Principles of Operation

Roof Opening Panel - Actuating the roof opening panel switch in the forward or rearward direction supplies a ground signal to the roof opening panel module. The roof opening panel module then supplies power and ground to the roof opening panel motor. The vent and soft stop functions are controlled by the roof opening panel module and an internal roof opening panel position switch within the roof opening panel motor. These positions are obtained when an internal motor cam opens the roof opening panel position switch that removes ground to the roof opening panel module.

Normal Operation

When the roof opening panel glass is completely closed, it is flush with the roof panel and correctly sealed.

This pinpoint test is intended to diagnose the following

1. Roof opening panel glass adjustment
2. Roof opening panel glass seals

When the roof opening panel glass is completely closed, it is flush with the roof panel and correctly sealed. The drain channel collects water and drains it through the front drain hose located in the A-pillar and the rear drain hose located in the C-pillar.

This pinpoint test is intended to diagnose the following

1. Roof opening panel glass adjustment
2. Roof opening panel drain hoses
3. Roof opening panel glass seals

When the roof opening panel glass is completely closed, it is flush with the roof panel. All components should be secured correctly.

This pinpoint test is intended to diagnose the following

1. Roof opening panel glass adjustment
2. Roof opening panel lifter assemblies
3. Roof opening panel tracks
4. Roof opening panel drain channels and guides
5. Roof opening panel shield
6. Roof opening panel air deflector
7. Roof opening panel assembly

The roof opening panel operates smoothly while opening and closing.

This pinpoint test is intended to diagnose the following

1. Roof opening panel glass adjustment
2. Roof opening panel tracks
3. Roof opening panel shield
4. Roof opening panel motor

PINPOINT TEST D: THE ROOF OPENING PANEL IS NOISY DURING OPERATION

1. D1 CHECK THE ROOF OPENING PANEL GLASS FOR OBSTRUCTIONS OR DAMAGE Check the roof opening panel glass for any obstructions or damage from the following: sand. dirt. leaves. Are there any obstructions or damage? YES : REMOVE all obstructions. REPAIR the roof opening panel as necessary. TEST the system for normal operation. NO : Go to D2 .
2. D2 CHECK THE ROOF OPENING PANEL GLASS OPERATION Check the roof opening panel glass during operation. Is the roof opening panel glass loose or not correctly adjusted? YES : ADJUST the roof opening panel. REFER to «Roof Opening Panel Alignment»(ref-292162-S41493689282008073100000) . VERIFY all bolts are tightened to specification. TEST the system for normal operation. NO : Go to D3 .
3. D3 CHECK THE ROOF OPENING PANEL TRACKS Open the roof opening panel glass. Check the tracks for obstructions or signs of damage. Are the tracks OK? YES : Go to D4 . NO : REMOVE all obstructions. REPAIR any damage as necessary. TEST the system for normal operation.
4. D4 CHECK THE ROOF OPENING PANEL SHIELD Check the roof opening panel shield for correct movement. Is the shield moving correctly? YES : Go to D5 . NO : REPAIR or INSTALL a new roof opening panel shield. REFER to «Roof Opening Panel Shield»(ref-292162-S26195090662008073100000) . TEST the system for normal operation.
5. D5 CHECK THE ROOF OPENING PANEL MOTOR Gain access to the roof opening panel motor. Open the roof opening panel. Does the motor make excessive noise? YES : INSTALL a new roof opening panel motor. REFER to «Roof Opening Panel Motor»(ref-292162-S23635447482008073100000) . TEST the system for normal operation. NO : ADJUST the roof opening panel glass. REFER to «Roof Opening Panel Alignment»(ref-292162-S41493689282008073100000) . TEST the system for normal operation.

The roof opening panel module receives voltage on circuit CBP47 (GN/BU) when the ignition switch is in the ACC or ON position. The roof opening panel module is grounded through circuit GD182 (BK/GY). When the roof opening panel switch is pressed, circuit (BK) and circuit (WH) are connected for open/tilt down or circuit (BK) and circuit (VT) are connected for close/tilt up. The roof opening panel module controls the roof opening panel motor by directing power and ground on circuit (OG) and circuit (RD) to the motor.

