VIN LOCATION
The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.
VIN CODE ID EXPLANATION
Numbers preceding the explanations in the legend below refer to the sequence of characters as listed on VIN identification label. See VIN example below.
VIN Code ID Explanation. Scheme 3
SEVERE & NORMAL SERVICE DEFINITIONS
Note. Use the Severe Service schedule if the vehicle to be serviced is operated under ANY (one or more) of these conditions
Service is recommended at mileage intervals based on vehicle operation. Service schedules are based on the following primary operating conditions
Normal Service
- Driven More Than 10 Miles Daily
- No Operating Conditions From Severe Service Schedule
Severe Service (Unique Driving Conditions)
- Short Trips In Freezing Temperatures
- Towing Or Commercial Use
- Driving In Salty Or Sandy Areas
- Severe Dust Conditions
- Hot Weather, Stop-And-Go Driving
- Extensive Idling
CAMSHAFT TIMING BELT
| CAUTION | Failure to replace a faulty camshaft timing belt may result in serious engine damage. |
The condition of camshaft drive belts should always be checked on vehicles which have more than 50,000 miles. Although some manufacturers do not recommend belt replacement at a specified mileage, others require it at 60,000-100,000 miles. A camshaft drive belt failure may cause extensive damage to internal engine components on most engines, although some designs do not allow piston-to-valve contact. These designs are often called "Free Wheeling".
Many manufacturers changed their maintenance and warranty schedules in the mid-1980's to reflect timing belt inspection and/or replacement at 50,000-60,000 miles. Most service interval schedules in this manual reflect these changes.
Belts or components should be inspected and replaced if any of the following conditions exist
- Cracks Or Tears In Belt Surface
- Missing, Damaged, Cracked Or Rounded Teeth
- Oil Contamination
- Damaged Or Faulty Tensioners
- Incorrect Tension Adjustment
Replace camshaft timing and balancer belts at 60,000 mile intervals.
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
SERVICE LABOR TIMES
Note. For 1990 and newer vehicles, labor times are provided, where available, within appropriate SERVICE INTERVAL table in SCHEDULED SERVICES article.
WHEEL & TIRE SPECIFICATIONS
Tire specifications are imprinted on the tire side wall. The recommended cold tire inflation pressures are listed on a label attached to the rear face of the driver's door.
| CAUTION | DO NOT mix tires of different design such as radial ply with bias or bias-belted tires. Mixing tire types will adversely affect road handling and may lead to loss of vehicle control. DO NOT use tire chains on rear wheels. |
TORQUE SPECIFICATIONS
| Wheel Type | Ft. Lbs. (N.m.) | |
|---|---|---|
| 1985-86 Models | ||
| Steel | 50-57 (70-80) | |
| Aluminum | 65-80 (88-108) | |
| 1987-94 Models | ||
| Steel & Aluminum | 65-80 (88-108) | |
| 1995-96 Models | ||
| Steel & Aluminum | 65-80 (90-110) | |
TORQUE SPECIFICATIONS
BATTERY SPECIFICATIONS
| CAUTION | When battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION Section. |
Battery is located in the engine compartment. All 1985-88 vehicles are delivered with a permanently sealed maintenance-free battery. On 1989-94 models, it may be necessary to add distilled water if vehicle is driven under severe conditions. Charge condition for all models can be checked by a visual test indicator on top of battery.
SUPPLEMENTAL RESTRAINT SYSTEM (SRS) AIR BAG SYSTEM
Note. See the AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT Section.
The SRS has no user-servicable parts. Always have servicing done by an authorized dealer.
