>> A << CRANKSHAFT POSITION SENSOR INSTALLATION

  1. Install the crankshaft position sensor to the cylinder block front case.
  2. Tighten the crankshaft position sensor mounting bolts by hand.
  3. Tighten the crankshaft position sensor mounting bolts to the specified torque. Tightening torque: 8.5 +/- 0.5 N.m (76 +/- 4 in-lb)

Scheme 1

Scheme 1: >> B << CLIP INSTALLATION
  1. Install the clip to the timing belt front upper cover as shown in illustration.
  2. Tighten the clip mounting bolt to the specified torque. Tightening torque: 11 +/- 1 N.m (98 +/- 8 in-lb)

REMOVAL AND INSTALLATION < 2.4L ENGINE >

CAUTIONWhen the knock sensor replacement is performed, use scan tool MB991958 to initialize the learning value (Refer to INITIALIZATION PROCEDURE FOR LEARNING VALUE IN MFI ENGINE ).

Scheme 2

Scheme 2

Required Special Tool

MD998773: Knock Sensor Wrench

<< A >> KNOCK SENSOR REMOVAL

Use special tool MD998773 to remove the knock sensor.

Scheme 3

Scheme 3: << A >> KNOCK SENSOR REMOVAL

>> A << KNOCK SENSOR INSTALLATION

Use special tool MD998773 to tighten the knock sensor to the specified torque in the same manner as removal.

Tightening torque: 23 +/- 2 N.m (17 +/- 1 ft-lb)

Scheme 4

Scheme 4: >> A << KNOCK SENSOR INSTALLATION

REMOVAL AND INSTALLATION < 3.8L ENGINE >

CAUTIONWhen the knock sensor replacement is performed, use scan tool MB991958 to initialize the learning value (Refer to INITIALIZATION PROCEDURE FOR LEARNING VALUE IN MFI ENGINE ).

Scheme 5

Scheme 5

Required Special Tool

MD998773: Knock Sensor Wrench

Use special tool MD998773 to remove the knock sensor.

Scheme 6

Scheme 6: << A >> KNOCK SENSOR REMOVAL

Use special tool MD998773 to tighten the knock sensor to the specified torque in the same manner as removal.

Tightening torque: 23 +/- 2 N.m (17 +/- 1 ft-lb)

Scheme 7

Scheme 7: >> A << KNOCK SENSOR INSTALLATION

Scheme 8

Scheme 8: >> B << CLIP INSTALLATION
  1. Install the clip to the timing belt front upper cover as shown in illustration.
  2. Tighten the clip mounting bolt to the specified torque. Tightening torque: 11 +/- 1 N.m (98 +/- 8 ft-lb)
