REMOVAL AND INSTALLATION
| WARNING | Batteries contain sulfuric acid and produce explosive gases. Work in a well-ventilated area. Do not allow the battery to come in contact with flames, sparks or burning substances. Avoid contact with skin, eyes or clothing. Shield eyes when working near the battery to protect against possible splashing of acid solution. In case of acid contact with skin or eyes, flush immediately with water for a minimum of 15 minutes, then get prompt medical attention. If acid is swallowed, call a physician immediately. Failure to follow these instructions may result in serious personal injury. |
| WARNING | Always lift a plastic-cased battery with a battery carrier or with hands on opposite corners. Excessive pressure on the battery end walls may cause acid to flow through the vent caps, resulting in personal injury and/or damage to the vehicle or battery. |
- Disconnect the battery. For additional information, refer to «Battery Disconnect»(ref-293478-S25714090482008080700000) .
- Remove the bolt and the battery hold-down clamp. To install, tighten to 9 Nm (80 lb-in).
- Remove the battery.
- To install, reverse the removal procedure.
- Remove the battery. For additional information, refer to «Battery»(ref-293478-S06243143242008080700000) .
- Disconnect the 4 wiring harness fasteners from the battery tray.
- Remove the 4 bolts from the battery tray. To install, tighten to 23 Nm (17 lb-ft).
- Disconnect the power distribution box (PDB) fastener and remove the battery tray.
- To install, reverse the removal procedure.
Scheme 1
| Item | Part Number | Description |
|---|---|---|
| 1 | W705661 | Engine ground cable bolt |
| 2 | Engine ground cable end (part of 14300) | |
| 3 | S705790 | Battery negative terminal cable end nut |
| 4 | Battery positive protective cover | |
| 5 | S705790 | Battery positive terminal cable end nut |
| 6 | Battery positive terminal cable end (part of 14300) | |
| 7 | 14300 | Battery cable terminals |
| 8 | Battery positive cable end (part of 14300) | |
| 9 | Battery junction box (BJB) cable end (part of 14300) | |
| 10 | S705790 | BJB cable nut |
| 11 | Body ground cable bolt | |
| 12 | Body ground cable terminal (part of 14300) | |
| 13 | Generator B+ terminal cover | |
| 14 | W711953 | Generator B+ cable nut |
| 15 | Generator B+ cable end (part of 14300) | |
| 16 | Generator electrical connector (part of 14300) | |
| 17 | Generator B+ terminal | |
| 18 | 11N087 | Starter terminal cover |
| 19 | W706414-S | Starter B+ cable nut |
| 20 | Battery cable starter cable | |
| 21 | Starter solenoid cable terminal (part of 14B060) | |
| 22 | W706414-S | Battery cable starter solenoid terminal nut |
| 23 | Battery cable harness locators (part of 14B060) | |
| 24 | 14A163 | Battery cable locators (3 required) |
- Remove the battery tray. For additional information, refer to «Battery Tray»(ref-293478-S11582228642008080700000) .
- Remove the bolt and position the battery cable body ground terminal aside. To install, tighten to 12 Nm (9 lb-ft).
- Remove the nut and position the battery junction box (BJB) cable terminal aside. To install, tighten to 8 Nm (71 lb-in).
- Remove the starter solenoid terminal cover.
- Remove the nut and position the battery cable starter solenoid terminal aside. To install, tighten to 12 Nm (9 lb-ft).
- Remove the nut and position the battery cable starter motor terminal aside. To install, tighten to 12 Nm (9 lb-ft).
- Release the battery cable locator from the engine.
- Remove the bolt and position the battery cable engine ground terminal aside. To install, tighten to 12 Nm (9 lb-ft).
- Release the battery cable from the top of the intake manifold.
- Release the 3 battery cable locators from the LH valve cover.
- Position the generator protective cover aside, remove the nut and position the generator B+ terminal aside. To install, tighten to 12 Nm (9 lb-ft).
- Remove the battery cables.
- To install, reverse the removal procedure.