When performing maintenance on air bag equipped vehicles always observe proper safety precautions.
| WARNING | To avoid injury from accidental air bag deployment, read and carefully follow all warnings and service precautions. See appropriate AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT section. |
| CAUTION | Disconnect negative battery cable before servicing any air bag system, steering column or passenger side dash component. After any repair, turn ignition key to the ON position from passenger's side of vehicle in case of accidental air bag inflation |
ANTI-LOCK BRAKE SYSTEM (ABS)
| CAUTION | Never mix different diameter tires. On loose or uneven surfaces, the ABS system may require longer stopping distances than conventional brake systems. Exercise caution when removing mud or snow from the wheels so as not to damage the ABS wiring or speed sensors. |
BATTERY WARNING
| WARNING | When battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See appropriate COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section below. |
REPLACING BLOWN FUSES
Before replacing a blown fuse, remove ignition key, turn off all lights and accessories to avoid damaging the electrical system. Be sure to use fuse with the correct indicated amperage rating. The use of an incorrect amperage rating fuse may result in a dangerous electrical system overload.
BRAKE PAD WEAR INDICATOR
Indicator will cause a squealing or scraping noise, warning that brake pads need replacement.
CATALYTIC CONVERTER
Continued operation of vehicle with a severe malfunction could cause converter to overheat, resulting in possible damage to converter and vehicle.
COOLANT (PROPYLENE-GLYCOL FORMULATIONS)
| CAUTION | To avoid possible damage to vehicle use only ethylene-glycol based coolants with a mixture ratio from 44-68% anti-freeze. DO NOT use 100% anti-freeze as it will cause the formation of cooling system deposits. This results in coolant temperatures of over 300° F (149°C) which can melt plastics. 100% anti-freeze has a freeze point of only -8° F (-22°C). |
| CAUTION | Propylene-Glycol Mixtures has a smaller temperature range than Ethylene-Glycol. The temperature range (freeze-boil) of a 50/50 Anti-Freeze/Water Mix is as follows: Propylene-Glycol -26° F (-32°C) - 257° F (125°C) Ethylene-Glycol -35° F (-37°C) - 263° F (128°C) |
| CAUTION | Propylene-Glycol/Ethylene-Glycol Mixtures can cause the destabilization of various corrosion inhibitors. Also Propylene-Glycol/Ethylene-Glycol has a different specific gravity than Ethylene-Glycol coolant, which will result in inaccurate freeze point calculations. |
ELECTROSTATIC DISCHARGE SENSITIVE (ESD) PARTS
| WARNING | Many solid state electrical components can be damaged by static electricity (ESD). Some will display a warning label, but many will not. Discharge personal static electricity by touching a metal ground point on the vehicle prior to servicing any ESD sensitive component. |
ENGINE OIL
| CAUTION | Never use non-detergent or straight mineral oil. |
FUEL SYSTEM SERVICE
| WARNING | Relieve fuel system pressure prior to servicing any fuel system component (fuel injection models). |
HALOGEN BULBS
| WARNING | Halogen bulbs contain pressurized gas which may explode if overheated. DO NOT touch glass portion of bulb with bare hands. Eye protection should be worn when handling or working around halogen bulbs. |
RADIATOR CAP
| CAUTION | Always disconnect the fan motor when working near the radiator fan. The fan is temperature controlled and could start at any time even when the ignition key is in the OFF position. DO NOT loosen or remove radiator cap when cooling system is hot. |
RADIATOR FAN
| WARNING | Keep hands away from radiator fan. Fan is controlled by a thermostatic switch which may come on or run for up to 15 minutes even after engine is turned off. |
TURBOCHARGED MODELS
| CAUTION | Do not race engine immediately after starting. When stopping engine, allow engine to idle for approximately 60 seconds before shutting it off. Failure to do so may cause turbocharger damage due to lack of oil flowing to the turbocharger bearings. |
WARRANTY INFORMATION
| CAUTION | Due to the different warranties offered in various regions and the variety of after-market extended warranties available, please refer to the warranty package that came with the vehicle to verify all warranty options. |
NEW VEHICLE LIMITED WARRANTY
Covers all manufacturer-installed parts and components for any repairs, replacements or adjustments needed to correct defects in materials or workmanship under normal use and maintenance for 36 months or 36,000 miles, whichever comes first, from date of delivery to the first retail buyer or first date of use.
