Seat System: Removal & Installation Mercury Sable V

REMOVAL

Note. The air bag warning indicator illuminates when the correct restraint control module (RCM) fuse is removed and the ignition switch is ON.

Note. The supplemental restraint system (SRS) must be fully operational and free of faults before releasing the vehicle to the customer.

All seats

1. Position the seat to access all the seat-to-floor bolts and the safety belt anchor.
2. Depower the SRS. For additional information, refer to SRS Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-293481) article.
3. Slide up and remove the cushion side shield cover.
4. Remove the nut and separate the safety belt anchor (driver seat) or safety belt anchor with belt tension sensor (BTS) (passenger seat) from the seat mounting stud. If passenger seat, disconnect the BTS electrical connector. Pull the safety belt anchor through the seat side shield to allow for seat removal.
5. Pull out and remove the 2 seat-to-floor bolt covers.
6. Remove the 2 seat-to-floor bolts.
7. Remove the 2 seat rear mounting bolts.
8. Tip the seat and disconnect the seat electrical connector(s). If power seat, release the pin-type retainer and detach the wiring harness from the seat.
9. Tip the seat and disconnect the memory seat electrical connector. Pinch the locking tab toward the lever to release the lever. Pivot the lever all the way back and disconnect the electrical connector.
10. Remove the seat. Fold the passenger seat forward to aid in removal.

INSTALLATION

All seats

1. Position the seat in the vehicle.
2. Connect the seat electrical connector(s).
3. Connect the memory seat electrical connector. Make sure the lever is all the way back and in the fully released position. Align the connector uniformly and lightly push in until a subtle audible click is heard and slight resistance is felt. Using the lever, pivot it toward the seat connector end, drawing the connector into its mating end. Make sure the locking tab is engaged to the retainer on the lever.
4. Position the seat track on the SIPS bar and install the 2 seat rear mounting bolts. Align the seat track rear locators into the SIPS. Tighten to 48 Nm (35 lb-ft).
5. Install the 2 seat-to-floor bolts. Tighten to 48 Nm (35 lb-ft).
6. Install the 2 seat-to-floor bolt covers.
7. Position the safety belt anchor (driver seat) or safety belt anchor with BTS (passenger seat) onto the stud and install the nut. Tighten to 35 Nm (26 lb-ft). If passenger seat, connect the BTS electrical connector.
8. Install the seat cushion side shield cover. Make sure the safety belts and buckles are accessible to the occupants after installation. Verify the safety belt retractor operates without excessive effort or binding.
9. Repower the SRS. For additional information, refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-293481) article.

Seat - Exploded View, Front

Note. RH shown, LH similar.

Scheme 133

Scheme 134

Scheme 135

1. For additional information, refer to the procedures in this article.

REMOVAL AND INSTALLATION

Note. The air bag warning indicator illuminates when the correct restraint control module (RCM) fuse is removed and the ignition switch is ON.

Note. The supplemental restraint system (SRS) must be fully operational and free of faults before releasing the vehicle to the customer.

All seats

Note. If a side air bag deployment took place, a new seat back pad, trim cover and side air bag module and nuts must be installed. The seat back frame should be replaced if necessary.

Note. The air bag warning indicator illuminates when the correct restraints control module (RCM) fuse is removed and the ignition switch is ON.

Note. The supplemental restraint system (SRS) must be fully operational and free of faults before releasing the vehicle to the customer.

1. Depower the SRS. For additional information, refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-293481) article.
2. Remove the head restraint.
3. If equipped, remove the screw and lumbar adjust handle.
4. Release the backrest trim cover lower J-clips and hook-and-loop strips.
5. Place a hand between the backrest trim cover and backrest foam pad and carefully separate the hook-and-loop strips, then carefully roll up the backrest trim cover in an inside out fashion to the first row of hog rings in the front. On passenger seats, pull the backrest latch fold-flat release strap through the backrest trim cover bezel opening.
6. Remove the first row of hog rings in the front.
7. Release the hook-and-loop strip, invert the trim cover and remove the second row of hog rings in the front.
8. Release the J-clips at the back of the backrest trim cover.
9. Release the side air bag module backrest trim cover chute J-clip from around the side air bag module.
10. Feed the side air bag module backrest trim cover chute and J-clip retainers out through the side air bag module backrest foam pad opening.
11. Release the hook-and-loop strips in front, invert the backrest trim cover and remove the hog rings at the back.
12. Release the tabs and remove the head restraint guide.
13. Remove the backrest trim cover.

