Removal & Installation
Remove driver's door pull cup. Disconnect power window master switch connector. Remove power window master switch assembly from door pull cup. To install, reverse removal procedure.
- Disconnect negative battery cable. Using 1/4" flat-blade screwdriver, carefully pry off front door inside handle escutcheon and trim plate. Remove 2 cover caps and door panel screws. Slide flat-blade screwdriver behind each door trim panel retainer and twist to disengage. Disconnect connectors.
- Remove 2 front door trim panel bracket bolts and bracket. Remove weatherseal from door frame. Lower door glass to access regulator-to-bottom channel bolts. Remove window glass from door.
- Remove 2 door brace bolts and brace. Disconnect power window motor connector. Remove 4 window regulator track bolts (2 at top and 2 at bottom). Remove 3 power window motor attaching bolts. Remove window regulator and motor as an assembly. To install, reverse removal procedure.
Remove passenger's door pull cup. Disconnect power window switch connector. Remove power window switch assembly from door pull cup. To install, reverse removal procedure.
