SPECIFICATIONS
| Application | Specification |
|---|
| Compressor Type | Ford FS-10 10-Cyl. |
| Compressor Belt Deflection (1) |
| New (2) | 5/32-7/32" (4-6 mm) |
| Used | 3/16-15/64" (5-7 mm) |
| Service Limit | 25/64" (10 mm) |
| System Oil Capacity |
| With Auxiliary Unit | 10 ozs. |
| Without Auxiliary Unit | 7 ozs. |
| Refrigerant (R-134a) Capacity |
| With Auxiliary Unit | 52 ozs. |
| Without Auxiliary Unit | 32 ozs. |
| System Operating Pressures (3) |
| High Side | 125-230 psi (8.8-16.2 kg/cm 2 ) |
| Low Side | 23.5-47.0 psi (1.65-3.30 kg/cm 2 ) |
| (1) Measure deflection with 22-lb. pressure applied midway way between A/C clutch pulley and crankshaft pulley. Ensure engine is cold or has been stopped for at least 30 minutes. (2) Any belt in use less than 5 minutes. (3) Approximate pressures with ambient temperature at 77°F (25°C). |
| (1) | Measure deflection with 22-lb. pressure applied midway way between A/C clutch pulley and crankshaft pulley. Ensure engine is cold or has been stopped for at least 30 minutes. |
| (2) | Any belt in use less than 5 minutes. |
| (3) | Approximate pressures with ambient temperature at 77°F (25°C). |
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| A/C Compressor Bolts | 15 (20) |
| Compressor Manifold Bolt | 19 (26) |
| Compressor Bracket Bolts | 21 (29) |
| Driver Air Bag Module Bolts | 15 (21) |
| Passenger Air Bag Module Nuts | 18 (24) |
| Steering Column Nuts | 13 (17) |
| Tensioner Bracket Bolts | 15 (20) |
| INCH Lbs. (N.m) |
| Cooling Fan & Shroud Mounting Bolts | 71 (9) |
| Condenser Bolts | 53-70 (6.0-8.0) |
| Instrument Panel Bolts | 44 (5) |
| Instrument Panel Cowl Top Screws | 44 (5) |
| Instrument Panel Screws | 27 (3) |
| Instrument Panel Support Bolts/Nuts | 89 (10) |
| Instrument Panel Screws | 23-32 (2.6-3.6) |
| Instrument Panel Center Support Bracket Bolts | 44 (5) |
| Instrument Panel Lower Support Bolts | 89 (10) |
| Peanut Fitting | 80 (9) |
| Radiator-To-Support | 71 (9) |
| Steering Column Cover Reinforcement Bolts | 44 (5) |
| Suction/Accumulator Clamp Bolt | 96 (11) |
Automatic A/C-Heater System Wiring Diagram (2000-01 Villager - Auxiliary System). Scheme 21
Scheme 21: Automatic A/C-Heater System Wiring Diagram (2000-01 Villager - Auxiliary System)
Automatic A/C-Heater System Wiring Diagram (2000-01 Villager - 1 Of 2). Scheme 22
Scheme 22: Automatic A/C-Heater System Wiring Diagram (2000-01 Villager - 1 Of 2)
Automatic A/C-Heater System Wiring Diagram (2000-01 Villager - 2 Of 2). Scheme 23
Scheme 23: Automatic A/C-Heater System Wiring Diagram (2000-01 Villager - 2 Of 2)
