Remote Convenience: Overview Mercury Sable V

Normal Operation

The universal transmitter receives voltage on circuit CLN09 (YE/GN) and ground on circuit GD133 (BK).

This pinpoint test is intended to diagnose the following

1. Wiring, terminals or connectors
2. Universal transmitter
3. Receiver unit

Scheme 1

Scheme 2

1. A1 CHECK THE UNIVERSAL TRANSMITTER Check the illumination of the transmitter. Does the transmitter illuminate? YES : Go to A2 . NO : Go to A3 .
2. A2 PROGRAM A HAND-HELD TRANSMITTER INTO THE UNIVERSAL TRANSMITTER Program the universal transmitter. Refer to «Universal Transmitter Programming»(ref-293529-S23425818032008080700000) . Does the universal transmitter program successfully? YES : The universal transmitter is OK. VERIFY the receiver operates correctly. NO : INSTALL a new LH sun visor assembly. TEST the system for normal operation.
3. A3 CHECK CIRCUIT CLN09 (YE/GN) FOR VOLTAGE Key in OFF position. Disconnect: LH Vanity Mirror Lamp C907 Key in ON position. Measure the voltage between the LH vanity mirror lamp C907-1, circuit CLN09 (YE/GN), harness side and ground. Is the voltage greater than 10 volts? YES : Go to A4 . NO : REPAIR the circuit. TEST the system for normal operation.
4. A4 CHECK CIRCUIT GD133 (BK) FOR AN OPEN Key in OFF position. Measure the resistance between the LH vanity mirror lamp C907-2, circuit GD133 (BK), harness side and ground. Is the resistance less than 5 ohms? YES : INSTALL a new LH sun visor assembly. TEST the system for normal operation. NO : REPAIR the circuit. TEST the system for normal operation.
