ACTUATOR TEST REFERENCE Mitsubishi Eclipse IV рестайлинг

Heater, Air Conditioning & Ventilation: Diagnosis 1 illustration

ACTUATOR TEST REFERENCE

MUT-III SCAN TOOL DISPLAYITEM NO.INSPECTION ITEMDRIVE CONTENT
Rear defogger switch: OFF35Rear window defogger switchRear window defogger: OFF
Rear defogger switch: ON36Rear window defogger: ON
Air mix damper motor: 0%42Air mixing damper control motorOpening degree: approx. 0% (Max cool)
Air mix damper motor: 100%43Opening degree: approx. 100% (Max hot)
Air mix damper motor: 50%44Opening degree: approx. 50%
Air outlet c/o dumper: Bi_Level67Mode selection damper control motorFOOT/FACE
Air outlet c/o dumper: DEF68DEF
Air outlet c/o dumper: DEF/FOOT69DEF/FOOT
Air outlet c/o dumper: FACE70FACE
Air outlet c/o dumper: FOOT71FOOT
In/out changeover damper: Fresh72Outside/inside air selection damper control motorOutside
In/out changeover damper: Recirc73Inside
Idle up request: high load74Idle up operationIdle up: high load
Idle up request: low load75Idle up: low load
Idle up request: OFF76Idle up: OFF
Condenser fan: 0%77Condenser fanOFF
Condenser fan: 100%78High speed
Condenser fan: 50%79Middle speed
Rheostat: 0%80Heater control IlluminationIllumination: 0%
Rheostat: 100%81Illumination: 100%
Rheostat: 50%82Illumination: 50%

ACTUATOR TEST REFERENCE

Scheme 361

Scheme 361: CHECK AT A/C-ECU TERMINAL
Scheme 361: CHECK AT A/C-ECU TERMINAL
TERMINAL NO.CHECK ITEMCHECKING REQUIREMENTSNORMAL CONDITION
1A/C pressure sensor groundAlways0 V
2GroundAlways0 V
3A/C pressure sensorIgnition switch: ON5 V
4A/C pressure sensorAt 2.6 MPa (377 psi)3.9 V
5, 6
7Power supply to the ignition switch (ACC)Ignition switch: ONBattery positive voltage
8Back-up power supplyAlwaysBattery positive voltage
9Air mixing damper control motorWhen the air mix damper is moved to the MAX. COOL position.10 V
When the air mix damper is moved to the MAX. HOT position.0.5 V
10Sensors and potentiometers groundAlways0 V
11Mode selection damper control motor potentiometer inputWhen the damper has moved to the DEF position.0.67 V
12Air mixing damper control motor potentiometer inputWhen the damper door has moved to the MAX. HOT position.1.4 V
13Air thermo sensor inputWhen sensor temperature is 25°C (77°F) [1.5 kohms]2.2 V
14Ambient air temperature sensor inputWhen sensor temperature is 25°C (77°F) [4 kohms]1.9 V
15Potentiometer power supplyIgnition switch: ON5 V
16Power supply to the ignition switch (IG2)Ignition switch: ONBattery positive voltage
21ILL power supplyLighting switch: ONBattery positive voltage
22Illumination groundAlways0 V
23A/C compressor relayA/C compressor relay: ONBattery positive voltage
24Blower switchIgnition switch: ON Blower switch: ONBattery positive voltage
25, 26
27Rear window defogger relayIgnition switch: ONBattery positive voltage
28Outside/inside air selection damper control motor (outside)When the damper flap is moving to the air recirculation position.0.5 V
When the damper flap is moving to the outside air position.0 V (when the motor is stopped)
29Outside/inside air selection damper control motor (inside)When the damper flap is moving to the air recirculation position.0 V (when the motor is stopped)
When the damper flap is moving to the outside air position.0.5 V
30Mode selection damper control motor (DEF)When the damper is moved to the FACE position.0.5 V
When the damper is moved to the DEF position.10 V
31Mode selection damper control motor (FACE)When the damper is moved to the FACE position.10 V
When the damper is moved to the DEF position.0.5 V
32Air mixing damper control motorWhen the air mix damper is moved to the MAX. COOL position.0.5 V
When the air mix damper is moved to the MAX. HOT position.10 V
