Wiring diagrams Section: Pin Voltage Charts

All sections

Engine Controls - Reference Values (Except Diesel & Hybrid): Diagnosis Mercury Sable V

Pin Voltage Charts 3 illustrations

Reference Value Symptom Chart

The Reference Value Symptom Chart provides guidance in selecting the appropriate parameter identification (PID) or measured signal related to the fault area. Select a symptom from the symptom chart along with the category number and go to the PID/Measured Signal Chart. For multiple symptoms, select the symptom that is the most evident.

Symptom Chart

Symptom Occurs During	Symptom	Category Number
Startup	No start/Normal crank	1
	Hard start/Long crank	2
	Stall after start	3
	Diesels/Runs on	4
Idle	MIL	5
	Stalls/Quits	6
	Slow	7
	Slow return	8
	Rolling	9
	Fast	10
	Rough	11
	Misses	12
	Backfires	13
Acceleration	Stalls/Quits	6
	Misses	12
	Bucks/Jerks	14
	Backfires	13
	Hesitation	15
	Lack/Loss of power	16
	Surge	17
	Spark knock	18
	Cooling system temperature	19
	Poor fuel economy	20
	Emissions compliance	21
Cruise	Stalls/Quits	6
	Misses	12
	Bucks/Jerks	14
	Backfires	13
	Lack/Loss of power	16
	Surge	17
	Spark knock	18
	Cooling system temperature	19
	Poor fuel economy	20
	Emissions compliance	21
Deceleration	Stalls/Quits	6
	Backfires	13
Transmission Operation: (Automatic)	Shift/engagement concerns	22
	No overdrive	23

Typical Diagnostic Reference Values

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
BOO1	B13	OFF	ON (E)	OFF	OFF	ON/OFF
APP1	B28	0.77/15.29	0.77/15.29	1.38/25.49	1.45/28.24	DCV/%
APP2	B29	0.38/7.45	0.38/7.45	0.69/13.73	0.73/14.51	DCV/%
ACP_PRESS	B31	1.56/66.55	1.69/74.53	1.45/59.30	1.39/55.69	DCV/PSI
FPM	B32	0	100	100	100	%
MAF	B40	0	0.6	1.83	1.87	DCV
BOO2	B46	OFF	ON (E)	OFF	OFF	ON/OFF
IAT	B47	1.78/120.2 (K)	1.99/111.2 (K)	2.53/93.2 (K)	2.66/87.8 (K)	DCV/DEG F
FTP	B65	2.6/0	2.6/0	2.6/0	2.6/0	DCV/PSI
O2S11	E11	(L)	Switching (C)	Switching (C)	Switching (C)	DCV
CHT	E15	3.2/224.6	3.56/204.8	0.67/186.8	0.67/186.8	DCV/DEG F
IMRC1M (PZEV)	E25	0.1	0.1	4.98	4.98	DCV
MAP	E40	4.02/14.35 (W)	1.15/4.06(W)	2.42/8.70 (W)	3.15/11.31 (W)	DCV/PSI
TP1	E44	4.10	4.33	3.90	4.06	DCV
TP2	E45	1.19	0.72	1.60	1.27	DCV
HTRCM11	E52	1.58	1.58	1.65	1.65	AMPS
O2S13 (PZEV)	T7	0.1	(D)	(D)	(D)	DCV
O2S12	T16	(L)	(D)	(D)	(D)	DCV
HTRCM12	T18	676	676	634	634	MA
TFT (A/T)	T19	118 (K)	117 (K)	147 (K)	144 (K)	DEG F
TFTV (A/T)	T19	1.9 (K)	1.9 (K)	1.3 (K)	1.4 (K)	DCV
PSP	T29	OFF	OFF	OFF	OFF	ON/OFF
TCC (A/T)	T30	0	0	0	99.61	%
TSS_SRC (A/T)	T37	0	731	1513	1844	RPM
APP	PID	0	0	19	21	%
APP_ MAXDIFF	PID	0	0	0	0.06	DEG
BARO	PID	14.5/29.53	14.5/29.53	14.5/29.53	14.5/29.53	PSI/IN HG
B+	PID	VBAT	VBAT	VBAT	VBAT	DCV
CPP/PNP	PID	NEUTRAL	NEUTRAL	DRIVE	DRIVE	MODE
DECHOKE	PID	YES	NO	NO	NO	YES/NO
ETC_ACT	PID	7.73	1.48	7.79	8.25	DEG
ETC_DSD	PID	7.60	1.45	7.71	8.12	DEG
ETC_TRIM	PID	0	0	0.01	0.02	DEG
GENMON	PID	0	54.9	18.96	22.1	%
LOAD	PID	0 (L)	27	55.29	74.9	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	702	2527	1887	RPM
TP_MAXDIFF	PID	4	8	8	8	DEG
TR (A/T)	PID	PARK	PARK	OVERDRIVE	OVERDRIVE	MODE
VSS	PID	0	0	30	55	MPH

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B19	0/OFF	100/ON	100/ON	100/ON	%/ON-OFF
EVAPCV	B20	0/OFF	0/OFF	0/OFF	0/OFF	%/ON-OFF
EVMV	B55	0/OFF	0/OFF	500-900 (F)/VARYING	500-900 (F)/VARYING	MA/OFF- VARYING
IMRC (PZEV)	E22	ON	ON	OFF	OFF	ON/OFF
HTR11	E52	OFF (O)	ON	ON	ON	ON/OFF
SSA (SS1) (A/T)	T11	OFF	ON	OFF	OFF	ON/OFF
HTR12	T18	OFF (O)	ON	ON	ON	ON/OFF
SSB (SS2) (A/T)	T23	0/OFF	0/OFF	0/OFF	100/ON	%/ON-OFF
HTR13 (PZEV)	T25	OFF (O)	ON	ON	ON	ON/OFF
EGRPCT	PID	0	0.78	43.14	49.02	%
EGR_STEP	PID	0	1	23	26	0-52
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAPSOAK	PID	YES	YES	YES	YES	YES/NO
FUELSYS1	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/ CLOSED LOOP
GENCMD	PID	0	0 (Q)	0 (Q)	0 (Q)	%
HFC	PID	OFF	ON (B)	OFF	OFF	ON/OFF
LFC	PID	OFF	ON (B)	OFF	OFF	ON/OFF
LONGFT1	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
LOOP_ CONTRL	PID	OPEN	OPEN	CLOSED	CLOSED	OPEN/ CLOSED
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/ DISABLED
SHRTFT1	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SPARKADV	PID	10	9.75	39.75	23.75	DEG

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VREF	B52, E63, T70	5	5	5	5	DCV
VPWR	B67/68	VBAT	VBAT	VBAT	VBAT	DCV

Scheme 1

Scheme 1: 2.3L 4V Fusion/Milan

Scheme 1: 2.3L 4V Fusion/Milan

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
APP1	B25	4.1	4.1	3.8	3.8	DCV
APP2	B26	1.5	1.5	1.6	1.7	DCV
APP3	B27	1.0	1	1	1.1	DCV
FPM	B30	OFF	ON	ON	ON	ON/OFF
MAF	B41	0	0.71	1.2	1.28	DCV
IAT	B43	1.6/126 (K)	1.71/122 (K)	3.5/54 (K)	3.43/55 (K)	DCV/DEG F
FTP	B44	2.6/-0.01	2.5/-0.02	2.3/-0.09	2.2/-0.11	DCV/PSI
BOO	B46	OFF	ON (E)	OFF	OFF	ON/OFF
BPA	B47	OFF	ON (E)	OFF	OFF	ON/OFF
AIRM (PZEV)	B50	OFF	OFF	OFF	OFF	ON/OFF
A/CT	B53	95	98.6 (A)	113	113	DEG F
A/CT_V	B53	2.46	2.38	1.98	1.98	DCV
ACP_PRESS	B63	2.4/240	2.43/243	1.65/158	1.68/162	DCV/PSI
O2S12	E3	(L)	(D)	(D)	(D)	DCV
O2S13 (PZEV)	E5	0.1	(D)	(D)	(D)	DCV
HTRCM12	E23	582	582	582	582	MA
GENMON	E26	0	40	25	21.8	%
O2S11	E28	(L)	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
CHT	E41	4.5-1/240-160	3.4/212	3.22/224	3.18/226	DCV/DEG F
KNOCK 1	E49	219	175	264	373	N/A
TP2	E60	1.15/23.14	0.66/13.33	0.93/18.43	2.12/42.35	DCV/%
TP1	E61	4.12/17.26	4.36/12.55	4.22/15.29	3.64/27.06	DCV/%
MAP	E62	4/14.35 (W)	1.15/4.06 (W)	2.66/9.42 (W)	2.87/10.29 (W)	DCV/PSI
IMTV	E64	OFF	ON	ON	ON	ON/OFF
PSP	E65	LOW	HIGH (I)	LOW	LOW	HIGH/LOW
HTRCM11	E69	1.49	1.49	1.49	1.49	AMPS
APP	PID	0	0	10.5	19	%
BARO	PID	14.3/156.2	14.3/156.2	14.3/156.2	14.3/156.2	PSI/HZ
B+	PID	VBAT	VBAT	VBAT	VBAT	DCV
CPP/PNP	PID	NEUTRAL	NEUTRAL	DRIVE	DRIVE	NEUTRAL/ DRIVE
DECHOKE	PID	YES	NO	NO	NO	YES/NO
ETC_ACT	PID	7.25	1.25	8.43	11.69	DEG
ETC_DSD	PID	6.5	1.28	8.45	11.68	DEG
FLI	PID	36 (H)	36 (H)	40 (H)	36 (H)	%
LOAD	PID	54 (L)	17.6	19.7	22.4	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	797	1717	2434	RPM
VSS	PID	0	0	30	55	MPH

Actuators/ Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/ Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
AIR (PZEV)	B1	OFF	OFF	OFF	OFF	ON/OFF
EVMV	B4	0/OFF	450/ VARYING	801/ VARYING	930/ VARYING	MA/OFF- VARYING
FANVAR	B8	0	55	0	0	%
EVAPCV	B61	0/OFF	0/OFF	0/OFF	0/OFF	%/ON-OFF
FP	B62	OFF	ON	ON	ON	ON/OFF
WAC/ACCR	B64	OFF	ON	OFF	OFF	ON/OFF
SPARKDUR_2	E11	0	2.06	1.37	781	US
SPARKDUR_3	E12	0	2.12	1.46	719	US
GENCMD	E13	3.79	0 (Q)	0 (Q)	0 (Q)	%
SPARKDUR_4	E16	0	2.31	1.21	719	US
SPARKDUR_1	E17	0	2.25	1.37	656	US
HTR12	E23	OFF	ON	ON	ON	ON/OFF
HTR13 (PZEV)	E25	ON (O)	ON	ON	ON	ON/OFF
VCTDC	E67	0	0	0	0	%
HTR11	E69	ON (O)	ON	ON	ON	ON/OFF
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/ DISALLOW
EVAP020R	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EVAPSOAK	PID	NO	NO	NO	NO	YES/NO
EVAP_EVAL	PID	YES	YES	YES	YES	YES/NO
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/ CLOSED LOOP
VCTADV	PID	0	0	0.37	1.06	DEG
VCTADVERR	PID	0	0	0.37	1.06	DEG
LONGFT1	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
SHRTFT1	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SPARKADV	PID	10	4.5	25.75	29.75	DEG

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B51/52	VBAT	VBAT	VBAT	VBAT	DCV

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
APP1	B25	4	4	3.9	3.7	DCV
APP2	B26	1.5	1.5	1.6	1.8	DCV
APP3	B27	1	1	1.1	1.2	DCV
FPM	B30	OFF	ON	ON	ON	ON/OFF
MAF	B41	0	0.68	1.27	1.83	DCV
IAT	B43	1.75/120 (K)	2.02/109 (K)	3.16/64 (K)	3.22/63 (K)	DCV/DEG F
FTP	B44	2.6/-0	2.6/-0	2.57/-0.01	2.5/-0.03	DCV/PSI
BPA	B47	OFF	ON (E)	OFF	OFF	ON/OFF
A/CT	B53	3.1/73.4	3.05/75.2 (A)	4/39	3.92/42	DCV/DEG F
ACP_PRESS	B63	2.36/235	2.39/239	2.24/223	2.12/210	DCV/PSI
PSP	B65	LOW	HIGH (I)	LOW	LOW	HIGH/LOW
O2S12	E3	(L)	(D)	(D)	(D)	DCV
O2S22	E4	0.1	(D)	(D)	(D)	DCV
ECT	E18	0.45/210	0.44/210	0.53/199	0.57/196	DCV/DEG F
HTRCM12	E23	617	617	617	617	MA
HTRCM22	E24	605	605	605	605	MA
GENMON	E26	0	35.16	28.13	25	%
O2S11	E28	(L)	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
O2S21	E29	0	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
BOO	E46	OFF	ON (E)	OFF	OFF	ON/OFF
KNOCK 1	E49	654	650	1366	1621	N/A
TP2	E60	1.22/24.31	0.74/14.9	0.99/19.61	1.3/25.88	DCV/%
TP1	E61	4.05/18.82	4.29/13.73	4.17/16.47	4/19.61	DCV/%
MAP	E62	4.02/14.35 (W)	1.28/4.49 (W)	2.37/8.55 (W)	1.86/6.67 (W)	DCV/PSI
HTRCM11	E69	1.62	1.62	1.62	1.62	AMPS
HTRCM21	E70	1.58	1.58	1.58	1.58	AMPS
APP	PID	0	0	4	11	%
BARO	PID	14.48/157.4	14.48/157.4	14.48/157.4	14.48/157.4	PSI/HZ
B+	PID	VBAT	VBAT	VBAT	VBAT	DCV
CPP/PNP	PID	NEUTRAL	NEUTRAL	DRIVE	DRIVE	NEUTRAL/ DRIVE
DECHOKE	PID	YES	NO	NO	NO	YES/NO
ETC_ACT	PID	8	2.62	6.45	8.93	DEG
ETC_DSD	PID	7.79	2.62	6.45	9.08	DEG
FLI	PID	73.5 (H)	73 (H)	90 (H)	83 (H)	%
LOAD	PID	65 (L)	17	19	25	%
MISFIRE	PID	NO	NO	NO	NO	ON/OFF
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
O2BANK2	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	766	1600	1700	RPM
VSS	PID	0	0	30	55	MPH

Actuators/ Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/ Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
EVMV	B4	0/OFF	0/OFF	480/ VARYING	962/ VARYING	MA/OFF- VARYING
FANVAR	B8	0	38	32	71	%
FP	B62	OFF	ON	ON	ON	ON/OFF
WAC/ACCR	B64	OFF	ON	OFF	OFF	ON/OFF
PCVHC	E2	0	0	0	0	%
SPKDUR_6	E10	0	2.18	2.12	1.15	Ms
SPKDUR_5	E11	0	2.06	1.87	1.09	Ms
SPKDUR_4	E12	0	2.37	2.15	1.43	Ms
GENCMD	E13	3.79	0 (Q)	0 (Q)	0 (Q)	%
SPKDUR_3	E15	0	1.71	2.12	0.875	Ms
SPKDUR_2	E16	0	2.28	1.71	1	Ms
SPKDUR_1	E17	0	2.4	2	1.46	Ms
HTR12	E23	OFF	ON	ON	ON	ON/OFF
HTR22	E24	OFF	ON	ON	ON	ON/OFF
VCTDC	E67	0	0	41.7	39.5	%
VCTDC2	E68	0	0	43.3	33.7	%
HTR11	E69	ON (O)	ON	ON	ON	ON/OFF
HTR21	E70	ON (O)	ON	ON	ON	ON/OFF
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/ DISALLOW
EVAP020R	PID	READY	READY	READY	READY	READY/NOT READY
EVAPCV	PID	0/OFF	0/OFF	0/OFF	0/OFF	%/ON-OFF
EVAPSOAK	PID	NO	NO	NO	NO	YES/NO
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/ CLOSED LOOP
LONGFT1	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
LONGFT2	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
SHRTFT1	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SHRTFT2	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SPARKADV	PID	10	14	36	40	DEG
VCTADV	PID	0	0.37	10.8	32	DEG
VCTADV2	PID	0	1	8	33.7	DEG
VCTADVERR	PID	0	0.68	0.81	1.12	DEG
VCTADVERR2	PID	0	1	1.56	0.43	DEG

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B51/52	VBAT	VBAT	VBAT	VBAT	DCV

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
PSP	B17	0.1/LOW	VBAT/HIGH (I)	0.1/LOW	0.1/LOW	DCV/ HIGH-LOW
GENMON	B23	0	41.41	30.47	27.34	%
APP1	B25	3.9	3.9	3.5	3.3	DCV
APP2	B26	1.6	1.7	1.8	2.1	DCV
APP3	B27	1.0	1.0	1.3	1.5	DCV
FPM	B30	OFF	ON	ON	ON	ON/OFF
ACP	B37	0.8/70	0.86/73	0.9/75	1.0/87	DCV/PSI
MAF	B41	0	0.7	1.4	1.5	DCV
MAF SIGRTN	B42	0	0.6-1.9	1-1.6	1.3-2.3	DCV
IAT	B43	80 (K)	50 (K)	37 (K)	34 (K)	DEG F
FTP	B44	2.6/-0.01	2.6/-0.01	2.6/-0.01	2.6/-0.01	DCV/PSI
BOO	B46	VBAT/OFF	0.1/ON (E)	VBAT/OFF	VBAT/OFF	DCV/ON-OFF
BPA	B47	0.1/OFF	VBAT/ON (E)	0.1/OFF	0.1/OFF	DCV/ON-OFF
FEPS	B55	0.5-0.6	0.5-0.6	0.5-0.6	0.5-0.6	DCV
HO2S12	E23	(L)	(D)	(D)	(D)	DCV
HO2S22	E24	0.1	(D)	(D)	(D)	DCV
HO2S21	E28	0	Switching (C)	Switching (C)	Switching (C)	DCV
HO2S11	E29	(L)	Switching (C)	Switching (C)	Switching (C)	DCV
CHT	E41	3.6/199	3.6/199	3.58/201	3.45/208	DCV/DEG F
CMP2	E44	0	5-7	13-16	20-23	Hz
CMP1	E45	0	5-7	13-16	20-23	Hz
CKP	E47	0	400-500	850-1050	1050-1150	Hz
KNOCK 1	E49	23.99k	25.01k	25.73k	44.51k	N/A
TP2	E60	1.1/25	0.8/15	1.0/19	1.4/27	DCV/%
TP1	E61	4.1/17	4.4/13	4.2/16	4.0/19	DCV/%
ACCS	PID	VBAT/OFF	VBAT/ON (A)	VBAT/OFF	VBAT/OFF	DCV/ON-OFF
APP	PID	3.9	0	0	22	%
APP_FLT	PID	NO FAULT	NO FAULT	NO FAULT	NO FAULT	FAULT/NO FAULT
CPP/PNP	PID	NEUTRAL	NEUTRAL	DRIVE	DRIVE	NEUTRAL/ DRIVE
ETC_ACT	PID	7.56	1.27	6.22	12.74	DEG
ETC_DSD	PID	7.62	1.31	6.19	12.73	DEG
ETC_TRIM	PID	0.23	0.21	0.24	0.24	DEG
FANVAR_F	PID	NO FAULT	NO FAULT	NO FAULT	NO FAULT	FAULT/NO FAULT
FLI	PID	71 (H)	72 (H)	82 (H)	81 (H)	%
LOAD	PID	51.4 (L)	16.1	35.4	34.7	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
RPM	PID	0	600	1200	1500	RPM
VSS	PID	0	0	30	55	MPH
WAC_F	PID	NO FAULT	NO FAULT	NO FAULT	NO FAULT	FAULT/NO FAULT

