GENERAL DESCRIPTION
Inertia principal axes system is incorporated into the engine mount system.
- The liquid-filled mount system have been adopted for engine mounting and transaxle mounting to improve ride feeling by optimizing the insulator.
- Installation of roll stopper in the upper area has reduced engine rolling. Furthermore, enlargement of insulator diameter has reduced idle vibration.
Scheme 911
SPECIAL TOOL
SPECIAL TOOL TOOL TOOL NUMBER AND NAME SUPERSESSION APPLICATION MB991897 Ball joint remover MB991113-01, MB990635-01 or General service tool Knuckle and tie rod end ball joint disconnection NOTE: Steering linkage puller (MB990635 or MB991113)is also used to disconnect knuckle and tie rod end ball joint
Scheme 912
REMOVAL AND INSTALLATION
| CAUTION | *: Indicates parts which should be initially tightened, and then fully tightened after placing the vehicle horizontally and loading the full weight of the engine on the vehicle body. |
Scheme 913
>> A << ENGINE MOUNTING CUSHION STOPPER INSTALLATION
Arrow marks on the engine mounting cushion stopper should face the shown direction.
Note. Disregard F and R stamped as a shared part.
Scheme 914
INSPECTION
- Check the engine mounting insulator for cracks, separation or deformation.
- Check the engine mounting cushion stoppers for deformation.
| CAUTION | *: Indicates parts which should be initially tightened, and then fully tightened after placing the vehicle horizontally and loading the full weight of the engine on the vehicle body. |
Scheme 915
>> A << TRANSAXLE MOUNTING STOPPER INSTALLATION
Install the transaxle mounting stopper so that its arrow points upward.
Scheme 916
- Check the transaxle mounting insulator for cracks, separation or deformation.
- Check the transaxle mounting stoppers for deformation.
| CAUTION | *: Indicates parts which should be initially tightened, and then fully tightened after placing the vehicle horizontally and loading the full weight of the engine on the vehicle body. |
Scheme 917
>> A << ENGINE FRONT ROLL STOPPER BRACKET INSTALLATION
Install the front roll stopper so that its hole points towards the front side of the vehicle.
Scheme 918
- Check the engine roll stopper insulators for cracks, separation or deformation.
Scheme 919
Required Special Tool
- MB991897: Ball Joint Remover
<< A >> LOWER ARM ASSEMBLY REMOVAL
Lift the transaxle with a transmission jack, and then withdraw the front mounting bolt on the left lower arm assembly.
Scheme 920
<< B >> TIE ROD END AND KNUCKLE DISCONNECTION
| CAUTION | Do not remove the nut from ball joint. Loosen it and use special tool MB991897 to avoid possible damage to ball joint threads. Hang special tool MB991897 with cord to prevent it from falling. |
Scheme 921
Scheme 922
- Install the special tool MB991897 as shown in the figure.
- Turn the bolt and knob as necessary to make the jaws of special tool MB991897 parallel, tighten the bolt by hand and confirm that the jaws are still parallel. NOTE: When adjusting the jaws in parallel, make sure the knob is in the position shown in the figure.
- Tighten the bolt with a wrench to disconnect the tie rod end.
<< C >> FRONT AXLE NO.1 CROSSMEMBER ASSEMBLY REMOVAL
Retain the crossmember with a transmission jack, and then remove the crossmember mounting bolt.
Scheme 923
>> A << STABILIZER BAR INSTALLATION
Align the identification color on the left side of the stabilizer bar with the right end of the bushing.
Scheme 924
- Check the front axle No.1 crossmember for cracks or damage.
FASTENER TIGHTENING SPECIFICATIONS
| ITEM | SPECIFICATION |
|---|---|
| Crossmember | |
| Engine rear roll stopper rod bracket bolt | 45 +/- 5 N. m (34 +/- 3 ft-lb) |
| Engine rear roll stopper rod nut | 52 +/- 7 N. m (39 +/- 5 ft-lb) |
| Front axle No.1 crossmember bolt | 49 +/- 10 N. m (37 +/- 7 ft-lb) |
| Front axle No.1 crossmember nut | 167 +/- 9 N. m (123 +/- 7 ft-lb) |
| Lower arm and front axle No.1 crossmember connecting bolt front | 186 +/- 10 N. m (138 +/- 7 ft-lb) |
| Lower arm and front axle No.1 crossmember connecting bolt rear | 167 +/- 9 N. m (123 +/- 7 ft-lb) |
| Lower arm and knuckle connecting nut | 108 +/- 10 N. m (80 +/- 7 ft-lb) |
| Pressure hose eye bolt | 57 +/- 7 N. m (42 +/- 5 ft-lb) |
| Pressure hose bolt | 12 +/- 2 N. m (102 +/- 22 in-lb) |
| Return hose and return pipe bolt | 12 +/- 2 N. m (102 +/- 22 in-lb) |
| Return hose and return pipe nut | 15 +/- 3 N. m (11 +/- 2 ft-lb) |
| Stabilizer bar bracket bolt | 21 +/- 4 N. m (16 +/- 2 ft-lb) |
| Stabilizer link nut | 39 +/- 5 N. m (29 +/- 3 ft-lb) |
| Steering gear and linkage bolt | 70 +/- 10 N. m (52 +/- 7 ft-lb) |
| Steering shaft assembly and gear box connecting bolt | 18 +/- 2 N. m (13 +/- 2 ft-lb) |
| Tie rod end and knuckle connecting nut | 25 +/- 5 N. m (19 +/- 3 ft-lb) |
| Engine mounting | |
| Engine mounting insulator nut | 67 +/- 7 N. m (50 +/- 5 ft-lb) |
| Engine mounting nut | 98 +/- 10 N. m (73 +/- 7 ft-lb) |
| Power steering oil pressure hose bolt | 12 +/- 2 N. m (102 +/- 22 in-lb) |
| Engine roll stopper, centermember | |
| Engine front roll stopper bracket bolt | 45 +/- 5 N. m (34 +/- 3 ft-lb) |
| Engine front roll stopper bracket nut | 52 +/- 7 N. m (39 +/- 5 ft-lb) |
| Engine rear roll stopper rod bracket bolt | 45 +/- 5 N. m (34 +/- 3 ft-lb) |
| Engine rear roll stopper rod nut | 52 +/- 7 N. m (39 +/- 5 ft-lb) |
| Front axle crossmember bar bolt | 49 +/- 10 N. m (37 +/- 7 ft-lb) |
| Front suspension centermember bolt | 69 +/- 10 N. m (51 +/- 7 ft-lb) |
| Transaxle case front roll stopper bracket bolt | 70 +/- 10 N. m (52 +/- 7 ft-lb) |
| Transaxle case rear roll stopper bracket bolt | 70 +/- 10 N. m (52 +/- 7 ft-lb) |
| Transaxle mounting | |
| Transaxle mounting insulator nut | 47 +/- 7 N. m (35 +/- 5 ft-lb) |
| Transaxle mounting nut < 5M/T > | 82 +/- 7 N. m (61 +/- 5 ft-lb) |
| Transaxle mounting bolt < 6M/T > | 82 +/- 7 N. m (61 +/- 5 ft-lb) |
FASTENER TIGHTENING SPECIFICATIONS
