ENGINE COMPARTMENT

Fuse holder 3 is located at the left rear of engine compartment (Scheme 1) To identify fuse placement (Scheme 2)

Scheme 1

Scheme 2

Fuse holder 3 fuses protect

1. F01: 5A - Digital motor electronics control unit/ Convertible Soft Top Control Unit (Convertible)
2. F02: 20A - Digital motor electronics control unit/ Ignition coil/ Cylinder 1-4 fuel injection valves/ Crankshaft position sensor (From K6300 87)
3. F03: 15A - Camshaft position sensor/ O2 sensor before cat/ O2 sensor after cat/ Solenoid valve, fuel tank ventilation/ Relay K19 control power (From K6300 87)/ Relay K96
4. F04: 15A - Tank Leakage diagnosis pump
5. F05: 5A - Electric fan relay (From K6300 87)
6. F06: 30A - ABS control module or ABS/DSC control module
7. F07: 30A - Magnetic clutch for A/C compressor via relay K19
8. F08: 30A - I01152 Elec.Fan Relay/ Steering control Unit fan Relay/ Switch unit 1 or 2 speed blower/ Elec.fan 1 motor
9. F09: 20A - BC1 (X11177 2) unit via I01136 and I01137 (Relay wiper motor fast/slow and Relay wiper motor on/off)
10. F010: 15A - BC1/ Left fog/ Right fog/ Switch panel via K47

Note. The high current fuses FL1-FL5 are underneath (on the bottom) of the Engine Compartment Fuse panel.

1. FL1: 50A - Feed to Passenger Compartment Fuseholder (F14, F31, F32)
2. FL2: 50A - Feed to Passenger Compartment Fuseholder
3. FL3: No Info
4. FL4: 100A - Steering control unit/ Hydraulic pump
5. FL5: 50A - Feed to Passenger Compartment Fuseholder (F15, F16, F17)
6. FL6: 30A - ABS or ABS/DSC unit
7. FL7: 50A - Feed to ignition switch
8. FL8: 50A - Terminal 30
9. FL9: 30A - 2-Stage blower switching unit/ Elec.Fan Stage 2 Relay
10. FL10: 50A - K416 Relay windshield defroster
11. FL11: No Info
12. FL12: 50A - Terminal 30

PASSENGER COMPARTMENT

Fuse holder 2 is located at the left footwell trim (Scheme 3) To identify fuse placement (Scheme 4)

Scheme 3

Scheme 4

Fuse holder 2 fuses protect

1. F1: 30A - BC1 (X332 3) Terminal 30
2. F2: 5A - Steering angle sensor
3. F3: 5A - Instrument cluster control unit/ Outside mirror fold-in control unit
4. F4: 5A - BC1 (X254 27) Terminal 30
5. F5: 5A - Control module for instrument cluster
6. F6: 5A - Brake light switch/ Clutch switch module/ Electronic immobilizer control unit
7. F7: 5A - BC1 (X254 36) Terminal R/ Rain sensor
8. F8: 5A - Turn indicator/low beam switch
9. F9: 5A - Control module for instrument cluster
10. F10: 5A - Navigation computer/ On-board monitor control unit/Radio control unit/ Universal electronic charging and hands-free module (ULF)/ Eject box
11. F11: 5A - Rear washer pump relay K119/ Front washer pump relay K5
12. F12: 20A - Ignition switch
13. F13: 5A - Reversing light switch/ CVT switch
14. F14: 10A - BC1 (X332 14) Terminal 30
15. F15: 20A - Sunroof module control unit
16. F16: 30A - BC1/ Rear window w/o antenna or Wave trap 1 w/Rear window antenna via K13
17. F17: 15A - Rear window wiper motor via rear wiper motor relay
18. F18: 5A - Hall sensor driver & passenger buckle/ Multiple restraint system/ Passenger airbag deactivation switch
19. F19: 30A - BC1 (X332 7) Terminal 30
20. F20: 20A - Fuel pump relay 1 (K96)
21. F21: 10A - Control module for instrument cluster
22. F22: 15A - On board monitor control unit/ Navigation computer/ Eject box or Universal electronic charging and hands-free module (ULF)
23. F23: 20A - K5 Relay front washer pump/ K119 relay rear washer pump/ BC1
24. F24: 5A - Electronic immobilizer control unit/ Horn for antitheft alarm system/ Microwave sensors (Convertible)
25. F25: 30A - Headlight washer pump via K6
26. F26: 10A - Gearshift lock, via I01148 relay
27. F27: 15A - Radio control unit/ CD Changer/ Amplifier
28. F28: 15A - Volute spring/ Right & Left horns, via K2
29. F29: 5A - Heating and AC control module/ Interior temperature fan Sensor
30. F30: 5A - Heating and AC control module/ Interior temperature fan Sensor
31. F31: 30A - BC1 via K4 (X253 23)
32. F32: 15A - Front cigar lighter, via Relay I01151
33. F33: 10A - ABS or ABS/DSC unit
34. F34: 10A - Digital motor electronics control unit (Gas or Diesel)
35. F35: 5A - Mirror adjustment switch/ Electrochromic rear view mirror/ Windshield washer jets heater/ Outside mirrors
36. F36: 5A - Windshield defroster, Relay K416
37. F37: 20A - BC1 (X332 1)
38. F38: 5A - Steering control unit/hydraulic pump/ Alternator
39. F39: 5A - Steering angle sensor/ Switch panel
40. F40: 5A - Control module for instrument panel/ Switch panel/ Steering angle sensor
41. F41: 5A - Park distance control unit/ Steering control unit fan, Relay K69923
42. F42: No Info

LUGGAGE COMPARTMENT

Note. Cooper S models are equipped with an additional fusebox that carries a single 250A fusible link, located adjacent to the battery in the luggage compartment. (Scheme 5)

Scheme 5