Actuators/ Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/ Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
GENCMD	B22	3.79	0 (Q)	0 (Q)	0 (Q)	%
SMC	B34	0	0	0	0	DCV
CTO	B49	0	0	0	0	Hz
EVMV	B50	0	337	0	847	MA
EVAPCV	B61	0	0	0	0	%
FP	B62	8.3/75	3.6/27	3.6/27	3.8/29	DCV/%
WAC/ACCR	B64	OFF	OFF	OFF	OFF	ON/OFF
HTR12	E1	VBAT/OFF	0.2/ON	0.2/ON	0.2/ON	DCV/ON-OFF
HTR22	E2	VBAT/OFF	0.2/ON	0.2/ON	0.2/ON	DCV/ON-OFF
CD6F (CYL 6)	E10	VBAT	VBAT	VBAT	VBAT	DCV
CD5D (CYL 5)	E11	VBAT	VBAT	VBAT	VBAT	DCV
CD4B (CYL 4)	E12	VBAT	VBAT	VBAT	VBAT	DCV
CD3E (CYL 3)	E15	VBAT	VBAT	VBAT	VBAT	DCV
CD2C (CYL 2)	E16	VBAT	VBAT	VBAT	VBAT	DCV
CD1A (CYL 1)	E17	VBAT	VBAT	VBAT	VBAT	DCV
PCVHC	E33	0	0	0	0	%
TACM (+)	E34	3.7	VBAT	VBAT	VBAT	DCV
TACM (-)	E51	3.7	VBAT	VBAT	VBAT	DCV
VCTADV	E67	0	.031	27.56	30.94	DEG
VCTADV2	E68	0	0	27.69	31.06	DEG
HTR11	E69	0.1/ON (O)	0.1/ON	0.1/ON	0.1/ON	DCV/ON-OFF
HTR21	E70	0.1/ON (O)	0.1/ON	0.1/ON	0.1/ON	DCV/ON-OFF
FANVAR	PID	0	0	0	0	%
FANDC	PID	7.5	7.5	7.5	7.5	%
FP	PID	ON/OFF	ON	ON	ON	ON/OFF
LONGFT1	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
LONGFT2	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
SHRTFT1	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SHRTFT2	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SPARKADV	PID	10	13.25	44	45.25	DEG
VCTDC	PID	0	0	47.32	80	%
VCTDC2	PID	0	0	46.8	80	%
VCTADVERR	PID	0	0.18	0.37	0.18	DEG
VCTADVERR2	PID	0	0.06	0.43	0	DEG

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
ETCVREF	B21/28	5	5	5	5	DCV
VREF	B33/E57	5	5	5	5	DCV
VPWR	B51/52	VBAT	VBAT	VBAT	VBAT	DCV
KAPWR	B54	VBAT	VBAT	VBAT	VBAT	DCV

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
APP1	B25	4.1	4.2	3.9	3.7	DCV
APP2	B26	1.6	1.7	1.9	2.1	DCV
APP3	B27	1.0	1.1	1.3	1.5	DCV
FPM	B30	OFF	ON	ON	ON	ON/OFF
MAF	B41	0	0.62	1.06	1.44	DCV
IAT	B43	1.89/114.8 (K)	2.13/104 (K)	3.32/59 (K)	3.37/57.2 (K)	DCV/DEG F
FTP	B44	2.55/-0.01	2.53/-0.02	2.49/-0.03	2.28/-0.08	DCV/PSI
BOO	B46	OFF	ON (E)	OFF	OFF	ON/OFF
BPA	B47	OFF	ON (E)	OFF	OFF	ON/OFF
ACP_PRESS	B63	1.46/47.99	1.48/51.98	1.42/41.99	1.42/41.99	DCV/PSI
PSP	E65	LOW	HIGH (I)	LOW	LOW	HIGH/LOW
O2S12	E3	(L)	(D)	(D)	(D)	DCV
O2S22	E4	(L)	(D)	(D)	(D)	DCV
HTRCM12	E23	582	582	582	582	MA
HTRCM22	E24	613	613	613	613	MA
GENMON	E26	0	50.78	31.25	31.25	%
O2S11	E28	(L)	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
O2S21	E29	0	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
CHT	E41	0.61/192.2	0.64/190.4	0.71/181.4	0.69/183.2	DCV/DEG F
KNOCK 1	E49	26590	27310	32090	40910	N/A
TP2	E60	1.25/25.1	0.85/16.8	0.82/16	1.26/25.1	DCV/%
TP1	E61	4.1/16.9	4.4/12.2	4.3/12.9	4.2/14.9	DCV/%
HTRCM11	E69	1.43	1.43	1.43	1.43	AMPS
HTRCM11	E70	1.49	1.49	1.49	1.49	AMPS
ACCS	PID	OFF	ON (A)	OFF	OFF	ON/OFF
BARO	PID	14.24/155.8	14.24/155.8	14.24/155.8	14.24/155.8	PSI/HZ
B+	PID	VBAT	VBAT	VBAT	VBAT	DCV
APP	PID	0	0	19.5	24.5	%
CPP/PNP	PID	NEUTRAL	NEUTRAL	DRIVE	DRIVE	NEUTRAL/ DRIVE
DECHOKE	PID	YES	NO	NO	NO	YES/NO
ETC_ACT	PID	7.25	1.87	5.68	7.81	DEG
ETC_DSD	PID	7.62	1.94	5.66	7.81	DEG
FLI	PID	13.58 (H)	13.59 (H)	23.15 (H)	28 (H)	%
LOAD	PID	49 (L)	17	21	29	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
O2BANK2	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	640	1146	1675	RPM
VSS	PID	0	0	30	55	MPH

Actuators/ Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/ Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
EVMV	B4	0/OFF	155/ VARYING	553/ VARYING	905/ VARYING	MA/OFF- VARYING
EVAPCV	B61	0/OFF	0/OFF	0/OFF	0/OFF	%/ON-OFF
FP	B62	OFF	ON	ON	ON	ON/OFF
WAC/ACCR	B64	OFF	OFF	OFF	OFF	ON/OFF
PCVHC	E2	0	0	0	0	%
SPKDUR_6	E10	0	2.31	1.53	1.56	Ms
SPKDUR_5	E11	0	2.12	1.62	1.34	Ms
SPKDUR_4	E12	0	2.31	1.87	1.59	Ms
GENCMD	E13	3.79	0 (Q)	0 (Q)	0 (Q)	%
SPKDUR_3	E15	0	2.12	1.75	1.5	Ms
SPKDUR_2	E16	0	2.5	1.75	1.5	Ms
SPKDUR_1	E17	0	2.31	1.78	1.9	Ms
HTR12	E23	OFF	ON	ON	ON	ON/OFF
HTR22	E24	OFF	ON	ON	ON	ON/OFF
VCTADV	E67	0	0.5	0.5	40.44	DEG
VCTADV2	E68	0	0.06	0.12	40	DEG
HTR11	E69	ON (O)	ON	ON	ON	ON/OFF
HTR21	E70	ON (O)	ON	ON	ON	ON/OFF
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/ DISALLOW
EVAP020R	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EVAPSOAK	PID	NO	YES	YES	YES	YES/NO
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
FANDC	PID	7.5	7.5	7.5	7.5	%
FANVAR	PID	0	29	29	0	%
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/ CLOSED LOOP
LONGFT1	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
LONGFT2	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
SHRTFT1	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SHRTFT2	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SPARKADV	PID	31.25	25.5	47.5	42.5	DEG
STRT_RLY	PID	ENABLED	DISABLED	DISABLED	DISABLED	ENABLED/ DISABLED
VCTADVERR	PID	0	0.31	1.56	0.43	DEG
VCTADVERR2	PID	0	0.31	2.06	0.12	DEG
VCTDC	PID	0	0	0	80	%
VCTDC2	PID	0	0	0	80	%

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B51/52	VBAT	VBAT	VBAT	VBAT	DCV

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
PSP	B17	LOW	HIGH (I)	LOW	LOW	HIGH/LOW
GENMON	B23	0	46.09	22.66	25.78	%
APP1	B25	3.9	3.9	3.5	3.3	DCV
APP2	B26	1.6	1.7	1.8	2.1	DCV
APP3	B27	1.0	1.0	1.3	1.5	DCV
FPM	B30	OFF	ON	ON	ON	ON/OFF
ACP_PRESS	B37	1.34/103.98	1.34/103.98	0.89/47.99	0.93/51.98	DCV/PSI
MAF	B41	0	0.7	1.4	1.5	DCV
IAT	B43	2.1/105.8 (K)	2.1/105.8 (K)	3.9/32 (K)	3.9/32 (K)	DCV/DEG F
FTP	B44	2.6/-0.01	2.6/-0.01	2.6/-0.01	2.6/-0.01	DCV/PSI
BPA	B47	OFF	ON	OFF	OFF	ON/OFF
O2S11_CUR (PZEV)	E18	0	66	16	137	UA
O2S21_CUR (PZEV)	E20	0	4	39	213	UA
O2S12	E23	0.87	0.33	0.78	0.6	DCV
O2S22	E24	0.16	0.21	0.8	0.6	DCV
CHT	E41	0.74/179.6	0.71/181.4	3.86/183.2	3.81/188.6	DCV/DEG F
TP2	E60	1.1/25	0.8/15	1.0/19	1.4/27	DCV/%
TP1	E61	4.1/17	4.4/13	4.2/16	4.0/19	DCV/%
TSS	T15	0	601.3	1130	1519	RPM
ACCS	PID	OFF	ON	OFF	OFF	ON/OFF
APP	PID	0	0	16.5	17	%
B+	PID	12.06	14.06	14.5	14.25	DCV
BARO	PID	149.6/13.26	149.6/13.26	149.6/13.26	149.6/13.26	Hz/PSI
BOO	PID	OFF	ON (E)	OFF	OFF	ON/OFF
CPP/PNP	PID	NEUTRAL	NEUTRAL	DRIVE	DRIVE	NEUTRAL/ DRIVE
DECHOKE	PID	NO	NO	NO	NO	YES/NO
EONV_RDY	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EQ_RAT11	PID	0	(-)2-(+)2	(-)2-(+)2	(-)2-(+)2	RATIO
EQ_RAT21	PID	0	(-)2-(+)2	(-)2-(+)2	(-)2-(+)2	RATIO
ETC_ACT	PID	7.37	2.95	4.68	23	DEG
ETC_DSD	PID	7.62	2.98	4.74	23.19	DEG
ETC_TRIM	PID	0.63	0.61	0.54	0.54	DEG
FCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
FLI	PID	50 (H)	50 (H)	50 (H)	50 (H)	%
GEAR	PID	1	1	5	6	GEAR
INJPWR_M	PID	0.34	13.97	14.19	14.14	DCV
LOAD	PID	51.4 (L)	16.1	35.4	34.7	%
MIL_DIS	PID	0	0	0	0	Miles
MISFIRE	PID	NO	NO	NO	NO	YES/NO
NM	PID	0	0	0	0	COUNT
O2S11_ IMPED (PZEV)	PID	4.94	1.0	0.93	0.97	DCV
O2S21_ IMPED (PZEV)	PID	4.94	1.03	0.98	0.95	DCV
OSS	PID	0	0	1131	1990	RPM
OSS_SRC	PID	0	0	1121	2027	RPM
RPM	PID	0	600	1200	1500	RPM
STRT_RLY	PID	ENABLED	DISABLED	DISABLED	DISABLED	ENABLED/ DISABLED
TCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
TFT	PID	176	176	192.2	192.2	DEG F
TFTV	PID	0.8	0.81	0.63	0.62	DCV
TORQUE	PID	207	4	18.7	45.42	Nm
TR	PID	P	P	OD	OD	MODE
TR2	PID	OPEN	OPEN	CLOSED	CLOSED	OPEN/ CLOSED
TSS/ISS	PID	0	600.8	1130	1516	RPM
TSS_SRC	PID	0	600.3	1131	1516	RPM
VSS	PID	0	0	30	55	MPH

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
GENCMD	B22	3.79	0 (Q)	0 (Q)	0 (Q)	%
EVMV	B50	0/OFF	0/OFF	543/ VARYING	289/ VARYING	MA/OFF- VARYING
FP	B62	OFF	ON	ON	ON	ON/OFF
HTR12	E1	OFF	ON	ON	ON	ON/OFF
HTRCM12	E1	609	609	566	566	MA
HTR22	E2	OFF	ON	ON	ON	ON/OFF
HTRCM22	E2	715	715	586	586	MA
PCVHC	E33	0	0	0	0	%
VCTADV	E67	0	.031	27.56	30.94	DEG
VCTADV2	E68	0	0	27.69	31.06	DEG
O2S11_HTR (PZEV)	E69	0	36.4	32.12	33.35	%
HTR11 (Non-PZEV)	E69	ON (O)	OFF	ON	ON	ON/OFF
HTRCM11	E69	1.37	1.37	1.39	1.39	Amps
O2S21_HTR (PZEV)	E70	0	39.5	28.29	25.48	%
HTR21 (Non PZEV)	E70	ON (O)	ON	ON	ON	ON/OFF
HTRCM21	E70	1.35	1.35	1.35	1.35	Amps
CAT_EVAL	PID	YES	YES	YES	YES	YES/NO
CLRDIST	PID	40.37	40.37	11.8	10.56	MILES
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/ DISALLOW
EVAP020R	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EVAPCV	PID	0/OFF	0/OFF	0/OFF	0/OFF	%/ON-OFF
EVAPSOAK	PID	YES	YES	YES	YES	YES/NO
EVAPSTA	PID	6-MONITOR COMPLETE	6-MONITOR COMPLETE	6-MONITOR COMPLETE	1-VAC STABLE	STATUS
EVAP_EVAL	PID	YES	YES	YES	NO	YES/NO
FANDC	PID	7.5	7.5	7.5	7.5	%
FANVAR	PID	0	0	0	0	%
FTP_H20	PID	0.03	0.03	2.13	3.38	In H2O
FUELSYST	PID	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/ CLOSED LOOP
IGN_R/S	PID	ON	ON	ON	ON	ON/OFF
LONGFT1	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
LONGFT2	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
O2S_EVAL	PID	YES	YES	YES	YES	YES/NO
O2SHTR_ EVAL	PID	YES	YES	YES	YES	YES/NO
RPMDSD	PID	1120	731.8	1179	608	RPM
SHRTFT1	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SHRTFT2	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SPARKADV	PID	10	13.25	44	45.25	DEG
TRIP_CNT	PID	1	1	0	0	COUNT
VCTADVERR	PID	0	0.18	0.37	0.18	DEG
VCTADVERR2	PID	0	0.06	0.43	0	DEG
VCTDC	PID	0	0	47.32	80	%
VCTDC2	PID	0	0	46.8	80	%
VCTSYS	PID	OL	CL	CL	CL	OPEN/ CLOSED LOOP

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B51/52/53	VBAT	VBAT	VBAT	VBAT	DCV
VREF	C64	5	5	5	5	DCV

Scheme 2

Scheme 2: 4.0L Mustang

Scheme 2: 4.0L Mustang

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FTP	B3	2.6/0	2.6/0	2.6/0	2.6/0	DCV/PSI
FTP_H2O	B3	0	0.2	0.61	0.34	IN-H2O
APP1	B5	4.1	4.1	3.8	3.8	DCV
ACCS	B15	OFF	OFF	OFF	OFF	ON/OFF
APP2	B17	1.4	1.4	1.65	1.65	DCV
FPM	B21	0	0	0	0	%
ACP_PRESS	B26	0.8/63.98	0.8/63.98	0.8/63.98	0.8/63.98	DCV/PSI
APP3	B28	0.9	0.9	1.1	1.1	DCV
TCS (A/T)	B29	NOT DEPRESSED	DEPRESSED (G)	NOT DEPRESSED	NOT DEPRESSED	DEPRESSED/ NOT DEPRESSED
CPP-BT	B33	CLOSED	CLOSED	CLOSED	CLOSED	OPEN/ CLOSED
PSP	B34	LOW	LOW	LOW	LOW	HIGH/LOW
BOO	B46	OFF	OFF	OFF	OFF	ON/OFF
BPA	B47	OFF	OFF	OFF	OFF	ON/OFF
GENMON	E5	0	24.22	21.09	21.09	%
ECT	E18	0.56/199.4	0.56/199.4	0.56/199.4	0.56/199.4	DCV/DEG F
FRT	E19	2.7/86 (K)	2.7/86 (K)	3.49/57.2 (K)	3.49/57.2 (K)	DCV/DEG F
DPFEGR	E21	0.25-1.3	0.25-1.3	0.25-4.65	0.25-4.65	DCV
IAT	E22	3/73 (K)	3.1/68 (K)	3.9/32 (K)	4/25 (K)	DCV/DEG F
MAF	E25	0	0.86	1.8	1.9	DCV
O2S11	E28	(L)	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
O2S21	E29	0	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
FRP	E32	3.35/53	3.06/45	2.8/39	2.8/39	DCV/PSI
KNOCK 1	E49	16380	177	339	313	N/A
TP2	E60	1.31/26.28	0.92/18.43	1.11/22.35	1.11/22.35	DCV/%
TP1	E61	4.1/17.65	4.29/13.73	4.2/15.69	4.2/15.69	DCV/%
MAP	E62	4.3/-0.29/14.64 (W)	1.05/21.55/3.91 (W)	1.61/17.71/5.8 (W)	2.18/14.16/7.54 (W)	DCV/in Hg/PSI
OSS_SRC	T3	0	0	1256	2275	RPM
ISS (A/T)	T4	0	365-380/ 630-720	595/1080	1070/1640 - 2060	Hz/RPM
TSS (A/T)	T15	0	634	913	1642	RPM
TR 1 (A/T)	T16	0	0	11.5	11.5	DCV
TR 2 (A/T)	T17	0	0	11.5	11.5	DCV
O2S12	T24	(L)	(D)	(D)	(D)	DCV
O2S22	T25	0.1	(D)	(D)	(D)	DCV
TR 3 (A/T)	T27	0/PARK	0/PARK	1.7/OD	1.7/OD	DCV/MODE
TR 4 (A/T)	T28	0	0	11.5	11.5	DCV
TFT (A/T)	T29	2.2/107 (K)	2.1/109 (K)	0.9/172 (K)	0.9/169 (K)	DCV/DEG F
APP	PID	0	0	8.5	10	%
B+	PID	VBAT	VBAT	VBAT	VBAT	DCV
BARO	PID	158.1/14.61	158.1/14.61	158.1/14.61	158.1/14.61	Hz/PSI
CPP/PNP	PID	NEUTRAL	DRIVE	DRIVE	DRIVE	NEUTRAL/ DRIVE
DECHOKE	PID	YES	NO	NO	NO	YES/NO
ETC_ACT	PID	7.56	1	4.91	8.53	DEG
ETC_DSD	PID	7.62	0.96	4.88	8.52	DEG
ETC_TRIM	PID	0.18	0.18	0.19	0.18	DEG
FCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
FLI	PID	50 (H)	50 (H)	50 (H)	50 (H)	%
GEAR	PID	1	1	5	5	GEAR
LOAD	PID	70 (L)	17	16.35	32.32	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
O2BANK2	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	631	1232	1675	RPM
VSS	PID	0	0	30	55	MPH