1. Position the backrest trim cover to the backrest foam pad and backrest frame.
2. Position the backrest trim cover and install the hog rings. Position the backrest trim cover duon tube above the lumbar support wire hooks. Install the hog rings.
3. Roll down the backrest trim cover to the side air bag module.
4. Feed the side air bag module backrest trim cover chute and J-clip retainers back through the side air bag module backrest foam pad opening.
5. Install the side air bag module backrest trim cover chute and J-clips around the side air bag module and backrest frame. Attach the chute J-clips.
6. Attach the J-clips at the back of the backrest trim cover.
7. Attach the hook-and-loop strips, roll the backrest trim cover down and install the second row of hog rings in the front.
8. Attach the hook-and-loop strips, roll the backrest trim cover down and install the first row of hog rings in the front. If passenger seat, pull the backrest latch fold-flat release strap through the backrest trim cover bezel opening.
9. Attach the backrest trim cover lower J-clip.
10. If equipped, install the lumbar adjust handle and screw.
11. Install the head restraint guides.
12. Install the head restraint.
13. Repower the SRS. For additional information, refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-293481) article.

Note. The air bag warning indicator illuminates when the correct restraint control module (RCM) fuse is removed and the ignition switch is ON.

Note. The supplemental restraint system (SRS) must be fully operational and free of faults before releasing the vehicle to the customer.

All seats

Note. The air bag warning indicator illuminates when the correct restraint control module (RCM) fuse is removed and the ignition switch is ON.

Note. The supplemental restraint system (SRS) must be fully operational and free of faults before releasing the vehicle to the customer.

1. Remove the front passenger seat. For additional information, refer to «Seat - Front»(ref-293480-S42343260962008080700000) .
2. Remove the heated seat module. Remove the rivet. Tip the heated seat module and slide the retainers out of the cushion frame bracket. Disconnect the electrical connector.
3. To install, reverse the removal procedure.
4. Install the front passenger seat. For additional information, refer to «Seat - Front»(ref-293480-S42343260962008080700000) .
5. Repower the SRS. For additional information, refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-293481) article.

Note. If a side air bag deployment took place, a new seat back pad, trim cover and side air bag module and nuts must be installed. The seat back frame should be replaced if necessary.

Note. The air bag warning indicator illuminates when the correct restraints control module (RCM) fuse is removed and the ignition switch is ON.

Note. The supplemental restraint system (SRS) must be fully operational and free of faults before releasing the vehicle to the customer.

1. Depower the SRS. For additional information, refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-293481) article.
2. Remove the screw and lumbar adjust handle.
3. Release the backrest trim cover lower J-clips and hook-and-loop strips.
4. Place a hand between the backrest trim cover and backrest foam pad and carefully separate the hook-and-loop strips, then carefully roll up the backrest trim cover in an inside out fashion to the first row of hog rings in the front. Pull the backrest latch fold-flat release strap through the trim cover bezel opening.
5. Remove the first row of hog rings in the front.
6. Release the hook-and-loop strip, invert the backrest trim cover and remove the second row of hog rings in the front.
7. Release the J-clips at the back of the backrest trim cover.
8. Release the side air bag module backrest trim cover chute J-clip from around the side air bag module.
9. Feed the side air bag module backrest trim cover chute and J-clip retainers out through the side air bag module backrest foam pad opening.
10. Release the hook-and-loop strips in front, invert the backrest trim cover and remove the hog rings at the back.
11. Remove the hog rings attaching the lumbar basket and backrest foam pad to the backrest frame.
12. Remove the tie straps at the top and outboard side of the backrest frame.
13. Remove the 2 screws and separate the lumbar adjuster.
14. Release the lumbar basket at the bottom and top and remove the assembly.

1. Attach the lumbar basket to the backrest frame at the bottom and top.
2. Position the lumbar adjuster and install the 2 screws.
3. Install the hog rings attaching the lumbar basket (if equipped) or backrest support (if equipped) and backrest foam pad to the backrest frame.
4. Position the backrest trim cover and install the hog rings. Position the backrest trim cover duon tube above the lumbar support wire hooks. Install the hog rings.
5. Install the third row of hog rings in front and attach the hook-and-loop strips.
6. Roll down the backrest trim cover to the side air bag module.
7. Feed the side air bag module backrest trim cover chute and J-clip retainers back through the side air bag module backrest foam pad opening.
8. Install the side air bag module backrest trim cover chute and J-clips around the side air bag module and backrest frame. Attach the chute J-clips.
9. Attach the J-clips at the back of the backrest trim cover.
10. Attach the hook-and-loop strips, roll the backrest trim cover down and install the second row of hog rings in the front.
11. Attach the hook-and-loop strips, roll the backrest trim cover down and install the first row of hog rings in the front.
12. If passenger seat, pull the backrest latch fold-flat release strap through the trim cover bezel opening.
13. Attach the backrest trim cover lower J-clip.
14. Install the lumbar adjust handle and screw.
15. Repower the SRS. For additional information, refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-293481) article.

