Sunroof: Diagnosis Mercury Sable V

Inspection and Verification

1. Verify the customer concern by operating the system.
2. Visually inspect for obvious signs of mechanical or electrical damage. VISUAL INSPECTION CHART Mechanical Electrical Roof opening panel Roof opening panel frame Roof opening panel drain hoses Roof opening panel lifter assemblies Roof opening panel water trough Roof opening panel air deflector assembly Roof opening panel seal Roof opening panel shield Smart junction box (SJB) fuse(s): 19 (25A) 41 (15A) Circuitry Accessory delay relay Roof opening panel motor and module assembly Roof opening panel switch
3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
4. If the concern is not visually evident, determine the symptom. Go to «Symptom Chart - Roof Opening Panel»(ref-293467-S21157341842008080700000) or Go to «Symptom Chart - Noise, Vibration and Harshness (NVH)»(ref-293467-S21071178042008080700000) .

Symptom Chart - Roof Opening Panel

Symptom Chart - Roof Opening Panel

Symptom Chart - Noise, Vibration and Harshness (NVH)

Note. Noise, vibration and harshness (NVH) symptoms should be identified using the diagnostic tools that are available. For a list of these tools, an explanation of their uses and a glossary of common terms, refer to NOISE, VIBRATION AND HARSHNESS article. Since it is possible any one of multiple systems may be the cause of a symptom, it may be necessary to use a process of elimination type of diagnostic approach to pinpoint the responsible system. If this is not the causal system for the symptom, refer back to NOISE, VIBRATION AND HARSHNESS article for the next likely system and continue diagnosis.

Symptom Chart - Noise, Vibration and Harshness (NVH)

PINPOINT TEST A: THE ROOF OPENING PANEL HAS EXCESSIVE WIND NOISE

1. A1 VERIFY ROOF OPENING PANEL NOISE Road test the vehicle with the roof opening panel in the CLOSED and OPEN positions. Is the wind noise present only in the OPEN position? YES : Go to A4 . NO : Go to A2 .
2. A2 CHECK THE ROOF OPENING PANEL WEATHERSTRIP NOTE: Make sure the weatherstrip is secured to the glass, not cut, cracked, pinched, loose or obstructed in CLOSED, VENT and OPEN positions. Check the roof opening panel weatherstrip. Is the roof opening panel weatherstrip OK? YES : Go to A3 . NO : INSTALL a new roof opening panel weatherstrip. REFER to «Roof Opening Panel - Exploded View»(ref-293467-S31183086162008080700000) . TEST the system for normal operation.
3. A3 CHECK ROOF OPENING PANEL ADJUSTMENT Check the roof opening panel adjustment. Is the adjustment OK? YES : CHECK for correct installation of the roof opening panel and motor/module. REFER to «Roof Opening Panel - Exploded View»(ref-293467-S31183086162008080700000) , «Roof Opening Panel Frame»(ref-293467-S34744189802008080700000) and «Roof Opening Panel Motor»(ref-293467-S22199766602008080700000) . TEST the system for normal operation. NO : ADJUST the roof opening panel. REFER to «Roof Opening Panel Alignment»(ref-293467-S38885178292008080700000) . TEST the system for normal operation.
4. A4 CHECK THE AIR DEFLECTOR Make sure the air deflector is securely attached and check for damaged or unsecured springs. Is the air deflector OK? YES : PARTIALLY close the roof opening panel until the noise is eliminated. If the noise is eliminated, INFORM the customer that changing glass location will eliminate the wind noise. If the wind noise is not eliminated, READJUST panel. TEST the system for normal operation. NO : INSTALL new air deflector assembly. REFER to «Roof Opening Panel - Exploded View»(ref-293467-S31183086162008080700000) and «Air Deflector»(ref-293467-S25562126142008080700000) . TEST the system for normal operation.

