IDENTIFICATION
| WARNING | Modifications or improper maintenance, including incorrect removal and installation of the Supplemental Restraint System (SRS), can adversely affect system performance. DO NOT cover, obstruct or change the steering wheel horn pad in any way, as such action could cause improper function of the system. Use only plain water when cleaning the horn pad. Solvents or cleaners could adversely affect the air bag cover and cause improper deployment of the system. To avoid injury from accidental air bag deployment, see PRECAUTIONS BEFORE SERVICE in GENERAL INFORMATION article. |
| WARNING | When battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See COMPUTER RELEARN PROCEDURES in GENERAL INFORMATION article. |
| CAUTION | Disconnect negative battery cable before servicing any air bag system, steering column or passenger side dash component. After any repair, turn ignition key to the ON position from passenger's side of vehicle in case of accidental air bag inflation. |
COMPONENT LOCATION
For fuse box locations, refer to illustrations below.
Scheme 5
Scheme 6
ENGINE COMPARTMENT
For fuse locations, refer to illustrations below.
Scheme 7
Scheme 8
Scheme 9
| No. | POWER SUPPLY CIRCUIT | NAME | RATED CAPACITY (A) | HOUSING COLOR | LOAD CIRCUIT |
|---|---|---|---|---|---|
| 1 | Battery/Generator (Fusible link No.26) | Fusible link | 60 | Yellow | Fuse No.15, 19, 20 (in junction block) circuit |
| 2 | Battery/Generator (Fusible link No.26) | Fusible link | 50 | Red | Fan control module |
| 3 | Battery/Generator (Fusible link No.26) | Fusible link | 60 | Yellow | ABS-ECU |
| 4 | Battery/Generator (Fusible link No.26) | Fusible link | 40 | Green | Ignition switch circuit |
| 5 | Battery/Generator (Fusible link No.26) | Fusible link | 30 | Pink | Power window main switch, power window sub switch, and sunroof motor assembly |
| 6 | Battery/Generator (Fusible link No.26) | Fuse | 15 | Blue | Fog light, combination meter and fog light relay |
| 7 | Battery/Generator (Fusible link No.26) | Fuse | 10 | Red | Horn (High), horn (Low), horn relay and horn |
| 8 | Battery/Generator (Fusible link No.26) | Fuse | 20 | Yellow | MFI relay, throttle actuator control motor relay, evaporative emission ventilation solenoid valve, injector, EGR solenoid valve, camshaft position sensor, crankshaft position sensor, evaporative emission purge solenoid valve, mass air flow sensor, powertrain control module, idle air control motor, engine control module, exhaust gas recirculation valve and engine oil control valve |
| 9 | Battery/Generator (Fusible link No.26) | Fuse | 10 | Red | A/C compressor assembly |
| 10 | Battery/Generator (Fusible link No.26) | Fuse | 15 | Blue | ABS-ECU, powertrain control module, high-mounted stoplight, rear combination light, auto-cruise control-ECU, engine control module, and rear combination light assembly (Stop: LH, RH) |
| 11 | Battery/Generator (Fusible link No.26) | Fuse | |||
| 12 | Battery/Generator (Fusible link No.26) | Fuse | 7.5 | Brown | Generator |
| 13 | Battery/Generator (Fusible link No.26) | Fuse | 10 | Red | ETACS-ECU, front turn-signal light, rear combination light, side turn-signal light and combination meter |
| 14 | Battery/Generator (Fusible link No.26) | Fuse | 20 | Yellow | A/T control solenoid valve assembly and powertrain control module |
| 15 | Battery/Generator (Fusible link No.26) | Fuse | 20 | Yellow | Fuel pump module, fuel pump relay (1), (2) and fuel level sensor |
| 16 | Front-ECU (Headlight relay: High) | Fuse | 10 | Red | Headlight (RH) |
| 17 | Front-ECU (Headlight relay: High) | Fuse | 10 | Red | Headlight (LH) |
| 18 | Front-ECU (Headlight relay: Low) | Fuse | 10 | Red | Headlight (RH) |
| 19 | Front-ECU (Headlight relay: Low) | Fuse | 10 | Red | Headlight (LH) |
| 20 | Front-ECU (Taillight relay) | Fuse | 7.5 | Brown | Position light (RH), rear combination light assembly (Tail light: RH), fog light switch, A/C-ECU, clock, cigarette lighter illumination light, heater control unit, ashtray illumination light, A/T selector lever position illumination light, rheostat, radio and CD player and hazard warning light switch |
| 21 | Front-ECU (Taillight relay) | Fuse | 7.5 | Brown | Position light (LH), rear combination light assembly (Tail light: LH), license plate light, sunroof motor assembly and combination meter |
| 22 | Battery/Generator (Fusible link No.26) | Fuse | 10 | Red | Radio and CD player, column switch, ETACS-ECU, clock, front-ECU, door switch (Front: LH), key reminder switch and combination meter |
| 23 | Ignition switch (ACC) | Fuse | 10 | Red | Clock, ETACS-ECU and radio and CD player |
| 24 | Battery/Generator (Fusible link No.26) | Fuse | 20 | Yellow | Audio amplifier |
| 25 | Battery/Generator (Fusible link No.26) | Fuse | |||
| 26 | Generator | Fusible link | 100 | Battery, Fusible link No.1, 2, 3, 4, 5, Fuse No.6, 7, 8, 9, 10, 12, 13, 14, 15, 22, 24 (in relay box) and front-ECU. |
IDENTIFYING FUSES (ENGINE COMPARTMENT)
Some fuses may not be installed on your vehicle, depending on the vehicle model or specifications.