Note. The air bag warning indicator illuminates when the correct restraint control module (RCM) fuse is removed and the ignition switch is ON.

Note. The supplemental restraint system (SRS) must be fully operational and free of faults before releasing the vehicle to the customer.

1. Depower the SRS. For additional information, refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-293481) article.
2. If equipped, pull out and remove the manual recline handle.
3. If equipped, remove the seat control switch knob and power recline knob.
4. Remove the rear screw, pull out on the side and front and separate the side shield.
5. Release the seat control switch wire harness pin-type retainer and remove the seat control switch from the side shield. Disconnect and remove the seat control switch.
6. To install, reverse the removal procedure.
7. Repower the SRS. For additional information, refer to Supplemental Restraint System (SRS) Depowering and Repowering in the General Procedures portion of «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-293481) article.

Note. The air bag warning indicator illuminates when the correct restraint control module (RCM) fuse is removed and the ignition switch is ON.

Note. The supplemental restraint system (SRS) must be fully operational and free of faults before releasing the vehicle to the customer.

All seats

Note. Occupant classification sensor (OCS) system components (seat cushion foam pad, bladder with pressure sensor and occupant classification system module [OCSM]) are calibrated to each other and are serviced as an assembly. The OCS system components are not to be installed separately. If a new OCS system, OCS system component or seat cushion foam pad are needed, a new OCS system service kit (seat cushion foam pad, bladder with pressure sensor and OCSM) must be installed as an assembly.

Note. To identify between a production OCS system and an OCS system service kit, inspect the OCSM electrical connector. A production OCS system allows the disconnection of the OCSM electrical connector. An OCS system service kit has the OCSM electrical connector glued to the OCSM, it cannot and should not be disconnected or altered.

Note. The air bag warning indicator illuminates when the correct restraint control module (RCM) fuse is removed and the ignition switch is ON.

Note. The supplemental restraint system (SRS) must be fully operational and free of faults before releasing the vehicle to the customer.

Note. The memory seat track position sensors are integral to the memory seat track motors. The memory seat track motor electrical connectors will connect to a seat track without the memory option. Make sure the correct seat track is being installed.

All seats

Scheme 136

Scheme 137

60 percent and 40 percent backrest

1. Remove the rear seat cushion. For additional information, refer to «Seat Cushion - Rear, Taurus, Sable»(ref-293480-S12863367722008080700000) .
2. Remove the 40 percent backrest lower outboard nut. To install, tighten to 48 Nm (35 lb-ft).
3. Pull the 40 percent backrest release strap, releasing the backrest latch from the striker and pivot the 40 percent seat forward.
4. Slide the 40 percent backrest out of the 60 percent pivot rod and remove.
5. Remove the 3 lower nuts from the 60 percent backrest at the 2 backrest mounting brackets. To install, tighten to 48 Nm (35 lb-ft).
6. Pull the 60 percent backrest release strap, releasing the backrest latch from the striker and pivot the 60 percent seat forward and remove.
7. To install, reverse the removal procedure. Make sure the safety belts and buckles are accessible to the occupants after installation.

Scheme 138

Note. LH shown, RH similar.

All bolsters

1. Remove the rear seat cushion. For additional information, refer to «Seat Cushion - Rear, Taurus, Sable»(ref-293480-S12863367722008080700000) .
2. Remove the nut from the lower retainer stud. To install, tighten to 8 Nm (71 lb-in).
3. Separate the LH rear door weatherstrip at the seat backrest side bolster.
4. Between the pinch weld and the LH scuff plate, pry out and release the side bolster lower retainer.
5. Slide the LH side bolster up and out to remove.
6. To install, reverse the removal procedure. When installing the side bolster, install a M6 x 1.0 nut on the lower retainer stud. Tighten to 8 Nm (71 lb-in).

Scheme 139

1. From under the front of the cushion assembly, push each of the 2 seat cushion floor latch release levers to the left of the vehicle. Lift up at the front and release the front of the cushion assembly.
2. Push the cushion assembly back as far as possible. Lift up at the rear outboard ends of the cushion assembly, clearing the retainer hooks from the cushion assembly wire, pull the cushion assembly forward and remove it.
3. To install, reverse the removal procedure. Make sure the safety belt buckles are accessible to the occupants after installation.