This pinpoint test is intended to diagnose the following

1. Circuit breaker
2. Wiring, terminals or connectors
3. Roof opening panel switch
4. Roof opening panel motor
5. Roof opening panel module

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

1. E1 CHECK CIRCUIT (DB) FOR POWER Key in OFF position. Disconnect: Roof Opening Panel Module Connector Key in ON position. Measure the voltage between the roof opening panel module connector, pin 6, circuit (DB), harness side and ground. Is the voltage greater than 10 volts? YES : Go to E2 . NO : VERIFY the smart junction box (SJB) circuit breaker 47 (30A) is OK. If OK, REPAIR the circuit. TEST the system for normal operation. If not OK, REFER to the Wiring Diagrams Manual to identify the possible causes of the circuit short. TEST the system for normal operation.
2. E2 CHECK CIRCUIT (BK) FOR AN OPEN Key in OFF position. Measure the resistance between the roof opening panel module connector, pin 4, circuit (BK), harness side and ground. Is the resistance less than 5 ohms? YES : Go to E3 . NO : REPAIR the circuit. TEST the system for normal operation.
3. E3 CHECK POWER TO THE ROOF OPENING PANEL MOTOR - CIRCUIT (OG) Connect: Roof Opening Panel Module Connector Disconnect: Roof Opening Panel Motor Connector Key in ON position. While pressing the roof opening panel switch to the OPEN position, measure the voltage between the roof opening panel motor connector, pin 3, circuit (OG), harness side and ground. Is the voltage greater than 10 volts? YES : Go to E6 . NO : Go to E4 .
4. E4 CHECK CIRCUIT (OG) FOR AN OPEN Key in OFF position. Disconnect: Roof Opening Panel Module Connector Measure the resistance between the roof opening panel motor connector, pin 3, circuit (OG), harness side and the roof opening panel module connector, pin 8, circuit (OG), harness side. Is the resistance less than 5 ohms? YES : Go to E5 . NO : REPAIR the circuit. TEST the system for normal operation.
5. E5 CHECK CIRCUIT (OG) FOR A SHORT TO GROUND Measure the resistance between the roof opening panel motor connector, pin 3, circuit (OG), harness side and ground. Is the resistance greater than 10,000 ohms? YES : Go to E9 . NO : REPAIR the circuit. TEST the system for normal operation.
6. E6 CHECK VOLTAGE TO THE ROOF OPENING PANEL MOTOR - CIRCUIT (RD) While pressing the roof opening panel switch to the CLOSED position, measure the voltage between the roof opening panel motor connector, pin 1, circuit (RD), harness side and ground. Is the voltage greater than 10 volts? YES : INSTALL a new roof opening panel motor. REFER to «Roof Opening Panel Motor»(ref-292162-S23635447482008073100000) . TEST the system for normal operation. NO : Go to E7 .
7. E7 CHECK CIRCUIT (RD) FOR AN OPEN Key in OFF position. Disconnect: Roof Opening Panel Module Connector Measure the resistance between the roof opening panel module connector, pin 7, circuit (RD), harness side and the roof opening panel motor connector, pin 1, circuit (RD), harness side. Is the resistance less than 5 ohms? YES : Go to E8 . NO : REPAIR the circuit. TEST the system for normal operation.
8. E8 CHECK CIRCUIT (RD) FOR A SHORT TO GROUND Measure the resistance between the roof opening panel motor connector, pin 1, circuit (RD), harness side and ground. Is the resistance greater than 10,000 ohms? YES : Go to E9 . NO : REPAIR the circuit. TEST the system for normal operation.
9. E9 CHECK THE ROOF OPENING PANEL SWITCH Disconnect: Roof Opening Panel Switch Connector Carry out the roof opening panel control switch component test. Refer to appropriate COMPONENT TESTING article. Did the roof opening panel control switch pass the component test? YES : Go to E10 . NO : INSTALL a new roof opening panel switch. TEST the system for normal operation.
10. E10 CHECK CIRCUIT (VT) FOR AN OPEN OR SHORT TO GROUND Disconnect: Roof Opening Panel Module Connector Connect: Roof Opening Panel Switch Connector Measure the resistance between the roof opening panel module connector, pin 3, circuit (VT), harness side and ground with the roof opening panel control switch at rest, and then while pressing the roof opening panel switch to the CLOSE position. Is the resistance greater than 10,000 ohms with the switch at rest, and less than 5 ohms with the switch in the CLOSE position? YES : Go to E11 . NO : REPAIR the circuit. TEST the system for normal operation
11. E11 CHECK CIRCUIT (WH) FOR AN OPEN OR SHORT TO GROUND Measure the resistance between the roof opening panel module connector, pin 2, circuit (WH), harness side and ground with the roof opening panel control switch at rest, and then while pressing the roof opening panel switch to the OPEN position. Is the resistance greater than 10,000 ohms with the switch at rest, and less than 5 ohms with the switch in the OPEN position? YES : INSTALL a new roof opening panel module. REFER to «Roof Opening Panel Module»(ref-292162-S16108980742008073100000) . TEST the system for normal operation. NO : REPAIR the circuit. TEST the system for normal operation.