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B12	75/OFF	24/ON	21/ON	24/ON	%/ON-OFF
WAC/ACCR	B14	OFF	OFF	OFF	OFF	ON-OFF
GENCMD	B32	3.79	0 (Q)	0 (Q)	0 (Q)	%
HFC	E4	OFF	OFF	OFF	OFF	ON/OFF
EVMV	E6	0/OFF	0/OFF	331/ VARYING	353/ VARYING	MA/OFF- VARYING
LFC	E7	OFF	OFF	OFF	OFF	ON/OFF
EGRVR	E63	0	0	(T)	(T)	%
HTR11	E69	ON (O)	ON	ON	ON	ON/OFF
HTRCM11	E69	1.15	1.15	1.15	1.15	AMPS
HTR21	E70	ON (O)	ON	ON	ON	ON/OFF
HTRCM21	E70	1.11	1.11	1.11	1.11	AMPS
PC1 (A/T)	T11	7/8	9/8	9-9.8/12-22	9-10.7/18-22	DCV/PSI
PC2 (A/T)	T23	8.6	10.7	10.4	10.5	DCV
PC3 (A/T)	T34	5.8	8.1	VBAT	VBAT	DCV
SSA (SS1) (A/T)	T42	0.1/ON	0.1/ON	VBAT/OFF	VBAT/OFF	DCV/ON-OFF
SSB (SS2) (A/T)	T43	VBAT/OFF	VBAT/OFF	VBAT/OFF	VBAT/OFF	DCV/ON-OFF
SSC (SS3) (A/T)	T44	VBAT/OFF	VBAT/OFF	0.35/ON	0.1/ON	DCV/ON-OFF
SSD (SS4) (A/T)	T45	0.1/ON	0.1/ON	0.35/ON	0.1/ON	DCV/ON-OFF
TCC (A/T)	T46	0.2/100	VBAT/0	11.1-VBAT/ 0-45	0.2/95-100	DCV/%
HTR12	T47	ON (O)	ON	ON	ON	ON/OFF
HTRCM12	T47	641	641	641	641	MA
HTR22	T48	ON (O)	ON	ON	ON	ON/OFF
HTRCM22	T48	652	652	652	652	MA
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/ DISALLOW
EVAP020R	PID	READY	READY	READY	READY	READY/NOT READY
EVAPCV	PID	0/OFF	0/OFF	0/OFF	0/OFF	%/ON-OFF
EVAPSOAK	PID	NO	NO	NO	NO	YES/NO
EVAPSTA	PID	NOT RUNNING	NOT RUNNING	NOT RUNNING	NOT RUNNING	STATUS
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/ CLOSED LOOP
LONGFT1	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
LONGFT2	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/ DISABLED
SHRTFT1	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SHRTFT2	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SPARKADV	PID	0-10	17-23	30-40	31-40	DEG
TCIL	PID	OFF	OFF	OFF	OFF	ON/OFF

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B35/36	VBAT	VBAT	VBAT	VBAT	DCV
VREF	B40/E57	5	5	5	5	DCV

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FTP	B3	2.6/0 (M)	2.6/0 (M)	2.1/-0.13 (M)	2.6/-0.24 (M)	DCV/PSI
FTP_H2O	B3	0.06	0.06	0.41	0.37	IN H2O
APP1	B5	4.0	4.0	3.7	3.7	DCV
ACCS	B15	OFF	ON (A)	OFF	OFF	ON/OFF
APP2	B17	1.5	1.5	1.7	1.7	DCV
FPM	B21	100	100	100	100	%
ACP	B26	OPEN	OPEN	OPEN	OPEN	OPEN/ CLOSED
APP3	B28	1.0	1.1	1.3	1.5	DCV
TCS (A/T)	B29	NOT DEPRESSED	NOT DEPRESSED	NOT DEPRESSED	NOT DEPRESSED	DEPRESSED/ NOT DEPRESSED
GENMON	E5	0	38	36.7	35.9	%
FRT	E19	0.5-3/210-110 (K)	0.5-3/210-110 (K)	0.5-3/210-110 (K)	0.5-3/210-110 (K)	DCV/DEG F
IAT	E22	1.7-3.5/120-50 (K)	1.7-3.5/120-50 (K)	1.7-4.1/120-32 (K)	1.7-4.1/120-32 (K)	DCV/DEG F
MAF (A/T)	E25	0	0.88-0.94	0.8-1.5	1.3-1.9	DCV
MAF (M/T)	E25	0	1	1.5	1.3	DCV
O2S11	E28	(L)	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
O2S21	E29	0	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
KNOCK 2	E31	0	288	218	292	N/A
FRP	E32	3.35/56	3/39	2.8/40	2.8/39	DCV/PSI
CHT	E41	3.6/199	3.6/199	3.58/201	3.45/208	DCV/DEG F
KNOCK 1	E49	0	235	266	357	N/A
TP2	E60	1.18/23.53	0.66/12.94	0.96/19.22	1.05/20.78	DCV/%
TP1	E61	4.09/18.04	4.35/12.55	4.2/15.69	4.16/16.47	DCV/%
HTRCM11	E69	1.01	1.01	1.03	1.03	AMPS
HTRCM21	E70	1.01	1.01	1.01	1.01	AMPS
OSS (A/T)	T3	0	0	1385	2400	RPM
OSS (M/T)	T3	0	0	1420	2500	RPM
TSS (A/T)	T15	0	680	595	2060	RPM
TR 2 (A/T)	T17	CLOSED	CLOSED	OPEN	OPEN	OPEN/ CLOSED
O2S12	T24	(L)	(D)	(D)	(D)	DCV
O2S22	T25	0.1	(D)	(D)	(D)	DCV
TFT (A/T)	T29	0.5-2/210-110 (K)	0.5-2/210-110 (K)	0.5-2/210-110 (K)	0.5-2/210-110 (K)	DCV/DEG F
CPP-BOT (M/T)	T33	NO	YES (J)	NO	NO	YES/NO
HTRCM12	T47	664	664	664	664	MA
HTRCM22	T48	660	660	660	660	MA
APP	PID	0	0	11	18.5	%
BARO	PID	155.8/14.24	155.8/14.24	155.8/14.24	155.8/14.24	Hz/PSI
B+	PID	VBAT	VBAT	VBAT	VBAT	DCV
CPP/PNP	PID	NEUTRAL	DRIVE	DRIVE	DRIVE	NEUTRAL/ DRIVE
DECHOKE	PID	YES	NO	NO	NO	YES/NO
ECT_ACT	PID	7.43	1.06	7.45	9.66	DEG
ECT_DSD	PID	7.62	1.04	7.52	9.66	DEG
ECT_TRIM	PID	0.18	0.18	0.25	0.25	DEG
FLI	PID	50 (H)	50 (H)	50 (H)	50 (H)	%
GEAR (A/T)	PID	1	1	5	5	GEAR
LOAD	PID	59 (L)	16	22	18	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
O2BANK2	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	660	1200	1450	RPM
TR (A/T)	PID	P	P	OD	OD	MODE
VSS	PID	0	0	30	55	MPH

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B12	75/OFF	28/ON	28/ON	28/ON	%/ON-OFF
EVAPCV	B13	0/OFF	0/OFF	0 (R)/OFF	0 (R)/OFF	%/ON-OFF
WAC/ACCR	B14	ON	OFF (A)	ON	ON	ON/OFF
GENCMD	B32	3.79	0 (Q)	0 (Q)	0 (Q)	%
HFC	E4	OFF	ON (B)	OFF	OFF	ON/OFF
EVMV	E6	0/OFF	0/OFF	350/ VARYING	235/ VARYING	MA/OFF- VARYING
LFC	E7	OFF	ON (B)	OFF	OFF	ON/OFF
IMRC	E50	OFF	OFF	OFF	OFF	ON/OFF
VCTDC	E67	0	0	41.7	39.5	%
VCTDC2	E68	0	0	43.3	33.7	%
HTR11	E69	ON (O)	ON	ON	ON	ON/OFF
HTR21	E70	ON (O)	ON	ON	ON	ON/OFF
TCC (A/T)	T46	0/OFF	0/OFF	0/OFF	100/ ENGAGED	%/OFF- ENGAGED
HTR12	T47	ON (O)	ON	ON	ON	ON/OFF
HTR22	T48	ON (O)	ON	ON	ON	ON/OFF
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/ DISALLOW
EVAP020R	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EVAPSOAK	PID	NO	NO	YES	YES	YES/NO
EVAPSTA	PID	NOT RUNNING	NOT RUNNING	NOT RUNNING	NOT RUNNING	STATUS
EVAP_EVAL	PID	YES	YES	YES	YES	YES/NO
LONGFT1	PID	(L)	(L)	(-)20-(+)20	(-)20-(+)20	%
LONGFT2	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
SHRTFT1	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SHRTFT2	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SPARKADV	PID	10-0	15-20	29-38	34-41	DEG
TCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
VCTADV	PID	0	0.37	10.8	32	DEG
VCTADV2	PID	0	1	8	33.7	DEG
VCTADVERR	PID	0	0.68	0.81	1.12	DEG
VCTADVERR2	PID	0	1	1.56	0.43	DEG

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B35/36	VBAT	VBAT	VBAT	VBAT	DCV
VREF	B40/E57	5	5	5	5	DCV

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FTP	B3	2.6/0 (M)	2.6/0 (M)	2.1/-0.13 (M)	2.6/-0.24 (M)	DCV/PSI
APP1	B5	4.0	4.0	3.8	3.6	DCV
APP2	B17	1.5	1.5	1.7	1.7	DCV
APP3	B28	1.0	1.1	1.3	1.5	DCV
CPP-BOT	B33	NO	NO	NO	NO	YES/NO
GENMON	E5	0	34	24	27	%
ACCS	E15	OFF	ON (A)	OFF	OFF	ON/OFF
FRT	E19	1.7/122 (K)	1.8/120 (K)	2.9/79 (K)	2.7/84 (K)	DCV/DEG F
IAT	E22	1.7/158 (K)	1.9/135 (K)	3.8/34 (K)	3.9/30 (K)	DCV/DEG F
MAF	E25	0	0.6	1.1	1.3	DCV
IAT2	E27	1.2/158 (K)	1.3/135 (K)	2.5/93 (K)	2.7/84 (K)	DCV/DEG F
O2S11	E28	(L)	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
O2S21	E29	0	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
FRP	E32	2.6/36	3/44	3/44	3/44	DCV/PSI
CHT	E41	3.6/199	3.6/199	3.58/201	3.45/208	DCV/DEG F
TP2	E60	1.23/24.31	0.74/14.51	0.87/17.26	0.96/19.22	DCV/%
TP1	E61	4.1/17.65	4.35/12.94	4.28/14.12	4.23/14.9	DCV/%
HTRCM11	E69	1.02	1.02	1.02	1.02	AMPS
HTRCM21	E70	1.02	1.02	1.02	1.02	AMPS
OSS_SRC	T3	0	0	1251	2268	RPM
O2S12	T24	(L)	(D)	(D)	(D)	DCV
O2S22	T25	0.1	(D)	(D)	(D)	DCV
HTRCM12	T47	676	676	676	676	MA
HTRCM22	T48	660	660	660	660	MA
APP	PID	0	0	9.5	9.5	%
BARO	PID	14.73/158.9	14.73/158.9	14.73/158.9	14.73/158.9	PSI/HZ
B+	PID	VBAT	VBAT	VBAT	VBAT	DCV
DECHOKE	PID	YES	NO	NO	NO	YES/NO
ETC_ACT	PID	7.62	1.7	6.5	5.43	DEG
ETC_DSD	PID	7.62	1.57	6.44	5.4	DEG
ETC_TRIM	PID	0.12	0.12	0.12	0.12	DEG
FLI	PID	50 (H)	50 (H)	50 (H)	50 (H)	%
LOAD	PID	73 (L)	16	23.7	27.3	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
O2BANK2	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	660-780	1200-1300	1450-1740	RPM
VSS	PID	0	0	30	55	MPH

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B12	75/OFF	21.59/ON	21.26/ON	20.94/ON	%/ON-OFF
EVAPCV	B13	OFF	OFF	OFF	OFF	ON/OFF
WAC/ACCR	B14	ON	OFF (A)	ON	ON	ON/OFF
FPM	B21	100.2	100.2	99.71	103.4	%
GENCMD	B32	3.79	0 (Q)	0 (Q)	0 (Q)	%
HFC	E4	OFF	ON (B)	OFF	OFF	ON/OFF
EVMV	E6	0/OFF	327/ VARYING	427/ VARYING	200/ VARYING	MA/OFF- VARYING
LFC	E7	OFF	ON (B)	OFF	OFF	ON/OFF
SPKDUR_8	E9	0	1.78	1.46	1.59	Ms
SPKDUR_5	E10	0	1.56	1.37	1.81	Ms
SPKDUR_2	E11	0	1.75	1.43	1.46	Ms
SPKDUR_3	E12	0	1.84	1.62	1.53	Ms
SPKDUR_4	E14	0	1.78	1.59	1.62	Ms
SPKDUR_6	E15	0	1.56	1.65	1.56	Ms
SPKDUR_7	E16	0	1.96	1.62	1.43	Ms
SPKDUR_1	E17	0	1.9	1.75	1.43	Ms
HTR11	E69	ON (O)	ON	ON	ON	ON/OFF
HTR21	E70	ON (O)	ON	ON	ON	ON/OFF
HTR12	T47	ON (O)	ON	ON	ON	ON/OFF
HTR22	T48	ON (O)	ON	ON	ON	ON/OFF
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/ DISALLOW
EVAP020R	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EVAPSOAK	PID	NO	NO	NO	NO	YES/NO
EVAP_EVAL	PID	YES	YES	YES	YES	YES/NO
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/ CLOSED LOOP
LONGFT1	PID	(L)	(L)	(-)20-(+)20	(-)20-(+)20	%
LONGFT2	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
SHRTFT1	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SHRTFT2	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SPARKADV	PID	10	14.7	34.7	31	DEG

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B35/36	VBAT	VBAT	VBAT	VBAT	DCV
VREF	B40/E57	5	5	5	5	DCV

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FTP	B3	2.6/0 (M)	2.6/0 (M)	2.6/0 (M)	1.4/-0.3 (M)	DCV/PSI
APP1	B5	4.0	4.0	3.8	3.6	DCV
BPP/BOO	B8	OFF	OFF	OFF	OFF	ON/OFF
ACCS	B15	OFF	OFF	OFF	OFF	ON/OFF
APP2	B17	1.5	1.5	1.7	1.7	DCV
ACP	B26	1.64/157	1.64/157	1.27/117	1.27/117	DCV/PSI
APP3	B28	1.0	1.1	1.3	1.5	DCV
TCS	B29	NOT DEPRESSED	NOT DEPRESSED	NOT DEPRESSED	NOT DEPRESSED	DEPRESSED/ NOT DEPRESSED
GENMON	E5	0	46	34	27	%
FRT	E19	3.4/62 (K)	3.4/64 (K)	3.2/68 (K)	3.3/66 (K)	DCV/DEG F
DPFEGR	E21	0.25-1.3	0.25-1.3	0.25-4.65	0.25-4.65	DCV
IAT	E22	1.9/115 (K)	2.6/86 (K)	3.2/63 (K)	3.2/61 (K)	DCV/DEG F
MAF	E25	0	0.9	1.97	1.94	DCV
O2S11	E28	(L)	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
O2S21	E29	0	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
FRP	E32	3.35/50	3/43	2.8/39	2.8/39	DCV/PSI
CHT	E41	3.64/190.4	3.7/188.6	3.76/186.8	3.76/186.8	DCV/DEG F
KNOCK 1	E48	0	235	266	357	N/A
TP2	E60	1.2	0.7	0.90	1.2	DCV
TP1	E61	4.1	4.4	4.1	4.1	DCV
MAP	E62	4.39/0/14.79	1.25/69/4.49	2.27/46/7.83	2.06/51/7.1	DCV/kPa/PSI
OSS_SRC	T3	0	0	1385-1420	2400-2500	RPM
TSS	T15	0	624	737	1339	RPM
TR2	T17	CLOSED	CLOSED	OPEN	OPEN	OPEN/ CLOSED
O2S12	T24	(L)	(D)	(D)	(D)	DCV
O2S22	T25	0.1	(D)	(D)	(D)	DCV
TFT	T29	1.4/142 (K)	1.4/140 (K)	0.8/176 (K)	0.8/179 (K)	DCV/DEG F
APP	PID	0	0	6	10.5	%
B+	PID	VBAT	VBAT	VBAT	VBAT	DCV
BARO	PID	159.3/14.79	159.3/14.79	159.3/14.79	159.3/14.79	Hz/PSI
BPA	PID	OFF	OFF	OFF	OFF	ON/OFF
CPP/PNP	PID	NEUTRAL	DRIVE	DRIVE	DRIVE	NEUTRAL/ DRIVE
DECHOKE	PID	YES	NO	NO	NO	YES/NO
ETC_ACT	PID	7.87	1.62	6.22	12.74	DEG
ETC_DSD	PID	7.85	1.65	6.19	12.73	DEG
FLI	PID	50 (H)	50 (H)	50 (H)	50 (H)	%
GEAR	PID	1	1	4	4	GEAR
LOAD	PID	58 (L)	15	19	14	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
O2BANK2	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	638	1065	1330	RPM
TR	T16	P	P	OD	OD	MODE
VSS	PID	0	0	30	55	MPH

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
PATSENABL	B2	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/ DISABLED
FP	B12	75/OFF	17/ON	28/ON	28/ON	%/ON-OFF
WAC/ACCR	B14	ON	OFF (A)	ON	ON	ON/OFF
EGRVR	E63	0	0	(T)	(T)	%
HTR11	E69	ON (O)	ON	ON	ON	ON/OFF
HTRCM11	E69	1.1	1.1	1.1	1.1	Amps
HTR21	E70	ON (O)	ON	ON	ON	ON/OFF
HTRCM21	E70	1.04	1.04	1.04	1.04	Amps
TCC	T46	0/OFF	0/OFF	0/OFF	100/ ENGAGED	%/OFF- ENGAGED
HTR12	T47	ON (O)	ON	ON	ON	ON/OFF
HTRCM12	T47	629	629	629	629	MA
HTR22	T48	ON (O)	ON	ON	ON	ON/OFF
HTRCM22	T48	629	629	629	629	MA
EGR_EVAL	PID	YES	YES	NO	NO	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/ DISALLOW
EVAP020F	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EVAPCV	PID	0/OFF	0/OFF	0/OFF	0/OFF	%/ON-OFF
EVAPSOAK	PID	NO	NO	NO	NO	YES/NO
EVAPSTA	PID	NOT RUNNING	NOT RUNNING	NOT RUNNING	NOT RUNNING	STATUS
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
EVMV	PID	0/OFF	VARYING	VARYING	VARYING	MA/OFF- VARYING
FCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/ CLOSED LOOP
GENCMD	PID	3.79	0 (Q)	0 (Q)	0 (Q)	%
LONGFT1	PID	(L)	(L)	(-)20-(+)20	(-)20-(+)20	%
LONGFT2	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
SHRTFT1	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SHRTFT2	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SPARKADV	PID	10	17.7	20	37	DEG

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B35/36	VBAT	VBAT	VBAT	VBAT	DCV
VREF	B40/E57	5	5	5	5	DCV