Scheme 140

Scheme 141

1. For additional information, refer to the procedures in this article.

1. Remove the rear seat cushion. For additional information, refer to «Seat Cushion - Rear, Taurus, Sable»(ref-293480-S12863367722008080700000) .
2. Remove the 60 percent rear seat backrest. For additional information, refer to «Seat Backrest - Rear, Taurus, Sable»(ref-293480-S09518954512008080700000) .
3. Push in on the head restraint adjust button and remove the head restraint assembly.
4. Remove the screw and the armrest bracket outboard cover.
5. Remove the armrest-to-bracket bolt. To install, tighten to 23 Nm (17 lb-ft).
6. Slide the pin, on the inboard side of the armrest, out of the backrest and remove the armrest.
7. Fold the armrest pocket panel of the trim cover up and move aside.
8. Remove the pin-type retainers.
9. Release the J-clip at the bottom of the backrest trim cover and release the trim cover hook-and-loop strips at the back.
10. Release the hook-and-loop strips, invert the trim cover and remove the 3 rows of hog rings. Invert the trim cover to the headrest guide sleeves.
11. Pull the latch release strap through the trim cover.
12. Lift the backrest foam pad, pinch the head restraint guide together and remove the 2 head restraint guides.
13. Remove the backrest trim cover.
14. To install, reverse the removal procedure.

1. Remove the rear seat cushion. For additional information, refer to «Seat Cushion - Rear, Taurus, Sable»(ref-293480-S12863367722008080700000) .
2. Remove the 40 percent rear seat backrest. For additional information, refer to «Seat Backrest - Rear, Taurus, Sable»(ref-293480-S09518954512008080700000) .
3. Push in on the head restraint adjust button and remove the head restraint assembly.
4. Release the J-clip at the bottom of the backrest trim cover and release the trim cover hook-and-loop strips at the back.
5. Remove the bushing.
6. Release the hook-and-loop strips, invert the backrest trim cover and remove the 3 rows of hog rings. Invert the trim cover to the head restraint guide.
7. Pull the latch release strap through the backrest trim cover.
8. Lift the backrest foam pad, pinch the head restraint guide together and remove the 2 head restraint guides.
9. Remove the backrest trim cover.
10. To install, reverse the removal procedure.

Scheme 142

Note. LH shown, RH similar.

Scheme 143

Scheme 144

Scheme 145

Power-fold seat

1. Disconnect the power-fold seat electrical connector.
2. Fold the affected 40 percent or 60 percent seat up to the E-Z entry position. If the 60 percent seat backrest does not fold down, go to Step 5. If the 60 percent seat backrest folds down but will not release from the floor strikers, go to Step 9. If the 40 percent seat cannot be placed in the E-Z entry position: for manually released 40 percent seat, go to Step 14. for electrically released 40 percent seat, refer to «Symptom Chart»(ref-293480-S00759729432008080700000) in Diagnosis and Testing.
3. Remove the 2 riser/seat track-to-floor pan bolts and 2 riser/seat track-to-floor pan nuts for the 40 percent or 60 percent seat.
4. Remove the affected seat.
5. Remove the screw and manual recline handle.
6. Remove the 2 screws and LH recliner outer cover.
7. Use a suitable tool and pull the RH recliner release cable while pulling the release strap to fold down the backrest.
8. If the backrest did not fold down, pull the LH and RH latch release cables to release the seat from the floor. After seat removal, repair the seat as needed or refer to Diagnosis and Testing in this article to diagnose the concern.
9. Remove the screw and manual recline handle.
10. Remove the 2 screws and LH recliner outer cover.
11. Use a suitable tool and pull the LH and RH latch release cables to release the seat from the floor.
12. If a latch cannot be released, use a suitable drill or hole saw to open access holes in the affected recliner latch cover and remove the 2 latch bolts.
13. Raise the seat and manually release the latch from the striker. After seat removal, repair the seat as needed or refer to Diagnosis and Testing in this article to diagnose the concern.
14. Remove the screw and manual recline handle.
15. Remove the 2 screws and RH recliner outer cover.
16. Use a suitable tool and pull the LH and RH latch release cables to release the seat from the floor.
17. If a latch cannot be released, use a suitable drill or hole saw to open access holes in the affected recliner latch cover and remove the 2 latch bolts.
18. Raise the seat and manually release the latch from the striker. After seat removal, repair the seat as needed or refer to Diagnosis and Testing in this article to diagnose the concern.
19. Remove the 2 screws and the console bracket cover.
20. Remove the 2 bolts and the inboard seat striker.
21. Remove the 2 bolts and the outboard striker.