PINPOINT TEST B: THE ROOF OPENING PANEL LEAKS

1. B1 CHECK THE ADJUSTMENT OF THE ROOF OPENING PANEL NOTE: Make sure the roof opening panel weatherstrip is not cracked or loose. Check the roof opening panel weatherstrip. Does the roof opening panel seal correctly? YES : Go to B2 . NO : ADJUST the roof opening panel. REFER to «Roof Opening Panel Alignment»(ref-293467-S38885178292008080700000) . TEST the system for normal operation.
2. B2 CHECK THE ROOF OPENING PANEL DRAIN HOSES NOTE: Make sure the roof opening panel drain hoses are not cracked, slit, pinched or obstructed. Check the 4 roof opening panel drain hoses for correct operation. Are the roof opening panel drain hoses OK? YES : Go to B3 . NO : REPAIR or INSTALL a new roof opening panel drain hose(s). TEST the system for normal operation.
3. B3 CHECK THE ROOF OPENING PANEL DRAIN HOSE ATTACHMENT POINTS NOTE: Make sure the roof opening panel drain hose attachment points are not damaged or obstructed. Check the roof opening panel drain hose attachment points for correct attachment. Are the roof opening panel drain hose attachment points OK? YES : Go to B4 . NO : REPAIR or INSTALL a new roof opening panel frame. REFER to «Roof Opening Panel - Exploded View»(ref-293467-S31183086162008080700000) and «Roof Opening Panel Frame»(ref-293467-S34744189802008080700000) . TEST the system for normal operation.
4. B4 CHECK THE ROOF OPENING PANEL REAR TROUGH CONDITION Check the roof opening panel rear trough for damage and make sure it is correctly attached. Is the roof opening panel trough OK? YES : Go to B5 . NO : REPAIR or INSTALL a new roof opening rear trough. REFER to «Roof Opening Panel - Exploded View»(ref-293467-S31183086162008080700000) , «Roof Opening Panel Frame»(ref-293467-S34744189802008080700000) , «Trough Assembly - Taurus, Sable»(ref-293467-S03333489332008080700000) or «Trough Assembly - Taurus X»(ref-293467-S05144151572008080700000) . TEST the system for normal operation.
5. B5 CHECK THE CONDITION OF THE ROOF OPENING GLASS PANEL Check the roof opening panel frame for damage that may cause the roof opening panel glass seal to seat incorrectly. Is the roof opening panel frame OK? YES : INSTALL a new roof opening panel glass. REFER to «Roof Opening Panel - Exploded View»(ref-293467-S31183086162008080700000) and «Roof Opening Panel Glass»(ref-293467-S25446362912008080700000) . TEST the system for normal operation NO : REPAIR or INSTALL a new roof opening panel frame. REFER to «Roof Opening Panel - Exploded View»(ref-293467-S31183086162008080700000) «Roof Opening Panel Frame»(ref-293467-S34744189802008080700000) . TEST the system for normal operation.

This pinpoint test is intended to diagnose the following

1. Roof opening panel glass
2. Roof opening panel air deflector assembly
3. Roof opening panel trough
4. Roof opening panel lifter assemblies
5. Headliner
6. Roof opening panel motor/module pad
7. Roof opening panel frame