POWERTRAIN LIMITED WARRANTY
Upon expiration of New Vehicle Limited Warranty, this warranty covers powertrain against defects in materials or workmanship up to a maximum of 36 months or 50,000 miles, whichever occurs first. On 1991-94 models, warranty period is extended to 5 years or 60,000 miles, whichever occurs first. See copy of warranty for specific components covered.
BATTERY WARRANTY
Covers replacement of original battery for 12 months or 12,000 miles, whichever occurs first.
AIR CONDITIONER WARRANTY
Covers manufacturer's air conditioners for 36 months or 36,000 miles, whichever occurs first. Air conditioner refrigerant charge is covered for the first 12 months or 12,000 miles, whichever occurs first. On 1991-1994 models, refrigerant is covered only as part of a warranty repair.
ANTI-CORROSION PERFORATION LIMITED WARRANTY
Covers perforation (rust-through) in any body sheet metal panel due to corrosion for 36 months regardless of mileage. Outer panel coverage is extended to 7 years or 100,000 miles, whichever occurs first, on 1990 and later models.
EMISSION SYSTEM DEFECT WARRANTY (EXCEPT CALIFORNIA)
Warrants that the vehicle was designed, built and equipped to conform at the time of sale with all applicable U.S. emission standards. Covers any repairs needed to correct defects in materials or workmanship that would cause the vehicle not to meet these standards for 5 years or 50,000 miles, whichever occurs first.
EMISSION SYSTEM PERFORMANCE WARRANTY (EXCEPT CALIFORNIA)
Covers all repairs, adjustments, or replacements if vehicle has been maintained in accordance with the prescribed scheduled maintenance instructions, but fails to conform to applicable emission standards, and such failure results or will result in the vehicle owner having to bear any penalty or other sanctions under local, state or federal law. Warranty period is 5 years or 50,000 miles, whichever occurs first. Covers repairs of non-conformity if vehicle fails to pass an EPA approved emissions test during the first 24 months or 24,000 miles of this warranty. During the remainder of the warranty period, covers repairs of non-conformity resulting from failure of certain emission-related components. See customer's copy of warranty for specific components covered.
EMISSION SYSTEM WARRANTY (CALIFORNIA)
Warrants that vehicle was designed, built and equipped to conform at time of sale with all applicable U.S. and California emission standards, and that emission control system is free from defects in materials or workmanship that would cause vehicle not to meet these standards for 3 years or 50,000 miles, whichever occurs first. Certain emission-related components are covered for 7 years or 70,000 miles, whichever occurs first. See customer's copy of warranty for specific components covered.
FUSE PANEL LOCATION
The fuse block is located under the instrument panel on the driver's side. If a fuse is blown, locate the cause before replacing the fuse. Spare fuses are contained in the fuse block.