Outboard seat strikers

1. Position the outboard seat striker to the floor and install the 2 bolts. Tighten to 48 Nm (35 lb-ft).
2. Position the inboard seat striker to the floor and install the 2 bolts. Tighten to 80 Nm (59 lb-ft).
3. Position the console bracket cover and install the 2 screws.
4. Position the seat in the vehicle and install the retainers in the following sequence. Install the riser/seat track-to-floor pan rear inboard nut. Tighten to 48 Nm (35 lb-ft). Install the riser/seat track-to-floor pan rear outboard nut. Tighten to 48 Nm (35 lb-ft). Install the riser/seat track-to-floor pan front outboard bolt. Tighten to 48 Nm (35 lb-ft). Install the riser/seat track-to-floor pan front inboard bolt. Tighten to 48 Nm (35 lb-ft).
5. Position the seat in the vehicle and install the retainers in the following sequence. Install the riser/seat track-to-floor pan rear inboard nut. Tighten to 48 Nm (35 lb-ft). Install the riser/seat track-to-floor pan rear outboard nut. Tighten to 48 Nm (35 lb-ft). Install the riser/seat track-to-floor pan front outboard bolt. Tighten to 48 Nm (35 lb-ft). Install the riser/seat track-to-floor pan front inboard bolt. Tighten to 48 Nm (35 lb-ft).
6. Connect the electrical connector.
7. Check the seat for correct operation. With the seat in the upright position, both latch feet must lock to the strikers. When releasing the seat to the E-Z entry position, the latches must release freely and not bind to the strikers. Make sure the safety belts and buckles are accessible to the occupants after installation.

Seat - Exploded View, Second Row, Taurus X

Note. Power-fold seat shown, manual 40 percent similar.

Note. LH shown, RH similar.

Scheme 146

Note. LH shown, RH similar.

Note. Both seat riser and seat track are shown.

Scheme 147

Note. LH shown, RH similar.

Scheme 148

Scheme 149

Scheme 150

1. For additional information, refer to the procedures in this article.

Note. With the seat out of the vehicle and the backrest in the fold-flat position, the inboard latch foot must be in the LATCHED position to pivot the backrest back to the UPRIGHT position.

Note. When installing the backrest, the retaining bolts must be tightened in the sequence shown.

1. Remove the 60 percent seat from the vehicle. For additional information, refer to «Seat - Rear, Second Row, Taurus X»(ref-293480-S31080261562008080700000) .
2. From under the seat, release 3 sets of cushion trim cover J-clips.
3. From under the seat and at the back, between the cushion foam pad and frame, release the J-clip attached to the seat cushion frame.
4. From under the seat, release the J-clip at the RH side of the cushion frame.
5. Pull the cushion trim cover outboard retainer out from between the riser and the cushion frame.
6. Remove the cushion foam pad and cushion trim cover.
7. Remove the bolt and separate the safety belt buckle and safety belt anchor assembly from the RH recliner.
8. Release the 2 backrest trim cover lower J-clips.
9. Release the 4 backrest trim cover inside J-clips from the hard back panel.
10. Roll the trim cover up and remove the 2 LH recliner-to-backrest frame bolts.
11. Pull and remove the outboard pivot cover.
12. Remove the pivot bolt.
13. Lift the backrest foam pad and trim cover. Remove the 2 RH recliner-to-backrest frame bolts.
14. Remove the backrest.

1. Position the backrest frame to the cushion frame.
2. Install the backrest frame bolts in the sequence shown. Install the 2 LH recliner-to-backrest frame bolts. Tighten to 50 Nm (37 lb-ft). Install the pivot bolt. Tighten to 23 Nm (17 lb-ft). Install the 2 RH recliner-to-backrest frame bolts. Tighten to 50 Nm (37 lb-ft).
3. Position and install the outboard pivot cover.
4. Reposition the backrest trim cover and attach the 4 backrest trim cover inside J-clips to the hard back panel.
5. Attach the 2 backrest trim cover lower J-clips.
6. Position the safety belt buckle and the safety belt anchor assembly to the RH recliner and install the bolt. Tighten to 48 Nm (35 lb-ft).
7. Reposition the cushion foam pad and cushion trim cover to the cushion frame.
8. Insert the cushion trim cover LH retainer back between the riser and the cushion frame.
9. From under the seat, attach the cushion trim cover J-clip at the RH side of the cushion frame.
10. From under the seat and at the back, between the cushion foam pad and frame, attach the cushion trim cover J-clip to the seat cushion frame.
11. From under the seat, attach 3 sets of cushion trim cover J-clips.
12. Install the 60 percent seat into the vehicle. For additional information, refer to «Seat - Rear, Second Row, Taurus X»(ref-293480-S31080261562008080700000) .

1. With the backrest folded down, release the backrest trim cover lower J-clip.
2. Release the 2 backrest trim cover inside J-clips from the hard back panel.
3. Separate and remove the outer pivot cover on the inboard side of the seat.
4. If equipped, disconnect the heater mat electrical connector.
5. Remove the pivot bolt. To install, tighten to 23 Nm (17 lb-ft).
6. Partially invert the backrest trim cover and remove the 2 recliner-to-backrest frame bolts. To install, tighten to 50 Nm (37 lb-ft).
7. Remove the backrest.
8. To install, reverse the removal procedure.

