ENGINE COOLANT LEAK CHECK
| WARNING | When pressure testing the cooling system, slowly release cooling system pressure to avoid getting burned by hot coolant. |
| CAUTION | Be sure to completely clean away any moisture from the places checked. When the tester is taken out, be careful not to spill any coolant. Be careful when installing and removing the tester and when testing not to deform the filler neck of the radiator. |
Scheme 40
- Check that the coolant level is up to the filler neck. Install a radiator tester and apply 160 kPa (23 psi) pressure, and then check for leakage from the radiator hose or connections.
- If there is leakage, repair or replace the appropriate part.
RADIATOR CAP PRESSURE CHECK
Note. Be sure that the cap is clean before testing. Rust or other foreign material on the cap seal will cause an improper reading.
Scheme 41
- Use a cap adapter to attach the cap to the tester.
- Increase the pressure until the indicator of the gauge stops moving. Minimum limit: 83 kPa (12 psi) Standard value: 93 - 123 kPa (14 - 18 psi)
- Replace the radiator cap if the reading does not remain at or above the limit.
< 2.4L ENGINE >
| CAUTION | Never replace the DOR radiator with the NON-DOR radiator. < Vehicles for California emission regulation> Never clean the DOR radiator with a high concentration of alkaline cleaner. < Vehicles for California emission regulation> |
Scheme 42
Scheme 43
<< A >> RADIATOR UPPER HOSE/RADIATOR LOWER HOSE DISCONNECTION
Make mating marks on the radiator hose and the hose clamp. Disconnect the radiator hose.
Scheme 44
Pre-removal and Post-installation Operation
Scheme 45
Scheme 46
Scheme 47
<< A >> RADIATOR LOWER HOSE DISCONNECTION
Make mating marks on the radiator hose and the hose clamp. Disconnect the radiator hose.
Scheme 48
<< A >> RADIATOR UPPER HOSE DISCONNECTION
After making mating marks on the radiator hose and hose clamp, disconnect the radiator hose.
Scheme 49
>> A << RADIATOR UPPER HOSE DISCONNECTION
After making mating marks on the radiator hose and hose clamp, disconnect the radiator hose.
Scheme 50
WATER PIPE AND HOSE CHECK
Check the water pipe and hose for cracks, damage and clogs. Replace them if necessary.
