Emission Control System: Removal & Installation Mitsubishi Galant IX

Testing & Diagnostics 8 illustrations ~175 words

VACUUM HOSE INSTALLATION

  1. When connecting the vacuum hoses, they should be securely inserted onto the nipples.
  2. Connect the hoses correctly, using the VACUUM HOSE ROUTING diagram as a guide.

REMOVAL AND INSTALLATION < 2.4L ENGINE >

Pre-removal and Post-installation Operation

Air Cleaner Cover, Air Intake Hose and Resonator Removal and Installation. Refer to AIR CLEANER .

Scheme 30

Scheme 30: REMOVAL AND INSTALLATION < 2.4L ENGINE >

>> A << EGR VALVE GASKET INSTALLATION

Install the EGR valve gasket as shown in the illustration.

Scheme 31

Scheme 31: >> A << EGR VALVE GASKET INSTALLATION

REMOVAL AND INSTALLATION < 3.8L ENGINE >

Pre-removal and Post-installation Operation

Strut Tower Bar Removal and Installation.

Scheme 32

Scheme 32: REMOVAL AND INSTALLATION < 3.8L ENGINE >

Install the EGR valve gasket as shown in the illustration.

Scheme 33

Scheme 33: >> A << EGR VALVE GASKET INSTALLATION

Scheme 34

Scheme 34: REMOVAL AND INSTALLATION

Scheme 35

Scheme 35: EVAPORATIVE EMISSION VENTILATION SOLENOID CHECK

Scheme 36

Scheme 36

Scheme 37

Scheme 37
  1. Connect a hand vacuum pump to nipple (A) of the solenoid.
  2. Check air tightness by applying a vacuum with voltage applied directly from the battery to the evaporative emission ventilation solenoid and without applying voltage.
  3. Measure the resistance between the terminals of the solenoid. Standard value: 17 - 21 ohms [at 20°C (68°F)]