1. With the 60 percent seat in the E-Z entry position, release 3 sets of cushion trim cover J-clips from under the seat.
2. Pull the cushion trim cover outboard retainer out from between the riser and the cushion frame.
3. With the 60 percent seat positioned down, lift the cushion foam pad and cushion trim cover up. Remove the safety belt anchor and buckle bolt from the inboard recliner. To install, tighten to 50 Nm (37 lb-ft).
4. Release the 2 backrest trim cover lower J-clips.
5. Release the 4 backrest trim cover inside J-clips from the hard back panel.
6. Remove the LH and RH head restraints.
7. Squeeze the opening together and remove the outer safety belt trim guide.
8. Release the hook-and-loop strips, invert the backrest trim cover and remove the 3 rows of hog rings.
9. Release the hook-and-loop strips and invert the backrest trim cover to the top of the backrest.
10. Squeeze the tabs in and remove the 4 head restraint guides.
11. Feed the safety belt through and remove the backrest trim cover.
12. To install, reverse the removal procedure. Make sure the safety belts and buckles are accessible to the occupants after installation. Verify the safety belt retractor operates without excessive effort or binding.

1. Remove the head restraint.
2. With the backrest folded down, release the backrest trim cover lower J-clip.
3. Separate and remove the outer pivot cover.
4. Release the 2 backrest trim cover inside J-clips to hard back panel.
5. If equipped, disconnect the backrest heater mat electrical connector and route through the backrest trim cover.
6. Release the hook-and-loop strips, invert the backrest trim cover and remove the 3 rows of hog rings.
7. Release the hook-and-loop strips and invert the backrest trim cover to the top of the backrest.
8. Lift the backrest foam pad, squeeze the tabs in and remove the 2 head restraint guides.
9. Remove the backrest trim cover.
10. To install, reverse the removal procedure.

1. Fold the 60 percent seat up to the E-Z entry position.
2. From under the seat, release 3 sets of cushion trim cover J-clips.
3. From under the seat and at the back, between the cushion foam pad and cushion frame, release the J-clip attached to the seat cushion frame.
4. From under the seat, release the J-clip at the RH side of the cushion frame.
5. Pull the cushion trim cover outboard retainer out from between the riser and the cushion frame.
6. Position the second row 60 percent seat down.
7. Remove the cushion trim cover from the cushion foam pad.
8. To install, reverse the removal procedure.

Power-fold seat

1. Remove the seat. For additional information, refer to «Seat - Rear, Second Row, Taurus X»(ref-293480-S31080261562008080700000) .
2. Position the seat forward on the seat track and release the 2 forward trim cover J-clips.
3. Release the hook-and-loop strips from the bottom side of the cushion trim cover.
4. Place the seat in the E-Z entry position.
5. Release the outer and inner J-clips at the rear of the cushion trim cover.
6. Release the 2 cushion trim cover side retainers and remove from between the cushion frame and seat track. Un-curl the retainer ends and push through the opening between the cushion frame and riser/seat track.
7. Manually lock the inboard seat-to-floor latch and raise the backrest. For manual-fold seat, lower and lock the seat to the floor.
8. Invert and remove the cushion trim cover from the cushion foam pad. Route the bottom trim cover flap through the seat track adjust handle. Remove the hog rings. Carefully route the cushion trim cover rear flap from between the backrest and cushion.
9. To install, reverse the removal procedure. Make sure the child safety seat attaching points are accessible.

1. Remove the 60 percent seat from the vehicle. For additional information, refer to «Seat - Rear, Second Row, Taurus X»(ref-293480-S31080261562008080700000) .
2. Remove the 60 percent rear seat backrest. For additional information, refer to «Seat Backrest - Second Row, 60 Percent, Taurus X»(ref-293480-S41040086202008080700000) .
3. Remove the pin-type retainer, screw and the RH recliner cover.
4. Remove the 3 RH recliner-to-riser bolts. To install, tighten to 50 Nm (37 lb-ft).
5. Remove the cushion frame yoke-to-RH recliner bolt, detach the cable and remove the RH recliner. To install, tighten to 50 Nm (37 lb-ft).
6. To install, reverse the removal procedure.

