POWER REAR QUARTER GLASS POWER LATCH MOTOR

Disconnect quarter glass power latch connector. Using jumper wires, connect battery to motor 2-pin connector. Latch should turn in one direction (open or close). Reverse battery connections. Motor should reverse rotation. If latch motor does not operate as specified, replace latch motor assembly.

POWER WINDOW MASTER SWITCH

Disconnect power window master switch connector. Using an ohmmeter, measure resistance between indicated terminals with switch in specified position. See POWER WINDOW MASTER SWITCH RESISTANCE (FRONT POWER) or POWER WINDOW MASTER SWITCH RESISTANCE (FRONT & REAR POWER) table. (Scheme 4)or (Scheme 5). If resistance is not as specified, replace power window master switch.

Switch PositionTerminals No.Ohms
Left Window Switch
Up1 & 2; 6 & 7Less Than 5
Down1 & 7; 2 & 6Less Than 5
Right Window Switch
Up1 & 12; 6 & 11Less Than 5
Down1 & 11; 6 & 12Less Than 5

POWER WINDOW MASTER SWITCH RESISTANCE (FRONT POWER)

Switch PositionTerminals No.Ohms
Left Front Window Switch
Up8 & 16; 13 & 15Less Than 5
Down8 & 13; 15 & 16Less Than 5
Right Front Window Switch
Up9 & 16; 10 & 13Less Than 5
Down9 & 13; 10 & 16Less Than 5
Left Rear Window Switch
Open5 & 16; 7 & 13Less Than 5
Closed5 & 13; 7 & 16Less Than 5
Right Rear Window Switch
Open1 & 16; 2 & 13Less Than 5
Closed1 & 13; 2 & 16Less Than 5

POWER WINDOW MASTER SWITCH RESISTANCE (FRONT & REAR POWER)

Scheme 4

Scheme 4

Scheme 5

Scheme 5

POWER WINDOW MOTOR

Disconnect power window motor connector. See POWER WINDOW MOTOR under REMOVAL & INSTALLATION. Using jumper wires, connect battery to motor 2-pin connector. Window will move in one direction (down or up). Reverse battery connections. Motor should reverse rotation. If power window motor does not operate as specified, replace power window motor.

PASSENGER'S POWER WINDOW SWITCH

Disconnect passenger's power window switch connector. Using an ohmmeter, measure resistance between indicated terminals with switch in specified position. See PASSENGER'S POWER WINDOW SWITCH RESISTANCE table. (Scheme 6) If resistance readings are not as specified, replace passenger's power window switch.

Switch PositionTerminals No.Ohms
Up2 & 3; 7 & 8Less Than 5
Down2 & 3; 6 & 7Less Than 5

PASSENGER'S POWER WINDOW SWITCH RESISTANCE

Scheme 6

Scheme 6
