SYMPTOM CHART
| SYMPTOM | INSPECTION PROCEDURE NO. | REFERENCE | |
|---|---|---|---|
| Communication with scan tool is not possible | Communication with all systems is impossible | INSPECTION PROCEDURE 1: COMMUNICATION WITH SCAN TOOL IS NOT POSSIBLE (COMMUNICATION WITH ALL SYSTEMS IS NOT POSSIBLE) . | |
| Communication with the TCL/ASC-ECU only is impossible | 1 | INSPECTION PROCEDURE 1: COMMUNICATION BETWEEN SCAN TOOL AND THE TCL/ASC-ECU IS NOT POSSIBLE. | |
| Communication with the steering wheel sensor only is impossible | 2 | INSPECTION PROCEDURE 2: COMMUNICATION BETWEEN SCAN TOOL AND THE STEERING WHEEL SENSOR IS NOT POSSIBLE. | |
| TCL/ASC-ECU power supply circuit system | 3 | INSPECTION PROCEDURE 3: TCL/ASC-ECU POWER SUPPLY CIRCUIT SYSTEM | |
| Steering wheel sensor power supply circuit system | 4 | INSPECTION PROCEDURE 4: STEERING WHEEL SENSOR POWER SUPPLY CIRCUIT SYSTEM | |
| When the ignition switch is turned to the "ON" position (engine stopped), the ASC OFF indicator dose not illuminate. | 5 | INSPECTION PROCEDURE 5: WHEN THE IGNITION SWITCH IS TURNED TO THE "ON" POSITION (ENGINE STOPPED), THE "ASC OFF" INDICATOR DOES NOT ILLUMINATE. INSPECTION PROCEDURE 6: WHEN THE IGNITION SWITCH IS TURNED TO THE "ON" POSITION (ENGINE STOPPED), THE TCL/ASC WORK INDICATOR DOES NOT ILLUMINATE. INSPECTION PROCEDURE 7: THE "ASC OFF" INDICATOR REMAINS ILLUMINATED AFTER THE ENGINE IS STARTED. INSPECTION PROCEDURE 8: THE TCL/ASC WORK INDICATOR REMAINS ILLUMINATED AFTER THE ENGINE IS STARTED. | |
| When the ignition switch is turned to the "ON" position (engine stopped), the TCL/ASC work indicator dose not illuminate. | 6 | ||
| The ASC OFF indicator remains illuminated after the engine is started. | 7 | ||
| The TCL/ASC work indicator remains illuminated after the engine is started. | 8 | ||
| When the ASC OFF switch is push on, ASC system does not be cancelled. | 9 | INSPECTION PROCEDURE 9: WHEN THE ASC OFF SWITCH IS PUSH ON, ASC DOES NOT BE CANCELLED. | |
| TCL/ASC system dose not operate. | 10 | INSPECTION PROCEDURE 10: TCL/ASC SYSTEM DOSE NOT OPERATE. | |