1. Release the backrest trim cover lower J-clip on the LH side.
2. Release the 2 backrest trim cover inside J-clips to hard back panel.
3. Roll the trim cover up and remove the 2 LH recliner-to-backrest frame bolts. To install, tighten to 50 Nm (37 lb-ft).
4. Remove 2 screws, pull and remove the riser LH inner cover.
5. Remove 3 screws and the riser LH outer cover.
6. Remove the screw and the manual recliner handle.
7. Remove 2 screws and the LH recliner outer cover. On assembly, make sure the release strap is through the cover opening.
8. From under the seat, release 3 sets of cushion trim cover J-clips.
9. From under the seat and at the back, between the cushion foam pad and frame, release the J-clip attached to the seat cushion frame.
10. Pull the cushion trim cover outboard retainer out from between the riser and the cushion frame.
11. Remove the pin-type retainer, release the locator pins and remove the LH recliner inner cover.
12. Remove the 3 cables from the LH recliner.
13. Remove the 4 bolts and the LH recliner. To install, tighten to 50 Nm (37 lb-ft).

Manual seat

1. With the backrest folded down, release the backrest trim cover lower J-clip.
2. Release the 2 backrest trim cover inside J-clips to hard back panel.
3. Roll the backrest trim cover up to access the 2 recliner-to-backrest frame bolts.
4. Pull the cushion trim cover outboard retainer out from between the riser/seat track and the cushion frame.
5. Remove 2 screws, pull and remove the riser/seat track LH inner cover.
6. Remove 3 screws and the riser/seat track LH outer cover.
7. Remove the screw and the recliner handle.
8. Remove 2 screws, pull and remove the recliner outer cover. On assembly, make sure the release strap is through the cover opening.
9. Remove the pin-type retainer, release the locator tabs and remove the recliner inner cover.
10. Remove the 2 cables from the recliner.
11. Remove the 4 bolts and the recliner. To install, tighten to 50 Nm (37 lb-ft).
12. Remove the seat backrest. For additional information, refer to «Seat Backrest - Second Row, 40 Percent, Taurus X»(ref-293480-S19921814502008080700000) .
13. Release the outboard cushion trim cover side retainer and remove from between the cushion frame and seat track. Un-curl the retainer ends and push through the opening between the cushion frame and seat track.
14. Remove the screw and recliner handle.
15. Remove the outer recliner cover. Remove the recliner cover screw. Release and separate the outer and inner recliner covers. Route the backrest release pull strap through the cover opening.
16. Release the pin-type retainer and remove the inner recliner cover.
17. With the recliner in the released (folded) position, detach the 3 cables. Disconnect the power-fold seat motor cable from the recliner. Rotate the cable end guide to release. Disconnect the cable jacket from the cable clamp. Detach the inboard and outboard latch cable jackets from the retainers. Un-hook the inboard and outboard latch cable ends.
18. Remove the 2 recliner-to-cushion frame bolts and recliner. To install, tighten to 50 Nm (37 lb-ft).
19. To install, reverse the removal procedure.
20. Check the seat for correct operation. With the seat in the upright position, both latch feet must lock to the strikers. When releasing the seat to the E-Z entry position, the latches must release freely and not bind to the strikers. Make sure the safety belts and buckles are accessible to the occupants after installation.

All seats

1. Remove the 40 percent rear seat. For additional information, refer to «Seat - Rear, Second Row, Taurus X»(ref-293480-S31080261562008080700000) .
2. Remove the 40 percent rear seat backrest. For additional information, refer to «Seat Backrest - Second Row, 40 Percent, Taurus X»(ref-293480-S19921814502008080700000) .
3. Position the seat forward on the seat track and release the 2 forward trim cover side J-clips.
4. Release the hook-and-loop strips from the bottom side of the cushion trim cover.
5. Release the outer and inner J-clips at the rear of the cushion trim cover.
6. Release the 2 cushion trim cover side retainers and remove from between the cushion frame and seat track. Un-curl the retainer ends and push through the opening between the cushion frame and riser/seat track.
7. Remove the cushion trim cover and cushion foam pad assembly.
8. Remove the screw and recliner handle.
9. Remove the outer recliner cover. Remove the recliner cover screw. Release and separate the outer and inner recliner covers. Route the backrest release pull strap through the cover opening.
10. With the recliner in the released (folded) position, detach the 3 cables. Disconnect the power-fold seat motor cable from the recliner. Rotate the cable end guide to release. Disconnect the cable jacket from the cable clamp. Detach the inboard and outboard latch cable jackets from the retainers. Un-hook the inboard and outboard latch cable ends.
11. Remove 2 screws, pull and remove the recliner outer cover. Route the backrest release pull strap through the cover opening.
12. Remove the 2 cables from the recliner and route them out of the seat cushion frame.
13. Remove the 6 cushion frame-to-seat track nuts and remove the seat track. If equipped, detach the electrical connector from the seat track. To install, tighten to 23 Nm (17 lb-ft).
14. To install, reverse the removal procedure.

