Overhaul (2.4L): Application Mitsubishi Eclipse IV

>> B << SEALANT APPLICATION TO ENGINE COOLANT TEMPERATURE SENSOR

Apply 3M™ AAD Part number 8731 or equivalent to the engine coolant temperature sensor.

Scheme 434

>> C << SEALANT APPLICATION TO ENGINE OIL PRESSURE SWITCH

Apply 3M™ AAD Part number 8672 or equivalent to the threads of the engine oil pressure switch.

Scheme 435

>> D << SEALANT APPLICATION TO ENGINE OIL PRESSURE SWITCH

Scheme 436

Scheme 437

1. Apply 3M™ AAD Part number 8672 or equivalent to the threads of the engine oil pressure switch.
2. Using special tool MD998012, tighten the engine oil pressure switch to the specified torque. Tightening torque: 19 +/- 3 N.m (14 +/- 2 ft-lb)

Scheme 438

Scheme 439

1. Apply a 3 mm (0.12 inch) diameter bead of sealant MITSUBISHI Genuine Part number MD970389 or equivalent to the groove as shown in illustration.
2. Coat the threads of the bolt indicated in the illustration with 3M™ AAD 8672 or equivalent before tightening.
3. Install the housing quickly (within 15 minutes) while the sealant is wet and tighten the bolts to the specified torque. Tightening torque: 24 +/- 4 N.m (18 +/- 2 ft-lb) NOTE: After installation, keep the sealed area away from the coolant for approximately one hour.

Scheme 440

1. Check that the rubber ring is undamaged and seated correctly in the thermostat flange.
2. Install the thermostat as shown in illustration. The jiggle valve must be at the top position.

Scheme 441

1. Install the intake manifold stay and tighten the bolts just finger tight.
2. Check to ensure that the stay is in close contact with the bosses of the intake manifold and cylinder block.
3. First tighten the intake manifold side bolts to the specified torque, then the cylinder block side bolts to the specified torque. Tightening torque: 31 +/- 3 N.m (23 +/- 2 ft-lb)