Scheme 11
Fuse & Circuit Breaker Identification
- 1 - 10 Amp Dome Light, Clock
- 2 - 10 Amp Stoplights
- 3 - 10 Amp (1986) Hazard Light, Power Window Relay
- 3 - 20 Amp (1987) Heater
- 4 - 20 Amp (1986) Heater
- 4 - 10 Amp (1987) Hazard Light, Power Window Relay
- 5 - 15 Amp Radio, Cigarette Lighter
- 6 - 20 Amp Wipers
- 7 - 20 Amp Defogger
- 8 - 15 Amp Power Door Locks, Electronic Control Suspension (If Equipped)
- 9 - 10 Amp Turn Signals, Gauges
- 10 - 10 Amp Back-Up Lights
- 11 - 10 Amp (1986) Defogger Relay, Heater Relay, Automatic Transaxle Control System
- 10 Amp (1987) Defogger Relay, Automatic Transaxle Control System
- 12 - 15 Amp (1986) Electronic Control Power Steering, Electronic Control Suspension (If Equipped)
- 13 - Spare Fuses
Scheme 12
- 1 - 15 Amp Cigarette Lighter, Dimming Mirror (If Equipped)
- 2 - 10 Amp Radio
- 3 - 10 Amp Defogger Relay, Heater Relay
- 4 - 10 Amp Electronic Control Power Steering (If Equipped)
- 5 - Blank (1989-90)
- 5 - 10 Amp (1991-93) Seat Belts
- 6 - 10 Amp Turn Signals
- 7 - 10 Amp Gauges (1989), Meters (1990-93)
- 8 - 10 Amp Horn
- 9 - 15 Amp Wipers
- 10 - Blank
- 11 - 10 Amp Automatic Transaxle Control System (If Equipped)
- 12 - 15 Amp Power Door Locks (If Equipped)
- 13 - 10 Amp Dome Light, Clock
- 14 - 10 Amp Back-Up Lights
- 15 - 15 Amp Stoplights
- 16 - 30 Amp Heater
- 17 - 20 Amp Sun Roof (Optional)
- 18 - 20 Amp (1989-91) Defogger
- 18 - Blank (1992-93)
- 19 - 20 Amp Electronic Control Suspension
- 20 - Spare Fuses
Scheme 13
- 1 - 10 Amp Horn
- 2 - 10 Amp Heater Relay
- 3 - 15 Amp Cigarette Lighter
- 4 - 10 Amp 4 A/T
- 5 - 10 Amp Remote Controlled Outside Mirror
- 6 - 20 Amp Sunroof
- 7 - 30 Amp Rear Window Defogger
- 8 - 10 Amp E.P.S.
- 9 - 10 Amp Meters
- 10 - 20 Amp Wiper
- 11 - 10 Amp Seat Belt
- 12 - 30 Amp Heater
- 13 - 10 Amp Back-Up Lights
- 14 - 10 Amp Turn Signals
- 15 - 10 Amp Stoplights
- 16 - Spare
Scheme 14
- 1 - 10 Amp Horn
- 2 - 10 Amp Heater Relay
- 3 - 15 Amp Cigarette Lighter
- 4 - 10 Amp 4 A/T
- 5 - 10 Amp Remote Controlled Outside Mirror
- 6 - 20 Amp Sunroof
- 7 - 30 Amp Rear Window Defogger
- 8 - 10 Amp Meters
- 9 - 15 Amp Wiper
- 10 - 30 Amp Heater
- 11 - 10 Amp Back-Up Lights
- 12 - 10 Amp Turn Signals
- 13 - 10 Amp Stoplights
- 14 - Spare
Scheme 15
- 1 - 30 Amp Ignition Switch
- 2 - 50 Amp ABS
- 3 - 30 Amp Radiator Fan
- 4 - 40 Amp Headlights
- 5 - 30 Amp Power Windows
- 6 - 30 Amp ABS
- 7 - 30 Amp Condenser Fan
- 8 - 10 Amp Hazard
- 9 - 20 Amp Engine
- 10 - 10 Amp Air Conditioning
- 11 - 10 Amp High Beam
- 12 - 10 Amp Tail Lights
- 13 - 10 Amp Theft
- 14 - 15 Amp Fog Lights
Scheme 16
- 1 - 30 Amp Engine
- 2 - 30 Amp Power Window
- 3 - 60 Amp ABS
- 4 - 30 Amp Radiator Fan
- 5 - 30 Amp Ignition Switch
- 6 - 40 Amp Headlights
- 7 - 10 Amp Hazard
- 8 - 10 Amp Theft
- 9 - 10 Amp ABS
- 10 - 15 Amp Radio
- 11 - 10 Amp Room Lights
- 12 - 25 Amp Air Conditioning
- 13 - 10 Amp Air Conditioning
- 14 - 10 Amp High Beam
- 15 - 15 Amp Fog Lights
- 16 - 10 Amp Tail Lights
