Scheme 247
Scheme 247: A/T CONTROL COMPONENT LAYOUT
Scheme 248
Scheme 249
SELECTOR LEVER OPERATION CHECK
- Apply the parking brake, and check that the selector lever moves smoothly and accurately to each position.
- Check that the engine starts when the selector lever is at the "N" or "P" position, and that it does not start when the selector lever is in any other position.
- Start the engine, release the parking brake, and check that the vehicle moves forward when the selector lever is moved from "N" position to "D", "3", "2" or "L" position, and that the vehicle reverses when the selector lever is moved to "R" position.
- Stop the engine.
- Turn the ignition switch to the "ON" position, and check that the backup lamp illuminates when the selector lever is shifted from "P" to "R" position.
Scheme 250
Scheme 251
Scheme 251: KEY INTERLOCK MECHANISM CHECK
Scheme 252
Scheme 253
- Carry out the following inspection.
- When any of the above checks are not normal, adjust the key interlock cable in following procedure. Remove the floor console. Shift the selector lever to "P" position. Turn the ignition key to "LOCK" (OFF) position. Loosen the locking nut of the key interlock cable. Tightening torque: 11 N.m (97 in-lb) Push the cable joint on the lock cam gently toward the arrow until the cable stops. Tighten the locking nut. Install the floor console.
- After adjusting, check the operation once more. If the operation is still incorrect, replace the key interlock cable. See «A/T KEY INTERLOCK AND SHIFT LOCK MECHANISMS»(ref-171231-S24410427372005020100000).
Scheme 254
Scheme 254: SHIFT LOCK MECHANISM CHECK
Scheme 255
- Carry out the following inspections.
- When the above operations are defective, adjust the shift lock cable as follows: Remove the floor console. see scheme 32 Shift the selector lever to "P" position. Loosen the locking nut of shift lock cable. Tighten the locking nut so that the end of the shift lock cable comes above the red marking of the lock cam. Tightening torque: 11 N.m (97 in-lb) Install the floor console. see scheme 32
- After adjusting, check the operation once more. If the operation is still incorrect, replace the shift lock cable. See «A/T KEY INTERLOCK AND SHIFT LOCK MECHANISMS»(ref-171231-S24410427372005020100000).
