Scheme 1
Scheme 2
OIL PRESSURE WARNING LIGHT
Light comes on with the ignition switch in the "ON" position as a bulb check, but should go out shortly after engine is started. If light remains on or comes on while driving, it indicates low oil pressure and possible system malfunction. Have the system checked and serviced immediately. Do not operate vehicle until cause is located and corrected.
ALTERNATOR WARNING LIGHT
Light comes on with the ignition switch in the "ON" position as a bulb check and goes out after engine is started. If light remains on or comes on while driving, it indicates possible fault in the electrical charging system. The alternator belt may be loose or broken. Have the system checked and serviced promptly. Do not drive vehicle if alternator belt is loose or broken.
"BRAKE" WARNING LIGHT
Light comes on with the ignition switch in the "ON" position as a bulb check and goes out after engine is started. Light will also come on with the parking brake fully or partially engaged and it will blink on and off if car is being driven with parking brake engaged. If light remains on or comes on at any other time, it indicates low brake fluid level in the master cylinder reservoir or the parking brake switch may be damaged. Have the system checked and serviced immediately if brake fluid level is low. Do not continue driving if further trouble is experienced.
"CHECK ENGINE" WARNING LIGHT (IF EQUIPPED)
Light is designed to come on briefly with the ignition switch in the "ON" position as a bulb check. If light remains on or comes on while driving, it indicates fault in the emission control system. An emission component may not be functioning properly and the system should be checked and serviced as soon as possible.
ANTI-LOCK BRAKE WARNING LIGHT (IF EQUIPPED)
Light comes on with the ignition switch in the "ON" position as a bulb check and goes out after engine is started. If light remains on or comes on while driving, it indicates a possible malfunction in the anti-lock braking system. Have the system checked and serviced promptly. The regular braking system will still operate normally, but without anti-lock function.
CHARGING SYSTEM WARNING LIGHT
Light illuminates when ignition key is turned to ON position (engine off). When engine is started, light should go off. If it remains on, battery charging system may be malfunctioning.
THEFT-ALARM STATUS LIGHT
SECURITY light will illuminate for approximately 20 seconds after vehicle doors are locked to indicate that the anti-theft alarm system is armed.
4-WHEEL STEERING FLUID LEVEL WARNING LIGHT (IF EQUIPPED)
4WS light illuminates when power steering fluid level is low. Normally, light comes on when ignition key is turned to START position and goes out when key is moved to ON position.
A/T OIL TEMPERATURE WARNING LIGHT
Automatic transaxle oil temperature light illuminates when fluid temperature becomes abnormally high. If warning light does not go out with reduced engine speed and acceleration rate, stop vehicle and idle engine until light goes out.
