Fuse Identification
- 1 - 20 Amp - Front Blower Motor (A/C-Heater)
- 2 - 20 Amp - Front Blower Motor (A/C-Heater)
- 3 - Relay - Rear Defrost
- 4 - 5 Amp - Electronic Engine Control
- 5 - 15 Amp - Rear Blower Motor (A/C-Heater)
- 6 - Relay - Accessory #1
- 7 - 15 Amp - Rear Blower Motor (A/C-Heater)
- 8 - 20 Amp - Front Wiper/Washer, Interval Wiper
- 9 - 10 Amp - Electronic Engine Control
- 10 - 15 Amp - Fuel Pump, Electronic Engine Control
- 11 - Relay - Accessory #2
- 12 - 10 Amp - Audio System
- 13 - 10 Amp - Air Conditioning
- 14 - 20 Amp - Cigarette Lighter, Horn
- 15 - 15 Amp - Rear Wiper/Washer, Power Mirrors
- 16 - Relay - Ignition
- 17 - 10 Amp - A/C-Heater, Electronic Automatic Transaxle, Illuminated Entry, Instrument Cluster, Keyless Entry, Rear Window Defrost, Warning Chime
- 18 - 10 Amp - Anti-Lock Brake System, Autolights/Delayed Exit, Backup Lights, Daytime Running Lights (Canada Only), Electronic Automatic Transaxle, Passive Restraint System, Shift Lock, Speed Control, Starting System
- 19 - Spare Fuse
- 20 - 15 Amp - Courtesy Lights, Illuminated Entry, Keyless Entry, Passive Restraint System, Warning Chime
- 21 - Spare Fuse
- 22 - 15 Amp - Anti-Lock Brake system, Shift Lock, Speed Control, Trailer Adapter: Turn, Stop, Hazard Lights
- 23 - 10 Amp - Audio System
- 24 - 10 Amp - Turn Signals, Trailer Adapter: Turn, Stop, Hazard Lights, Warning Chime
- 25 - 10 Amp - A/C-Heater, Electronic Engine Control, Ignition System, Instrument Cluster, Vehicle Speed Sensor, Warning Chime
- 26 - 10 Amp - A/C-Heater, Autolights/Delayed Exit, Engine Cooling Fan, Electronic Engine Control, Instrument Cluster, Moon Roof, Power Windows, Rear Window Defrost, Speed Control, Warning Chime
- 27 - 15 Amp - Autolights/Delayed Exit, Cornering Lights, Headlights (Without DRL), Warning Chime
- 28 - 15 Amp - Horn, Cigar Lighter, Speed Control
- 29 - Spare Fuse
- 30 - 15 Amp - Trailer Adapter: Turn, Stop, Hazard Lights
- 31 - 20 Amp - Rear Defogger
- 32 - Spare Fuse
- 33 - 20 Amp - Rear Window Defogger
- 34 - 20 Amp - Audio Amp
Note. see scheme 3
- 1 - 20 Amp - Front Blower Motor (A/C-Heater)
- 2 - 20 Amp - Front Blower Motor (A/C-Heater)
- 3 - Relay - Rear Defrost
- 4 - 5 Amp - Electronic Engine Control, Daytime Running Lights (Canada)
- 5 - 15 Amp - Rear Blower Motor (A/C-Heater)
- 6 - Relay - Accessory #1
- 7 - 15 Amp - Rear Blower Motor (A/C-Heater)
- 8 - 20 Amp - Front Wiper/Washer, Interval Wiper
- 9 - 10 Amp - Electronic Engine Control
- 10 - 15 Amp - Fuel Pump, Electronic Engine Control
- 11 - Relay - Accessory #2
- 12 - 10 Amp - Audio System
- 13 - 20 Amp - Audio Amp
- 14 - 20 Amp - Cigarette Lighter, Horn