PASSENGER COMPARTMENT
For fuse location and values, refer to illustrations below.
Scheme 10
Scheme 11
| NO. | POWER SUPPLY CIRCUIT | FUSE TYPE | RATED CAPACITY (A) | HOUSING COLOR | LOAD CIRCUIT |
|---|---|---|---|---|---|
| 1 | Ignition switch (IG1) | Fuse | 10 | Red | Ignition coil (1), (2), (3) and ignition coil (4) |
| 2 | Ignition switch (IG1) | Fuse | 7.5 | Brown | Column switch, combination meter, ETACS-ECU, SRS-ECU, and vehicle speed sensor |
| 3 | Ignition switch (IG1) | Fuse | 7.5 | Brown | A/T control relay, input shaft speed sensor, output shaft speed sensor, vehicle speed sensor, backup light switch, SRS-ECU and transmission range switch |
| 4 | Ignition switch (IG1) | Fuse | 7.5 | Brown | Auto-cruise control-ECU |
| 5 | Ignition switch (IG2) | Fuse | 7.5 | Brown | A/C-ECU, blower relay, rear window defogger relay, front-ECU, heater control unit, combination meter, A/C compressor clutch relay, ETACS-ECU, column switch and outside/inside air selection damper control motor |
| 6 | Rear window defogger relay | Fuse | 7.5 | Brown | Remote controlled mirror (Mirror heater) |
| 7 | Ignition switch (ACC) | Fuse | 20 | Yellow | Front-ECU and windshield wiper motor |
| 8 | Ignition switch (IG1) | Fuse | 7.5 | Brown | Fuel pump relay (1), fuel pump relay (2), engine control module and powertrain control module |
| 9 | Ignition switch (ACC) | Fuse | 15 | Blue | Cigarette lighter |
| 10 | Ignition switch (ACC) | Fuse | |||
| 11 | Ignition switch (ACC) | Fuse | 7.5 | Brown | Remote controlled mirror switch |
| 12 | Ignition switch (IG2) | Fuse | 7.5 | Brown | ABS-ECU and sunroof motor assembly |
| 13 | Ignition switch (ACC) | Fuse | |||
| 14 | Ignition switch (ACC) | Fuse | 15 | Blue | ETACS-ECU |
| 15 | Fusible link No.1 | Fuse | 15 | Blue | Data link connector |
| 16 | Fusible link No.1 | Fuse | |||
| 17 | Fusible link No.1 | Fuse | |||
| 18 | Fusible link No.1 | Fuse | |||
| 19 | Fusible link No.1 | Fuse | 30 | Green | Blower motor and blower relay |
| 20 | Fusible link No.1 | Fuse | 30 | Green | Rear window defogger |
| 21 | Fusible link No.1 | Fuse | 20 | Yellow | Sunroof motor assembly |
| 22 | Fuse | ||||
| 23 | Fuse | ||||
| 24 | Fuse |
IDENTIFYING FUSES (PASSENGER COMPARTMENT)
Some fuses may not be installed on your vehicle, depending on the vehicle model or specifications.
The table above shows the main equipment corresponding to each fuse.
The fuse box does not contain spare 7.5A 10A and 15A fuses. If a fuse of one of these capacities blows, replace it temporarily by borrowing a fuse of correct rating from
- 7.5A: Door mirror heater
- 10A: Dome light (Engine Compartment)
- 15A: Cigarette lighter (Power outlet)
Replace the borrowed fuse as soon as possible.
FUSE IDENTIFICATION CHART
| Fuse Rating | Color |
|---|---|
| 7.5A | Brown |
| 10A | Red |
| 15A | Blue |
| 20A | Yellow (Fuse Type) Light Blue (Fusible Link Type) |
| 25A | Natural (White) |
| 30A | Green (Fuse Type) Pink (Fusible Link Type) |
| 40A | Green |
| 60A | Yellow |
| 80A | White |