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FTP	B3	2.6/0 (M)	2.6/0 (M)	2.6/0 (M)	1.4/-0.3 (M)	DCV/PSI
APP1	B5	4.0	4.0	3.8	3.6	DCV
SMR	B7	VBAT (V)	0	0	0	DCV
BPP	B8	VBAT/OFF	0.1/ON (E)	VBAT/OFF	VBAT/OFF	DCV/ON-OFF
BPS	B9	0.1/OFF	VBAT/ON (E)	0.1/OFF	0.1/OFF	DCV/ON-OFF
ACCS	B15	0.1/OFF	VBAT/ON (A)	0.1/OFF	0.1/OFF	DCV/ON-OFF
APP2	B17	1.5	1.5	1.7	1.7	DCV
FPM	B21	3.5/100	3.5/100	3.5/100	3.5/100	DCV/%
ACP	B26	1.3/80	1.4/75	1.3/80	1.3/80	DCV/PSI
APP3	B28	1.0	1.1	1.3	1.5	DCV
TCS	B29	0.1/OFF	VBAT/ON (G)	0.1/OFF	0.1/OFF	DCV/ON-OFF
PSP	B34	0.1/LOW	VBAT/HIGH (I)	0.1/LOW	0.1/LOW	DCV/ HIGH-LOW
PATS IN	B42	VBAT	VBAT	VBAT	VBAT	DCV
FEPS	B44	0.1	0.1	0.1	0.1	DCV
GENMON	E5	0	39.8	30	24	%
FRT	E19	2.6/90 (K)	3.2/ 70 (K)	3.1/72 (K)	3.2/70 (K)	DCV/DEG F
DPFEGR	E21	0.25-1.3	0.25-1.3	0.25-4.65	0.25-4.65	DCV
IAT	E22	2.74/81 (K)	2.9/73 (K)	4/27 (K)	3.9/30 (K)	DCV/DEG F
MAF	E25	0	0.9	1	1.5	DCV
HO2S11	E28	(L)	Switching (C)	Switching (C)	Switching (C)	DCV
HO2S21	E29	0	Switching (C)	Switching (C)	Switching (C)	DCV
FRP	E32	3.35/50	3/43	2.8/39	2.8/39	DCV/PSI
CHT	E41	3.54/194	3.54/194	3.72/188.6	3.65/190.4	DCV/DEG F
CMP1	E45	0	5-7	10-12	12-16	Hz
CKP	E47	0	390-450	650-760	980-1020	Hz
KNOCK 1	E48	0	235	266	357	N/A
TP2	E60	1.2	0.7	0.90	1.2	DCV
TP1	E61	4.1	4.4	4.1	4.1	DCV
MAP	E62	4.3/14.5 (W)	1.2/4.5 (W)	1.2/4.4 (W)	1.7/5.8 (W)	DCV/PSI
OSS_SRC	T3	0	0	1201	2236	RPM
TSS	T15	0	623	825	1569	Hz/RPM
TR 1	T16	0	0	11.5	11.5	DCV
TR 2	T17	0	0	11.5	11.5	DCV
HO2S12	T24	(L)	(D)	(D)	(D)	DCV
HO2S22	T25	0.1	(D)	(D)	(D)	DCV
TR3A	T27	0/PARK	0/PARK	1.7/OD	1.7/OD	DCV/MODE
TR 4	T28	0	0	11.5	11.5	DCV
TFT	T29	1.5/135 (K)	1.5/136 (K)	1.2/154 (K)	1.2/156 (K)	DCV/DEG F
CPP/PNP	PID	NEUTRAL	DRIVE	DRIVE	DRIVE	NEUTRAL/ DRIVE
FLI	PID	50 (H)	50 (H)	50 (H)	50 (H)	%
FRT	PID	2.5/93 (K)	2.6/90 (K)	3.1/72 (K)	3.1/72 (K)	DCV/DEG F
GEAR	PID	1	1	4	4	GEAR
LOAD	PID	14 (L)	14	17	19	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
RPM	PID	0	660-780	1200-1300	1450-1740	RPM
VSS	PID	0	0	30	55	MPH

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
PATSTRT	B2	0	0	0	0	DCV
FP	B12	3.7/75	1.3/28	1.3/28	1.3/28	DCV/%
CANV	B13	VBAT/0	VBAT/0	VBAT/0 (R)	VBAT/0 (R)	DCV/%
PATS OUT	B31	10.5	VBAT (A)	VBAT	VBAT	DCV
WAC/ACCR	B14	0.1/ON	VBAT/OFF (A)	0.1/ON	0.1/ON	DCV/ON-OFF
GENCMD	B32	3.79	0 (Q)	0 (Q)	0 (Q)	%
PCVHC	E3	0.1/ON	0.1/ON	VBAT/OFF	0.1/ON	DCV/ON-OFF
EVAPPDC	E6	0	0-10/0-100	0-10/0-100	0-10/0-100	Hz/%
VFC	E7	0-100	0-100	0-100	0-100	%
CDH (CYL 8)	E9	VBAT	VBAT	VBAT	1.3/28	DCV
CDF (CYL 5)	E10	VBAT	VBAT	VBAT	VBAT	DCV
CDD (CYL 2)	E11	VBAT	VBAT	VBAT	VBAT	DCV
CDB (CYL 3)	E12	VBAT	VBAT	VBAT	VBAT	DCV
CDG (CYL 4)	E14	VBAT	VBAT	VBAT	VBAT	DCV
CDE (CYL 6)	E15	VBAT	VBAT	VBAT	VBAT	DCV
CDC (CYL 7)	E16	VBAT	VBAT	VBAT	VBAT	DCV
CDA (CYL 1)	E17	VBAT	VBAT	VBAT	VBAT	DCV
TACM (+)	E34	3.7	VBAT	VBAT	VBAT	DCV
TACM (-)	E51	3.7	VBAT	VBAT	VBAT	DCV
EGRVR	E63	VBAT/0	VBAT/0	(T)	(T)	DCV/%
HTR11	E69	0.1/ON (O)	0.1/ON	0.1/ON	0.1/ON	DCV/ON-OFF
HTR21	E70	0.1/ON (O)	0.1/ON	0.1/ON	0.1/ON	DCV/ON-OFF
EPC	T11	7.9/20	9.5/20	9.3/22	9.5/22	DCV/PSI
SSA (SS1)	T42	0.1/ON	0.1/ON	VBAT/OFF	VBAT/OFF	DCV/ON-OFF
SSB (SS2)	T43	VBAT/OFF	VBAT/OFF	VBAT/OFF	VBAT/OFF	DCV/ON-OFF
TCC	T46	0.1/100	VBAT/0	VBAT/0	0.2/95-100	DCV/%
HTR12	T47	0.2/ON (O)	0.2/ON	0.2/ON	0.2/ON	DCV/ON-OFF
HTR22	T48	0.2/ON (O)	0.2/ON	0.2/ON	0.2/ON	DCV/ON-OFF
LONGFT1	PID	(L)	(L)	(-)20-(+)20	(-)20-(+)20	%
LONGFT2	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
SHRTFT1	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SHRTFT2	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SPARKADV	PID	10	17.5	32.7	37.7	DEG
TCIL	PID	OFF	OFF	OFF	OFF	ON/OFF

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B35/36	VBAT	VBAT	VBAT	VBAT	DCV
VREF	B40/E57	5	5	5	5	DCV
KAPWR	B45	VBAT	VBAT	VBAT	VBAT	DCV
ETCVREF	E66	5	5	5	5	DCV

Scheme 3

Scheme 3: 2.3L 4V Escape/Mariner

Scheme 3: 2.3L 4V Escape/Mariner

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
BOO	B8	OFF	ON (E)	OFF	OFF	ON/OFF
FTP	B9	2.6/0	2.6/0	2.5/-0.03	2.15/-0.12	DCV/PSI
FTP_H2O	B9	0.13	0.13	0.86	3.27	In-Hg
ACCS	B15	OFF	ON (A)	OFF	OFF	ON/OFF
IAT	B20	111/1.96 (K)	104/2.16 (K)	3.15/66 (K)	3.18/64 (K)	DCV/DEG F
TCS (A/T)	B27	0.1/OFF	VBAT/ON (G)	0.1/OFF	0.1/OFF	DCV/ON-OFF
MAF (A/T)	B32	0	0.9	1.4	2.5	DCV
MAF (M/T)	B32	0	1-1.08	1-1.7	1.2-2.5	DCV
GENMON	E16	0	37.5	15.63	15.63	%
TP	E19	0.53-1.27	0.53-1.27	1-1.3	1.1-2	DCV
MAP	E23	4/14.3 (W)	1.2/4.2 (W)	1.1/4.1 (W)	3.3/11.9 (W)	DCV/PSI
FRT	E28	2.5/93 (K)	2.6/90 (K)	3.1/72 (K)	3.1/72 (K)	DCV/DEG F
O2S11	E30	(L)	Switching (C)	Switching (C)	Switching (C)	DCV
CHT	E33	3.4/210	3.4/212	3.4/212	3.2/225	DCV/DEG F
FRP	E37	1.3/14	3.7/39	3.7/39	3.7/39	DCV/PSI
VSS (M/T)	T3	0	0	30	55	MPH
OSS (A/T)	T4	0	0	67-400	120/7300	RPM
TSS (A/T)	T15	0	686	1547	1995	RPM
O2S12	T24	(L)	(D)	(D)	(D)	DCV
TRS (A/T)	T27	4.4/PARK	4.4/PARK	2.1/OD	2.1/OD	DCV/MODE
CPP (M/T)	T27	0/ON	0/ON	12/OFF	12/OFF	DCV/ON-OFF
TFT (A/T)	T29	1.2/154 (K)	1.1/156 (K)	1.4/140 (K)	1.4/142 (K)	DCV/DEG F
ACP	PID	OPEN (OK)	OPEN (OK)	OPEN (OK)	OPEN (OK)	OPEN/ CLOSED
B+	PID	13	14.3	14.19	14.19	DCV
BARO	PID	157.7	157.7	157.7	155.8	Hz
CHT_COLD	PID	80.6	75.2	82.4	80.6	DEG F
CHT_HOT	PID	237.2	231.8	240.8	239	DEG F
CPP/PNP	PID	NEUTRAL	NEUTRAL	DRIVE	DRIVE	NEUTRAL/ DRIVE
EVMV	PID	0	0	36	741	MA
FLI	PID	50 (H)	50 (H)	50 (H)	50 (H)	%
GEAR (A/T)	PID	1	1	3	4	GEAR
HTRCM11	PID	1.46	1.46	1.53	1.53	Amps
HTRCM12	PID	750	750	852	852	MA
LOAD (A/T)	PID	54 (L)	17.4	19.2	24.7	%
LOAD (M/T)	PID	(L)	10-20	19-30	30-48	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
RPM	PID	0	680	1877	2252	RPM
PSP	PID	LOW	HIGH (I)	LOW	LOW	HIGH/LOW
TPCT	PID	0.85	0.84	0.85	0.85	DCV
VSS	PID	0	0	30	55	MPH

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B12	75	18	19.5	19.8	%
WAC/ACCR	B25	VBAT/OFF	1.5/ON	VBAT/OFF	VBAT/OFF	DCV/ON-OFF
EVMV	B34	0	0-10/0-100	0-10/0-100	0-10/0-100	Hz/%
HFC	B38	VBAT/OFF	0.1/ON (B)	VBAT/OFF	VBAT/OFF	DCV/ON-OFF
LFC	B39	VBAT/OFF	VBAT/OFF	VBAT/OFF	VBAT/OFF	DCV/ON-OFF
GENCMD	E7	3.79	0 (Q)	0 (Q)	0 (Q)	%
IAC	E39	VBAT/6.89	10.1/37.37	8.2/60 (L)	7.6/64 (L)	DCV/%
HTR11	E49	OFF	0.1/ON	0.1/ON	0.1/ON	DCV/ON-OFF
EPC (A/T)	T11	7.5/0	8.4/0	9-10/25-37	10.3-11.2/42-51	DCV/PSI
SSC (SS3) (A/T)	T23	VBAT/OFF	VBAT/OFF	8.8/OFF	8.8/OFF	DCV/ON-OFF
SSA (SS1) (A/T)	T42	VBAT/OFF	VBAT/OFF	VBAT/OFF	0.1/ON	DCV/ON-OFF
SSB (SS2) (A/T)	T43	0.1/ON (O)	0.1/ON	VBAT/OFF	VBAT/OFF	DCV/ON-OFF
TCC (A/T)	T46	VBAT/0	VBAT/0	VBAT/0	0.2/100	DCV/%
HTR12	T47	0.2/ON (O)	0.2/ON	0.2/ON	0.2/ON	DCV/ON-OFF
CAT_EVAL	PID	NO	NO	NO	NO	YES/NO
EVAPCV	PID	OFF/0	OFF/0	OFF/0 (R)	OFF/0 (R)	ON-OFF/%
EVAPSOAK	PID	YES	YES	YES	YES	YES/NO
FAN	PID	OFF	OFF	OFF	OFF	ON/OFF
FCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
FRP_DSD	PID	39.15	39.15	39.15	39.15	PSI
FUELSYST	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/ CLOSED LOOP
IMTV	PID	OFF	ON	ON	ON	ON/OFF
LONGFT1	PID	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
MFC	PID	OFF	OFF	OFF	OFF	ON/OFF
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/ DISABLED
RPMDSD	PID	848	672	672	672	RPM
SHRTFT1	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SPARKADV (A/T)	PID	10	14-20	36-44	30-40	DEG
SPARKADV (M/T)	PID	0	15	46	45	DEG
STRT_RLY	PID	ENABLED	DISABLED	DISABLED	DISABLED	ENABLED/ DISABLED
TCIL (A/T)	PID	OFF	OFF	OFF	OFF	ON/OFF
TPCT	PID	0.85	0.84	0.85	0.85	DCV
TQ_CNTRL	PID	NONE	NONE	NONE	NONE	_

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B35/36	VBAT	VBAT	VBAT	VBAT	DCV

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
PSP	B3	0.1/LOW	VBAT/HIGH (I)	0.1/LOW	0.1/LOW	DCV/ HIGH-LOW
BOO	B8	0.1/OFF	VBAT/ON (E)	0.1/OFF	0.1/OFF	DCV/ON-OFF
FTP	B9	2.6/57	2.6/48	2.6/65	2.6/36	DCV/kPa
ACCS	B15	0.1/OFF	VBAT/ON (A)	0.1/OFF	0.1/OFF	DCV/ON-OFF
IAT	B20	1.58/125.6 (K)	1.74/120.2 (K)	3.6/48.2 (K)	3.64/46.4 (K)	DCV/DEG F
ACP	B26	1.3/80	1.4/75	1.3/80	1.3/80	DCV/%
MAF	B32	0	0.80-1.03	0.7-1.5	1.3-2	DCV
GENMON	E16	0	31.25	18.75	25	%
ECT	E21	0.5-2.7/210-110	0.5-2.7/210-110	0.5-2.7/210-110	0.5-2.7/210-110	DCV/DEG F
MAP	E23	4 (W)	1-1.4 (W)	1.5-2.1 (W)	1.9-2.3 (W)	DCV
O2S21	E26	0	Switching (C)	Switching (C)	Switching (C)	DCV
EGRVR	E27	VBAT/0	VBAT/0	(T)	(T)	DCV/%
FRT	E28	0.5-3/210-110 (K)	0.5-3/210-110 (K)	0.5-3/210-110 (K)	0.5-3/210-110 (K)	DCV/DEG F
O2S11	E30	(L)	Switching (C)	Switching (C)	Switching (C)	DCV
FRP	E37	3.7/39	3.7/39	3.7/39	3.8/40	DCV/PSI
DPFEGR	E44	0.25-1.3	0.25-1.3	0.25-4.65	0.25-4.65	DCV
OSS	T4	0	0	67/1360	120/2466	Hz/RPM
TSS	T15	0	45-50/ 700-770	90-100/ 1350-1450	110-120/ 1700-1800	Hz/RPM
O2S12	T24	(L)	(D)	(D)	(D)	DCV
O2S22	T25	0.1	(D)	(D)	(D)	DCV
TR	T27	PARK	PARK	OD	OD	MODE
TFT	T29	0.4-2/220-125 (K)	0.4-2/220-125 (K)	0.4-2.4/220-125 (K)	0.4-2/220-125 (K)	DCV/DEG F
B+	PID	12.63	14.63	14.5	14.44	DCV
BARO	PID	157.7/14.48	157.7/14.48	157.7/14.24	155.8/14.24	Hz/PSI
CAT_EVAL	PID	YES	YES	YES	YES	YES/NO
CPP/PNP	PID	NEUTRAL	NEUTRAL	DRIVE	DRIVE	NEUTRAL/ DRIVE
FLI	PID	50 (H)	50 (H)	50 (H)	50 (H)	%
GEAR	PID	1	1	3	4	GEAR
HTRCM11	PID	1.09	1.09	1.09	1.09	Amps
HTRCM12	PID	680	680	680	680	MA
HTRCM21	PID	1.11	1.11	1.11	1.11	Amps
HTRCM22	PID	660	660	660	660	MA
LOAD	PID	(L)	10-20	19-30	30-48	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
RPM	PID	0	705-820	1200-1500	1600-1800	RPM
TPCT	PID	0.85	0.85	0.85	0.85	DCV
TSS_ISS	PID	0	761.5	1356	1765	RPM
TSS_SRC	PID	0	761.8	1354	1768	RPM
VSS	PID	0	0	30	55	MPH

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B12	8.3/75	3.6/27	3.6/27	3.8/29	DCV/%
WAC/ACCR	B25	VBAT/OFF	1.5/ON	VBAT/OFF	VBAT/OFF	DCV/ON-OFF
EVMV	B34	0	0-10/0-100	0-10/0-100	0-10/0-100	Hz/%
HFC	B38	OFF	ON	OFF	OFF	ON/OFF
LFC	B39	OFF	ON (B)	OFF	OFF	ON/OFF
GENCMD	E7	3.79	0 (Q)	0 (Q)	0 (Q)	%
IAC	E39	0	32-40	30-55	50-79	%
HTR21	E48	ON (O)	ON	ON	ON	ON/OFF
HTR11	E49	ON	ON	ON	ON	ON/OFF
TCC	T46	0/ON	0/ON	0/ON	100/ON	%/ON-OFF
HTR12	T47	ON	ON	ON	ON	ON/OFF
HTR22	T48	ON	ON	ON	ON	ON/OFF
CAT_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAPCV	0/OFF	0/OFF	0/OFF	0/OFF	0/OFF	%/ON-OFF
EVAPSOAK	PID	YES	YES	YES	YES	YES/NO
FAN	PID	OFF	OFF	OFF	OFF	ON/OFF
FCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
FRP_DSD	PID	39.15	39.15	39.15	39.15	PSI
FTP_H2O	PID	0.13	0.13	0.86	3.27	In H2O
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/ CLOSED LOOP
LONGFT1	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
LONGFT2	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/ DISABLED
RPMDSD	PID	1120	763	672	672	RPM
SHRTFT1	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SHRTFT2	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SPARKADV	PID	0-10	5-20	36-44	30-40	DEG
STRT_RLY	PID	ENABLED	DISABLED	DISABLED	DISABLED	ENABLED/ DISABLED
TCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
TQ_CNTRL	PID	NONE	NONE	NONE	NONE	_

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B35/36	VBAT	VBAT	VBAT	VBAT	DCV

