GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Cooling System Pressure Test Specification | |
| Radiator | 138 kPa (20 psi) |
| Radiator Cap Pressure Test Specification | |
| Radiator cap | 120 kPa (17.4 psi) to 150 kPa (21.7 psi) |
| Thermostat Opening Temperatures | |
| Thermostat starts to open (2.3L) | 90°C (194°F) |
| Thermostat starts to open (3.0L 4V) | 84°C-88°C (183°F-190°F) |
| Thermostat fully open (2.3L) | 106°C (223°F) |
| Thermostat fully open (3.0L 4V) | 98.9°C (210°F) |
GENERAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| A/C condenser-to-radiator bolts | 8 |
| Block heater | 21 |
| Bypass tube bolt and stud bolt (3.0L) | 10 |
| Center support bolt | 10 |
| Center support nuts | 10 |
| Coolant pump bolts | 10 |
| Coolant pump pulley bolts | 20 |
| Cooling fan bolts | 8 |
| Degas bottle-to-fender nut | 6 |
| Front grille bolts | 10 |
| Hood latch bolts | 9 |
| Hood latch nut | 9 |
| Radiator bracket bolts | 10 |
| Thermostat housing bolts | 10 |
TORQUE SPECIFICATIONS
| CAUTION | The engine cooling system is filled with Motorcraft Premium Gold Engine Coolant. Mixing coolant types degrades the corrosion protection of Motorcraft Premium Gold Engine Coolant. |
Note. The addition of Cooling System Stop Leak Pellets VC-6 or equivalent meeting Ford specification WSS-M99B37-B6 darkens Motorcraft Premium Gold Engine Coolant from yellow to golden tan.
The cooling system consists of the following components
- Radiator
- Bypass tube
- Pressure relief cap
- Degas bottle
- Radiator draincock
- Coolant pump
- Coolant temperature indicator sender unit
- Thermostat housing
Engine coolant provides freeze protection, boil protection, cooling efficiency and corrosion protection to the engine and cooling components. In order to obtain these protections, the engine coolant must be maintained at the correct concentration and fluid level in the degas bottle.
When adding engine coolant, use a 50/50 mixture of engine coolant and distilled water.
To maintain the integrity of the coolant and the cooling system
- Add Motorcraft Premium Gold Engine Coolant or equivalent meeting Ford Specification WSS-M97B51-A1 (yellow color). Do not mix coolant types.
- Do not add/mix orange-colored Motorcraft Specialty Orange Engine Coolant or equivalent meeting Ford specification WSS-M97B44-D or green colored Motorcraft Premium Engine Coolant meeting Ford specification ESE-M97B44-A or equivalent. Mixing coolants may degrade the coolant's corrosion protection.
- Do not add alcohol, methanol, brine or any engine coolants mixed with alcohol or methanol antifreeze. These can cause engine damage from overheating or freezing.
- Do not mix with recycled coolant unless it meets the requirements of Ford specification WSS-M97B51-A1. Not all coolant recycling processes meet this Ford specification. Use of such a coolant may harm the engine and cooling system components.
Note. Black arrows indicate hot, white arrows indicate cold.
Scheme 1
| Item | Part Number | Description |
|---|---|---|
| 1 | 8A080 | Degas bottle |
| 2 | 8C633 | Degas bottle-to-radiator hose |
| 3 | 8W005 | Degas bottle overflow hose |
| 4 | 8501 | Coolant pump |
| 5 | 6010 | Engine block |
| 6 | 8575 | Thermostat housing |
| 7 | 8B273 | Lower radiator hose |
| 8 | 8005 | Radiator |
| 9 | 8B274 | Upper radiator hose |
| 10 | 8A582 | Coolant bypass hose |
| 11 | 9D475 | Exhaust gas recirculation (EGR) valve assembly |
| 12 | 8K556 | Coolant adapter assembly |
| 13 | 18K580 | Heater outlet hose |
| 14 | 18K579 | Heater inlet hose |
| 15 | 18A458 | Heater assembly |
| 16 | 6049 | Cylinder head |
| 17 | 6051 | Head gasket |
| 18 | 8C362 | Bleed valve |
Note. Black arrows indicate hot, white arrows indicate cold.
Scheme 2
| Item | Part Number | Description |
|---|---|---|
| 1 | 8A080 | Degas bottle |
| 2 | 8C633 | Degas bottle-to-radiator hose |
| 3 | 8W005 | Radiator overflow hose |
| 4 | 6010 | Engine block |
| 5 | 8501 | Coolant pump |
| 6 | 8B274 | Upper radiator hose |
| 7 | 8005 | Radiator |
| 8 | 8B273 | Lower radiator hose |
| 9 | 6050 | Cylinder head |
| 10 | 6083 | Head gasket |
| 11 | 8A586 | Thermostat housing |
| 12 | 8548 | Bypass tube |
| 13 | 8A505 | Coolant inlet tube |
| 14 | 18K579 | Heater inlet hose |
| 15 | 18K580 | Heater outlet hose |
| 16 | 9E926 | Throttle body |
| 17 | 18C553 | Coolant pump-to-throttle body hose |
| 18 | 18458 | Heater assembly |
Special Tools Illustration Tool Name Tool Number 73III Automotive Meter 105-R0057 or equivalent Battery/Antifreeze Tester 014-R1060 or equivalent Pressure Test Kit 014-R1072 or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware or equivalent scan tool
Scheme 3
Scheme 4
| Item | Specification |
|---|---|
| Motorcraft Premium Gold Engine Coolant with Bittering Agent (bittered in US only) VC-7-B (US); CVC-7-A (Canada); or equivalent (yellow color) | WSS-M97B51-A1 |
Material