PINPOINT TEST C: THE ROOF OPENING PANEL RATTLES

1. C1 CHECK THE ROOF OPENING PANEL TIGHTNESS With the roof opening panel in the CLOSED position, manually push up and fore/aft on the glass panel. Is the roof opening panel glass loose? YES : ADJUST the roof opening panel. REFER to «Roof Opening Panel Alignment»(ref-293467-S38885178292008080700000) . TEST the system for normal operation. NO : Go to C2 .
2. C2 CHECK THE ROOF OPENING PANEL TRACKS Open the roof opening panel. Check the roof opening panel tracks for obstructions and damage. Are the roof opening panel tracks OK? YES : Go to C3 . NO : REMOVE all the roof opening panel track obstructions and REPAIR the roof opening panel tracks. If the roof opening panel tracks cannot be repaired, INSTALL a new roof opening panel frame. REFER to «Roof Opening Panel - Exploded View»(ref-293467-S31183086162008080700000) and «Roof Opening Panel Frame»(ref-293467-S34744189802008080700000) . TEST the system for normal operation.
3. C3 CHECK THE ROOF OPENING PANEL WATER TROUGH AND TROUGH GUIDES Check the roof opening panel water trough and trough guides for any loose obstructions. Are the roof opening panel water trough and trough guides installed securely and free from obstructions? YES : Go to C4 . NO : REMOVE all obstructions from the roof opening panel water trough guides and install securely. INSTALL a new roof opening panel frame if the water trough guides are damaged. REFER to «Roof Opening Panel - Exploded View»(ref-293467-S31183086162008080700000) and «Roof Opening Panel Frame»(ref-293467-S34744189802008080700000) . TEST the system for normal operation.
4. C4 CHECK THE ROOF OPENING PANEL SHIELD (SUNSHADE) Check the roof opening panel shield for correct installation. Is the roof opening panel shield installed correctly? YES : Go to C5 . NO : INSTALL the roof opening panel shield correctly. REFER to «Roof Opening Panel Shield»(ref-293467-S07156672042008080700000) . TEST the system for normal operation.
5. C5 CHECK THE ROOF OPENING PANEL AIR DEFLECTOR ASSEMBLY Check the roof opening panel air deflector assembly for obstructions and damage. Is the roof opening panel air deflector assembly OK? YES : Go to C6 . NO : REMOVE all obstructions and REPAIR or INSTALL a new roof opening panel air deflector assembly. REFER to «Roof Opening Panel - Exploded View»(ref-293467-S31183086162008080700000) and «Roof Opening Panel Frame»(ref-293467-S34744189802008080700000) . TEST the system for normal operation.
6. C6 CHECK THE ROOF OPENING PANEL LIFTER ASSEMBLIES Verify the roof opening panel lifter assemblies are free from obstructions and damage. Are the roof opening panel lifter assemblies OK? YES : Go to C7 . NO : REMOVE all obstructions from the roof opening panel lifter assemblies and REPAIR any damage. If the roof opening panel lifter assemblies cannot be repaired, INSTALL a new roof opening panel frame. REFER to «Roof Opening Panel - Exploded View»(ref-293467-S31183086162008080700000) and «Roof Opening Panel Frame»(ref-293467-S34744189802008080700000) . TEST the system for normal operation.
7. C7 CHECK ROOF OPENING PANEL FRAME INSTALLATION Lower the headliner and check all roof opening fasteners for correct torque and verify correct installation of the roof opening panel frame. REFER to «Roof Opening Panel - Exploded View»(ref-293467-S31183086162008080700000) and «Roof Opening Panel Frame»(ref-293467-S34744189802008080700000) . Is the roof opening panel correctly installed and tightened to specification? YES : Go to C8 . NO : TIGHTEN the loose fasteners or REINSTALL the roof opening panel frame. REFER to «Roof Opening Panel - Exploded View»(ref-293467-S31183086162008080700000) and «Roof Opening Panel Frame»(ref-293467-S34744189802008080700000) . TEST the system for normal operation.
8. C8 CHECK THE ROOF OPENING PANEL FRAME FOR RATTLES Check the roof opening panel frame assembly for any loose parts or for any condition that will cause rattles. Is there a condition that will cause rattles? YES : INSTALL a suitable sound damper material to correct the condition. If the rattle still persists, INSTALL a new roof opening panel frame. REFER to «Roof Opening Panel - Exploded View»(ref-293467-S31183086162008080700000) and «Roof Opening Panel Frame»(ref-293467-S34744189802008080700000) . TEST the system for normal operation. NO : INSTALL a new roof opening panel frame. REFER to «Roof Opening Panel - Exploded View»(ref-293467-S31183086162008080700000) and «Roof Opening Panel Frame»(ref-293467-S34744189802008080700000) . TEST the system for normal operation.

Pinpoint Test E: The Roof Opening Panel Does Not Open or Close

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Roof Opening Panel for schematic and connector information.

The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed or a new roof opening panel assembly has been installed. Refer to Roof Opening Panel Motor Initialization .