- 15 - 10 Amp - Rear Wiper/Washer, Power Mirrors
- 16 - Relay - Ignition
- 17 - 10 Amp - A/C-Heater, Electronic Automatic Transaxle, Illuminated Entry, Instrument Cluster, Keyless Entry, Rear Window Defrost, Warning Chime
- 18 - 10 Amp - Anti-Lock Brake System, Autolights/Delayed Exit, Backup Lights, Daytime Running Lights (Canada Only), Electronic Automatic Transaxle, Passive Restraint System, Shift Lock, Speed Control, Starting System
- 19 - Spare Fuse
- 20 - 15 Amp - Courtesy Lights, Illuminated Entry, Keyless Entry, Passive Restraint System, Warning Chime
- 21 - Spare Fuse
- 22 - 15 Amp - Anti-Lock Brake system, Shift Lock, Speed Control, Trailer Adapter: Turn, Stop, Hazard Lights
- 23 - 10 Amp - Audio System
- 24 - 10 Amp - Turn Signals, Trailer Adapter: Turn, Stop, Hazard Lights, Warning Chime
- 25 - 10 Amp - A/C-Heater, Electronic Engine Control, Ignition System, Instrument Cluster, Vehicle Speed Sensor, Warning Chime
- 26 - 10 Amp - A/C-Heater, Autolights/Delayed Exit, Engine Cooling Fan, Electronic Engine Control, Instrument Cluster, Moon Roof, Power Windows, Rear Window Defrost, Speed Control, Warning Chime
- 27 - 15 Amp - Autolights/Delayed Exit, Cornering Lights, Headlights (Without DRL), Warning Chime
- 28 - 15 Amp - Horn, Cigar Lighter, Speed Control
- 29 - Spare Fuse
- 30 - 15 Amp - Trailer Adapter: Turn, Stop, Hazard Lights
- 31 - 20 Amp - Rear Defogger
- 32 - Spare Fuse
- 33 - 20 Amp - Rear Window Defogger
- 34 - 10 Amp - Air Bag System
Scheme 1
- 1 - 20 Amp - Front Blower Motor (A/C-Heater)
- 2 - 20 Amp - Front Blower Motor (A/C-Heater)
- 3 - 5 Amp - Engine Control - Daytime Running Lamps (DRL), Powertrain Control Module (PCM)
- 4 - 15 Amp - Rear Blower Motor - A/C Heater
- 5 - 15 Amp - Rear Blower Motor - A/C-Heater
- 6 - 20 Amp - Front Wiper - Interval Wiper/Washer
- 7 - 10 Amp - Engine Control - Powertrain Control Module
- 8 - 15 Amp - Fuel Pump - Powertrain Control Module
- 9 - 10 Amp - Audio - Radio
- 10 - 20 Amp - Audio Amplifier - Radio (Mid-Line, Ford Super Sound)
- 11 - 20 Amp - Cigar Lighter
- 12 - 10 Amp - Rear Wiper - Liftgate Wiper/Washer, Power Side View Mirrors
- 13 - 10 Amp - Electron Bat - A/C-Heater, Electronic Automatic Transaxle, Illuminated Entry, Instrument Cluster, Keyless Entry, Rear Window Defrost, Warning Chime
- 14 - 10 Amp - Air Bag System
- 15 - 20 Amp - Rear Window Defrost
- 16 - 20 Amp - Rear Window Defrost
- 17 - 15 Amp - Trailer/Camper Adapter, Turn/Stop/Hazard Lamp
- 18 - 15 Amp - Horn, Speed Control
- 19 - 15 Amp - Tail Lamp - Autolamps/Delayed Exit, Cornering Lamps, Headlamps (With Out Daytime Running Lamps), Warning Chime
