GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Brake Pads | |
| Brake pad minimum thickness | 3.0 mm (0.118 in) |
| Brake pad maximum taper wear (in any direction) | 3.0 mm (0.118 in) |
| Brake Disc | |
| Front brake disc minimum thickness | 26.5 mm (1.043 in) |
| Minimum thickness to machine front brake disc | 27.1 mm (1.066 in) |
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Bleeder screw | 11 |
| Brake caliper anchor plate bolts | 150 |
| Brake caliper guide pin bolts | 60 |
| Brake caliper flow bolt (lubricated) | 30 |
| Brake disc screw | 12 |
| Brake disc shield bolts | 15 |
| Brake flexible hose bracket bolt | 30 |
| Brake tube fittings | 18 |
TORQUE SPECIFICATIONS
The front brake disc system consists of the following components
- Brake caliper anchor plate
- Brake caliper
- Brake disc
- Brake disc shield
- Brake flexible hose
When mechanical force is applied by the driver to the brake pedal, the force is converted into hydraulic pressure by the master cylinder. The hydraulic force is directed to the disc brake calipers and transferred to the brake pads. The brake pads are then forced against the brake friction surfaces by the brake caliper pistons. The friction of the brake pads on the brake disc causes the slowing of wheel rotation and the vehicle.
Refer to BRAKE SYSTEM - GENERAL INFORMATION article.
Scheme 1
| Item | Part Number | Description |
|---|---|---|
| 1 | Brake caliper guide pin bolts (2 required) (part of 2B134) | |
| 2 | 2B294 RH/ 2B302 LH | Brake caliper |
| 3 | 2001 | Brake pads |
| 4 | Spring clips (2 required) (part of 2001) | |
| 5 | W713220 | Brake caliper anchor plate bolts (2 required) |
| 6 | Steering stop | |
| 7 | 2B134 | Brake caliper anchor plate |
| 8 | W708733 | Brake disc screw |
| 9 | 1125 | Brake disc |
| 10 | W712797 | Brake disc shield bolts (3 required) |
| 11 | 2K004 RH/ 2K005 LH | Brake disc shield |
| 12 | W709290 | Brake caliper flow bolt |
| 13 | 388949 | Copper washers (2 required) |
| 14 | 2078 RH/ 2B557 LH | Brake flexible hose |
| 15 | Brake tube fitting | |
| 16 | W704911 | Brake flexible hose bracket bolt |
| 17 | 2L126 | Bleeder screw cap |
| 18 | 2208 | Bleeder screw |
- For additional information, refer to the procedures in this article.
See also:
• JACKING AND LIFTING