1. Fuse(s)
2. Wiring, terminals or connectors
3. Roof opening panel switch
4. Roof opening panel motor/module assembly
5. Accessory delay relay

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

1. E1 CHECK THE MOTOR/MODULE FOR INITIALIZATION Carry out the roof opening panel motor initialization procedure. Refer to «Roof Opening Panel Motor Initialization»(ref-293467-S20526691362008080700000) . Is the concern still present? YES : Go to E2 . NO : The system is operating normally at this time. The roof opening panel motor was not initialized.
2. E2 CHECK THE POWER WINDOWS Key in ON position. Verify the power windows operate. Do the power windows operate? YES : Go to E3 . NO : REFER to «GLASS, FRAMES AND MECHANISMS»(ref-293466) article to diagnose the accessory delay relay circuit.
3. E3 CHECK THE ROOF OPENING PANEL SWITCH Key in OFF position. Disconnect: Roof Opening Panel Switch Carry out the Roof Opening Panel Switch Component Test. Refer to appropriate appropriate COMPONENT TESTING article article. Is the roof opening panel switch OK? YES : Go to E4 . NO : INSTALL a new roof opening panel switch. TEST the system for normal operation.
4. E4 CHECK VOLTAGE TO THE ROOF OPENING PANEL MOTOR/MODULE - CIRCUITS CBP41 (BU) AND SBP19 (BU/RD) Key in OFF position. Disconnect: Roof Opening Panel Motor/Module C921 Key in ON position. Measure the voltage between roof opening panel motor/module C921-3, circuit CBP41 (BU) and C921-6, circuit SBP19 (BU/RD), harness side and ground. Are the voltages greater than 10 volts, but less than 16 volts? YES : Go to E5 . NO : VERIFY SJB fuse 19 (25A) and fuse 41 (15A) are OK. If OK, REPAIR the circuit. TEST the system for normal operation.
5. E5 CHECK THE ROOF OPENING PANEL GROUND - CIRCUIT GD133 (BK) Key in OFF position. Measure the resistance between roof opening panel motor/module C921-1, circuit GD133 (BK), harness side and ground. Is the resistance less than 5 ohms? YES : Go to E6 . NO : REPAIR the circuit. TEST the system for normal operation.
6. E6 CHECK CIRCUIT CPR39 (VT/WH) FOR AN OPEN Measure the resistance between overhead console C930-4, circuit CPR39 (VT/WH), and roof opening panel motor/module C921-2, circuit CPR39 (VT/WH) harness side. Is the resistance less than 5 ohms? YES : CHECK the overhead console jumper harness for loose pins, an open or a short in circuit CPR39 (VT/WH) between the roof opening panel switch socket and overhead console C930-4. If the overhead console jumper harness is not OK, INSTALL a new overhead console jumper harness and TEST the system for normal operation. If the overhead console jumper harness is OK, go to E7 . NO : REPAIR the circuit. TEST the system for normal operation.
7. E7 CHECK CIRCUIT CPR40 (YE/OG) FOR AN OPEN Measure the resistance between overhead console C930-3, circuit CPR40 (YE/OG), and roof opening panel motor/module C921-10, circuit CPR40 (YE/OG) harness side. Is the resistance less than 5 ohms? YES : CHECK the overhead console jumper harness for loose pins, an open or a short in circuit CPR40 (YE/OG) between the roof opening panel switch socket and overhead console C930-3. If the overhead console jumper harness is not OK, INSTALL a new overhead console jumper harness and TEST the system for normal operation. If the overhead console jumper harness is OK, go to E8 . NO : REPAIR the circuit. TEST the system for normal operation.
8. E8 CHECK CIRCUIT CPR31 (VT/BN) FOR AN OPEN Measure the resistance between overhead console C930-7, circuit CPR31 (VT/BN), and roof opening panel motor/module C921-5, circuit CPR31 (VT/BN) harness side. Is the resistance less than 5 ohms? YES : CHECK the overhead console jumper harness for loose pins, an open or a short in circuit CPR31 (VT/BN) between the roof opening panel switch socket and overhead console C930-7. If the overhead console jumper harness is not OK, INSTALL a new overhead console jumper harness, and TEST the system for normal operation. If the overhead console jumper harness is OK, go to E9 . NO : REPAIR the circuit. TEST the system for normal operation.
9. E9 CHECK THE ROOF OPENING PANEL MOTOR/MODULE FOR CORRECT OPERATION Disconnect all roof opening panel motor/module connectors. Check for: corrosion. bent pins. pushed-out pins. Connect all roof opening panel motor/module connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new roof opening panel motor/module. REFER to «Roof Opening Panel Motor»(ref-293467-S22199766602008080700000) . TEST the system for normal operation. NO : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. TEST the system for normal operation.

