ASSEMBLY Mitsubishi Eclipse IV рестайлинг

ASSEMBLY

Scheme 1011

Scheme 1012

Scheme 1013

Scheme 1014

Scheme 1015

Scheme 1016

Scheme 1017

Scheme 1018

Scheme 1019

Scheme 1020

Scheme 1021

Scheme 1022

Scheme 1023

Scheme 1024

Scheme 1025

Scheme 1026

Scheme 1027

Scheme 1028

Scheme 1029

Scheme 1030

Scheme 1031

Scheme 1032

Scheme 1033

Scheme 1034

Scheme 1035

Scheme 1036

Scheme 1037

Scheme 1038

Scheme 1039

Scheme 1040

Scheme 1041

Scheme 1042

Scheme 1043

Scheme 1044

Scheme 1045

Scheme 1046

Scheme 1047

Scheme 1048

Scheme 1049

Scheme 1050

Scheme 1051

Scheme 1052

Scheme 1053

Scheme 1054

Scheme 1055

Scheme 1056

Scheme 1057

Scheme 1058

Scheme 1059

Scheme 1060

Scheme 1061

Scheme 1062

Scheme 1063

Scheme 1064

Scheme 1065

Scheme 1066

Scheme 1067

Scheme 1068

Scheme 1069

Scheme 1070

Scheme 1071

Scheme 1072

Scheme 1073

Scheme 1074

Scheme 1075

Scheme 1076

Scheme 1077

Scheme 1078

Scheme 1079

Scheme 1080

Scheme 1081

Scheme 1082

Scheme 1083

Scheme 1084

Scheme 1085

Scheme 1086

Scheme 1087

Scheme 1088

Scheme 1089

Scheme 1090

Scheme 1091

Scheme 1092

Scheme 1093

Scheme 1094

Scheme 1095

1. Install special tool MD998412 in the installation screw hole of the transfer drive gear bearing located in the transaxle case. Using this as a guide, install the transfer drive gear bearing and gear in the transaxle case.
2. Tighten the mounting bolts (eight pieces) of the transfer drive gear bearing to the specified torque. Tightening torque: 34 +/- 2 N. m (25 +/- 1 ft-lb)
3. Install the low-reverse brake piston, return spring, and spring retainer into the transaxle case.
4. Fit a new O-ring into the groove of one-way clutch inner race.
5. Check the placement of the identification notches in the one-way clutch inner race. Install the one-way clutch inner race to the transfer drive gear bearing so that the notches fall along the A - A line.
6. Put the snap ring on the inner race.
7. Set special tools MD999577 and MD998924 as shown in illustration, and then compress the one-way clutch inner race and install the snap ring.
8. Install the wave spring onto the low-reverse brake piston.
9. Install the brake discs (six pieces), brake plates (five pieces) and snap ring as shown in illustration. NOTE: Do not install the pressure plate at this time.
10. Install special tool MB991632 on the brake disc.
11. Install the reaction plate and the used snap ring.
12. Move special tool MB991632 to measure the end play of reaction plate. Then replace the snap ring installed in Step 11 to adjust the end play to standard value. Standard value: 0-0.16 mm (0-0.0063 inch)
13. Install the brake discs (four pieces) and brake plates (three pieces) as shown in illustration. NOTE: Do not install the pressure plate at this time.
14. Place special tool MB991632 on top of the brake disc in place of the pressure plate.
15. Install the return spring, second brake piston and snap ring.
16. Move special tool MB991632 and measure its movement. Standard value of end play (Reference): 1.09-1.55 mm (0.0429-0.0610 inch)
17. Select a pressure plate whose thickness corresponds to the measured amount of movement from the following table. PRESSURE PLATE FOR SECOND BRAKE PRESSURE PLATE THICKNESS AND MOVEMENT AMOUNT FOR SECOND BRAKE MOVEMENT AMOUNT mm (in) THICKNESS mm (in) ID SYMBOL 1.1-1.3 (0.043-0.051) 1.8 (0.071) E 1.3-1.5 (0.051-0.059) 2.0 (0.079) D 1.5-1.7 (0.059-0.067) 2.2 (0.087) C 1.7-1.9 (0.067-0.075) 2.4 (0.094) B 1.9-2.1 (0.075-0.083) 2.6 (0.102) A 2.1-2.3 (0.083-0.091) 2.8 (0.110) 0
18. Turn the transaxle over so that the installation surface of the torque converter housing is facing up. Install special tool MD998913 in a dial gauge, and then move special tool MB991632 and measure its movement. Standard value of end play (Reference): 1.65-2.11 mm (0.0649-0.0831 inch)
19. Select a pressure plate whose thickness corresponds to the measured amount of movement from the table. PRESSURE PLATE FOR LOW-REVERSE BRAKE PRESSURE PLATE THICKNESS AND MOVEMENT AMOUNT FOR LOW-REVERSE BRAKE MOVEMENT AMOUNT mm (in) THICKNESS mm (in) ID SYMBOL 1.0-1.2 (0.039-0.047) 1.6 (0.063) F 1.2-1.4 (0.047-0.055) 1.8 (0.071) E 1.4-1.6 (0.055-0.063) 2.0 (0.079) D 1.6-1.8 (0.063-0.071) 2.2 (0.087) C 1.8-2.0 (0.071-0.079) 2.4 (0.094) B 2.0-2.2 (0.079-0.087) 2.6 (0.102) A 2.2-2.4 (0.087-0.094) 2.8 (0.110) 0 2.4-2.6 (0.094-0.102) 3.0 (0.118) 1 CAUTION: If necessary, take the measurements in steps 9 to 18 after replacing the pressure plate, brake plate and brake disc.
20. Remove all parts and special tools that were installed to take the measurements in steps 9 to 18 . Remove and separate the pressure plate and snap ring chosen in steps 12 , 16 and 18 .
21. Install the needle bearing as shown in illustration.
22. Install the two seal rings.
23. Install the snap ring into the groove of transaxle case output shaft bore.
24. Install the snap ring.
25. Install the planetary carrier assembly.
26. Install the planetary reverse sun gear.
27. Install the wave spring on the low-reverse brake piston.
28. Install the pressure plate that was selected in Step 19 . Next, install brake discs (six pieces) and brake plates (five pieces), one on top of the other.
29. Install the snap ring.
30. Install the reaction plate.
31. Install the snap ring that was selected in Step 12 .
32. Install second brake discs (four pieces) and second brake plates (three pieces), one on top of the other. Next, install the pressure plate that was selected in Step 17 .
33. Install the return spring and second brake piston.
34. Install the snap ring. IDENTIFICATION OF THRUST BEARING, THRUST RACES, AND THRUST WASHERS THRUST BEARING THRUST RACES AND THRUST WASHERS DIMENSION SPECIFICATIONS SYMBOL OD mm (in) ID mm (in) THICKNESS mm (in) No. 1 59 (2.32) 47 (1.85) 1.8 (0.071) 59 (2.32) 47 (1.85) 2.0 (0.079) 59 (2.32) 47 (1.85) 2.2 (0.087) 59 (2.32) 47 (1.85) 2.4 (0.094) 59 (2.32) 47 (1.85) 2.6 (0.102) 59 (2.32) 47 (1.85) 2.8 (0.110) No. 2 49 (1.93) 34 (1.34) 3.6 (0.142) No. 3 57 (2.24) 38.5 (1.52) 4.1 (0.161) No. 4 55.4 (2.18) 38.5 (1.52) 3.3 (0.130) No. 5 57 (2.24) 38.5 (1.52) 4.1 (0.161) No. 6 57 (2.24) 38.5 (1.52) 4.1 (0.161) No. 7 59 (2.32) 37 (1.46) 2.8 (0.110) No. 8 48.9 (1.925) 37 (1.46) 1.6 (0.063) 48.9 (1.925) 37 (1.46) 1.7 (0.067) 48.9 (1.925) 37 (1.46) 1.8 (0.071) 48.9 (1.925) 37 (1.46) 1.9 (0.075) 48.9 (1.925) 37 (1.46) 2.0 (0.079) 48.9 (1.925) 37 (1.46) 2.1 (0.083) 48.9 (1.925) 37 (1.46) 2.2 (0.087) 48.9 (1.925) 37 (1.46) 2.3 (0.091) 48.9 (1.925) 37 (1.46) 2.4 (0.094) 48.9 (1.925) 37 (1.46) 2.5 (0.098) 48.9 (1.925) 37 (1.46) 2.6 (0.102) No. 9 80 (3.15) 60 (2.36) 2.5 (0.098) No. 10 80 (3.15) 60 (2.36) 2.5 (0.098) No. 11 55.4 (2.18) 38.5 (1.52) 3.3 (0.123) No. 12 54.6 (2.15) 43(1.69) 3.0 (0.118) CAUTION: Be sure to install the thrust bearing in the correct direction as shown in illustration.
35. Check the installation direction of the thrust bearing number 5, and install it on the hub of the planetary reverse sun gear. CAUTION: Use care to install the thrust bearing in the proper direction.
36. Attach thrust bearing number 6 to the inside of the overdrive clutch hub using petroleum jelly (Vaseline). Then install the assembly in the reverse and overdrive clutch.
37. Install the reverse and overdrive clutch. CAUTION: Be sure to install the thrust bearing in the correct direction as shown in illustration.
38. Check the installation direction of thrust bearing number 7, and install it on the reverse clutch retainer.
39. Use special tool MB990938 to tap the input shaft rear bearing in the rear cover.
40. Install the seal rings (four pieces) in the grooves of the rear cover.
41. Measure the end play of the under drive sun gear by the following procedures: Install the thinnest thrust race number 8 [thickness 1.6 mm (0.063 inch); part number MD707267] on thrust bearing number 7. Install the rear cover on the transaxle case and tighten the bolts to the specified torque. Tightening torque: 23 +/- 3 N. m (17 +/- 2 ft-lb) Turn over the transaxle case so that the installation surface of the torque converter housing is facing up. Install the under drive clutch hub on the under drive sun gear. Measure end play of the underdrive sun gear and record the measurement value. Standard value (Reference): 0.25-0.45 mm (0.0098-0.0177 inch) After taking the measurement in steps 5 , take out the installed parts in steps 1 through 4 .
42. Install the O-rings (six pieces).
43. Select a thrust race number 8 whose thickness corresponds to the measured values taken in Step 40 from the table. Install it on thrust bearing number 7. THRUST RACE THICKNESS AND MEASUREMENT VALUES CHART MEASUREMENT VALUE mm (in) THICKNESS mm (in) 0.3-0.4 (0.012-0.016) 1.6 (0.063) 0.4-0.5 (0.016-0.020) 1.7 (0.067) 0.5-0.6 (0.020-0.024) 1.8 (0.071) 0.6-0.7 (0.024-0.028) 1.9 (0.075) 0.7-0.8 (0.028-0.031) 2.0 (0.079) 0.8-0.9 (0.031-0.035) 2.1 (0.083) 0.9-1.0 (0.035-0.039) 2.2 (0.087) 1.0-1.1 (0.039-0.043) 2.3 (0.091) 1.1-1.2 (0.043-0.047) 2.4 (0.094) 1.2-1.3 (0.047-0.051) 2.5 (0.098) 1.3-1.4 (0.051-0.055) 2.6 (0.102)
44. Apply a 2 mm (0.08 inch) diameter bead of sealant (MITSUBISHI Genuine Part number MD974421 or equivalent) to the illustrated position of the rear cover. NOTE: Be sure to install the case quickly while the sealant is wet (within 15 minutes). Leaks will occur if the rear cover is installed after the sealant dries.
45. Install the rear cover, and tighten its mounting bolts to the specified torque. Tightening torque: 23 +/- 3 N. m (17 +/- 2 ft-lb) NOTE: After installation, keep the sealed area away from ATF for approximately one hour. CAUTION: Install the thrust bearing with the indicated side facing down.
46. Install the thrust race number12 and thrust bearing number11.
47. Finger-tighten the anchor plug and a new O-ring, then install the reduction brake band and direct clutch simultaneously.
48. Make sure that the direct clutch can be rotated only in the direction indicated in the illustration. NOTE: If the clutch can be rotated in the other direction, remove and reinstall it correctly.
49. Tighten the anchor plug to the specified torque. Tightening torque: 98 +/- 15 N. m (72 +/- 11 ft-lb)
50. Install the direct planetary carrier assembly.
51. Install the reduction brake spring and piston in position in the transmission case, then install the snap ring.
52. Adjust the reduction brake piston using the following procedure: Remove the nut from the reduction brake piston. Install the stopper of the special tool to hold the reduction brake piston against rotation. Using a torque wrench fitted with the socket of the special tool, tighten the adjusting rod to 10 N. m (89 in-lb), then loosen it. Repeat this operation twice. Tighten the adjusting rod to 5 N. m (43in-lb), then turn it back 5-1/2 (180 degrees) to 5-3/4 (270 degrees) turns. Install the nut on the adjusting rod and tighten the nut to 19 +/- 3 N. m (14 +/- 2 ft-lb) using the wrench of the special tool.
53. Install the reduction brake piston cover and snap ring.
54. Install the parking pawl, spacer, and spring. Then insert the parking pawl shaft.
55. Install the parking roller support, and then insert the parking roller support shafts (two pieces).
56. Install the underdrive clutch hub to the underdrive sun gear. CAUTION: Be sure to install the thrust bearing in the correct direction as shown in illustration.
57. Check the installation direction of thrust bearing number 2, and install it on the underdrive clutch hub.
58. Hold the input shaft, and install the underdrive clutch.
59. Place two beads of solder [each 10 mm (0.39 inch) in length, 3.5 mm (0.14 inch) in diameter] on the underdrive clutch retainer as shown in illustration.
60. Install special tool MD998412 as shown in illustration.
61. Install the oil pump to the transaxle case. NOTE: Do not install the oil pump gasket at this time.
