Overhaul (2.4L): Component Locations — Mitsubishi Eclipse IV (2005-2008)

Overhaul (2.4L): Component Locations Mitsubishi Eclipse IV

Mechanical 27 illustrations ~368 words

SPECIAL TOOLS

SPECIAL TOOLS CHART TOOL TOOL NUMBER AND NAME SUPERSESSION APPLICATION MD998781 Flywheel stopper General service tool Supporting drive plate MD998770 Oxygen sensor wrench MD998770-01 or General service tool Removal and installation of oxygen sensor MB991398 Spark plug wrench - Removal and installation of spark plug MD998778 Crankshaft sprocket puller General service tool Removal of crankshaft sprocket MD998785 Sprocket stopper MD998785 Supporting counterbalance shaft sprocket MB990767 End yoke holder MB990767-01 Holding camshaft sprocket when loosening or torquing bolt MD998719 Pins MIT308239 MD998738 Adjusting screw MD998738-01 Holding the auto-tensioner Timing belt tension adjustment MD998767 Tension pulley wrench MD998752-01 Adjustment of timing belt tension MD998012 Oil pressure switch wrench General service tool Removal and installation of engine oil pressure switch < to cylinder block > MD998713 Camshaft oil seal installer MD998713-01 Installation of camshaft oil seal MB991654 Cylinder head bolt wrench (12) General service tool Removal and installation of cylinder head bolt MD998735 Valve spring compressor MD998735-01 Compression of valve spring MB991999 Valve steam seal installer General service tool Installation of valve steam seal MD998727 Oil pan remover MD998727-01 Removal of oil pan MD998162 Plug wrench MD998162-01 Removal and installation of front case cap plug MD998783 Plug wrench retainer General service tool MD998371 Silent shaft bearing puller MD998371-01 Removal of counterbalance shaft front bearing MD998372 Silent shaft bearing puller MD998372-01 Removal of counterbalance shaft rear bearing MB991603 Bearing installer stopper General service tool Removal and installation of rear bearing MD998705 Silent shaft bearing installer MD998373-01 Use with MB990938-01 Installation of counterbalance shaft bearing MD998285 Crankshaft front oil seal guide MD998285-01 Installation of crankshaft front oil seal MD998375 Crankshaft front oil seal installer MD998375-01 MD998780 Piston pin setting tool MIT216941 Removal and installation of piston pin MB990938 Handle MB990938-01 Installation of crankshaft rear oil seal MD998776 Crankshaft rear oil seal installer MD998376-01