The roof opening panel position switch removes ground from circuit (OG/WH) when the roof opening panel reaches the CLOSED position and when the roof opening panel reaches the comfort position. In these positions the roof opening panel module will remove power from the roof opening panel motor.

This pinpoint test is intended to diagnose the following

1. Wiring, terminals or connectors
2. Roof opening panel motor
3. Roof opening panel module

Scheme 11

Scheme 12

Scheme 13

Scheme 14

1. F1 CHECK THE ROOF OPENING PANEL POSITION SWITCH FOR A SHORT TO GROUND IN THE CLOSED POSITION Key in ON position. Close the roof opening panel. Key in OFF position. Disconnect: Roof Opening Panel Module Connector With the roof opening panel in the CLOSED position, measure the resistance between the roof opening panel module connector, pin 1, circuit (OG/WH), harness side and ground. Is the resistance greater than 10,000 ohms? YES : Go to F3 . NO : Go to F2 .
2. F2 CHECK CIRCUIT (OG/WH) FOR A SHORT TO GROUND Disconnect: Roof Opening Panel Position Switch Connector Measure the resistance between the roof opening panel module connector, pin 1, circuit (OG/WH), harness side and ground. Is the resistance greater than 10,000 ohms? YES : INSTALL a new roof opening panel motor. REFER to «Roof Opening Panel Motor»(ref-292162-S23635447482008073100000) . TEST the system for normal operation. NO : REPAIR the circuit. TEST the system for normal operation.
3. F3 CHECK THE ROOF OPENING PANEL POSITION SWITCH FOR A SHORT TO GROUND IN THE COMFORT POSITION Key in OFF position. Connect: Roof Opening Panel Module Connector Key in ON position. Open the roof opening panel to the comfort position. Key in OFF position. Disconnect: Roof Opening Panel Module Connector With the roof opening panel in the comfort position, measure the resistance between the roof opening panel module connector, pin 1, circuit (OG/WH), harness side and ground. Is the resistance greater than 10,000 ohms? YES : Go to F4 . NO : INSTALL a new roof opening panel motor. REFER to «Roof Opening Panel Motor»(ref-292162-S23635447482008073100000) . TEST the system for normal operation.
4. F4 CHECK THE ROOF OPENING PANEL POSITION SWITCH SIGNAL Disconnect: Roof Opening Panel Position Switch Connector Measure the voltage between the roof opening panel position switch connector, pin 2, circuit (OG/WH), harness side and ground. Is the voltage greater than 10 volts? YES : Go to F6 . NO : Go to F5 .
5. F5 CHECK CIRCUIT (OG/WH) FOR AN OPEN Measure the resistance between the roof opening panel module connector, pin 1, circuit (OG/WH), harness side and the roof opening panel position switch connector, pin 2, circuit (OG/WH), harness side. Is the resistance less than 5 ohms? YES : INSTALL a new roof opening panel module. REFER to «Roof Opening Panel Module»(ref-292162-S16108980742008073100000) . TEST the system for normal operation. NO : REPAIR the circuit. TEST the system for normal operation.
6. F6 CHECK CIRCUIT (BK) FOR AN OPEN Measure the resistance between the roof opening panel position switch connector, pin 1, circuit (BK), harness side and ground. Is the resistance less than 5 ohms? YES : INSTALL a new roof opening panel motor. REFER to «Roof Opening Panel Motor»(ref-292162-S23635447482008073100000) . TEST the system for normal operation. NO : REPAIR the circuit. TEST the system for normal operation.
