Mitsubishi Eclipse IV facelift (2008-2011) Traction control circuit, with active skid control

17 18 B-18 ABS SOLENOID VALVE ANTI-LOCK IND ASC OFF IND ASC OFF SWITCH ASC/TCL IND BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BRAKE FLUID LEVEL SWITCH (ON SIDE OF MASTER CYLINDER) BRAKE IND C-203 C-215 COMBINATION METER COMPUTER DATA LINES SYSTEM CONVERTIBLE TOP CONTROL MODULE (LEFT FRONT OF LUGGAGE COMPT) COUPE DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH) ENGINE COMPARTMENT RELAY BOX (LEFT SIDE OF ENGINE COMPARTMENT) FUSE 11 FUSE 2 FUSE 20 FUSE 22 FUSIBLE LINK 3 G, YAW RATE SENSOR (UNDER REAR OF CENTER CONSOLE) GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE GRY/BLU WIRE GRY/RED WIRE HOT AT ALL TIMES HOT IN ON OR START HOT W/ TAILLIGHT RELAY ENERGIZED HYDRAULIC UNIT J/C 1 (C-28) (BEHIND LEFT SIDE OF DASH) J/C 2 (BEHIND LEFT SIDE OF DASH) J/C 2 (C-01) (BEHIND LEFT SIDE OF DASH) J/C 3 (C-03) (BEHIND LEFT SIDE OF DASH) JUNCTION BLOCK (UNDER LEFT END OF DASH) LEFT FRONT WHEEL SPEED SENSOR (AT LEFT FRONT WHEEL ASSEMBLY) LEFT REAR WHEEL SPEED SENSOR (AT LEFT REAR WHEEL ASSEMBLY) MOTOR NCA WIRE ORG/ WIRE POWERTRAIN CONTROL MODULE (A/T) ENGINE CONTROL MODULE (M/T) RED WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT WHEEL SPEED SENSOR (AT RIGHT FRONT WHEEL ASSEMBLY) RIGHT REAR WHEEL SPEED SENSOR (AT RIGHT REAR WHEEL ASSEMBLY) STEERING WHEEL SENSOR (TOP OF STEERING COLUMN) STOPLIGHT SWITCH (BEHIND LEFT SIDE OF DASH, ON BRAKE PEDAL SUPPORT) TCL/ASC-ECU (RIGHT REAR CORNER OF ENGINE COMPT, ON HYDRAULIC UNIT) WHT/BLU WIRE WHT/RED WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE
