A/C SYSTEM SPECIFICATIONS
| WARNING | To avoid injury from accidental air bag deployment, read and follow all SERVICE PRECAUTIONS and DISABLING & ACTIVATING AIR BAG SYSTEM procedures in AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT section. |
| Application | Specification |
|---|
| Compressor Type |
| 3.0L | Ford FS-10 10-Cyl. |
| 3.4L | Sanden Scroll |
| Compressor Belt Tension | (1) |
| System Oil Capacity (2) | 7 ozs. |
| Refrigerant (R-134a) Capacity | 32 ozs. |
| System Operating Pressures (3) |
| High Side | 125-230 psi (8.8-16.1 kg/cm 2 ) |
| Low Side | 22-45 psi (1.5-3.2 kg/cm 2 ) |
| (1) Serpentine belt tension is automatically adjusted by tensioner pulley. (2) Use YN-12b PAG Oil (WSH-M1C231-B). (3) Operating pressures at ambient temp. of 80°F (27°C). |
| (1) | Serpentine belt tension is automatically adjusted by tensioner pulley. |
| (2) | Use YN-12b PAG Oil (WSH-M1C231-B). |
| (3) | Operating pressures at ambient temp. of 80°F (27°C). |
A/C SYSTEM SPECIFICATIONS
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| A/C Compressor Bracket Bolts | 30-40 (41-54) |
| Hose Manifold-To-Compressor Bolt | 13-17 (17-23) |
| INCH Lbs. (N.m) |
| Blower Motor Bolts/Nuts | 53-71 (6-8) |
Scheme 1
Scheme 1: VACUUM HOSE DIAGRAM(S)
Automatic A/C-Heater System Wiring Diagram. Scheme 2
Scheme 2: Automatic A/C-Heater System Wiring Diagram
