Wiring diagram
Wiring diagram: Computer data lines — Computer data lines circuit
Mitsubishi Eclipse IV facelift · 2008-2011
Repair manualAll systems
- Air conditioning 2
- Anti-lock brakes 3
- Anti-theft 2
- Body control modules
- Computer data lines
- Cooling fan
- Cruise control 2
- Defoggers
- Engine performance 2.4l 2
- Engine performance 3.8l 2
- Exterior lights 2
- Ground distribution
- Headlights 2
- Horn
- Instrument cluster
- Interior lights 2
- Power distribution
- Power door locks
- Power mirrors 2
- Power seats 2
- Power top/sunroof 2
- Power windows
- Radio 2
- Starting/charging 2
- Supplemental restraints
- Transmission
- Trunk, tailgate, fuel door
- Warning systems 2
- Wiper/washer 2
Components on these wiring diagrams
Click a component to highlight it on every diagram it appears on.