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FTP	B3	2.6	2.6	2.6	2.6	DCV
FTP_H2O	B3	0	0	0	0	IN H20
ACCS	B15	OFF	ON (A)	OFF	OFF	ON/OFF
FPM	B21	OFF	ON	ON	ON	ON/OFF
TCS	B29	0.1/OFF	VBAT/ON (G)	0.1/OFF	0.1/OFF	DCV/ON-OFF
CPP/PNP	B33	NEUTRAL	NEUTRAL	DRIVE	DRIVE	MODE
PSP	B34	LOW	HIGH(I)	LOW	LOW	HIGH/LOW
FEPS	B44	0.1	0.1	0.1	0.1	DCV
IAT	E22	1.7-3.5/120-50 (K)	1.7-3.5/120-50 (K)	1.7-3.5/120-50 (K)	1.7-3.5/120-50 (K)	DCV/DEG F
MAF	E25	0	0.7-0.9	1.2-1.6	1.6-2.1	DCV
O2S11	E28	(L)	Switching (C)	Switching (C)	Switching (C)	DCV
CHT	E41	0.67 or 3.7/194 - 230	0.67 or 3.7/194 - 230	0.67 or 3.7/194 - 230	0.67 or 3.7/194 - 230	DCV/DEG F
KNOCK 1	E49	0	0	0	0	N/A
TP	E61	0.53-1.27	0.53-1.27	0.8-1.1	1.2-1.7	DCV
MAP	E62	3.99/14.21/28.9	0.95/3.33/6.79	1.58/5.91/11.22	2.01/6.81/13.87	DCV/PSI/IN HG
HTRCM11	E69	531	531	531	531	MA
OSS	T3	0	0	1250-1290	2100-2400	RPM
TSS	T15	0	320-360/ 630-670	500-713/ 1100-1300	845-985/ 1700-1800	Hz/RPM
TR 1	T16	0	0	VBAT	VBAT	DCV
TR 2	T17	0	0	VBAT	VBAT	DCV
O2S12	T24	(L)	(D)	(D)	(D)	DCV
TR3 V/TR3	T27	0/PARK	0/PARK	1.7/OD	1.7/OD	DCV/MODE
TR 4	T28	0	0	VBAT	VBAT	DCV
TFT	T29	0.5-2/210-110 (K)	0.5-2/210-110 (K)	0.5-2/210-110 (K)	0.5-2/210-110 (K)	DCV/DEG F
HTRCM12	T47	977	977	977	977	MA
BARO	PID	156.2/14.3	156.2/14.3	156.2/14.3	156.2/14.3	Hz/PSI
B+	PID	VBAT	VBAT	VBAT	VBAT	DCV
DECHOKE	PID	NO	NO	NO	NO	YES/NO
FLI	PID	50 (H)	50 (H)	50 (H)	50 (H)	%
GEAR	PID	1	1	4	5	GEAR
LOAD	PID	(L)	17-28	19-26	30-40	%
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	750	1300	1780	RPM
VSS	PID	0	0	30	55	MPH

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B12	OFF	ON	ON	ON	ON/OFF
EVAPCV	B13	0 (R)/OFF	0 (R)/OFF	0 (R)/OFF	0 (R)/OFF	%/ON-OFF
WAC/ACCR	B14	OFF	ON (A)	OFF	OFF	ON/OFF
EVMV	E6	0/OFF	0/OFF	500-900 (F)/VARYING	500-900 (F)/VARYING	MA/OFF- VARYING
IAC	E33	0	35	35-41 (L)	57-68 (L)	%
HTR11	E69	OFF (O)	ON	ON	ON	ON/OFF
EPC	T11	6.0	8.0	10.0	10.0	DCV
SSA (SS1)	T42	0.1/ON	0.1/ON	VBAT/OFF	VBAT/OFF	DCV/ON-OFF
SSB (SS2)	T43	VBAT/OFF	VBAT/OFF	VBAT/OFF	VBAT/OFF	DCV/ON-OFF
SSC (SS3)	T44	VBAT/OFF	VBAT/OFF	VBAT/OFF	0.1/ON	DCV/ON-OFF
SSD (SS4)	T45	0.1/ON	0.1/ON	0.1/ON	0.1/ON	DCV/ON-OFF
TCC	T46	VBAT/0	VBAT/0	VBAT/0	0.2/100	DCV/%
HTR12	T47	OFF (O)	ON	ON	ON	ON/OFF
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/ CLOSED LOOP
EGR_EVAL	PID	YES	YES	NO	NO	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/ DISALLOW
EVAP020R	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EVAPSOAK	PID	NO	NO	NO	NO	YES/NO
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
LONGFT1	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
LONGFT2	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
SHRTFT1	PID	0	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SHRTFT2	PID	0	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SPARKADV	PID	0	20-25	30-35	30-35	DEG
TCIL	PID	OFF	OFF	OFF	OFF	ON/OFF

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B35/B36	VBAT	VBAT	VBAT	VBAT	DCV
VREF	E57	5	5	5	5	DCV

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FTP	B3	2.6/0	2.6/0	2.6/0	2.6/0	DCV/PSI
ACCS	B15	OFF	ON (A)	OFF	OFF	ON/OFF
FPM	B21	OFF	ON	ON	ON	ON/OFF
TCS	B29	NOT DEPRESSED	NOT DEPRESSED	NOT DEPRESSED	NOT DEPRESSED	DEPRESSED/ NOT DEPRESSED
CPP/PNP	B33	NEUTRAL	NEUTRAL	DRIVE	DRIVE	MODE
ECT	E18	0.4-1/200-160	0.4-1/200-160	0.4-1/200-160	0.4-1/200-160	DCV/DEG F
DPFEGR	E21	0.25-1.30	0.25-1.30	0.25-4.65	0.25-4.65	DCV
IAT	E22	1.7-3.5/120-50 (K)	1.7-3.5/120-50 (K)	1.7-3.5/120-50 (K)	1.7-3.5/120-50 (K)	DCV/DEG F
MAF	E25	0	0.7-0.9	1.2-1.6	1.6-2.1	DCV
O2S11	E28	(L)	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
O2S21	E29	0	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
KNOCK 1	E49	0	0	0	0	N/A
TP	E61	0.53-1.27/CT	0.53-1.27/CT	0.8-1.1/PT	1.2-1.7/PT	DCV/MODE
HTRCM11	E69	539	539	539	539	MA
HTRCM21	E70	504	504	504	504	MA
OSS	T3	0	0	1250-1290	2100-2400	RPM
TSS	T15	0	630-670	1100-1300	1700-1800	RPM
TR 2	T17	CLOSED	CLOSED	OPEN	OPEN	OPEN/ CLOSED
O2S12	T24	(L)	(D)	(D)	(D)	DCV
O2S22	T25	0.1	(D)	(D)	(D)	DCV
TFT	T29	0.5-2/210-110 (K)	0.5-2/210-110 (K)	0.5-2/210-110 (K)	0.5-2/210-110 (K)	DCV/DEG F
HTRCM12	T47	969	969	969	969	MA
HTRCM22	T48	965	965	965	965	MA
BARO	PID	13.87/153.5	13.87/153.5	13.87/153.5	13.87/153.5	PSI/HZ
B+	PID	VBAT	VBAT	VBAT	VBAT	DCV
DECHOKE	PID	YES	NO	NO	NO	YES/NO
FLI	PID	50 (H)	50 (H)	50 (H)	50 (H)	%
GEAR	PID	1	1	4	5	GEAR
LOAD	PID	(L)	17-28	19-26	30-40	%
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
O2BANK2	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	750	1300-1350	1780	RPM
TR	PID	P	P	OD	OD	MODE
VSS	PID	0	0	30	55	MPH

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B12	OFF	ON	ON	ON	ON/OFF
EVAPCV	B13	0/OFF	0/OFF	0/OFF	0/OFF	%/ON-OFF
WAC/ACCR	B14	OFF	ON (A)	OFF	OFF	ON/OFF
PCVHC	E3	0	0	0	0	%
EVMV	E6	0	0	500-900 (F)/VARYING	500-900 (F)/VARYING	MA/OFF- VARYING
IAC	E33	0	35	35-41 (L)	57-68 (L)	%
EGRVR	E63	0	0	(T)	(T)	%
HTR11	E69	OFF (O)	ON	ON	ON	ON/OFF
HTR21	E70	OFF (O)	ON	ON	ON	ON/OFF
TCC	T46	0/OFF	0/OFF	0/OFF	100/ ENGAGED	%/OFF- ENGAGED
HTR12	T47	OFF (O)	ON	ON	ON	ON/OFF
HTR22	T48	OFF (O)	ON	ON	ON	ON/OFF
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/ DISALLOW
EVAPSOAK	PID	NO	NO	NO	NO	YES/NO
EVAP020R	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/ CLOSED LOOP
LONGFT1	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
LONGFT2	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
SHRTFT1	PID	0	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SHRTFT2	PID	0	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SPARKADV	PID	0	20-25	30-35	30-35	DEG

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B35/B36	VBAT	VBAT	VBAT	VBAT	DCV
VREF	B40/T40	5	5	5	5	DCV

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FTP	B3	2.6/0	2.6/0	2.6/0	2.6/0	DCV/PSI
FTP_H2O	B3	0	0	0	0	H2O
BOO	B8	OFF	OFF	OFF	OFF	ON/OFF
FPM	B21	OFF	ON	ON	ON	ON/OFF
TCS	B29	NOT DEPRESSED	NOT DEPRESSED	NOT DEPRESSED	NOT DEPRESSED	DEPRESSED/ NOT DEPRESSED
CPP/PNP	B33	NEUTRAL	NEUTRAL	DRIVE	DRIVE	NEUTRAL/ DRIVE
ECT	E18	0.4-1/200-160	0.4-1/200-160	0.4-1/200-160	0.4-1/200-160	DCV/DEG F
DPFEGR	E21	0.25-1.30	0.25-1.30	0.25-4.65	0.25-4.65	DCV
IAT	E22	1.7-3.5/120-50 (K)	1.7-3.5/120-50 (K)	1.7-3.5/120-50 (K)	1.7-3.5/120-50 (K)	DCV/DEG F
MAF	E25	0	0.7-0.9	1.2-1.6	1.6-2.1	DCV
O2S11	E28	(L)	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
O2S21	E29	0	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
KNOCK 1	E49	16380	196	173	212	N/A
TP	E61	1.05/CT	1.05/CT	1.21/PT	1.29/PT	DCV/CT/ PT/WOT
OSS	T3	0	0	1261	2294	RPM
TSS	T15	0	775	926	1716	RPM
TR2	T17	CLOSED	CLOSED	OPEN	OPEN	OPEN/ CLOSED
O2S12	T24	(L)	(D)	(D)	(D)	DCV
O2S22	T25	0.1	(D)	(D)	(D)	DCV
TFT	T29	0.5-2/210-110 (K)	0.5-2/210-110 (K)	0.5-2/210-110 (K)	0.5-2/210-110 (K)	DCV/DEG F
ACCS	PID	OFF	ON (A)	OFF	OFF	ON/OFF
B+	PID	VBAT	VBAT	VBAT	VBAT	DCV
BARO	PID	155.1/14.18	155.1/14.18	155.1/14.18	155.1/14.18	Hz/PSI
DECHOKE	PID	YES	NO	NO	NO	YES/NO
FCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
FLI	PID	50 (H)	50 (H)	50 (H)	50 (H)	%
GEAR	PID	1	1	4	5	GEAR
LOAD	PID	(L)	17-28	19-26	30-40	%
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
O2BANK2	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	750	1300-1350	1780	RPM
TORQUE	PID	238.7	10.85	8.13	179	Nm
TPCT	PID	1.05	1.05	1.05	1.05	DCV
TR	PID	P	P	OD	OD	MODE
TSS/ISS	PID	0	750	990	1720	RPM
VSS	PID	0	0	30	55	MPH

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B12	OFF	ON	ON	ON	ON/OFF
PCVHC	E3	0	0	0	0	%
EVMV	E6	0	0	500-900 (F)	500-900 (F)	MA
IAC	E33	0	35	35-41 (L)	57-68 (L)	%
EGRVR	E63	0	0	(T)	(T)	%
HTR11	E69	OFF (O)	ON	ON	ON	ON/OFF
HTRCM11	E69	539	539	535	535	MA
HTR21	E70	OFF (O)	ON	ON	ON	ON/OFF
HTRCM21	E70	504	504	500	500	MA
TCC	T46	0/OFF	0/OFF	0/OFF	100/ ENGAGED	%/OFF- ENGAGED
HTR12	T47	OFF (O)	ON	ON	ON	ON/OFF
HTRCM12	T47	938	938	906	906	MA
HTR22	T48	OFF (O)	ON	ON	ON	ON/OFF
HTRCM22	T48	922	922	945	945	MA
EGR_EVAL	PID	NO	NO	NO	NO	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/ DISALLOW
EVAP020R	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EVAPCV	PID	0/OFF	0/OFF	0/OFF	0/OFF	%/ON-OFF
EVAPSOAK	PID	YES	YES	NO	NO	YES/NO
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/ CLOSED LOOP
LONGFT1	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
LONGFT2	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
SHRTFT1	PID	0	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SHRTFT2	PID	0	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SPARKADV	PID	0	20-25	30-35	30-35	DEG

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B35/B36	VBAT	VBAT	VBAT	VBAT	DCV
VREF	B40/T40	5	5	5	5	DCV

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FTP	B3	2.61/0	2.61/0	2.19/-0.11	2.62/0	DCV/PSI
APP1	B5	4.0	4.0	3.4-4.0	2.9-4.0	DCV
BOO	B8	OFF	ON (E)	OFF	OFF	ON/OFF
ACCS	B15	OFF	ON (A)	OFF	OFF	ON/OFF
ACDS1	B16	ENABLE	ENABLE	ENABLE	ENABLE	ENABLE/ DISABLED
APP2	B17	1.4	1.5	1.5-1.9	1.5-2.4	DCV
ACP_PRESS	B18	117.97	101.97	81.98	83.98	PSI
APP3	B28	0.9	0.9	0.9-1.3	0.9-1.8	DCV
TCS	B29	NOT DEPRESSED	DEPRESSED (G)	NOT DEPRESSED	NOT DEPRESSED	DEPRESSED/ NOT DEPRESSED
ECT	E18	0.4-1/200-160	0.4-1/200-160	0.4-1/200-160	0.4-1/200-160	DCV/DEG F
FRT	E19	0.5-3/210-110 (K)	0.5-3/210-110 (K)	0.5-3/210-110 (K)	0.5-3/210-110 (K)	DCV/DEG F
DPFEGR	E21	0.25-1.30	0.25-1.30	0.25-4.65	0.25-4.65	DCV
IAT	E22	1.7-3.5/120-50 (K)	1.7-3.5/120-50 (K)	1.7-3.5/120-50 (K)	1.7-3.5/120-50 (K)	DCV/DEG F
FANSS	E24	0	300-500	300-550	300-500	RPM
MAF	E25	0	0.7-0.9	1.2-1.8	1.6-2.1	DCV
O2S11	E28	(L)	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
O2S21	E29	(L)	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
FRP	E32	3.4/55	2.8/40	2.8/40	2.8/38	DCV/PSI
KNOCK 1	E49	8.19k	132	127	121	N/A
TP2	E60	1.23/24.31	0.75/14.9	0.85/16.86	1.43/28.63	DCV/%
TP1	E61	4.05/18.82	4.29.13.73	4.24/14.9	3.96/20.39	DCV/%
MAP	E62	4.3/14.5 (W)	1.21/4.49 (W)	2.14/7.54 (W)	2.83/9.71 (W)	DCV/PSI
HTRCM11	E69	523	523	523	523	MA
HTRCM21	E70	477	477	477	477	MA
OSS_SRC	T3	0	0	1250-1330	2100-2400	RPM
TSS	T15	0	630-670	1100-1310	1700-1800	RPM
TR 2	T17	CLOSED	CLOSED	OPEN	OPEN	DCV
O2S12	T24	(L)	(D)	(D)	(D)	DCV
O2S22	T25	0.1	(D)	(D)	(D)	DCV
TFT	T29	0.5-2/210-110 (K)	0.5-2/210-110 (K)	0.5-2/210-110 (K)	0.5-2/210-110 (K)	DCV/DEG F
HTRCM12	T47	852	852	852	852	MA
HTRCM22	T48	887	887	887	887	MA
ACDS2	PID	ENABLE	ENABLE	ENABLE	ENABLE	ENABLE/ DISABLED
APP	PID	0	0	15.5	23.5	%
BARO	PID	14.54/157.7	14.54/157.7	14.54/157.7	14.54/157.7	PSI/HZ
B+	PID	VBAT	VBAT	VBAT	VBAT	DCV
B+	PID	VBAT	VBAT	VBAT	VBAT	DCV
DECHOKE	PID	YES	NO	NO	NO	YES/NO
ETC_ACT	PID	7.39	1.5	5.14	12.15	DEG
ETC_DSD	PID	7.62	1.42	5.12	12.22	DEG
GEAR	PID	1	1	4	5	GEAR
LOAD	PID	(L)	15-28	19-26	30-40	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
O2BANK2	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	750-820	1300-1520	1600-1780	RPM
TR	PID	P	P	OD	OD	MODE
VSS	PID	0	0	30	55	MPH

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B12	75/OFF	20.44/ON	20.65/ON	23.04/ON	%/ON-OFF
EVAPCV	B13	0/OFF	0/OFF	0/OFF	0/OFF	%/ON-OFF
WAC/ACCR	B14	OFF	ON (A)	OFF	OFF	ON/OFF
GENCMD (ILINE)	B22	0	8.62	8.75	8.81	DCV
PCVHC	E3	0	0	0	0	%
EVMV	E6	0/OFF	0/OFF	500-900 (F)/VARYING	500-900 (F)/VARYING	MA/OFF- VARYING
FANVAR	E7	0	0/100	13	10	%
EGRVR	E63	0	0	(T)	(T)	%
HTR11	E69	OFF (O)	ON	ON	ON	ON/OFF
HTR21	E70	OFF (O)	ON	ON	ON	ON/OFF
TCC	T46	0/OFF	0/OFF	0/OFF	100/ON	%/ON-OFF
HTR12	T47	OFF (O)	ON	ON	ON	ON/OFF
HTR22	T48	OFF (O)	ON	ON	ON	ON/OFF
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/ DISALLOW
EVAP020R	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EVAPSOAK	PID	NO	NO	NO	NO	YES/NO
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
LONGFT1	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
LONGFT2	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/ DISABLED
SHRTFT1	PID	0	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SHRTFT2	PID	0	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SPARKADV	PID	10	13-25	26-35	21-35	DEG
TCIL	PID	OFF	OFF	OFF	OFF	ON/OFF

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B35/B36	VBAT	VBAT	VBAT	VBAT	DCV
VREF	B40/E57	5	5	5	5	DCV

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FTP	B3	2.6/0	2.6/0	1.98/-0.16	2.05/-0.14	DCV/PSI
APP1	B5	4.0	4.0	3.4-4.0	2.9-4.0	DCV
ACCS	B15	OFF	ON (A)	OFF	OFF	ON/OFF
ACDS1	B16	ENABLE	ENABLE	ENABLE	ENABLE	ENABLE/ DISABLE
APP2	B17	1.4	1.4	1.4-1.9	1.4-2.4	DCV
ACP_PRESS	B18	101.97	105.98	87.98	87.98	PSI
APP3	B28	0.9	0.9	0.9-1.3	0.9-1.8	DCV
TCS	B29	NOT DEPRESSED	DEPRESSED (G)	NOT DEPRESSED	NOT DEPRESSED	DEPRESSED/ NOT DEPRESSED
FRT	E19	0.5-3/210-110 (K)	0.5-3/210-110 (K)	0.5-3/210-110 (K)	0.5-3/210-110 (K)	DCV/DEG F
IAT	E22	1.7-3.5/120-50 (K)	1.7-3.5/120-50 (K)	1.7-3.5/120-50 (K)	1.7-3.5/120-50 (K)	DCV/DEG F
FANSS	E24	0	300-1040	300-500	300-500	RPM
MAF	E25	0	0.7-0.9	1.2-1.7	1.5-2.4	DCV
EOT	E27	0.5-3/210-110	0.5-3/210-110	0.5-3/210-110	0.5-3/210-110	DCV/DEG F
O2S11	E28	(L)	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
O2S21	E29	(L)	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
FRP	E32	3.0/50	2.8/40	2.8/39	2.8/39	DCV/PSI
CHT	E41	0.6-3.7/194 (K)	0.6-3.7/194 (K)	0.6-3.7/194 (K)	0.6-3.7/194 (K)	DCV/DEG F
TP2	E60	1.27/25.1	0.72/14.51	0.76/14.9	3.96/78.82	DCV/%
TP1	E61	4.03/19.22	4.3/13.73	4.28/14.12	2.71/45.88	DCV/%
HTRCM11	E69	512	512	512	512	MA
HTRCM21	E70	512	512	512	512	MA
O2S12	T24	(L)	(D)	(D)	(D)	DCV
O2S22	T25	0.1	(D)	(D)	(D)	DCV
HTRCM12	T47	863	863	863	863	MA
HTRCM22	T48	863	863	863	863	MA
ACDS2	PID	ENABLE	ENABLE	ENABLE	ENABLE	ENABLE/ DISABLE
APP	PID	0	0	7	13	%
BARO	PID	14.48/157.4	14.48/157.4	14.48/157.4	14.48/157.4	PSI/BARO
B+	PID	VBAT	VBAT	VBAT	VBAT	DCV
DECHOKE	PID	YES	NO	NO	NO	YES/NO
ETC_ACT	PID	7.98	1.43	4.37	5	DEG
ETC_DSD	PID	7.6	1.37	4.24	4.77	DEG
FLI	PID	50 (H)	50 (H)	50 (H)	50 (H)	%
GEAR	PID	1	1	4	5	GEAR
LOAD	PID	(L)	16-23	15-20	25-37	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
O2BANK2	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	630-850	1400-1465	1500-1726	RPM
VSS	PID	0	0	30	55	MPH

