Interior: Other Mitsubishi Eclipse IV

SEAT BELT WARNING SYSTEM

If the driver turns the ignition switch to the "ON" position without fastening the seat belt, the seat belt warning light illuminates.

FUNCTION

When the mirror switch is set to "AUTO", the anti-glare function is activated automatically.

<< B >> CONNECTOR DISCONNECTION

Disconnect the connectors shown in the illustration.

CONNECTOR SPECIFICATIONS

Scheme 51

Scheme 52

<< A >> ACCESSORY SOCKET (BATTERY) CASE B

Disengage the claw shown in the illustration and remove the accessory socket.

Scheme 53

Scheme 54

Scheme 55

SEAT CUSHION HEATER CHECK

Measure the resistance between terminals.

Standard value: At room temperature 20 °C (68 °F)

Between terminals 2 and terminal 3: Approximately 3.98 ohms +/- 5%

Between terminals 1 and terminal 3: 3.98 ohms +/- 5%

Note. When the interior temperature rises 1°C (34°F), a measurement standard value increases 0.031 ohms. And when the interior temperature drops 1°C (34°F), a measurement standard value decreases 0.031 ohms.

Scheme 56

SEATBACK HEATER CHECK

Measure the resistance between terminals.

Standard value: At room temperature 20 °C (68 °F)

Approximately 4.51 ohms +/- 5%

Note. When the interior temperature rises 1°C (34°F), a measurement standard value increases 0.031 ohms. And when the interior temperature drops 1°C (34°F), a measurement standard value decreases 0.031 ohms.

Scheme 57

Scheme 58

1. Remove the instrument lower cover.
2. Remove the junction block mounting and slide the junction block to check the heated seat. HEATED SEAT RELAY CONTINUITY CHECK CHART BATTERY VOLTAGE TESTER CONNECTION SPECIFIED CONDITION Not applied 1-4 Open circuit Connect terminal 3 to the positive battery terminal Connect terminal 2 to the negative battery terminal 1-4 Less than 2 ohms

Scheme 59

POWER SEAT SWITCH CONTINUITY CHECK CHART

Scheme 60

1. Disconnect the connector of each motor.
2. Check that when the battery is directly connected to the motor terminal, the motor turns smoothly and each adjusting mechanism operates as stated below for each motor: Connect the battery power supply to the terminal 2 and ground the terminal 1, front slide side. Connect the battery power supply to the terminal 1 and ground the terminal 2, rear slide side. Connect the battery power supply to the terminal 3 and ground the terminal 2 for the front height down side and connect the battery power supply to the terminal 2 and ground the terminal 3 for the front height up side. Connect the battery power supply to the terminal 4 and ground the terminal 3 for the rear height up side and connect the battery power supply to the terminal 3 and ground the terminal 4 for the rear height down side.
3. If abnormality was found, check the power seat adjuster assembly.

< DRIVER'S SEAT >

Scheme 61

Scheme 62

Scheme 63

Scheme 64

1. Raise the seatback panel while holding it as shown, and disconnect the seatback frame wire and hook connection.
2. If the seatback panel cannot be removed by the steps above, remove it as follows. Insert a screwdriver and slide hook 1 to remove it from the panel. Swing the panel to the right and left, and remove hook 2 from the wire. Finally, remove hook 3.

SEAT BELT SWITCH CONTINUITY CHECK

SEAT BELT SWITCH CONTINUITY CHECK CHART

Scheme 65

Scheme 66