62. Tighten the six oil pump mounting bolts to the specified torque. Tightening torque: 29 +/- 2 N. m (21 +/- 1 ft-lb)
63. Remove the oil pump mounting bolts.
64. Using special tools MD998333, remove the oil pump and the crushed solders.
65. Use a micrometer to measure the thickness of the crushed solder beads and record the measured value.
66. Select a thrust washer number 1 whose thickness corresponds to the measured value from table. THRUST WASHER THICKNESS AND MEASUREMENT VALUES CHART MEASUREMENT VALUE mm (in) THICKNESS mm (in) ID SYMBOL 2.25-2.45 (0.089-0.096) 1.8 (0.071) 18 2.45-2.65 (0.096-0.104) 2.0 (0.079) 20 2.65-2.85 (0.104-0.112) 2.2 (0.087) 22 2.85-3.05 (0.112-0.120) 2.4 (0.094) 24 3.05-3.25 (0.120-0.128) 2.6 (0.102) 26 3.25-3.45 (0.128-0.136) 2.8 (0.110) 28
67. Install thrust washer number 1 that was selected in Step 65 on the underdrive clutch retainer.
68. Install special tool MD998412 as shown in illustration.
69. Install the new oil pump gasket on the transaxle case.
70. Install the oil pump and tighten the six mounting bolts to the specified torque. Tightening torque: 29 +/- 2 N. m (21 +/- 1 ft-lb)
71. Make sure that the input shaft end play meets the standard value. Standard value: 0.70-1.45 mm (0.028-0.057 inch)
72. Install the oil filter.
73. Use special tools MB990936 and MB990938 to tap the differential bearing outer race in the transaxle case.
74. Install the differential.
75. Place two beads of solder [each 10 mm (0.39 inch) in length, 3 mm (0.12 inch) in diameter] on the torque converter housing as shown in illustration.
76. Use special tools MB991445 to press the differential bearing outer race into the torque converter housing.
77. Install the torque converter housing to the transaxle case without applying sealant. Tighten its mounting bolts to the specified torque. Tightening torque: 48 +/- 6 N. m (35 +/- 4 ft-lb)
78. Loosen all the bolts, and remove the torque converter housing. Then remove the outer race and the crushed solders.
79. Use a micrometer to measure the thickness of the crushed solder beads and record the measured value. Add 0.045 to 0.105 mm (0.0018 to 0.0041 inch)* to the measured value and select a spacer with the corresponding thickness. Adjustment spacer sizes are all listed on «ADJUSTING PLATE, SNAP RING AND SPACERS»(ref-308285-S37827281332009020200000) . Select the most suitable one from among those listed. NOTE: * is the thickness for the differential case preload.
80. Install the spacer selected in Step 66 to the torque converter housing.
81. Use special tools MB991445 to press the outer race into housing.
82. Apply a 2 mm (0.08 inch) diameter bead of sealant (MITSUBISHI Genuine Part number MD974421 or equivalent) to the torque converter housing in the area shown. NOTE: Be sure to install the case quickly while the sealant is wet (with 15 minutes). Leaks will occur if the rear cover is installed after the sealant dries. NOTE: After installation, keep the sealed area away from ATF for approximately one hour.
83. Install the O-rings (two pieces).
84. Install the torque converter housing and then tighten its mounting bolts (twenty pieces) to the specified torque. Tightening torque: 48 +/- 6 N. m (35 +/- 4 ft-lb)
85. Insert the O-rings (two pieces) into the grooves of the manual control lever shaft.
86. Install the manual control lever shaft and parking pawl rod.
87. Align hole "A" with the groove in the manual control lever shaft. Insert the manual control lever shaft roller into hole "A."
88. Insert the new seal rings in the grooves of the accumulator pistons. NOTE: The piston and seal ring are common parts.
89. Install the piston and spring of the reduction brake accumulator, then install the accumulator cover.
90. Identify the accumulator spring and insert it and the accumulator piston into each hole of the transaxle case. NOTE: Accumulator springs are identified as shown in illustration. ACCUMULATOR SPRINGS IDENTIFICATION BLUEING CHART NO. NAME IDENTIFICATION "BLUEING" 1 For low-reverse brake None 2 For underdrive clutch Half 3 For second brake Whole surface 4 For overdrive clutch None