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B12	75/OFF	22.03/ON	19.89/ON	19.5/ON	%/ON-OFF
EVAPCV	B13	0/OFF	0/OFF	0/OFF	0/OFF	%/ON-OFF
WAC/ACCR	B14	OFF	ON (A)	OFF	OFF	ON/OFF
GENCMD (ILINE)	B22	0	8.68	8.81	8.81	DCV
EVMV	E6	0/OFF	0/OFF	500-900 (F)/VARYING	500-900 (F)/VARYING	MA/OFF- VARYING
SPKDUR_8	E9	0	1.71	1.65	1.53	MS
SPKDUR_5	E10	0	1.62	1.65	1.59	MS
SPKDUR_2	E11	0	1.71	1.68	1.21	MS
SPKDUR_3	E12	0	1.84	1.78	1.43	MS
SPKDUR_4	E14	0	1.71	1.71	1.4	MS
SPKDUR_6	E15	0	1.65	1.68	1.5	MS
SPKDUR_7	E16	0	1.65	1.59	1.53	MS
SPKDUR_1	E17	0	1.68	1.62	1.21	MS
IMRC	E50	OFF	OFF	OFF	OFF	ON/OFF
VCTDC	E67	0	0	47.49	48.31	DEG
VCTDC2	E68	0	0	41.94	47	DEG
HTR11	E69	OFF (O)	ON	ON	ON	ON/OFF
HTR21	E70	OFF (O)	ON	ON	ON	ON/OFF
HTR12	T47	OFF (O)	ON	ON	ON	ON/OFF
HTR22	T48	OFF (O)	ON	ON	ON	ON/OFF
CHTIL	PID	OFF	OFF	OFF	OFF	ON/OFF
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW DISALLOW
EVAP020R	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EVAPSOAK	PID	NO	NO	NO	NO	YES/NO
EVAP_EVAL	PID	YES	YES	YES	YES	YES/NO
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/ CLOSED LOOP
LONGFT1	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
LONGFT2	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/ DISABLED
SHRTFT1	PID	0	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SHRTFT2	PID	0	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SPARKADV	PID	0-10	9-16	30-35	28-35	DEG
VCTADV	PID	0	0.37	40.06	47.5	DEG
VCTADV2	PID	0	1	41.94	49.63	DEG
VCTADVERR	PID	0	0.37	1.06	0.75	DEG
VCTADVERR2	PID	0	1	0.75	1.25	DEG

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B35/B36	VBAT	VBAT	VBAT	VBAT	DCV
VREF	B40/E57/T40	5	5	5	5	DCV

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
ACCS	B19	0.1/OFF	VBAT/ON (A)	0.1/OFF	0.1/OFF	DCV/ON-OFF
GENMON	B23	0	28.13	16.41	21.88	%
APP1	B25	3.9	4	3.9	3.7	DCV
APP2	B26	1.5	1.5	1.9	1.7	DCV
APP3	B27	1	1	1.3	1.2	DCV
PATS IN	B37	VBAT	VBAT	VBAT	VBAT	DCV
CPP-BT	B39	NO	NO	NO	NO	YES/NO
FTP	B44	2.6/0	2.6/0	2.6/0	2.6/0	DCV/PSI
TCS (A/T)	B45	0.1/OFF	VBAT/ON (G)	0.1/OFF	0.1/OFF	DCV/ON-OFF
BPP	B46	VBAT/OFF	VBAT/ON (E)	VBAT/OFF	VBAT/OFF	DCV/ON-OFF
BPS	B47	0.1/OFF	VBAT/ON (E)	0.1/OFF	0.1/OFF	DCV/ON-OFF
FEPS	B55	0.5-0.6	0.5-0.6	0.5-0.6	0.5-0.6	DCV
FRT	E19	80.6 (K)	84.2 (K)	53.6 (K)	57.2(K)	DEG F
DPFEGR	E21	0.25-1.3	0.25-1.3	0.25-4.65	0.25-4.65	DCV
IAT	E22	1.58/125.6 (K)	1.74/120.2 (K)	3.6/48.2 (K)	3.64/46.4 (K)	DCV/DEG F
MAF	E25	0	0.86	0.93	1.6	DCV
HO2S21	E28	0	Switching (C)	Switching (C)	Switching (C)	DCV
HO2S11	E29	(L)	Switching (C)	Switching (C)	Switching (C)	DCV
FRP	E32	3.7/39	3.8/40	3.7/39	3.8/40	DCV/PSI
CHT	E41	0.63/190	0.66/188	3.71/194	3.7/194	DCV/DEG F
IMRCM	E43	NO FAULT	NO FAULT	NO FAULT	NO FAULT	FAULT/NO FAULT
CMP	E45	0	6	11	15	Hz
CKP	E47	0	475	800	1100	Hz
KNOCK 1	E49	16	25	18	29	N/A
TP2	E60	1.31	1	1.27	1.66	DCV
TP1	E61	4	4.1	4	3.8	DCV
MAP	E62	4.2/14.21 (W)	1.24/4.49 (W)	1.27/4.49 (W)	2/7.25 (W)	DCV/PSI
OSS (A/T)	T14	0	0	500-524/ 1250-1310	960-1020/ 2400-2550	Hz/RPM
OSS (M/T)	T14	0	0	1133	2151	RPM
TSS (A/T)	T15	0	320-360/ 630-670	500-713/ 1100-1300	845-985/ 1700-1800	Hz/RPM
TR1 (A/T)	T17	0	0	11.5	11.5	DCV
TR2 (A/T)	T18	0	0	11.5	11.5	DCV
TR3 V/TR (A/T)	T19	0/PARK	0/PARK	1.7/OD	1.7/OD	DCV/MODE
TFT (A/T)	T20	0.5-2/210-110 (K)	0.5-2/210-110 (K)	0.5-2/210-110 (K)	0.5-2/210-110 (K)	DCV/DEG
HO2S22	T21	0.1	(D)	(D)	(D)	DCV
HO2S12	T22	(L)	(D)	(D)	(D)	DCV
TR4 (A/T)	T32	0	0	11.5	11.5	DCV
APP	PID	0	0	1.5	8	%
CPP/PNP	PID	ON	ON	OFF	OFF	ON/OFF
FLI	PID	98.2 (H)	98.2 (H)	100 (H)	100 (H)	%
GEAR (A/T)	PID	1	1	3	4	GEAR
VSS	PID	0	0	30	55	MPH
LOAD	PID	61.89 (L)	15.38	23.54	28.42	%
MISFIRE	PID	NO	NO	OFF	OFF	ON/OFF
RPM	PID	0	1018	1138	1721	RPM

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
WAC/ACCR	B18	VBAT/OFF	0.1/ON (A)	VBAT/OFF	VBAT/OFF	DCV/ON-OFF
GENCMD	B22	3.79	0 (Q)	0 (Q)	0 (Q)	%
PATSTRT/SMC	B34	0	0	0	0	DCV
PAT IL	B35	0	0	0	0	DCV
PATS OUT	B36	10.5	VBAT (A)	VBAT	VBAT	DCV
EVAPCV	B61	VBAT/OFF	VBAT/OFF	VBAT/OFF (R)	VBAT/OFF (R)	DCV/ON-OFF
FP	B62	VBAT/OFF	0.1/ON	0.1/ON	0.1/ON	DCV/ON-OFF
VSO	B63	0	0	55	125	Hz
PCVHC	E3	0	0	100	100	%
CDB (CYL 3 and 4)	E12	VBAT	VBAT	VBAT	VBAT	DCV
CDC (CYL 2 and 6)	E16	VBAT	VBAT	VBAT	VBAT	DCV
CDA (CYL 1 and 5)	E17	VBAT	VBAT	VBAT	VBAT	DCV
TACM (+)	E34	3.7	VBAT	VBAT	VBAT	DCV
IMRC	E50	VBAT/OFF	VBAT/OFF	VBAT/OFF	0/ON	DCV/ON-OFF
TACM (-)	E51	3.7	VBAT	VBAT	VBAT	DCV
EGRVR	E63	0	0	(T)	48.43 (T)	%
EVAPPDC	E65	0	0-10/0-100	0-10/0-100	0-10/0-100	Hz/%
HTR11	E69	0.1/ON (O)	0.1/ON	0.1/ON	0.1/ON	DCV/ON-OFF
HTR21	E70	0.1/ON (O)	0.1/ON	0.1/ON	0.1/ON	DCV/ON-OFF
HTR12	T1	0.2/ON (O)	0.2/ON	0.2/ON	0.2/ON	DCV/ON-OFF
HTR22	T12	0.2/ON (O)	0.2/ON	0.2/ON	0.2/ON	DCV/ON-OFF
TCC (A/T)	T36	0.2/100	VBAT/0	0.2-VBAT/ 0-100	0.2/90-100	DCV/%
SSB (SS2) (A/T)	T37	VBAT/OFF	VBAT/OFF	0.1/ON	0.1/ON	DCV/ON-OFF
SSA (SS1) (A/T)	T38	0.1/ON	0.1/ON	VBAT/OFF	0.1/ON	DCV/ON-OFF
EPC (A/T)	T39	7.7/15-20	8.8-10.2/15-20	10.3-10.6/ 35-40	10.6/45	DCV/PSI
CHTFM	PID	NO FAULT	NO FAULT	NO FAULT	NO FAULT	FAULT/NO FAULT
LONGFT1	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
LONGFT2	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
OTS_STAT (A/T)	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/ DISABLED
SHRTFT1	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SHRTFT2	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SPARKADV	PID	0.5	19.25	14.5	37.75	DEG

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
ETCVREF	B21/B28/E66	5	5	5	5	DCV
BVREF	B29/E57	5	5	5	5	DCV
VPWR	B51/52/53	VBAT	VBAT	VBAT	VBAT	DCV
KAPWR	B54	VBAT	VBAT	VBAT	VBAT	DCV

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
ACCS	B19	OFF	ON (A)	OFF	OFF	ON/OFF
GENMON	B23	0	28.13	21.88	20.31	%
APP1	B25	4.0	4.0	3.9	3.7	DCV
APP2	B26	1.5	1.5	1.6	1.75	DCV
APP3	B27	1	1	1	1.2	DCV
4WDMCS	B32	8.8 (2HIGH)	9.6 (4LOW)	6.6 (4HIGH)	9.5 (2HIGH)	DCV
FTP	B44	2.59/0	2.53/-0.02	2.58/0	2.56/-0.01	DCV/PSI
TCS	B45	NOT DEPRESSED	DEPRESSED (G)	NOT DEPRESSED	NOT DEPRESSED	DEPRESSED- NOT DEPRESSED
BPP/BOO	B46	OFF	ON (E)	OFF	OFF	ON/OFF
DPFEGR	E21	0.25-1.3	0.25-1.3	0.25-4.65	0.25-4.65	DCV
IAT	E22	1.69/122 (K)	1.77/118(K)	3.07/68 (K)	3.08/68 (K)	DCV/DEG F
PSP	E24	4.99/1499.3	4.99/1499.3	4.99/1499.3	4.99/1499.3	DCV/PSI
MAF	E25	0	0.64	1.47	1.5	DCV
O2S21	E28	(L)	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
O2S11	E29	(L)	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
FRP	E32	3.59/55	2.8/40	2.8/40	2.8/40	DCV/PSI
CHT	E41	0.6/194	0.6/194	0.61/192	0.61/192	DCV/DEG F
KNOCK 1	E49	24290	20470	27570	55580	N/A
TP2	E60	1.29/25.49	0.89/17.65	1.39/27.45	1.53/30.59	DCV
TP1	E61	4.1/17.65	4.31/13.33	4.06/18.43	3.98/20	DCV
MAP	E62	4.34/14.64 (W)	1.24/4.49 (W)	2.13/7.54 (W)	2.19/7.68 (W)	DCV/PSI
OSS	T14	0	0	1220	2361	RPM
TSS	T15	0	649	863	1637	RPM
TR2	T18	CLOSED	CLOSED	OPEN	OPEN	OPEN/ CLOSED
TFT	T20	0.98/165.2 (K)	0.88/172.4 (K)	1.21/153 (K)	1.13/158 (K)	DCV/DEG F
O2S22	T21	(L)	Switching (D)	Switching (D)	Switching (D)	DCV
O2S12	T22	(L)	Switching (D)	Switching (D)	Switching (D)	DCV
APP	PID	0	0	2	10.5	%
BARO	PID	14.48/157.4	14.48/157.4	14.48/157.4	14.48/157.4	PSI/HZ
B+	PID	VBAT	VBAT	VBAT	VBAT	DCV
DECHOKE	PID	YES	NO	NO	NO	YES/NO
ETC_ACT	PID	7.37	2.25	5.06	11.02	DEG
ETC_DSD	PID	7.62	2.19	5.08	11.06	DEG
ETC_TRIM	PID	0.23	0.23	0.22	0.22	DEG
GEAR	PID	1	1	4	4	GEAR
LOAD	PID	65.78 (L)	15.83	15.55	27.35	%
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
O2BANK2	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	655	975	1650	RPM
TR	PID	P	P	OD	OD	MODE

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
WAC/ACCR	B18	OFF	ON (A)	OFF	OFF	ON/OFF
GENCMD	B22	3.79	0 (Q)	0 (Q)	0 (Q)	%
EVMV	B50	0/OFF	405/ VARYING	356/ VARYING	405/ VARYING	MA/OFF- VARYING
EVAPCV	B61	0/OFF	0/OFF	0/OFF	0/OFF	%/ON-OFF
FP	B62	75/OFF	19.66/ON	22.02/ON	20.34/ON	%/ON-OFF
SPKDUR_8	E9	0	1.65	1.68	1.03	Ms
SPKDUR_5	E10	0	1.5	1.37	1.15	Ms
SPKDUR_2	E11	0	1.71	1.43	1.31	Ms
SPKDUR_3	E12	0	1.37	1.56	1.31	Ms
SPKDUR_4	E14	0	1.75	1.37	1.09	Ms
SPKDUR_6	E15	0	1.75	1.43	1.25	Ms
SPKDUR_7	E16	0	1.75	1.59	0.906	Ms
SPKDUR_1	E17	0	1.68	1.12	1.25	Ms
EGRVR	E63	0	0	36.25 (T)	77.8 (T)	%
HTR11	E69	OFF (O)	ON	ON	ON	ON/OFF
HTR21	E70	OFF (O)	ON	ON	ON	ON/OFF
HTR12	T1	OFF (O)	ON	ON	ON	ON/OFF
HTR22	T12	OFF (O)	ON	ON	ON	ON/OFF
TCC	T36	0/OFF	0/OFF	0/OFF	100/ ENGAGED	%/OFF- ENGAGED
4WDC	T49	0.5	0.2	0.2	0.2	DCV
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/ DISALLOW
EVAP020R	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EVAPSOAK	PID	YES	YES	NO	NO	YES/NO
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/ CLOSED LOOP
LONGFT1	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
LONGFT2	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
OTS_STAT (A/T)	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/ DISABLED
SHRTFT1	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SHRTFT2	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SPARKADV	PID	10	0.5	28	35.75	DEG

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
BVREF	B29/E57	5	5	5	5	DCV
VPWR	B51/52/53	VBAT	VBAT	VBAT	VBAT	DCV

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
ACCS	B19	OFF	ON (A)	OFF	OFF	ON/OFF
GENMON	B23	0	34.36	21.88	20.31	%
APP1	B25	4.0	4.0	3.7	3.6	DCV
APP2	B26	1.5	1.5	1.7	1.8	DCV
APP3	B27	0.9	0.9	1.16	1.22	DCV
4WDMCS	B32	9.5 (2HIGH)	4.5 (4LOW)	6.6 (4HIGH)	9.5 (2HIGH)	DCV
FTP	B44	2.6/-0.01	2.6/-0.01	2.3/-0.09	2.7/-0.09	DCV/PSI
TCS	B45	NOT DEPRESSED	DEPRESSED (G)	NOT DEPRESSED	NOT DEPRESSED	DEPRESSED/ NOT DEPRESSED
BPP/BOO	B46	OFF	ON (E)	OFF	OFF	ON/OFF
BPA	B47	OFF	ON (E)	OFF	OFF	ON/OFF
FRT	E19	2.7/86 (K)	2.7/86 (K)	3.5/57 (K)	3.5/61 (K)	DCV/DEG F
IAT	E22	1.6/126 (K)	1.7/120 (K)	3.6/48 (K)	3.6/46 (K)	DCV/DEG F
PSP	E24	4.99/1499.3	4.99/1499.3	4.99/1499.3	4.99/1499.3	DCV/PSI
MAF	E25	0	0.72	1.25	1.75	DCV
O2S21	E28	(L)	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
O2S11	E29	(L)	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
KNOCK 2	E31	65.54k	170	183	234	N/A
FRP	E32	2.9/41.4	2.7/38.6	2.7/39	2.7/39.3	DCV/PSI
CHT	E41	3.6/201	3.5/204	3.5/201	3.5/207	DCV/DEG F
KNOCK 1	E49	175	178	205	254	N/A
TP2	E60	1.31/26.28	0.83/16.47	1.21/23.92	1.61/32.16	DCV/%
TP1	E61	4.08/18.04	4.32/13.33	4.14/17.65	3.93/21.18	DCV/%
HTRCM11	E69	516	516	516	516	MA
HTRCM21	E70	539	539	539	539	MA
HTRCM12	T1	500	500	500	500	MA
4WDP1 (ESOF)	T6	VBAT	VBAT	VBAT	VBAT	DCV
4WDP2 (ESOF)	T7	VBAT	VBAT	VBAT	VBAT	DCV
4WDMP1 (MSOF)	T7	0	0	0	0	DCV
4WDP3 (ESOF)	T8	VBAT	VBAT	VBAT	VBAT	DCV
4WDMP2 (MSOF)	T8	0	0	0	0	DCV
4WDP4 (ESOF)	T9	VBAT	VBAT	VBAT	VBAT	DCV
HTRCM22	T1	520	520	520	520	MA
OSS	T14	0	0	1162	2150	RPM
TSS	T15	0	724	823	1514	RPM
TCSS/VSS	T16	0	0	0	0	MPH
TR2	T18	CLOSED	CLOSED	OPEN	OPEN	OPEN/ CLOSED
TFT	T20	1.86/118 (K)	1.87/118 (K)	1.41/142 (K)	1.38/144 (K)	DCV/DEG F
O2S22	T21	(L)	Switching (D)	Switching (D)	Switching (D)	DCV
O2S12	T22	(L)	Switching (D)	Switching (D)	Switching (D)	DCV
APP	PID	0	0	9	16.5	%
BARO	PID	14.67/158.5	14.67/158.5	14.67/158.5	14.67/158.5	PSI/HZ
B+	PID	VBAT	VBAT	VBAT	VBAT	DCV
DECHOKE	PID	YES	NO	NO	NO	YES/NO
ETC_ACT	PID	7.62	1.02	3.5	8.06	DEG
ETC_DSD	PID	7.62	0.96	3.62	8.09	DEG
ETC_TRIM	PID	0.43	0.43	0.43	0.43	DEG
GEAR	PID	1	1	4	4	GEAR
LOAD	PID	62 (L)	14.5	21.4	32	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
O2BANK2	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	655	1230	1500	RPM
TR	PID	P	P	OD	OD	MODE
VSS	PID	0	0	30	55	MPH

