TACHOMETER CHECK Mitsubishi Galant IX рестайлинг

Chassis Electrical 5 illustrations ~376 words

TACHOMETER CHECK

Required Special Tools

  1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicle Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991911: M.U.T.-III Main Harness A (Vehicles with CAN communication system)
CAUTIONTo prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958.
  1. Connect scan tool MB991958 to the data link connector.
  2. A/T select lever: "P" position.
  3. Turn the ignition switch to "ON" position.
  4. Start the engine.
  5. Run the engine.
  6. Select MFI system data list and take a reading of the engine speed. Item 22: CKP SENSOR
  7. Compare the engine speed shown in the scan tool with that shown on the tachometer. The engine speeds shown on the tachometer should correspond to the table below. NOTE: The following standard value assumes that battery voltage is 13.5 volts. NOTE: The value in parentheses is a reference value. ENGINE SPEED SPECIFICATION (STANDARD VALUE) ENGINE SPEED r/min TACHOMETER INDICATING TOLERANCE r/min 600 500 - 700 (2,000) (1,900 - 2,100) 3,000 2,850 - 3,150 (4,000) (3,850 - 4,150) 5,000 4,850 - 5,150 6,000 5,850 - 6,150

Scheme 332

Scheme 332: FUEL LEVEL SENSOR CHECK
  1. Remove the rear seat cushion assembly. (Refer to «REAR SEAT ASSEMBLY»(ref-278192-S26714286552008012400000) .)
  2. Remove hole cover and remove the fuel pump module and fuel level sensor (sub) (Refer to «FUEL TANK»(ref-265871-S00191829182007092600000) .).

Scheme 333

Scheme 333: FUEL LEVEL SENSOR RESISTANCE
  1. Check the resistances between fuel level sensor main terminals 1 and 2 as well as sub terminals 1 and 2 of the fuel pump module, respectively. FUEL LEVEL SENSOR RESISTANCE (STANDARD VALUE) ITEM FUEL LEVEL SENSOR (main) FUEL LEVEL SENSOR (sub) Resistance ohms Point "F" (highest) 6.5 6.5 ± 1.0 Point "E" (lowest) 45.1 74.9 ± 1.0
  2. Check that resistance value changes smoothly when the float moves slowly between points.
  3. If all checks are correct, go to fuel unit height check. If any check is not correct, replace the fuel pump module or fuel level sensor (sub).

Scheme 334

Scheme 334: FUEL LEVEL SENSOR FLOAT HEIGHT

Scheme 335

Scheme 335
  1. Move the float and measure height A at point "F" (highest) and B at point "E" (lowest). FUEL LEVEL SENSOR FLOAT HEIGHT SPECIFICATION (STANDARD VALUE) ITEM FUEL LEVEL SENSOR (main) FUEL LEVEL SENSOR (sub) Height mm (in) A at point "F" 131.5 (5.1) 24.9 ± 3.0 (0.9 ± 0.1) B at point "E" 34.5 (1.3) 172.7 ± 3.0 (6.7 ± 0.1)
  2. If any check is not correct, replace the fuel pump module or fuel level sensor (sub).

Scheme 336

Scheme 336: REMOVAL AND INSTALLATION