Pinpoint Test F: The Roof Opening Panel Does Not Open or Close in VENT Position

Refer to appropriate SYSTEM WIRING DIAGRAMS article, Roof Opening Panel for schematic and connector information.

The roof opening panel motor must be initialized when repairs are carried out on any part of the roof opening panel system, including: whenever the roof opening panel motor has been removed from the roof opening panel system, the roof opening panel glass has been removed from the roof opening panel system, the roof opening panel assembly has been removed from the vehicle, a new roof opening panel motor has been installed, a new roof opening panel glass has been installed or a new roof opening panel assembly has been installed. Refer to Roof Opening Panel Motor Initialization .

1. Wiring, terminals or connectors
2. Roof opening panel switch
3. Roof opening panel motor/module assembly

Scheme 6

1. F1 CHECK THE MOTOR/MODULE FOR INITIALIZATION Attempt to carry out the roof opening panel motor initialization procedure. Refer to «Roof Opening Panel Motor Initialization»(ref-293467-S20526691362008080700000) . Is the concern still present, or does the roof opening panel motor fail to initialize? YES : Go to F2 . NO : The system is operating normally at this time. The roof opening panel motor was not initialized.
2. F2 CHECK THE ROOF OPENING PANEL SWITCH Key in OFF position. Disconnect: Roof Opening Panel Switch Carry out the Roof Opening Panel Switch Component Test. Refer to appropriate COMPONENT TESTING article. Is the roof opening panel switch OK? YES : Go to F3 . NO : INSTALL a new roof opening panel switch. TEST the system for normal operation.
3. F3 CHECK CIRCUIT CPR38 (WH/BU) FOR AN OPEN Measure the resistance between overhead console C930-2, circuit CPR38 (WH/BU), and roof opening panel motor/module C921-4, circuit CPR38 (WH/BU) harness side. Is the resistance less than 5 ohms? YES : CHECK the overhead console jumper harness for loose pins, an open or a short in circuit CPR38 (WH/BU) between the roof opening panel switch socket and overhead console C930-2. If the overhead console jumper harness is not OK, INSTALL a new overhead console jumper harness and TEST the system for normal operation. If the overhead console jumper harness is OK, go to F4 . NO : REPAIR the circuit. TEST the system for normal operation.
4. F4 CHECK CIRCUIT CPR40 (YE/OG) FOR AN OPEN Measure the resistance between overhead console C930-3, circuit CPR40 (YE/OG), and roof opening panel motor/module C921-10, circuit CPR40 (YE/OG) harness side. Is the resistance less than 5 ohms? YES : CHECK the overhead console jumper harness for loose pins, an open or a short in circuit CPR40 (YE/OG) between the roof opening panel switch socket and overhead console C930-3. If the overhead console jumper harness is not OK, INSTALL a new overhead console jumper harness and TEST the system for normal operation. If the overhead console jumper harness is OK, go to F5 . NO : REPAIR the circuit. TEST the system for normal operation.
5. F5 CHECK THE ROOF OPENING PANEL MOTOR/MODULE FOR CORRECT OPERATION Disconnect all roof opening panel motor/module connectors. Check for: corrosion. bent pins. pushed-out pins. Connect all roof opening panel motor/module connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? YES : INSTALL a new roof opening panel motor/module. REFER to «Roof Opening Panel Motor»(ref-293467-S22199766602008080700000) . TEST the system for normal operation. NO : The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. TEST the system for normal operation.
