TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Front seat track-to-floor bolts | 23 |
| Front seat track-to-floor nuts | 55 |
| Front seat side air bag module nuts | 10 |
| Front seat track-to-cushion frame bolts | 25 |
| Front seat safety belt buckle pretensioner bolt | 40 |
| Front seat backrest-to-seat track bolts | 58 |
| Front seat armrest bolt | 25 |
| Bench seat, second row LH and RH safety belt buckle bolts | 58 |
| Bench seat, second row center safety belt buckle bolts | 58 |
| Bench seat, second row backrest-to-cushion frame bolts | 58 |
| Bench seat, second row riser-to-seat track nuts | 50 |
| Bench seat, second row seat track-to-cushion frame bolts | 50 |
| Bench seat, second row armrest bolts | 35 |
| Bucket seat, second row safety belt buckle bolt | 58 |
| Bucket seat, second row Lower Anchors and Tethers for Children (LATCH) bolts | 50 |
| Bucket seat, second row front backrest-to-seat track bolts | 50 |
| Bucket seat, second row rear backrest-to-seat track bolts | 58 |
| Bucket seat, second row seat riser-to-seat track nuts | 25 |
| Bucket seat, second row seat track-to-cushion frame bolts | 25 |
| Bucket seat, second row armrest bolt | 35 |
| Third row cushion safety belt buckle bolts | 58 |
| Third row cushion-to-backrest nuts | 25 |
| Third row cushion latch bolts | 25 |
| Third row seat riser-to-floor nuts | 55 |
| Third row seat riser-to-floor bolts | 55 |
| Third row latch strikers to body | 20 |
TORQUE SPECIFICATIONS
Seats - Front
The front seats have the following features
- Manual recline
- Manual lumbar (optional)
- Driver memory (optional)
- Manual horizontal adjustment
- Power horizontal, vertical front and rear tilt adjustments (optional)
- Heated seats (optional)
- Climate controlled seats (optional)
- Hi-back seats linked to cloth (standard on Freestar)
- Low-back seats linked to leather (optional)
- Seat side air bag (optional)
- Occupant classification sensor (OCS) (passenger seat only)
- Armrest on inboard side
Power adjustment of the seat may be accomplished with the seat control switch located on the outboard side of the seat.
Seats - Second Row
The second row seat has the following features
- Manual recline
- Removable seating
- Bench is base
- Quad seats are high series
- Quad seats have optional 2-way manual horizontal adjustment
- Quad seats fold and tumble with 1 hand operation for EZ entry
- Bench has 2-way manual horizontal adjustment
- Bench has tip and slide with 1-lever operation for EZ entry
- Armrest on inboard and outboard side
- Quad seats have a serviceable seat riser strut that provides enhanced operation of the EZ entry feature. Refer to «SEAT - EXPLODED VIEW, SECOND ROW, BUCKET SEAT»(ref-234523-S27589157172006061000000) and «SEAT CUSHION - SECOND ROW, BUCKET»(ref-234523-S15960177722006061000000).
Scheme 1
To remove second row seating, refer to the owner's literature.
Seats - Third Row
The third row seat has the following features
- Three passenger seating positions
- Grocery hooks on rear of seat
- Stows-in-floor (SIF)
- Multi-position recliner
- Seat striker mounts to wheel house
- Adjustable latch striker. Refer to «SEAT - THIRD ROW»(ref-234523-S24638456462006061000000).
Scheme 2
Seats - Heated
This system allows the electrical heating of the front seats on demand.
The components of the system are
- the seat heater mats are located in the seat cushion and seat backrest.
- the heated seat module is located on the seat cushion frame bottom.
- the heated seat control switches are located in the electronic automatic temperature control (EATC) module.
- the temperature sensors are located within the cushion heater mats.
The heated seat system
- will only operate with the ignition switch in RUN.
- will operate with battery voltage as low as 9 volts.
- will maintain a temperature automatically once it is selected.
- has a low and high setting.
Seats - Manual Lumbar Support
The manual front seat backrest lumbar is adjusted by a knob mounted on the inboard side of the seat backrest.
Seats - Memory
This system allows automatic positioning of the driver seat, outside rearview mirrors and power adjustable pedals to 2 programmable positions.
The memory seat control switch is located on the driver door.
Seats - Climate Controlled
The climate controlled seat system is able to heat and cool the front seats. Each climate controlled front seat is controlled by a switch on the electronic automatic temperature control unit (EATC). Perforated leather is the only material available for the heated/cooled seats.