- 20 - 10 Amp - Relay Coil - A/C Heater, Autolmaps/Delayed Exit, Engine Cooling Fan Motor, Powertrain Control Module (PCM), Instrument Cluster, Power Moon Roof, Power Window, Rear Window Defrost, Speed Control, Warning Chime
- 21 - 10 Amp - A/C - Heater, Powertrain Control Module (PCM), Ignition System, Instrument Cluster, Vehicle Speed Sensor, Warning Chime
- 22 - 10 Amp - Turn - Trailer/Camper Adapter, Turn/Stop/Hazard Lamps, Warning Chime
- 23 - 15 Amp - Radio
- 24 - 15 Amp - Stop Lamp - Anti-Lock Brake System, Shift Lock, Speed Control, Trailer/Camper Adapter, Turn/Stop/Hazard Lamp
- 25 - 15 Amp - Room Lamp - Courtesy Lamps, Illuminated Entry, Keyless Entry, Passive Restraint System, Warning Chime
- 26 - 10 Amp - Anti-Lock Brake System, Autolamps/Delayed Exit, Backup Lamps, Daytime Running Lamps, Electronic Automatic Transaxle, Passive Restraint System, Shift Lock, Speed Control, Starting System
Scheme 2
Fuse & Relay Identification
- 1 - Not Used
- 2 - 10 Amp - A/C (Air Conditioning), Timer Module
- 3 - 10 Amp - Air Bag
- 4 - 10 Amp - Engine Emissions, Evaporative Emissions, Powertrain Control Module
- 5 - 10 Amp - Power Mirror, Timer Module
- 6 - 20 Amp - Cigar Lighter
- 7 - 20 Amp - Rear Power Plug
- 8 - 20 Amp - Front Windshield Wiper/Washer
- 9 - 10 Amp - Rear Window Wiper/Washer
- 10 - 7.5 Amp - Radio, Power Antenna, Rear Integrated Control Panel
- 11 - 20 Amp - Subwoofer Amplifier
- 12 - 7.5 Amp - Powertrain Control Module
- 13 - 7.5 Amp - A/C, Auto Light, Rear Defrost Switch
- 14 - 20 Amp - Rear Defrost
- 15 - 20 Amp - Rear Defrost
- 16 - 20 Amp - Heated Power Outside Side View Mirrors
- 17 - 10 Amp - Conering Lamp
- 18 - 7.5 Amp - Instrument Illumination, Radio Illumination
- 19 - 10 Amp - Rear Parking Lights
- 20 - 10 Amp - CD, Power Antenna, Radio
- 21 - 15 Amp - Dome Lamps, Step Lamps, Warning Chime
- 22 - 15 Amp - Shift Lock Solenoid, Stop Lamps
- 23 - 10 Amp - Hazard Flasher
- 24 - 15 Amp - Rear Blower Motor
- 25 - 15 Amp - Rear Blower Motor
- 26 - Not Used
- 27 - 10 Amp - Turn Signal Lights
- 28 - 20 Amp - Front Blower Motor
- 29 - 10 Amp - Relays In Main Fuse Junction Panel
- 30 - 10 Amp - Anti-Lock Brakes, Backup Lamps, Overdrive Off Lamp, PRND Switch
- 31 - 20 Amp - Front Blower Motor
- 32 - Not Used
- 33 - Relay - Accessory Relay #1 - Fuses 17-19
- 34 - Relay - Ignition Relay - Fuses 26, 27, 29, 30
- 35 - Relay - Accessory Relay #2 - Fuses 5-9
- 36 - Relay - Rear Defrost Relay - Fuses 14-16
- 37 - Relay - Blower Relay - Fuses 28, 31
- UNDERHOOD MAIN FUSE PANEL LOCATION
The main fuse panel is located in the engine compartment on the L/H fender Apron.