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
WAC/ACCR	B18	OFF	ON (A)	OFF	OFF	ON/OFF
GENCMD	B22	6.08	0 (Q)	0 (Q)	0 (Q)	%
EVAPCV	B61	0/OFF	0/OFF	0 (R)/OFF	0 (R)/OFF	%/ON-OFF
FP	B62	75/OFF	18.81/ON	19.45/ON	21.39/ON	DCV/%
4WDMCS	B32	9.5 (2HIGH)	4.5 (4LOW)	6.6 (4HIGH)	9.5 (2HIGH)	DCV
EVMV	C50	0/OFF	0/OFF	472 (F)/VARIES	760 (F)/VARIES	MA/OFF- VARIES
SPKDUR_8	E9	0	1.75	1.62	0.688	Ms
SPKDUR_5	E10	0	1.84	1.59	0.688	Ms
SPKDUR_2	E11	0	1.68	1.12	0.750	Ms
SPKDUR_3	E12	0	1.68	1.37	0.750	Ms
SPKDUR_4	E14	0	1.81	1.25	0.688	Ms
SPKDUR_6	E15	0	1.84	1.71	0.938	Ms
SPKDUR_7	E16	0	1.75	1.18	0.688	Ms
SPKDUR_1	E17	0	1.75	1	0.906	Ms
IMRC	E50	OFF	OFF	OFF	OFF	ON/OFF
VCTDC	E67	0	0	46.88	43.95	%
VCTDC2	E68	0	0	45.88	44.25	%
HTR11	E69	OFF (O)	ON	ON	ON	ON/OFF
HTR21	E70	OFF (O)	ON	ON	ON	ON/OFF
HTR12	T1	OFF (O)	ON	ON	ON	ON/OFF
HTR22	T12	OFF (O)	ON	ON	ON	ON/OFF
TCC	T36	0/OFF	0/OFF	0/OFF	100/ ENGAGED	%/OFF- ENGAGED
4WDC (ESOF)	T49	0.5	0.2	0.2	0.2	DCV
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/ DISALLOW
EVAP020R	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/ NOT READY
EVAPSOAK	PID	NO	NO	NO	NO	YES/NO
EVAP_EVAL	PID	YES	YES	YES	YES	YES/NO
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/ CLOSED LOOP
LONGFT1	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
LONGFT2	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
OTS_STAT (A/T)	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/ DISABLED
SHRTFT1	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SHRTFT2	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SPARKADV	PID	10	15.75	34	35.75	DEG
VCTADV	PID	0	0.62	50.69	49.56	DEG
VCTADV2	PID	0	0.5	50.75	50.38	DEG
VCTADVERR	PID	0	0.62	0.68	1.25	DEG
VCTADVERR2	PID	0	0.5	1.68	0.5	DEG

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VREF	B29/E57	5	5	5	5	DCV
VPWR	B51/52/53	VBAT	VBAT	VBAT	VBAT	DCV

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FTP	B3	2.6/0	2.6/0	2.6/0	2.6/0	DCV/PSI
APP1	B5	4.1	4.1	3.8	3.6	DCV
BPP/BOO	B8	OFF	ON (E)	OFF	OFF	ON/OFF
APP2	B17	1.64	1.7	1.7	1.9	DCV
TCS	B27	NOT DEPRESSED	DEPRESSED (G)	NOT DEPRESSED	NOT DEPRESSED	DEPRESSED/ NOT DEPRESSED
APP3	B28	1	1	1.2	1.3	DCV
ACCS	E4	OFF	ON (A)	OFF	OFF	ON/OFF
FRT	E19	2.02/109.4	2/111.2	2.45/96.8	2.5/93.2	DCV/DEG F
DPFEGR	E21	0.25-1.3	0.25-1.3	0.25-4.65	0.25-4.65	DCV
IAT	E22	2.9/75 (K)	3.1/66 (K)	3.6/50 (K)	3.6/50 (K)	DCV/DEG F
MAF	E25	0	0.78	.8	1.5	DCV
O2S11	E28	(L)	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
O2S21	E29	0	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
FRP	E32	3.2/47	2.8/40	2.8/40	2.8/40	DCV/PSI
CHT	E41	0.6/190	0.64/190	0.61/192	0.61/192	DCV/DEG F
KNOCK 1	E49	4095	56	87	116	N/A
TP2	E60	1.25/24.71	0.9/18.04	1.1/21.96	1.54/29.8	DCV/%
TP1	E61	4.08/18.04	4.26/14.51	4.16/16.47	3.94/20.78	DCV/%
MAP	E62	4.3/14.5 (W)	1.2/4.35 (W)	1.3/4.78 (W)	2.7/9.13 (W)	DCV/PSI
BPA	E65	OFF	ON (E)	OFF	OFF	ON/OFF
HTRCM11	E69	1.49	1.49	1.49	1.49	AMPS
HTRCM21	E70	1.57	1.57	1.57	1.57	AMPS
OSS_SRC	T3	0	0	1207	2298	RPM
TSS	T15	0	744	866	1610	RPM
TR	T16	P	P	OD	OD	MODE
TR2	T17	CLOSED	CLOSED	OPEN	OPEN	OPEN/ CLOSED
O2S12	T24	(L)	(D)	(D)	(D)	DCV
O2S22	T25	0.1	(D)	(D)	(D)	DCV
TFT	T29	2.3/102 (K)	2.6/93 (K)	1.7/124 (K)	1.65/129 (K)	DCV/DEG F
HTRCM12	T47	961	961	961	961	MA
HTRCM22	T48	945	945	945	945	MA
APP	PID	0	0	5.5	13.5	%
BARO	PID	14.36/156.6	14.36/156.6	14.36/156.6	14.36/156.6	PSI/HZ
B+	PID	VBAT	VBAT	VBAT	VBAT	DCV
CPP/PNP	PID	NEUTRAL	NEUTRAL	DRIVE	DRIVE	NEUTRAL/ DRIVE
DECHOKE	PID	YES	NO	NO	NO	YES/NO
ETC_ACT	PID	7.75	2.87	5.18	10.92	DEG
ETC_DSD	PID	7.62	2.51	5.15	10.92	DEG
ETC_TRIM	PID	0.23	0.23	0.23	0.23	DEG
FLI	PID	50 (H)	50 (H)	50 (H)	50 (H)	%
GEAR	PID	1	1	4	4	GEAR
LOAD	PID	59 (L)	18	16	28	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
O2BANK2	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	728	1315	1597	RPM
VSS	PID	0	0	30	55	MPH

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VSO	B1	0	0	65	125	Hz
FP	B12	75/OFF	20/ON	21/ON	22/ON	%/ON-OFF
EVAPCV	B13	0/OFF	0/OFF	0/OFF (R)	0/OFF (R)	%/ON-OFF
EVMV	E1	0/OFF	0/OFF	0/OFF	20/VARYING	MA/OFF- VARYING
PCVHC	E2	0	0	0	0	%
WAC/ACCR	E3	OFF	ON (A)	OFF	OFF	ON/OFF
EGRVR	E63	0	0	33 (T)	53 (T)	%
HTR11	E69	ON (O)	ON	ON	ON	ON/OFF
HTR21	E70	ON (O)	ON	ON	ON	ON/OFF
TCC	T46	0/OFF	0/OFF	0/OFF	100/ ENGAGED	%/OFF- ENGAGED
HTR12	T47	ON (O)	ON	ON	ON	ON/OFF
HTR22	T48	ON (O)	ON	ON	ON	ON/OFF
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/ DISALLOW
EVAP020R	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EVAPSOAK	PID	YES	YES	YES	YES	YES/NO
EVAP_EVAL	PID	YES	YES	YES	YES	YES/NO
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/ CLOSED LOOP
LONGFT1	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
LONGFT2	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/ DISABLED
SHRTFT1	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SHRTFT2	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SPARKADV	PID	10	11.75	27.5	41	DEG

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B35/36	VBAT	VBAT	VBAT	VBAT	DCV
VREF	B40/E57	5	5	5	5	DCV

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FTP	B3	2.6/0 (M)	2.6/0 (M)	2.1/-0.13 (M)	2.6/-0.24 (M)	DCV/PSI
APP1	B5	4.1	4	3.9	3.7	DCV
PTOIR V (5R110W)	B7	VBAT	VBAT	VBAT	VBAT	DCV
BPP/BOO	B8	OFF	ON (E)	OFF	OFF	ON/OFF
APP2	B17	1.4	1.4	1.6	1.8	DCV
PTO (5R110W)	B26	OFF	OFF	OFF	OFF	ON/OFF
TCS	B27	NOT DEPRESSED	DEPRESSED (G)	NOT DEPRESSED	NOT DEPRESSED	DEPRESSED/ NOT DEPRESSED
APP3	B28	1	0.9	1	3.7	DCV
ACCS	E4	OFF	ON (A)	OFF	OFF	ON/OFF
FRT	E19	3.4/62 (K)	3.4/64 (K)	3.2/68 (K)	3.3/66 (K)	DCV/DEG F
IAT	E22	3.5/52 (K)	3.6/48 (K)	4/27 (K)	4/23 (K)	DCV/DEG F
MAF	E25	0	0.71	1	1.7	DCV
O2S11	E28	(L)	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
O2S21	E29	0	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
FRP	E32	3.5/52	2.8/40	2.8/40	2.7/39	DCV/PSI
CHT	E41	0.61/192	0.67/187	3.7/195	3.6/197	DCV/DEG F
KNOCK 1	E49	4.09k	54	62	110	N/A
TP2	E60	1.23/24.31	0.79/15.69	1.12/22.35	1.33/26.28	DCV/%
TP1	E61	4.06/18.43	4.28/14.12	4.12/17.26	4.01/19.61	DCV/%
BPA	E65	OFF	ON (E)	OFF	OFF	ON/OFF
HTRCM11	E69	1.53	1.53	1.53	1.53	AMPS
HTRCM21	E70	1.57	1.57	1.57	1.57	AMPS
OSS_SRC	T3	0	0	1157	2264	RPM
TSS	T15	0	931	831	1600	RPM
TR2 (4R75E)	T17	CLOSED	CLOSED	OPEN	OPEN	OPEN/ CLOSED
TR-P (5R110W)	T19	P	P	OD	OD	MODE
O2S12	T24	(L) (M)	(D) (M)	(D) (M)	(D) (M)	DCV
O2S22	T25	0 (M)	(D) (M)	(D) (M)	(D) (M)	DCV
TFT	T29	2.9/82 (K)	3/77 (K)	2.3/100 (K)	2.2/104 (K)	DCV/DEG F
HTRCM12	T47	898	898	898	898	MA
HTRCM22	T48	906	906	906	906	MA
APP	PID	0	0	14.5	16	%
BARO	PID	14.48/157.4	14.48/157.4	14.48/157.4	14.48/157.4	PSI/HZ
B+	PID	VBAT	VBAT	VBAT	VBAT	DCV
CPP/PNP	PID	NEUTRAL	NEUTRAL	DRIVE	DRIVE	NEUTRAL/ DRIVE
DECHOKE	PID	YES	NO	NO	NO	YES/NO
ETC_ACT	PID	7.47	2.1	12.19	12.48	DEG
ETC_DSD	PID	7.62	2.06	12.29	12.61	DEG
ETC_TRIM	PID	0.33	0.35	0.3	0.3	DEG
FLI	PID	40 (H)	41(H)	43 (H)	48 (H)	%
GEAR (4R75E)	PID	1	1	4	4	GEAR
GEAR (5R110W)	PID	1	1	5	6	GEAR
LOAD	PID	71 (L)	15	18	32	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
O2BANK2	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	720	1100	1600	RPM
TR (4R75E)	PID	P	P	OD	OD	MODE
VSS	PID	0	0	30	55	MPH

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B12	75/OFF	20/ON	20/ON	23/ON	%/ON-OFF
EVAPCV	B13	0/OFF	0/OFF	0/OFF	0/OFF	%/ON-OFF
EVMV	E1	0/OFF	0/OFF	626/ VARYING	839/ VARYING	MA/OFF- VARYING
WAC/ACCR	E3	OFF	ON (A)	OFF	OFF	ON/OFF
HTR11	E69	ON (O)	ON	ON	ON	ON/OFF
HTR21	E70	ON (O)	ON	ON	ON	ON/OFF
TCC (4R75E)	T46	0/OFF	0/OFF	0/OFF	39.29/ ENGAGED	%/OFF- ENGAGED
HTR12	T47	ON (M) (O)	ON (M)	ON (M)	ON (M)	ON/OFF
HTR22	T48	ON (M) (O)	ON (M)	ON (M)	ON (M)	ON/OFF
TSPC (5R110W)	T49	VBAT	VBAT	VBAT	VBAT	DCV
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/ DISALLOW
EVAP020R	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EVAPSOAK	PID	NO	NO	NO	NO	YES/NO
EVAP_EVAL	PID	YES	YES	YES	YES	YES/NO
LONGFT1	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
LONGFT2	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/ DISABLED
SHRTFT1	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SHRTFT2	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SPARKADV	PID	10	8.75	27	29.75	DEG

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B35/36	VBAT	VBAT	VBAT	VBAT	DCV
VREF	E57	5	5	5	5	DCV

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FTP	B3	2.6/0 (M)	2.6/0 (M)	2.6/0 (M)	1.4/-0.3 (M)	DCV/PSI
APP1	B5	4	4	3.8	3.7	DCV
PTOIR V	B7	0.0	0.0	0.0	0.0	DCV
BOO	B8	OFF	ON (E)	OFF	OFF	ON/OFF
PTOLOAD	B9	NO	NO	NO	NO	YES/NO
O2S13	B14	0 (M)	Switching (C) (M)	Switching (C) (M)	Switching (C) (M)	DCV
APP2	B17	1.4	1.4	1.7	1.7	DCV
PTO	B26	OFF	OFF	OFF	OFF	ON/OFF
TCS	B27	NOT DEPRESSED	DEPRESSED (G)	NOT DEPRESSED	NOT DEPRESSED	DEPRESSED/ NOT DEPRESSED
APP3	B28	0.9	0.9	1.2	1.2	DCV
ACCS	E4	OFF	ON (A)	OFF	OFF	ON/OFF
FRT	E19	2.6/90 (K)	3.2/ 70 (K)	3.1/72 (K)	3.2/70 (K)	DCV/DEG F
IAT	E22	2.74/81 (K)	2.9/73 (K)	4/27 (K)	3.9/30 (K)	DCV/DEG F
MAF	E25	0	1	1.3	1.8	DCV
O2S11	E28	(L)	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
O2S21	E29	0	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
FRP	E32	3.3/49	4.2/65	4.2/65	4.2/65	DCV/PSI
CHT	E41	0.7/188	0.6/187	0.7/188	0.6/188	DCV/DEG F
TP2	E60	1.16/23.14	0.69/13.73	1.16/23.14	1.1/21.96	DCV/%
TP1	E61	4.09/18.04	4.32/13.33	4.09/18.04	4.12/17.26	DCV/%
BPA	E65	OFF	ON (E)	OFF	OFF	ON/OFF
HTRCM11	E69	1.59	1.59	1.59	1.59	AMPS
HTRCM21	E70	1.54	1.54	1.54	1.54	AMPS
OSS	T3	0	0	1317	2503	RPM
TSS	T15	0	769	894	1761	RPM
O2S12	T24	(L) (M)	(D) (M)	(D) (M)	(D) (M)	DCV
O2S22	T25	0 (M)	(D) (M)	(D) (M)	(D) (M)	DCV
TFT	T29	1.5/135 (K)	1.5/136 (K)	1.2/154 (K)	1.2/156 (K)	DCV/DEG F
HTRCM12	T47	969	969	969	969	MA
HTRCM22	T48	957	957	957	957	MA
APP	PID	0	0	5.5	12.5	%
BARO	PID	14.92/160	14.92/160	14.92/160	14.92/160	PSI/HZ
B+	PID	VBAT	VBAT	VBAT	VBAT	DCV
DECHOKE	PID	YES	NO	NO	NO	YES/NO
ETC_ACT	PID	7.54	1.62	4.85	8.47	DEG
ETC_DSD	PID	8	1.6	4.84	8.51	DEG
ETC_TRIM	PID	0.22	0.22	0.22	0.22	DEG
GEAR	PID	1	1	6	6	GEAR
LOAD	PID	40 (L)	40	20	27	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
O2BANK2	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
RPM	PID	0	670	1026	1828	RPM
VSS	PID	0	0	30	55	MPH

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B12	75/OFF	26/ON	26/ON	27/ON	%/ON-OFF
EVAPCV	B13	0/OFF (M)	0/OFF (M)	0/OFF (M) (R)	0/OFF (M) (R)	%/ON-OFF
HTR13	B38	ON (M) (O)	ON (M)	ON (M)	ON (M)	ON/OFF
PTOIL	B42	OFF	OFF	OFF	OFF	ON/OFF
TCIL	B43	OFF	OFF	OFF	OFF	ON/OFF
EVMV	E1	0/OFF	0/OFF	697/ VARYING	758/ VARYING	MA/OFF- VARYING
PCVHC	E2	0	0	0	0	%
WAC/ACCR	E3	OFF	ON	OFF	OFF	ON/OFF
HTR11	E69	ON (O)	ON	ON	ON	ON/OFF
HTR21	E70	ON (O)	ON	ON	ON	ON/OFF
HTR12	T47	ON (M) (O)	ON (M)	ON (M)	ON (M)	ON/OFF
HTR22	T48	ON (M) (O)	ON (M)	ON (M)	ON (M)	ON/OFF
CHTIL	PID	OFF	OFF	OFF	OFF	ON/OFF
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/ DISALLOW
EVAP020R	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EVAPSOAK	PID	NO	NO	NO	NO	YES/NO
EVAP_EVAL	PID	NO	NO	NO	NO	YES/NO
LONGFT1	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
LONGFT2	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
SHRTFT1	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SHRTFT2	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SPARKADV	PID	10	13.5	33.5	26-34	DEG

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VPWR	B35/36	VBAT	VBAT	VBAT	VBAT	DCV
VREF	E57	5	5	5	5	DCV