91. Install the strainer and second brake retainer oil seal.
92. Insert a new O-ring to the groove of the solenoid valve harness connector.
93. Insert the solenoid valve harness connector into the hole from the inside of the transaxle case so it is oriented as shown in illustration. Then secure the snap ring to the connector groove.
94. Install the steel balls into each of the two holes in the top face of the valve body (outside valve body).
95. Install the valve body and gasket to the transaxle case. Make sure that the manual valve's pin is in the groove in the detent plate of the manual control lever.
96. Install the valve body mounting bolts (twenty seven pieces), and tighten to the specified torque. Tightening torque: 11 +/- 1 N. m (97 +/- 9 in-lb)
97. Attach the solenoid valve harness to the valve body by connecting all the connectors.
98. Install the fluid temperature sensor to the specified torque. Tightening torque: 11 +/- 1 N. m (97 +/- 9 in-lb) SOLENOID VALVE HARNESS IDENTIFICATION CHART NO. PARTS TO BE CONNECTED SOLENOID VALVE HARNESS CABLE COLOR CONNECTOR HOUSING COLOR 1 Underdrive solenoid valve White, Red, Red Black 2 Overdrive solenoid valve Orange, Red Black 3 Low-reverse solenoid valve Brown, Yellow Milky White 4 Second solenoid valve Blue, Red, Red Milky White 5 Torque converter clutch control solenoid valve Blue, Yellow, Yellow Black 6 Reduction solenoid valve Green, Yellow, Yellow Black
99. Install the manual control shaft detent and tighten the bolt to the specified torque. Tightening torque: 6.0 +/- 1.0 N. m (53 +/- 9 in-lb)
100. Apply a 2.4-2.6 mm (0.09-0.10 inch) diameter bead of sealant (MITSUBISHI Genuine Part number MD974421 or equivalent) to the valve body cover in the area shown. NOTE: Be sure to install the case quickly while the sealant is wet (with 15 minutes) or leaks will occur if the rear cover is installed after the sealant dries. NOTE: After installation, keep the sealed area away from ATF for approximately one hour.
101. Install the valve body cover, and then tighten its mounting bolts to the specified torque. Tightening torque: 11 +/- 1 N. m (97 +/- 9 in-lb)
102. Press Face "A" of the air breather to be on the same plane as the Face "B" of the transaxle case as shown in illustration.
103. Install the sealing cap and tighten the bolt to the specified torque. Tightening torque: 5.0 +/- 1.0 N. m (44 +/- 9 in-lb)
104. Install the park/neutral position switch and tighten the bolt to the specified torque. Tightening torque: 11 +/- 1 N. m (97 +/- 9 in-lb)
105. Install the manual control lever and tighten the nut to the specified torque. Tightening torque: 22 +/- 3 N. m (16 +/- 2 ft-lb)
106. Install the input shaft speed sensor and output shaft speed sensor and tighten the bolt to the specified torque. Tightening torque: 11 +/- 1 N. m (97 +/- 9 in-lb)
107. Apply ATF on the both sides of the new gasket and threads of the eyebolts, and then tighten to the specified torque. Tightening torque: 24 +/- 3 N. m (18 +/- 2 ft-lb)
108. Tighten the oil cooler feed pipe clamp bolt to the specified torque. Tightening torque: 11 +/- 1 N. m (97 +/- 9 in-lb)
109. Install the oil dipstick.
110. Install the control cable support brackets to the specified torque. Tightening torque: 23 +/- 3 N. m (17 +/- 2 ft-lb)
111. Install the harness bracket to the specified torque. Tightening torque: 11 +/- 1 N. m (97 +/- 9 in-lb)
112. Install the roll stopper brackets. Tightening torque: 70 +/- 10 N. m (52 +/- 7 ft-lb) CAUTION: Apply ATF to the oil pump drive hub before installing the torque converter. Be careful not to damage the oil seal lip when installing the torque converter.
113. Install the torque converter, and align it with the oil pump so that the shown dimension "A" meets the reference value. Reference value: Approximately 9.4 mm (0.37 inch)

Scheme 1096

Required Special Tool

1. MD998334: Oil Seal Installer
