<< A >> INSTRUMENT PANEL UNDER COVER REMOVAL
Use a commercial ratchet screwdriver to remove the instrument panel under cover mounting screw.
Scheme 25
REMOVAL
Slide the instrument panel slightly and remove the clip from the instrument panel as shown and disconnect the photo sensor connector.
Scheme 26
Scheme 27
Scheme 28
Scheme 29
<< A >> FRONT PILLAR TRIM REMOVAL
Release the clip and remove the front pillar trim by pulling it to the direction shown in illustration.
Scheme 30
Scheme 31
<< A >> INSIDE HANDLE COVER REMOVAL
Insert special tool MB990784 as shown to remove the inside handle cover.
Scheme 32
Scheme 33
Scheme 34
REMOVAL AND INSTALLATION
| WARNING | When removing and installing the front passenger seat, be sure to carry out accuracy check of occupant classification sensor after the seat has been installed in the vehicle. (Refer to ON-VEHICLE SERVICE ). |
Scheme 35
<< A >> HEADLINING ASSEMBLY REMOVAL
Turn the headlining assembly 90° as shown in illustration and remove it from the liftgate side.
Scheme 36
INSIDE REAR VIEW MIRROR REMOVAL
Insert a narrow flat-tip screwdriver into the slit in the inside rear view mirror bracket, keep the spring pushed in and remove the inside rear view mirror in the direction of the arrow in the illustration.
Note. While the spring is pushed in, the connection between the spring and the pawl of the button is released.
Scheme 37
| WARNING | Before removing the front seat assembly, refer to, SERVICE PRECAUTIONS and AIR BAG MODULES AND CLOCK SPRING . When removing and installing the front passenger seat, be sure to carry out accuracy check of occupant classification sensor after the seat has been installed in the vehicle. (Refer to ON-VEHICLE SERVICE ). |
| CAUTION | Do not impact the seat. If any impact is applied to the seat, the occupant classification sensor transmitting error may occur. |
Scheme 38
>> A << FRONT SEAT ASSEMBLY INSTALLATION
| CAUTION | Install the front passenger's seat assembly before installing the outer seat belt. |
Scheme 39
- Temporarily tighten the nuts in mounting locations shown in the illustration with no weight on the front seat cushion and check the operation of the seat slide.
- Temporarily tighten the bolts in mounting locations shown in the illustration with no weight on the front seat cushion.
- Tighten the nuts and bolts in all mounting locations to the specified torque. Tightening torque: A: 30 +/- 5 N.m (22 +/- 4 ft-lb) B: 44 +/- 10 N.m (33 +/- 7 ft-lb)
Scheme 40
- Check for continuity between terminals.
- Check that the indicator is lighted at HI or LO when battery voltage is supplied to terminal 5 and terminal 8 is grounded.
- Check that indicator is lighted when battery voltage is supplied to terminals 2 and terminal 6.
Note. ( ) indicates positive or negative terminal of tester. Measuring at the opposite sides may cause open circuit.
<< B >> SEATBACK PANEL REMOVAL
| WARNING | Do not remove the occupant classification-ECU and the occupant classification sensor from the slide adjuster. |
Scheme 41
<< A >> INSTALLATION OF REAR SEAT CUSHION ASSEMBLY
Fit the rear seat cushion into the rear seat hook securely.
Scheme 42
Scheme 43
Scheme 44
Note. * If so equipped
