ENGINE COMPARTMENT

Front Power Distribution Box (A400a) is located at the left side of engine compartment (Scheme 6) Fuse Box (A406) is located at the right rear of engine compartment next to battery (Scheme 7)

Scheme 6

Front Power Distribution Box (A400a) fuses protect

1. F01: 5A - Digital motor electronics (DME) control unit
2. F02: 25A - Digital motor electronics (DME) control unit
3. F03: 20A - Digital motor electronics (DME) control unit/ Relay K6539
4. F04: 20A - Tank Leakage diagnosis pump
5. F05: 5A - Diagnostic module for fuel tank leakage/ Fuel injectors relay (Cooper S) or Valvetronic relay (Cooper)
6. F06: 25A - Dynamic stability control (DSC)
7. F07: 7.5A - Engine breather heater 1, via relay K6539
8. F08: 30A - Elec.Fan via Relay K21
9. F09: 25A - Relay K37 (Wiper module)/ Relay K36 (Junction box A4010)
10. F010: 15A - Relay K6326 (Junction box A4010 & DME control unit)

1. FL4: 80A - Electromechanical power steering
2. FL6: 40A - Dynamic stability control (DSC)
3. FL8: 30A - Dynamic stability control (DSC)
4. FL9: 50A - Relay K22: Elec.fan/ DME control unit (Cooper S)/ Digital diesel electronics control unit (Diesel)
5. FL10: 50A - Windscreen heater relay (K416)
6. FL12: 30A - DC/DC converter

Scheme 7

Fuse Box (A406) fuses protect

1. F60: 125A - Relay I01139 (Passenger Compartment Junction Box A4010)/ Front Power Distribution Box (A400a)
2. F67: 150A - Front Power Distribution Box (A400a)
3. F68: 40A - Valvetronic relay (Cooper)/ Fuel injectors relay (Cooper S)
4. F69: 100A - No info

PASSENGER COMPARTMENT

Junction Box (A4010) is located at the right footwell trim (Scheme 8)

Scheme 8

Junction Box (A4010) fuses protect

1. F1: No Info
2. F2: 20A - Trailer socket
3. F3: 30A - Headlight washer pump, via relay K6
4. F4: No Info
5. F5: 30A - Footwell module
6. F6: 20A - Amplifier
7. F7: 30A - Sunroof
8. F8: 30A - Footwell module
9. F9: 15A - System lock (Driver/Passenger doors)/ Central locking drive, fuel filler flap
10. F10: 10A - Telephone components/connections
11. F11: 10A - Video module/ Digital tuner/ Satellite receiver
12. F12: 10A - CD changer
13. F13: 15A - Transmission control
14. F14: 10A - Make-up mirror lights/ Roof operating unit/ Luggage compartment light
15. F15: 10A - Steering column switch cluster
16. F16: 5A - Dynamic stability control (DSC)
17. F17: 5A - Rain/Headlight sensor/ Tyre pressure control (RDC)
18. F18: 10A - Heating/Air conditioning system/ Glove compartment light
19. F19: 10A - Comfort access control unit
20. F20: 7.5A - Outside mirror fold-in
21. F21: 10A - MINI joystick/ Radio/ Central information display
22. F22: 15A - Rear wiper drive relay (K91)
23. F23: 10A - Compressor clutch relay (K19)
24. F24: 15A - Relays K5 and I01172 (Windscreen washer pump)
25. F25: 5A - Electrochromic rear view mirror/ Selector lever position switch
26. F26: 7.5A - Siren with tilt alarm senor
27. F27: 5A - OBDII socket
28. F28: No info
29. F29: 5A - Connector, telephone retrofit packages
30. F30: 5A - Park distance control (PDC)
31. F31: 5A - AUC sensor/ DC/DC converter
32. F32: 7.5A - Mirror adjustment switch/ Driver's seat heating module/ Passenger's seat heating module/ Electrochromic interior rear view mirror
33. F33: 5A - DSC sensor
34. F34: 5A - Car access system
35. F35: No info
36. F36: 5A - Navigation system connector (Japan navigation preparation)
37. F37: 5A - Additional instrument (Supply, terminal 30G - Connector X9002)
38. F38: 30A - Lockout circuit for rear window defogger (positive), via relay K13
39. F39: 30A - Passenger's seat heating module
40. F40: 30A - Driver's seat heating module
41. F41: No Info
42. F42: 20A - Front cigar lighter/ Charging socket, rear
43. F43: 20A - Electric fuel pump, via relay K96
44. F44: 20A - Steering column switch cluster/ Horns, via relay K2a
45. F45: 20A - CCC/M-ASK
46. F46: 30A - Heating/air conditioning system, via relay K4
47. F47: 40A - Footwell module
48. F48: 40A - Footwell module
49. F49: 40A - Car access system