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
GENMON	B23	0	25.78	22.66	4.68	%
APP1	B25	4.0	4.0	3.7	3.4	DCV
APP2	B26	1.5	1.5	1.7	2.0	DCV
APP3	B27	0.9	0.9	1.1	1.4	DCV
O2S12	B39	(L)	(D)	(D)	(D)	DCV
O2S22	B40	(L)	(D)	(D)	(D)	DCV
MAF	B41	0	0.77	1.56	1.75	DCV
IAT	B43	2.43/93.2 (K)	2.72/82.4 (K)	3.85/33.8 (K)	3.85/33.8 (K)	DCV/DEG F
FTP	B44	2.6/0	2.6/0	2.6/0	2.6/0	DCV/PSI
FTP_H2O	B44	0	0	0.24	1.86	In-Hg
BOO	B46	OFF	OFF	OFF	OFF	ON/OFF
BPA	B47	OFF	OFF	OFF	OFF	ON/OFF
O2S21	E28	(L)	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
O2S11	E29	(L)	Switching (C)	Switching (C)	Switching (C)	DCV/ RICH-LEAN
KNOCK 2	E31	0	283	322	396	N/A
CHT	E41	0.57/196	0.56/198	3.63/194	3.5/204	DCV/DEG F
KNOCK 1	E49	0	174	323	413	N/A
TP2	E60	25.1/1.26	14.9/0.74	18.82/0.92	26.7/1.34	%/DCV
TP1	E61	18/4	12.9/4.3	14.9/4.2	22/3.9	%/DCV
ACCS	PID	OFF	OFF	OFF	OFF	ON/OFF
APP	PID	0	0	11	15	%
B+	PID	VBAT	VBAT	VBAT	VBAT	DCV
BARO	PID	160.4/14.97	160.4/14.97	160.4/14.97	160.4/14.97	Hz/PSI
CPP/PNP	PID	NEUTRAL	NEUTRAL	DRIVE	DRIVE	NEUTRAL/ DRIVE
DECHOKE	PID	YES	NO	NO	NO	YES/NO
ETC_ACT	PID	7.56	1.39	6.65	7.75	DEG
ETC_DSD	PID	7.62	1.34	5.65	7.66	DEG
FCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
FLI	PID	50 (H)	50 (H)	50 (H)	50 (H)	%
GEAR	PID	1	1	5	6	GEAR
LOAD	PID	61.9 (L)	14.3	20.5	38.2	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
O2BANK1	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
O2BANK2	PID	VARIES	VARIES	VARIES	VARIES	RICH/LEAN
TCS	PID	NOT DEPRESSED	NOT DEPRESSED	NOT DEPRESSED	NOT DEPRESSED	DEPRESSED/ NOT DEPRESSED
RPM	PID	0	695	1516	1497	RPM
VSS	PID	0	0	30	55	MPH

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
HTR12	B10	OFF	ON	ON	ON	ON/OFF
HTRCM12	B10	895	895	895	895	MA
HTR22	B11	OFF	ON	ON	ON	ON/OFF
HTRCM22	B11	887	887	887	887	MA
WAC/ACCR	B18	OFF	OFF	OFF	OFF	ON/OFF
GENCMD	B22	6.08	57.54 (Q)	57.67 (Q)	57.65 (Q)	%
PTO	B26	OFF	OFF	OFF	OFF	ON/OFF
EVMV	B50	0/OFF	0/OFF	192/ VARYING	633/ VARYING	MA/OFF- VARYING
EVAPCV	B61	0/OFF	0/OFF	0/OFF	0/OFF	%/ON-OFF
FP	B62	0/OFF	100/ON	100/ON	100/ON	%/ON-OFF
IMRC	E50	OFF	OFF	OFF	OFF	ON/OFF
HTR11	E69	OFF	ON	ON	ON	ON/OFF
HTRCM11	E69	512	512	512	512	MA
HTR21	E70	OFF	ON	ON	ON	ON/OFF
HTRCM21	E70	527	527	527	527	MA
CHT_F	PID	NO FAULT	NO FAULT	NO FAULT	NO FAULT	FAULT/NO FAULT
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/ DISALLOW
EVAPSOAK	PID	NO	NO	YES	YES	YES/NO
EVAPSTA	PID	NOT RUNNING	NOT RUNNING	NOT RUNNING	NOT RUNNING	STATUS
EVAP_EVAL	PID	YES	YES	YES	YES	YES/NO
FUELSYS	PID	OPEN LOOP	CLOSED LOOP	CLOSED LOOP	CLOSED LOOP	OPEN/ CLOSED LOOP
LONGFT1	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
LONGFT2	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
PATSENABL	PID	ENABLED	ENABLED	ENABLED	ENABLED	ENABLED/ DISABLED
SHRTFT1	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SHRTFT2	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SPARKADV	PID	10	14.8	34	36	DEG
TCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
VCTADV	PID	0	0.31	35	56.56	DEG
VCTADV2	PID	0	0.62	32.63	55.94	DEG
VCTADVERR	PID	0	0.31	1.31	1.56	DEG
VCTADVERR2	PID	0	0.62	0.06	0.95	DEG
VCTDC	PID	0	0	39.69	38.85	%
VCTDC2	PID	0	0	41.39	40.34	%

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VREF	E57	5	5	5	5	DCV
VPWR	B51/52/53	VBAT	VBAT	VBAT	VBAT	DCV

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
SMC_MON	B2	OFF	OFF	OFF	OFF	ON/OFF
FTP	B3	2.6/0 (M)	2.6/0 (M)	2.3/-0.07 (M)	2.1/-0.13 (M)	DCV/PSI
FTP_H2O	B3	2.6/0 (M)	2.6/0 (M)	2.3/-0.07 (M)	2.1/-0.13 (M)	DCV/PSI
APP1	B5	4.1	4.1	3.9	3.4	DCV
PTOIR_V	B7	VBAT	VBAT	VBAT	VBAT	DCV
BOO	B8	VBAT/OFF	0.1/ON (E)	VBAT/OFF	VBAT/OFF	DCV/ON-OFF
APP2	B17	1.5	1.5	1.8	2.0	DCV
FPM	B21	0.1-VBAT	0.1-VBAT	0.1-VBAT	0.1-VBAT	DCV
PTO	B26	OFF	OFF	OFF	OFF	ON/OFF
TCS (A/T)	B27	0.1/NOT DEPRESSED	VBAT/ DEPRESSED (G)	0.1/NOT DEPRESSED	0.1/NOT DEPRESSED	DCV/ DEPRESSED- NOT DEPRESSED
APP3	B28	0.9	0.9	1.20	1.4	DCV
TCSS/VSS	B29	0	0	30	55	MPH
CPP/PNP (M/T)	B34	NEUTRAL	NEUTRAL	DRIVE	DRIVE	NEUTRAL/ DRIVE
BPA	B65	OFF	OFF	OFF	OFF	ON/OFF
WAC/ACCR	E3	OFF	OFF	OFF	OFF	ON/OFF
ACCS	E4	OFF	OFF	OFF	OFF	ON/OFF
SPKDUR_8	E9	0	1.7	1.3	1.1	Ms
SPKDUR_5	E10	0	1.1	1.1	1.2	Ms
SPKDUR_2	E11	0	1.6	1.5	1.3	Ms
SPKDUR_3	E12	0	1.8	1.2	1.2	Ms
SPKDUR_4	E14	0	1.6	1.4	1.6	Ms
SPKDUR_6	E15	0	1.7	1.1	1.2	Ms
SPKDUR_7	E16	0	1.7	1.2	1.0	Ms
SPKDUR_1	E17	0	1.6	1.3	1.4	Ms
FRT	E19	2.5/93 (K)	2.6/90 (K)	3.1/72 (K)	3.1/72 (K)	DCV/DEG F
IAT	E22	2.6/86 (K)	2.9/73 (K)	3.7/43 (K)	3.7/41 (K)	DCV/DEG F
MAF (A/T)	E25	0	0.8	1.45	1.77	DCV
MAF (M/T)	E25	0	0.83-0.91	1-1.6	1.7-2.4	DCV
KNOCK 2	E31	0	65	74	141	N/A
FRP	E32	3.5/53	2.8/40	2.8/40	2.7/39	DCV/PSI
CHT	E41	3.6/188	3.6/201	3.6/201	3.4/210	DCV/DEG F
HTRCM12	E47	844	844	844	844	MA
HTRCM22	E48	871	871	871	871	MA
KNOCK 1	E49	0	72	78	141	N/A
IMRC1M	E50	5.0	5.0	5.0	0	DCV
TP2	E60	1.2/27	0.7/17	1.1/25/21	1.7	DCV/%
TP1	E61	4.1/13	4.3/18	4.1/17	3.8/15	DCV/%
HTRCM21	E70	1.33	1.33	1.33	1.33	MA
OSS (A/T)	T3	0	0	1185	2224	RPM
O2S12	T24	(L)	(D)	(D)	(D)	DCV
O2S22	T25	0	(D)	(D)	(D)	DCV
TFT (A/T)	T29	1.5/136 (K)	1.5/136 (K)	1.2/154 (K)	1.4/156 (K)	DCV/DEG F
ACP	PID	OPEN (OK)	OPEN (OK)	OPEN (OK)	OPEN (OK)	OPEN/ CLOSED
APP	PID	NO PEDAL	NO PEDAL	NO PEDAL	NO PEDAL	YES/NO PEDAL
BARO	PID	156	156	159	157	Hz
CAT_EVAL	PID	YES	YES	YES	YES	YES/NO
CHTIL	PID	OFF	OFF	OFF	OFF	ON/OFF
CPP/PNP (A/T)	PID	NEUTRAL	NEUTRAL	DRIVE	DRIVE	NEUTRAL/ DRIVE
EGR_EVAL	PID	YES	YES	YES	YES	YES/NO
EONV_RDY	PID	NOT READY	NOT READY	NOT READY	NOT READY	READY/NOT READY
EVAP_EVAL	PID	YES	YES	YES	YES	YES/NO
EVAP020C	PID	NO	NO	NO	NO	YES/NO
EVAP020D	PID	ALLOW	ALLOW	ALLOW	ALLOW	ALLOW/ DISALLOW
EVAPSOAK	PID	NO	YES	YES	YES	YES/NO
FCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
FLI	PID	89 (H)	88 (H)	85 (H)	95 (H)	%
FUELSYS	PID	OPEN LOOP	OPEN LOOP	OPEN LOOP	OPEN LOOP	OPEN/ CLOSED LOOP
LOAD	PID	61	15	23	29	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
MP_LRN	PID	YES	YES	YES	YES	YES/NO
O2S_EVAL	PID	YES	YES	YES	YES	YES/NO
PTOLOAD	PID	NO	NO	NO	NO	YES/NO
RPM	PID	0	722	1288	1565	RPM
VCTADVERR	PID	0	0.56°	5.12°	0.93°	DEG
VCTADVERR2	PID	O	1.06°	2.56°	0.50°	DEG
VCTSYS	PID	OL	CL	CL	CL	OPEN/ CLOSED
VSS	PID	0	0	30	55	MPH

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FP	B12	75/ON	20.4/ON	22.58/ON	24.67/ON	%/ON-OFF
EVAPCV	B13	0%/OFF	0%/OFF	0%/OFF (R)	0%/OFF (R)	%/ON-OFF
PTOIL	B42	OFF	OFF	OFF	OFF	ON/OFF
PCVHC	E2	0	0	0	0	%
WAC/ACCR	E3	0.1/OFF	VBAT/ON (A)	0.1/OFF	0.1/OFF	DCV/ON-OFF
IMRC	E50	OFF	OFF	OFF	OFF	ON/OFF
VCTDC	E67	0	0	42	43.1	DCV
VCTDC2	E68	0	0	39.8	39.3	DCV
HTRCM11	PID	1.33	1.33	1.33	1.33	MA
HTRCM12	PID	844	844	844	844	MA
HTRCM21	PID	1.33	1.33	1.33	1.33	MA
HTRCM22	PID	871	871	871	871	MA
TCIL	PID	OFF	OFF	OFF	OFF	ON/OFF
VCTADV	PID	0	0.56	44.69	0.37	DEG
VCTADV2	PID	0	1.06	45.19	0.68	DEG
O2SHTR_ EVAL	PID	YES	YES	YES	YES	YES/NO
ETC_DSD	PID	7.62	1.36	2.61	8.26	DEG
FRP_DSD	PID	49.99	40	40	40	PSI
RPM_DSD	PID	640	640	624	624	RPM
LONGFT1	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
LONGFT2	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
SHRTFT1	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SHRTFT2	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SPARKADV	PID	10	12.25	37	37.2	DEG

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
APPVREF	B4/16	5	5	5	5	DCV
VPWR	B35/36	VBAT	VBAT	VBAT	VBAT	DCV
BVREF	E57	5	5	5	5	DCV
TPVREF	E66	5	5	5	5	DCV

Sensors/Inputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Sensors/Inputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
FTP	B3	2.6/0 (M)	2.6/0 (M)	2.6/0 (M)	1.6/-0.26 (M)	DCV/PSI
APP1	B5	4	4	3.9	3.7	DCV
PTOIR V	B7	0.02	0.02	0.02	0	DCV
BOO	B8	VBAT/OFF	0.1/ON (E)	VBAT/OFF	VBAT/OFF	DCV/ON-OFF
PTO LOAD	B9	NO	NO	NO	NO	YES/NO
HO2S13	B14	0 (M)	(D) (M)	(D) (M)	(D) (M)	DCV
APP2	B17	1.5	1.5	1.6	1.8	DCV
FPM	B21	0.1-VBAT	0.1-VBAT	0.1-VBAT	0.1-VBAT	DCV
PTO	B26	OFF	OFF	OFF	OFF	ON/OFF
TCS (A/T)	B27	0.1/OFF	VBAT/ON (G)	0.1/OFF	0.1/OFF	DCV/ON-OFF
APP3	B28	1	1.1	1.3	1.5	DCV
VSS	B29	0	0	30	55	MPH
CPP BT (M/T)	B34	OPEN	OPEN	OPEN	OPEN	OPEN/ CLOSED
ACCS	E4	0.1/OFF	VBAT/ON (A)	0.1/OFF	0.1/OFF	DCV/ON-OFF
FRT	E19	2.5/97 (K)	2.5/93 (K)	2.9/79 (K)	3/79 (K)	DCV/DEG F
IAT	E22	2.9/73 (K)	3.3/59 (K)	3.7/45 (K)	3.7/43 (K)	DCV/DEG F
MAF (A/T)	E25	0	1.1	1.2	2.1	DCV
MAF (M/T)	E25	0	1.1	1.2	2.1	DCV
HO2S11	E28	(L)	Switching (C)	Switching (C)	Switching (C)	DCV
HO2S21	E29	0	Switching (C)	Switching (C)	Switching (C)	DCV
KNOCK 2	E31	32770	206	245	303	N/A
FRP	E32	3.5/53	3.7/39	3.7/39	2.7/39	DCV/PSI
CHT	E41	0.61/192.2	0.6/194	3.58/201.2	3.56/204.8	DCV/DEG F
CMP	E45	0	6.5-10	10-13	13-16	Hz
CKP	E47	0	420-520	800-1050	1100-1300	Hz
KNOCK 1	E49	32770	205	212	319	N/A
TP2	E60	1.3	0.9	1	1.4	DCV
TP1	E61	4.1	4.3	4.2	4	DCV
BPA	E65	0.1/OFF	VBAT/ON (E)	0.1/OFF	0.1/OFF	DCV/ON-OFF
OSS	T3	0	0	1194	2278	RPM
ISS	T4	0	782	860	1623	RPM
TSS	T15	0	782	860	1623	RPM
HO2S12	T24	(L) (M)	(D) (M)	(D) (M)	(D) (M)	DCV
HO2S22	T25	0 (M)	(D) (M)	(D) (M)	(D) (M)	DCV
TFT (A/T)	T29	1.6/132 (K)	1.5/136 (K)	1.1/154 (K)	1.1/158 (K)	DCV/DEG F
CPP/PNP (A/T)	PID	NEUTRAL	NEUTRAL	DRIVE	DRIVE	NEUTRAL/ DRIVE
GEAR (A/T)	PID	1	1	6	6	GEAR
LOAD	PID	63 (L)	18	17	35	%
MISFIRE	PID	NO	NO	NO	NO	YES/NO
RPM	PID	0	654	1127	1618	RPM
VSS	PID	0	0	30	55	MPH

Actuators/Outputs	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Actuators/Outputs	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
VSO	B1	0	0	65	125	Hz
SMC	B2	0	0	0	0	DCV
FP	B12	75	20	20.8	21.3	%
EVAPCV	B13	VBAT/0 (M)	VBAT/0 (M)	VBAT/0 (M) (R)	VBAT/0 (M) (R)	DCV/%
CTO	B25	0	55-65	110-130	140-175	Hz
PTOIL	B42	OFF	OFF	OFF	OFF	ON/OFF
TCIL (A/T)	B43	VBAT/OFF	VBAT/OFF	VBAT/OFF	VBAT/OFF	DCV/ON-OFF
EVAPPDC	E1	0	0/0	0/0	0/0	Hz/%
PCVHC	E2	0 (M)	0 (M)	0 (M)	0 (M)	%
WAC/ACCR	E3	VBAT/OFF	0.1/ON (A)	VBAT/OFF	VBAT/OFF	DCV/ON-OFF
CDD (CYL 10)	E8	VBAT	VBAT	VBAT	VBAT	DCV
CDH (CYL 8)	E9	VBAT	VBAT	VBAT	VBAT	DCV
CDC (CYL 5)	E10	VBAT	VBAT	VBAT	VBAT	DCV
CDE (CYL 2)	E11	VBAT	VBAT	VBAT	VBAT	DCV
CDG (CYL 3)	E12	VBAT	VBAT	VBAT	VBAT	DCV
CDJ (CYL 9)	E13	VBAT	VBAT	VBAT	VBAT	DCV
CDI (CYL 4)	E14	VBAT	VBAT	VBAT	VBAT	DCV
CDB (CYL 6)	E15	VBAT	VBAT	VBAT	VBAT	DCV
CDF (CYL 7)	E16	VBAT	VBAT	VBAT	VBAT	DCV
CDA (CYL 1)	E17	VBAT	VBAT	VBAT	VBAT	DCV
TACM (+)	E34	3.7	VBAT	VBAT	VBAT	DCV
TACM (-)	E51	3.7	VBAT	VBAT	VBAT	DCV
IMTV	E64	0	0	0	VBAT	DCV
HTR11	E69	0.1/ON (O)	0.1/ON	0.1/ON	0.1/ON	DCV/ON-OFF
HTR21	E70	0.1/ON (O)	0.1/ON	0.1/ON	0.1/ON	DCV/ON-OFF
HTR12	T47	0.2/ON (M) (O)	0.2/ON (M)	0.2/ON (M)	0.2/ON (M)	DCV/ON-OFF
HTR22	T48	0.2/ON (M) (O)	0.2/ON (M)	0.2/ON (M)	0.2/ON (M)	DCV/ON-OFF
CHTIL	PID	OFF	OFF	OFF	OFF	ON/OFF
LONGFT1	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
LONGFT2	PID	(L)	(-)20-(+)20	(-)20-(+)20	(-)20-(+)20	%
MIL	PID	OFF	OFF	OFF	OFF	ON/OFF
SHRTFT1	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SHRTFT2	PID	(L)	(-)10-(+)10	(-)10-(+)10	(-)10-(+)10	%
SPARKADV	PID	10	13.75	29.5	27.25	DEG

Other	PCM Pin/PID only	Measured/PID Values				Units Measured/PID
Other	PCM Pin/PID only	KOEO	Hot Idle	48 KM/H (30 MPH)	89 KM/H (55 MPH)	Units Measured/PID
APVREF	B4/16	5	5	5	5	DCV
VPWR	B35/36	VBAT	VBAT	VBAT	VBAT	DCV
KAPWR	B45	VBAT	VBAT	VBAT	VBAT	DCV
BVREF	E57	5	5	5	5	DCV
TPVREF	E66	5	5	5	5	DCV
VBPWR	T39	VBAT	VBAT	VBAT	VBAT	DCV