Scheme 151

1. Remove the rear panel from the front floor console. Detach the 6 retainer clips. Disconnect the LH and RH heated seat switch electrical connectors. If equipped, disconnect the power point electrical connector.
2. Detach and remove the heated seat switch(s).
3. To install, reverse the removal procedure.

Scheme 152

1. Remove the front floor console. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-293483) article.
2. Disconnect the heated seat module electrical connector at the bottom of the front center console.
3. Remove the screw and un-hook the heated seat module.
4. To install, reverse the removal procedure.
5. Install the front floor console. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-293483) article.

1. Remove the affected second row seat. For additional information, refer to «Seat - Rear, Second Row, Taurus X»(ref-293480-S31080261562008080700000) .
2. Remove the cushion trim cover and cushion foam pad. For additional information, refer to «Seat Cushion Cover - Second Row, 40 Percent, Taurus X»(ref-293480-S31421985692008080700000) . Disconnect the cushion heater mat electrical connector and release the pin-type retainer.
3. Remove the screw and recliner handle.
4. Remove the outer recliner trim cover from the outboard side. Remove the screw. Release the retainer tabs and separate the trim covers. Route the pull strap through the hole in the trim cover.
5. Disconnect the power-fold seat motor cable from the recliner. Disconnect the cable jacket from the cable clamp. Rotate the cable end guide to release.
6. Remove the 2 screws and detach the power-fold seat motor.
7. Loosen the 2 recliner-to-cushion frame bolts, route the cable from the cushion frame and remove the power-fold seat motor. To install, tighten to 50 Nm (37 lb-ft).
8. To install, reverse the removal procedure.

Scheme 153

1. Remove the left and right side rear quarter trim panels. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-293479) article.
2. Remove the 2 load floor supports (1 shown) from the load floor panel(s). Push the load floor support back and lift up on the load floor to disengage.
3. Remove the 4 bolts and remove the third row seat. To install, tighten to 80 Nm (59 lb-ft).
4. To install, reverse the removal procedure. Make sure the safety belt buckles are accessible to the occupants after installation.

Scheme 154

Scheme 155

Scheme 156

Scheme 157

1. For additional information, refer to the procedures in this article.

1. Release the backrest trim cover lower J-strip, open the trim cover and release the inner J-clips.
2. Remove the head restraint(s).
3. Release the hook-and-loop strips, invert the backrest trim cover and remove the 3 rows of hog rings.
4. Remove the head restraint guides. For bench seats, remove 4 head restraint guides. For 50/50 seats, remove 2 head restraint guides.
5. Remove the backrest trim cover. Pull the strap through the trim cover.
6. To install, reverse the removal procedure.

1. Remove the 2 rivets and pull the cushion handle out of the pocket. Using an appropriate tool, from under the rivet head, pry the rivet up. When removing the plastic rivet, make sure not to get under the insert or the rivet will not come out. Another method that can be used to remove the plastic rivets is to drive a screw partially into the rivet head and pull the screw and rivet head out. This will require new plastic rivets be installed.
2. Separate the pivot release cable and casing and remove the pivot release handle.
3. Remove the 2 screws on each side at the bottom of the load floor panel.
4. Pull out to release the retainers and remove the load floor panel. Use a suitable tool (pin-type retainer tool, etc.) to disengage the load floor from the seat.
5. Remove the screw, release the tab and remove the floor latch cover. For bench seats, remove 2 floor latch covers.
6. Release the cushion trim cover retainers from the cushion frame and remove the cushion trim cover. On assembly, the lower anchors and tethers for children (LATCH) and child safety seat tether anchor must be accessible through the trim cover.
7. To install, reverse the removal procedure.

1. Release the backrest trim cover lower J-strip, open the trim cover and release the inner J-clips.
2. Roll the backrest trim cover up, remove the 4 backrest latch-to-backrest frame bolts and remove the backrest frame. To install, tighten to 50 Nm (37 lb-ft).
3. To install, reverse the removal procedure.

Note. LH 50 percent third row seat shown, RH similar.

Note. To remove the RH 50 percent third row seat backrest, the LH seat inboard trim cover must be removed before the RH seat inboard trim cover can be removed.

1. Remove the LH seat inboard-outer pivot cover.
2. Release the backrest trim cover lower J-strip, open the trim cover and release the inner J-clips.
3. Remove the pivot bolt. To install, tighten to 23 Nm (17 lb-ft).
4. Roll the backrest trim cover up, remove the 2 backrest latch-to-backrest frame bolts and remove the backrest frame. To install, tighten to 50 Nm (37 lb-ft).
5. To install, reverse the removal procedure.
