive in the dust cover until it is fully seated.
4. Check the dust cover for cracks or damage by pushing it with your finger.

Scheme 26

LOWER ARM REAR BUSHING REPLACEMENT

Required Special Tools

1. MB990883: Rear suspension bushing arbor
2. MB990971: Rear wheel bearing and Installer joint1
3. MB990887: Ring
4. MB990890: Rear suspension bushing base

Replace the bushing as follows

Scheme 27

Scheme 28

1. Use special tools MB990883, MB990971, MB990887, and MB990890 to drive out the bushing.
2. Position the bushing so that its projection is as shown, and then use special tools MB990883, MB990971, MB990887, and MB990890 to press in the bushing.
3. Press the bushing until its outer tube is flush with the lower arm assembly surface.

Scheme 29

Scheme 30

Required Special Tool

1. MB991897: Ball Joint Remover

<< A >> TIE ROD END AND KNUCKLE DISCONNECTION

Scheme 31

1. Install the special tool MB991897 as shown in the figure.
2. After turning the bolt and knob to adjust the insert arms of the special tool MB991897 in parallel, tighten the bolt by hand and confirm that the insert arms are parallel. NOTE: When adjusting the insert arms in parallel, turn the knob in the direction shown in the figure.
3. Tighten the bolt with a wrench to disconnect the tie rod end.

Scheme 32

<< B >> FIXTURE/BUSHING/STABILIZER BAR REMOVAL

Carry out the following operations to ensure working space in order to remove the fixture, the bushing and the stabilizer bar.

1. Use a transmission jack to hold the crossmember, and then remove the crossmember mounting nuts and bolts. CAUTION: Be careful not to lower the crossmember excessively, otherwise the power steering return hose bracket may deform.
2. Lower the crossmember until the fixture, the bushing and the stabilizer bar can be removed.

Scheme 33

>>A<< STABILIZER BAR/BUSHING/FIXTURE INSTALLATION

Align the stabilizer bar identification mark with the right end of the bushing.

Scheme 34

>>B<< JAM NUT INSTALLATION

Tighten the jam nut until its protruding length meets the standard value.

Standard value (A): 22 +/- 1.5 mm (0.87 +/- 0.06 inch)

Scheme 35

FASTENER TIGHTENING SPECIFICATIONS

FASTENER TIGHTENING SPECIFICATIONS

COIL SPRING

COIL SPRING SPECIFICATIONS

SERVICE SPECIFICATIONS

SERVICE SPECIFICATIONS