Scheme 3
- 1 - Relay - Engine Control (Powertrain Control Module)
- 2 - 20 Amp - Anti-Lock Brake System
- 3 - 15 Amp - Front Grill Illumination Bar
- 4 - 10 Amp - Alt (Generator)
- 5 - 15 Amp - R/H Headlight
- 6 - 15 Amp - L/H Headlight
- 7 - Spare Fuse
- 8 - 45 Amp - Rear Window Defroster
- 9 - 30 Amp - Ignition Switch
- 10 - 25 Amp - Electronic Engine Control
- 11 - 25 Amp - Fuel Injectors
- 12 - 30 Amp - Power Windows
- 13 - 30 Amp - Anti-Lock Brakes
Note. (Scheme 3)
- 1 - Relay - Powertrain Control Module
- 2 - 20 Amp - Anti-Lock Brake System
- 3 - 20 Amp - Autolamps, Delayed Exit, Courtesy Lamps, Exterior Lamps, Trailer Lamp Adapter
- 4 - 10 Amp - Charging System
- 5 - 15 Amp - Autolamps/Delayed Exit, Daytime Running Lamps, Headlamps (W/O DRL)
- 6 - 15 Amp - Autolamps/Delayed Exit, Daytime Running Lamps, Headlamps (W/O DRL)
- 7 - Spare Fuse
- 8 - 45 Amp - Rear Window Defroster
- 9 - 30 Amp - A/C Heater, Daytime Running Lamps, Powertrain Control Module, Ignition System, Starting System
- 10 - 25 Amp - Powertrain Control Module
- 11 - 25 Amp - Powertrain Control Module
- 12 - 30 Amp - Keyless Entry, Passive Restraint System, Power Door Lock, Power Lumbar, Power Moon Roof, Power Seat, Power Window
- 13 - 30 Amp - Anti-Lock Brake System
Scheme 4
- 1 - Relay - Cooling Fan (Low Speed)
- 2 - Relay - Cooling Fan (Medium Speed)
- 3 - Relay - Cooling Fan (High Speed)
- 4 - 30 Amp - Power Seat, Power Window, Sun Roof
- 5 - 30 Amp - Anti-Lock Brake Control Module
- 6 - 65 Amp - Cooling Fan
- 7 - 65 Amp - Front Blower Motor
- 8 - 100 Amp - Hazard Lamps, Interior Illumination, Radio, Stoplamps, Transmission Control Module
- 9 - 120 Amp - Mini Fuse Portion Of Main Fuse Junction Panel
- 10 - 45 Amp - Heated Mirrors, Heated Rear Window, Rear Blower Motor
- 11 - 30 Amp - Ignition Switch
- 12 - Not Used
- 13 - Not Used
- 14 - 15 Amp - Right Hand Headlight
- 15 - 15 Amp - Left Hand Headlight
- 16 - 10 Amp - Alternator Input
- 17 - 10 Amp - Powertrain Control Module Relay
- 18 - 10 Amp - Fuel Injectors
- 19 - 15 Amp - Fuel Pump Relay
- 20 - 15 Amp - Horn Relay
- 21 - 20 Amp - Anti-Lock Brake Hydraulic Actuator
- 22 - 15 Amp - Hood Illumination Lamp
- 23 - 7.5 Amp - Keyless Entry Beeper, Timer Module
- 24 - Relay - High Horn, Low Horn
- 25 - Relay - Fuel Pump
- 26 - Relay - Starter Motor
- 27 - Relay - Right Hand Headlight
- 28 - Relay - Brake Warning Lamp, Charge Warning Lamp
- 29 - Relay - Speed Control Module
- Underhood "High-Current" Fuse Panel Location
The "high-current" fuse panel is located in the engine compartment between the radiator and coolant recovery bottle.
| WARNING | Always disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician. |
Scheme 5
- 1 - 120 Amp - Alt (Generator)
- 2 - 100 Amp - Main
- 3 - 65 Amp - Engine Cooling Fan
- 4 - 65 Amp - Blower Motor (Front)
- RELAY FUSE PANEL LOCATION - 1995 ONLY
This relay box is in 1995 vehicles only. It is located in the engine compartment near the windshield washer fluid reservoir.
Scheme 6
Relay Identification
- 1 - Relay - Not Used
- 2 - Relay - Headlamp LH
- 3 - Relay - Not Used
- 4 - Relay - FICD
- 5 - Relay - Auto Light Headlamp
- 6 - Relay - Auto Light Taillamp
- 7 - Relay - Headlamp RH
- 8 - Relay - Air Conditioning
- 9 - Relay - Inhibit (Manual Level Position Switch)
- 10 - Relay - Rad Fan (HI 2) (Cooling Fan High Relay)
- 11 - Relay - Fuel Pump
- 12 - Relay - Horn
- 13 - Relay - Not Used
- 14 - Relay - Front Grille Lamp
- 15 - Relay - Radiator Fan (LO)
- 16 - Relay - Radiator Fan (HI 1)
- 17 - Relay - Bulb Check
- 18 - Relay - ASCD HOLD (Speed Control Relay)
Scheme 7
- 1 - Relay - Antitheft (Interrupt)
- 2 - Relay - Headlamp LH
- 3 - Relay - Not Used
- 4 - Relay - FICD
- 5 - Relay - Auto Light Headlamp/Antitheft Headlamp
- 6 - Relay - Air Conditioner
